Datenblatt für xPico Device Server Guide von Lantronix, Inc.

LANTQONIX® xPico:
Part Number 900-618
Revision E December 2017
xPico
Embedded Device Server
User Guide
d: httQ://gatents.Iantronix.com For de‘ails on the Lantronix warranty www.Iantronix.com/suppm/warranty ical Support www.|antronix.com/support Sales Offices or a currem Iis‘ of our domestic and www.Iamronix.com/about/contact
xPico® Embedded Device Server User Guide 2
Intellectual Property
© 2017 Lantronix. All rights reserved. No part of the contents of this publication may be
transmitted or reproduced in any form or by any means without the written permission of
Lantronix.
DeviceLinx and xPico are registered trademarks of Lantronix in the United States and other
countries. DeviceInstaller is a trademark of Lantronix, Inc.
Patented: http://patents.lantronix.com; additional patents pending.
Ethernet is a trademark of XEROX Corporation. UNIX is a registered trademark of the Open
Group. Windows is a trademark of Microsoft Corp.
Warranty
For details on the Lantronix warranty policy, please go to our Web site at
www.lantronix.com/support/warranty.
Contacts
Lantronix Corporate Headquarters
7535 Irvine Center Drive
Suite 100
Irvine, CA 92618, USA
Toll Free: 800-526-8766
Phone: 949-453-3990
Fax: 949-450-3995
Technical Support
Online: www.lantronix.com/support
Sales Offices
For a current list of our domestic and international sales offices, go to the Lantronix web site
at www.lantronix.com/about/contact
Disclaimer
Operation of this equipment in a residential area is likely to cause interference, in which case
the user, at his or her own expense, will be required to take whatever measures may be
required to correct the interference.
Note: This product has been designed to comply with the limits for a Class B digital
device pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy, and if not
installed and used in accordance with this guide, may cause harmful interference to
radio communications.
For me latest revisxon of this produc‘ docum www.Iamronix.com/sugpor1/documentalion. rs
xPico® Embedded Device Server User Guide 3
Changes or modifications to this device not explicitly approved by Lantronix will void the
user's authority to operate this device.
Note: With the purchase of xPico embedded device server, the OEM agrees to an
OEM firmware license agreement that grants the OEM a non-exclusive, royalty-free
firmware license to use and distribute the binary firmware image provided, only to the
extent necessary to use the xPico hardware. For further details, please see the xPico
OEM firmware license agreement.
Revision History
Date Rev. Comments
April 2012 A Initial release for firmware version 6.8.0.0.
January 2013 B Updated for firmware version 6.8.0.3.
November 2014 C Updated for firmware version 6.10.0.1. Updates include a new
security settings command for the 77FEh Access Mode and a new
monitor mode command to show flash write counts.
September 2016 D Updated for firmware version 6.11.0.4.
December 2017 E Updated enhanced password information.
For the latest revision of this product document, please check our online documentation at
www.lantronix.com/support/documentation.
List of Tables and Figures
xPico® Embedded Device Server User Guide 4
Table of Contents
Intellectual Property __________________________________________________ 2
Warranty ___________________________________________________________ 2
Contacts ___________________________________________________________ 2
Disclaimer __________________________________________________________ 2
Revision History _____________________________________________________ 3
List of Tables _______________________________________________________ 8
List of Figures _______________________________________________________ 9
1. Using This Guide 10
Purpose and Audience _______________________________________________ 10
Chapter Summary __________________________________________________ 10
Additional Documentation_____________________________________________ 11
2. Introduction 12
Capabilities ________________________________________________________ 12
Applications _______________________________________________________ 12
Protocol Support ____________________________________________________ 13
Configuration Methods _______________________________________________ 13
Addresses and Port Numbers _________________________________________ 13
Hardware Address _______________________________________________ 13
IP Address _____________________________________________________ 14
Port Numbers ___________________________________________________ 14
Product Information Label ____________________________________________ 14
3. Using DeviceInstaller 15
Installing DeviceInstaller ______________________________________________ 15
Assigning an IP Address _____________________________________________ 15
Accessing the xPico Embedded Device Server Using DeviceInstaller __________ 16
Viewing the Current Configuration ______________________________________ 16
4. Configuration Using Web Manager 19
Accessing Web Manager Using DeviceInstaller ___________________________ 19
Table of Contents
xPico® Embedded Device Server User Guide 5
Network Configuration _______________________________________________ 21
Network Mode __________________________________________________ 21
Automatic IP Address Configuration _________________________________ 21
Static IP Address Configuration _____________________________________ 22
Ethernet Configuration ____________________________________________ 23
Server Configuration _________________________________________________ 24
Server Configuration _____________________________________________ 24
Advanced ______________________________________________________ 25
Host List Configuration _______________________________________________ 25
Retry Settings ___________________________________________________ 26
Host Information _________________________________________________ 26
Channel 1 and 2 Configuration _________________________________________ 26
Serial Settings __________________________________________________ 27
Connection Settings - TCP ________________________________________ 30
Connection Settings - UDP ________________________________________ 33
Configurable Pin Settings _____________________________________________ 34
Configurable Pin Functions ________________________________________ 35
Apply Settings ______________________________________________________ 35
Apply Defaults _____________________________________________________ 35
5. Configuration via Telnet or Serial Port (Setup Mode) 37
Accessing Setup Mode _______________________________________________ 37
Telnet Connection _______________________________________________ 37
Serial Port Connection ____________________________________________ 39
Exiting Setup Mode _________________________________________________ 39
6. Setup Mode: Server Configuration 40
Server Configuration (Option 0) ________________________________________ 40
IP Address ________________________________________________________ 40
Set Gateway IP Address _____________________________________________ 42
Netmask: Number of Bits for Host Part __________________________________ 42
Set DNS Server IP Address ___________________________________________ 42
Change Telnet/Web Manager Password _________________________________ 43
DHCP Name _______________________________________________________ 43
Table of Contents
xPico® Embedded Device Server User Guide 6
7. Setup Mode: Channel Configuration 44
Channel 1 (Option 1) or Channel 2 (Option 2) _____________________________ 44
Baudrate __________________________________________________________ 44
I/F (Interface) Mode _________________________________________________ 45
Flow _____________________________________________________________ 45
Port Number _______________________________________________________ 46
Connect Mode _____________________________________________________ 46
a) Incoming Connection ___________________________________________ 47
b) Response ____________________________________________________ 48
c) Active Startup _________________________________________________ 48
d) Datagram Type _______________________________________________ 51
e) Modem Mode _________________________________________________ 51
Send the Escape Sequence (+++) in Modem Mode ________________________ 54
Show IP addr after 'RING' ____________________________________________ 54
Auto Increment Source Port ___________________________________________ 54
Remote IP Address _________________________________________________ 54
Remote Port _______________________________________________________ 54
DisConnMode ______________________________________________________ 55
Flush Mode (Buffer Flushing) __________________________________________ 56
Pack Control _______________________________________________________ 56
Packing Interval _________________________________________________ 57
Trailing Characters _______________________________________________ 57
Send Characters ________________________________________________ 57
DisConnTime (Inactivity Timeout) ______________________________________ 57
Send Characters ____________________________________________________ 58
Telnet Terminal Type ________________________________________________ 58
Channel (Port) Password _____________________________________________ 58
8. Setup Mode: Advanced Settings 59
Expert Settings (Option 5) ____________________________________________ 59
TCP Keepalive time in seconds _____________________________________ 60
ARP Cache timeout in seconds _____________________________________ 60
CPU Performance _______________________________________________ 60
Disable Monitor Mode at bootup ____________________________________ 60
HTTP Port Number ______________________________________________ 60
MTU Size ______________________________________________________ 61
Table of Contents
xPico® Embedded Device Server User Guide 7
TCP Re-Transmission Timeout _____________________________________ 61
Enable alternate MAC ____________________________________________ 61
Ethernet Connection Type _________________________________________ 61
Security Settings (Option 6) ___________________________________________ 61
Disable SNMP __________________________________________________ 62
SNMP Community Name __________________________________________ 62
Disable Telnet Setup _____________________________________________ 62
Disable TFTP Firmware Upgrade ___________________________________ 63
Disable Port 77FE (Hex) __________________________________________ 63
77FEh Access Mode _____________________________________________ 63
Disable Web Server ______________________________________________ 63
Disable Web Setup ______________________________________________ 63
Disable ECHO Ports _____________________________________________ 64
Enable Encryption _______________________________________________ 64
Enable Enhanced Password _______________________________________ 65
Disable Port 77F0 (Hex) __________________________________________ 65
Default Settings (Option 7) ____________________________________________ 65
Channel 1 and Channel 2 Configuration Defaults _______________________ 65
Expert Settings Defaults __________________________________________ 66
Security Settings Defaults _________________________________________ 66
9. GPIO Interface 68
Configurable Pins ___________________________________________________ 68
Features _______________________________________________________ 68
Control Protocol ____________________________________________________ 69
Guidelines _____________________________________________________ 69
Commands _____________________________________________________ 69
Examples _________________________________________________________ 72
10. Firmware Upgrades 73
Obtaining Firmware _________________________________________________ 73
Reloading Firmware _________________________________________________ 73
Using TFTP: Graphical User Interface ________________________________ 73
Using TFTP: Command Line Interface _______________________________ 74
Recovering the Firmware Using the Serial Port and DeviceInstaller _________ 75
Table of Contents
xPico® Embedded Device Server User Guide 8
11. Monitor Mode 76
Entering Monitor Mode Using the Serial Port ______________________________ 76
Entering Monitor Mode Using the Network Port ____________________________ 76
Monitor Mode Commands _________________________________________ 76
12. Troubleshooting 79
Problems and Error Messages _________________________________________ 79
A: Technical Support 82
B: Binary to Hexadecimal Conversions 83
Converting Binary to Hexadecimal ______________________________________ 83
Conversion Table ________________________________________________ 83
Scientific Calculator ______________________________________________ 83
C: Compliance 85
RoHS, REACH and WEEE Compliance Statement _________________________ 85
List of Tables
Table 6-1. BootP/DHCP/AutoIP Options _________________________________ 40
Table 6-2. Standard IP Network Netmasks _______________________________ 42
Table 7-1. Interface Mode Options ______________________________________ 45
Table 7-2. RS232 Interface Mode Settings _______________________________ 45
Table 7-3. Flow Control Options ________________________________________ 46
Table 7-4. Reserved Port Numbers _____________________________________ 46
Table 7-5. Connect Mode Options ______________________________________ 47
Table 7-6. Manual Connection Address Example __________________________ 49
Table 7-7. Modem Mode Messages _____________________________________ 52
Table 7-8. Modem Mode Commands ____________________________________ 53
Table 7-9. Disconnect Mode Options ____________________________________ 55
Table 7-10. Flush Mode Options _______________________________________ 56
Table 7-11. Pack Control Options ______________________________________ 56
Table 10-1. Firmware Files ____________________________________________ 73
Table 11-1. Monitor Mode Commands ___________________________________ 77
Table 11-2. Command Response Codes _________________________________ 78
Table of Contents
xPico® Embedded Device Server User Guide 9
List of Figures
Figure 2-1. Product Label _____________________________________________ 14
Figure 4-1. Web Manager Login Window _________________________________ 20
Figure 4-2. Lantronix Web Manager _____________________________________ 20
Figure 4-3. Network Settings __________________________________________ 21
Figure 4-4. Server Settings____________________________________________ 24
Figure 4-5. Hostlist Settings ___________________________________________ 26
Figure 4-6. Channel Serial Settings _____________________________________ 27
Figure 4-7. TCP Connection Settings ____________________________________ 30
Figure 4-8. UDP Connection Settings ___________________________________ 33
Figure 4-9. Configurable Pins Settings ___________________________________ 34
Figure 4-10. Apply Settings and Apply Defaults ____________________________ 36
Figure 5-1. xPico MAC Address ________________________________________ 38
Figure 5-2. xPico SMT MAC Address ___________________________________ 38
Figure 5-3. Setup Menu Options _______________________________________ 38
Figure 7-1. Serial Port Parameters ______________________________________ 44
Figure 7-2. Hostlist Option ____________________________________________ 50
Figure 8-1. Expert Settings ____________________________________________ 59
Figure 8-2. Security Settings __________________________________________ 61
Figure 10-1. TFTP Window ___________________________________________ 74
rs
xPico® Embedded Device Server User Guide 10
1. Using This Guide
Purpose and Audience
This guide covers the xPico® embedded device server. It provides the information needed to
configure, use, and update the xPico firmware and is intended for OEMs and system
integrators who are embedding the xPico embedded device server in their product designs.
Chapter Summary
Document
Description
2: Introduction Describes the main features of the xPico embedded device server and the
protocols it supports.
3: Using DeviceInstaller Provides information for getting your unit up and running, using
DeviceInstaller to assign an IP address.
4: Configuration Using
Web Manager
Details using the Web Manager to set parameters such as port and server
properties.
5: Configuration via Telnet
or Serial Port (Setup Mode)
Provides instructions for accessing Setup Mode (command line interface)
using a Telnet connection through the network or a terminal or terminal
emulation program through the serial port.
6: Setup Mode: Server
Configuration
Details the network (server) settings.
7: Setup Mode: Channel
Configuration
Details the serial port settings.
8: Setup Mode: Advanced
Settings
Details expert and security settings and explains how to reset the unit to
factory default values.
9: GPIO Interface Provides instructions for configuring the 8 General Purpose I/O pins (CP1-8).
10: Firmware Upgrades Provides instructions for obtaining the latest firmware and updating the xPico
embedded device server.
11: Monitor Mode Provides instructions for accessing and using the command line interface
for monitoring the network and diagnosing problems.
12: Troubleshooting Describes common problems and error messages and how to contact
Lantronix Technical Support.
A: Technical Support Provides contact information for Lantronix and other technical support options.
B: Binary to Hexadecimal
Conversions
Provides instructions for converting binary numbers to hexadecimals.
C: Compliance Provides compliance information.
www.|aniron|x com/suggori/documentaiion Provides the sieps for gemng ihe xPico evaluaiion board up Provides informaiion aboui ihe XPiCO hardware, iesiing ihe Insiruciions for using ihe xPico embedded device server on Provides informaiion on using the Windows® uriliiy ro creare a Provides informaiion on using Deviceinsiallerw applieaiion m (a)
1: Using This Guide
xPico® Embedded Device Server User Guide 11
Additional Documentation
Visit the Lantronix Web site at www.lantronix.com/support/documentation for the latest
documentation and the following additional documentation.
Document
Description
xPico Embedded Device Server
Quick Start
Provides the steps for getting the xPico evaluation board up
and running.
xPico Embedded Device Server
Integration Guide
Provides information about the xPico hardware, testing the
xPico embedded device server using the evaluation board,
and integrating the xPico unit into your product.
xPico Development Kit Quick
Start
Instructions for using the xPico embedded device server on
the xPico evaluation board.
Com Port Redirector User Guide
Provides information on using the Windows® utility to create a
virtual com port.
DeviceInstaller Online Help
Provides information on using DeviceInstaller™ application to
configure IP addresses and locate Lantronix devices on the
network.
xPico® Embedded Device Server User Guide 12
2. Introduction
This chapter summarizes the xPico embedded device server’s features and the basic
information needed to get started.
Capabilities
The xPico embedded device server has the following capabilities:
Connects devices through a TCP data channel or through a Telnet connection to
computers or to another device server. The xPico embedded device server also supports
UDP datagrams.
Contains a web [HTTP] server allowing presentation of custom content and easy
configuration through a browser.
Has eight programmable I/O pins used to monitor or control attached devices.
Applications
The xPico embedded device server connects serial devices such as those listed below to
Ethernet networks using the IP protocol family.
ATM machines
CNC controllers
Data collection devices
Environmental sensors
Universal Power Supply (UPS) management units
Telecommunications equipment
Data display devices
Security alarms and access control devices
Handheld instruments
Modems
Time/attendance clocks and terminals
2: Introduction
xPico® Embedded Device Server User Guide 13
Protocol Support
The xPico embedded device server uses the Internet Protocol (IP) for network
communications. It uses the Transmission Control Protocol (TCP) to assure that no data is
lost or duplicated, and that everything sent to the connection arrives correctly at the target.
Supported protocols include:
ARP, TCP/IP, UDP/IP, BOOTP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, and SNMP
for network communications and management.
TCP/IP, UDP/IP, and Telnet for connections to the serial port.
TFTP for firmware and web page updates.
IP for addressing, routing, and data block handling over the network.
User Datagram Protocol (UDP) for typical datagram applications in which devices interact
with other devices without maintaining a point-to-point connection.
Configuration Methods
For the unit to operate correctly on a network, it must have a unique IP address on the
network. There are three basic methods for logging into the device server to assign an IP
address and configure the unit:
DeviceInstaller: Assign an IP address and view the current xPico configuration using a
Graphical User Interface (GUI) on a PC attached to a network.
(See Chapter 3: Using DeviceInstaller.)
Web Manager: Through a web interface, configure the xPico embedded device server
and its settings using the xPico unit’s Web Manager.
(See Chapter 4: Configuration Using Web Manager
Serial & Telnet Ports: There are two approaches to accessing Serial Mode. Make a
Telnet connection to the network port (9999) or connect a terminal (or a PC running a
terminal emulation program) to the unit’s serial port.
(See Chapter 5: Configuration via Telnet or Serial Port (Setup Mode) )
Addresses and Port Numbers
Hardware Address
The hardware address is also referred to as the Ethernet address or the MAC address. The
first three bytes of the Ethernet address identify the unit as a Lantronix product. The fourth,
fifth, and sixth bytes are unique numbers assigned to each unit.
Example: 00-80-A3-14-01-18
Note: Make note of the MAC address. It is needed to locate the xPico embedded
device server using the DeviceInstaller utility.
_ wwwmmmmmmmmm 4._._.,._._.:._._.:._ M xx>>>> on: R + X_=O¢._.Z P g Date Code Manufacmnn
2: Introduction
xPico® Embedded Device Server User Guide 14
IP Address
Every device connected to an IP network must have a unique IP address. This address is
used to reference the specific unit. The xPico embedded device server is automatically
assigned an IP address on DHCP-enabled networks, as it is DHCP-enabled by default.
Port Numbers
Every TCP connection and every UDP datagram is defined by a destination IP address and a
port number. For example, a Telnet application commonly uses port number 23. A port
number is similar to an extension on a phone system.
The unit's serial channel (port) can be associated with a specific TCP/UDP port number. Port
number 9999 is reserved for access to the unit's Setup (configuration) Mode window. Ports 0-
1024 are reserved as well. For more information on reserved port numbers, see to Table 7-4.
Reserved Port Numbers on page 46.
Product Information Label
The product information label on the unit contains the following information about the specific
unit:
Part Number
Revision
Manufacturing Date Code
Product Model
Country of Origin
Lantronix Datamatrix Barcode
MAC Address
Figure 2-1. Product Label
Part Number
Manufacturing
Date Code
Lantronix
Datamatrix
Barcode
Country of Origin
Revision
MAC Address
at www.Iantronix.com/suggort/downloads. Devicelnstaller Online Helg httgzllwwaantronix.com/downloads. mm
xPico® Embedded Device Server User Guide 15
3. Using DeviceInstaller
This chapter covers the steps for getting the xPico embedded device server online and
viewing its current configuration.
Note: DeviceInstaller is a free utility program provided by Lantronix that discovers,
configures, upgrades, and manages Lantronix Device Servers. It can be downloaded
from the Lantronix website at www.lantronix.com/support/downloads.
For instructions on using DeviceInstaller to configure the IP address and related
settings or for more advanced features, see the DeviceInstaller Online Help.
Installing DeviceInstaller
To install DeviceInstaller:
1. Download the latest version of DeviceInstaller from http://www.lantronix.com/downloads.
2. Run the executable to start the installation process.
3. Respond to the installation wizard prompts. (If prompted to select an installation type,
select Typical).
Assigning an IP Address
The unit’s IP address must be configured before it can work correctly on a network. You have
several options for assigning an IP to your unit. We recommend that you manually assign the
IP address over the network using DeviceInstaller.
Note: To use a serial connection instead of an Ethernet connection to configure the
device, see 5 Configuration via Telnet or Serial Port (Setup Mode) on page 39.
The unit’s IP address is normally set to 0.0.0.0 at the factory. The hardware address is on the
product label. The unit is DHCP enabled as the default.
To assign an IP address manually:
1. Click Start
Programs
Lantronix
DeviceInstaller
DeviceInstaller. If your PC has
more than one network adapter, a message displays. Select an adapter and click OK.
Note: If the unit already has an IP address (e.g., DHCP has assigned an IP address),
click the Search icon and select the unit from the list of Lantronix device servers on
the local network.
2. Click the Assign IP icon .
3. If prompted, enter the hardware address (on the product label) and click Next.
3: Using DeviceInstaller
xPico® Embedded Device Server User Guide 16
4. Select Assign a specific IP address and click Next.
5. Enter the IP address. The Subnet mask displays automatically based on the IP address;
if desired, you may change it. On a local network, you can leave the Default gateway
blank (all zeros). Click Next.
6. Click the Assign button and wait several seconds until a confirmation message displays.
Click Finish.
7. Select the device from the main window list and select Ping from the Tools menu. The
Ping Device dialog box shows the IP address of the selected unit.
8. From the Tools menu, click the Ping button. The results display in the Status window.
Click the Clear Status button to clear the window so you can ping the device again.
Note: If you do not receive “Reply” messages, make sure the unit is properly
attached to the network and that the IP address assigned is valid for the particular
network segment you are working with. If you are not sure, check with your systems
administrator.
9. Click the Close button to close the dialog box and return to the main window.
Accessing the xPico Embedded Device Server Using
DeviceInstaller
1. Click Start
Programs
Lantronix
DeviceInstaller 4.4
DeviceInstaller.
2. Click the xPico folder. The list of available Lantronix xPico modules display.
3. Expand the list of xPico embedded device servers by clicking the + symbol next to the
xPico icon. Select the xPico unit by clicking on its IP address to view its configuration.
Viewing the Current Configuration
DeviceInstaller provides a view of the unit's configuration.
To view the unit's current settings:
1. Follow the instructions above to locate the xPico embedded device server.
2. In the right pane, click the Device Details tab. The current xPico configuration displays:
Name Configurable field. A name that identifies the xPico embedded
device server.
Double-click the field, type in the value, and press Enter to
complete. This name is not visible on other PCs or laptops
using the DeviceInstaller utility.
Displays “Dynamically" if lhe XPlCO embedded device server Oblain via DHCP wilh value of True or False. Oblain via BOOTP with value of True or False Oblain via RARP with value of True or False Oblain via Aulo IP wilh value of True or False 9999 rs
3: Using DeviceInstaller
xPico® Embedded Device Server User Guide 17
DHCP Device Name Non-configurable field. Displays the name associated with
xPico embedded device server’s current IP address, if the IP
address was obtained dynamically.
To change the DHCP device name, see Configuration Using
Web Manager or Configuration via Telnet or Serial Port (Setup
Mode).
Group Configurable field. A group name to categorize the xPico
embedded device server.
Double-click the field, type in the value, and press Enter to
complete. This group name is not visible on other PCs or
laptops using DeviceInstaller.
Comments
Configurable field. Information about the xPico embedded
device server.
Double-click the field, type in the value, and press Enter to
complete. This description or comment is not visible on other
PCs or laptops using DeviceInstaller.
Device Family Non-configurable field. Displays the xPico embedded device
server’s device family as “xPico.”
Type
Non-configurable field. Displays the device type as “xPico.”
ID
Non-configurable field. Displays the xPico embedded device
server’s ID embedded within the unit.
Hardware Address Non-configurable field. Displays the xPico embedded device
server’s hardware (or MAC) address.
Firmware Version Non-configurable field. Displays the firmware currently installed
on the xPico embedded device server.
Extended Firmware Version Non-configurable field. Displays the full version nomenclature of
the firmware.
Online Status
Non-configurable field. Displays the xPico embedded device
server’s status as online, offline, unreachable (the xPico unit is
on a different subnet), or busy (the xPico embedded device
server is currently performing a task).
IP Address Non-configurable field. Displays the xPico embedded device
server’s current IP address. To change the IP address, see
Assigning an IP Address on page 15.
IP Address was Obtained
Displays “Dynamically” if the xPico embedded device server
automatically received an IP address (e.g., from DHCP).
Displays “Statically” if the IP address was configured manually.
If the IP address was assigned dynamically, the following fields
appear:
Obtain via DHCP with value of True or False.
Obtain via BOOTP with value of True or False.
Obtain via RARP with value of True or False
Obtain via Auto IP with value of True or False
Subnet Mask
Non-configurable field. Displays the xPico embedded device
server’s current subnet mask. To change the subnet mask, see
Assigning an IP Address on page 15.
3: Using DeviceInstaller
xPico® Embedded Device Server User Guide 18
Gateway Non-configurable field. Displays the xPico embedded device
server’s current gateway. To change the gateway, see
Assigning an IP Address on page 15.
Number of COB partitions
supported
Non-configurable field. Displays the number of COB partitions
supported.
Number of Ports Non-configurable field. Displays the number of ports on the
xPico embedded device server.
TCP Keepalive Non-configurable field. Displays 1-65s, the xPico embedded
device server’s TCP keepalive value. The default setting is 45.
Telnet Supported Non-configurable field. Indicates if Telnet sessions are
permitted.
Telnet Port Non-configurable field. Displays the xPico embedded device
server’s port for Telnet sessions.
Web Port
Non-configurable field. Displays the xPico embedded device
server’s port for Web Manager configuration.
Maximum Baud Rate Supported Non-configurable field. Displays the xPico embedded device
server’s maximum baud rate.
Note: the xPico embedded device server may not currently be
running at this rate.
Firmware Upgradeable Non-configurable field. Displays True, indicating the xPico
firmware is upgradeable as newer version become available.
Supports Configurable Pins Non-configurable field. Displays True, indicating configurable
pins are available on the xPico embedded device server.
Supports Email Triggers Non-configurable field. Displays False, indicating email triggers
are not supported on xPico embedded device server.
Supports AES Data Stream Non-configurable field. Displays True. xPico embedded device
server supports AES encryption.
Supports 485 Non-configurable field. Displays True. xPico embedded device
server supports the RS-485 protocol.
Supports 921K Baud Rate Non-configurable field. Displays True. xPico embedded device
server supports baud rates up to 921600 bits per second (bps).
Supports HTTP Server Non-configurable field. Displays True.
Supports HTTP Setup Non-configurable field. Displays True.
Supports 230K Baud Rate Non-configurable field. Displays True.
Supports GPIO Non-configurable field. Displays True, indicating the xPico
embedded device server supports General Purpose Input
Output (GPIO).
xPico® Embedded Device Server User Guide 19
4. Configuration Using Web Manager
You must configure the unit so that it can communicate on a network with your serial device.
For example, you must set the way the unit will respond to serial and network traffic, how it
will handle serial packets, and when to start or close a connection.
The unit’s configuration is stored in nonvolatile memory and is retained without power. You
can change the configuration at any time. The unit performs a reset after you change and
store the configuration.
In this chapter, we describe how to configure the xPico embedded device server using Web
Manager, Lantronix’s browser-based configuration tool. (For information on using Setup
Mode, our command line configuration interface, see Chapter 5: Configuration via Telnet or
Serial Port (Setup Mode).
Note: The examples in this section show a typical device. Your device may have
different configuration options.
Accessing Web Manager Using DeviceInstaller
Note: For more information on DeviceInstaller, see Chapter 3: Using DeviceInstaller.
1. Run DeviceInstaller and search for the list of available Lantronix device servers.
2. Click on the xPico folder. The list of available xPico embedded device servers display.
3. Expand the list of xPico embedded device servers by clicking the + symbol next to the
xPico icon.
4. Select the xPico unit by clicking its hardware address.
5. In the right pane, click the Web Configuration tab.
6. To view the xPico’s Web Manager in the current DeviceInstaller window, click the Go
button. To open the Web Manager in a web browser, click the External Browser button.
Note: Alternatively, to open Web Manager, open your web browser and enter the
IP address of the xPico embedded device server.
A dialog box appears to prompt for a User Name and Password.
numenliralinn Required 0 Men-mm Sen/m Srrml 7mm Has" 5 Channel 1 Finnw-n Vammn: vsn 04 y mm u" a...” nun: nv-swzous Channel 1 m Sam; "M m mmchaM CummurameFms W‘rad Am 5mg, < none=""> up Adams: 1121910143 mama...” 172 m In nus 5m.» 1721911 mu: Iwo App‘y Dciauus Li... 1: 115221236018.htm", 1, Man. Lm- z: R5232,960D,5,Non:,1‘None
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 20
Figure 4-1. Web Manager Login Window
7. Perform one of the following:
If no Telnet password has been defined, leave both fields blank and click OK.
If a Telnet password has been defined, leave the username blank, type in the
password, and then click OK.
The Web Manager displays.
Note: We recommend that you always use the enhanced password setting and
create a strong 16 character password. See Security Settings (Option 6) on page
61.
Figure 4-2. Lantronix Web Manager
The main menu is in the left pane of the Web Manager window.
Network Settings NetwurkMDde Wrred omy v F confluuralinn 0 Guam IP address autnmaucauy Autn Cnnflguratmn Methods BOOT? Enab‘e Dlsahls DHCP Enabte Dlsable AutuIP Enab‘e Dlsable DHCF HustName :] @ UsemerouawmgIPconngmarmn IPAumess E] SubnetMask W‘ Deraunsarewav E] DNS Server W‘ Ethernet Cnnflunratim Auto N Eflottate Speed mumbps 10mm: Dup‘m Fun Half Network Mode Wired Only rs the only choice It enables the Ethernet network
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 21
Network Configuration
The unit’s network values display when you select Network from the main menu. The
following sections describe the configurable parameters on the Network Settings page.
Figure 4-3. Network Settings
Network Mode
1. Click Network from the main menu.
2. Note the following:
Network Mode
Wired Only is the only choice. It enables the Ethernet network
connectivity.
Automatic IP Address Configuration
An IP address can be assigned automatically. You then enter related network settings.
To assign an IP address automatically:
1. On the main menu, click Network.
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 22
2. Select Obtain IP address automatically.
3. Enter the following (as necessary):
BOOTP Select Enable to permit the Bootstrap Protocol (BOOTP).
server to assign the IP address from a pool of addresses
automatically. Enable is the default.
DHCP Select Enable to permit the Dynamic Host Configuration
Protocol (DHCP) to assign a leased IP address to the xPico
unit automatically. Enable is the default.
AutoIP Select Enable to permit the xPico embedded device server to
generate an IP in the 169.254.x.x address range with a Class
B subnet. Enable is the default.
DHCP Host Name Enter the desired host name for the xPico embedded device
server.
Note: Disabling BOOTP, DHCP, and AutoIP (all three checkboxes) is not advised as
the only available IP assignment method will then be ARP or serial port.
4. When you are finished, click the OK button.
5. On the main menu, click Apply Settings.
Static IP Address Configuration
You manually assign an IP address to the unit and enter related network settings.
To assign an IP address manually:
1. On the main menu, click Network.
2. Select Use the following IP configuration.
3. Enter the following (as necessary):
IP Address If DHCP is not used to assign IP addresses, enter it manually
in decimal-dot notation. The IP address must be set to a
unique value in the network.
Subnet Mask A subnet mask defines the number of bits taken from the IP
address that are assigned for the host part.
Default Gateway The gateway address, or router, allows communication to
other LAN segments. The gateway address should be the IP
address of the router connected to the same LAN segment as
the unit. The gateway address must be within the local
network.
DNS Server The DNS server allows the name of a remote machine to be
resolved automatically. Enter the IP address of the DNS
server. If the device is DHCP enabled, the DHCP server
provides the DNS server IP address, which will override this
configured value.
Note: This setting is applicable only in Manual Connection
mode.
Speed: T 100 Mbp Duplex: is Full.
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 23
4. When you are finished, click the OK button.
5. On the main menu, click Apply Settings.
Ethernet Configuration
You must specify the speed and direction of data transmission.
To specify how data will be transmitted:
1. On the main menu, click Network.
2. Enter the following (as necessary):
Auto Negotiate With this option, the Ethernet port auto-negotiates the speed
and duplex with the hardware endpoint to which it is
connected. This is the default.
If this option is not selected, the complete the fields that
become available:
Speed: The speed of data transmission. The default is
100 Mbps.
Duplex: The direction of data transmission. The default
is Full.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Server Settings Selvet Cnnfigurafl’nn Advanced Passwavd OEname ® Dlsahlz TEmeWVeh Managev Passwum Pewpe Passwmd Amman ARP Cams Tlmeuul (secs) BUD TCP KeepaWe (sees) 45 MomlmMade @Bamup Gsname ODISahIE CPU Penarmance Mode OLuw GRzgular OHIgh HTrF' Sawaqun an Carma servevPon MTU $sz 1400 TOP RE-tvansmwssmn I‘mEaul (m5) EDI] Enable: 5e creafion, a in lengm. Disable: selecfin creafion, allowin by‘es in lengm.
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 24
Server Configuration
The unit’s server values display when you select Server from the main menu. The following
sections describe the configurable parameters on the Server Settings page.
Figure 4-4. Server Settings
To configure the xPico device server settings:
1. On the main menu, click Server.
2. Configure or modify the following fields:
Server Configuration
Advanced Password
Note: We recommend that you
always enable the enhanced
password setting, and create a
strong 16 character password.
Select whether to enable advanced password:
Enable: selecting this option enables advanced password
creation, allowing you to create passwords up to 16 bytes
in length.
Disable: selecting this option disables advanced password
creation, allowing you to create basic passwords up to 4
bytes in length.
Telnet/Web
Manager Password
Enter the password required for Telnet configuration and Web
Manager access.
Retype Password Re-enter the password required for Telnet configuration and
Web Manager access.
(a)
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 25
Advanced
ARP Cache Timeout When the unit communicates with another device on the
network, it adds an entry into its ARP table. ARP Cache
timeout defines the number of seconds (1-600) before it
refreshes this table. Entering 0 disables the ARP cache
timeout.
TCP Keepalive TCP Keepalive time defines how many seconds the unit waits
during an inactive connection before checking its status. If the
unit does not receive a response, it drops that connection.
Enter a value between 0 and 60 seconds. 0 disables
keepalive. The default setting is 45.
Monitor Mode @ Bootup Select Disable to disable entry into the monitor mode using
the 'yyy' or 'xx1' key sequence at startup. This field prevents
the unit from entering monitor mode by interpreting the stream
of characters that are received during the device server's
initialization at startup.
CPU Performance Mode Select the xPico embedded device server’s performance
mode. Higher performance settings require more energy.
Regular is 48 Mhz; High is 88 Mhz. The default is Regular.
HTTP Server Port This option allows the configuration of the web server port
number. The valid range is 1-65535. The default port is 80.
Config Server Port Not applicable for this product.
MTU Size The Maximum Transmission Unit (MTU) is the largest physical
packet size a network can transmit for TCP and UDP. Enter
between 512 and 1400 bytes. The default is 1400 bytes.
TCP Re-transmission timeout
(ms)
The desired TCP re-transmission timeout value. If the ACK is
not received for a packet sent from the xPico device, then the
unit will retransmit the data. The valid range is 500-4000
msec.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Host List Configuration
The xPico embedded device server scrolls through the host list until it connects to a device
listed in the host list table. After a successful connection, the unit stops trying to connect to
any others. If this connection fails, the unit continues to scroll through the table until the next
successful connection.
The host list supports a minimum of 1 and a maximum of 12 entries. Each entry contains an
IP address and a port number.
Note: The host list is disabled for Manual and Modem Mode. The unit does not
accept a data connection from a remote device when the hostlist option is enabled.
To configure the xPico host list:
Hostlist Settings Retry Settings Reteruuntev 3 RelrvTxmenut 25D H051 Infnrmation Mn. Hns1 Addizss Ml. H1151 Address 1 1000— r2 W‘ Im—\ 3 1000— r W‘ !°—\ 5 W F 6 W‘ !°—\ 7 W F a W‘ !°—\ 9 WV“. WNW 1. [Win—12 WNW
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 26
1. On the main menu, click Hostlist.
Figure 4-5. Hostlist Settings
2. Enter or modify the following fields:
Retry Settings
Retry Counter Enter the value for the number of times the xPico embedded
device server should attempt to retry connecting to the host
list.
Retry Timeout Enter the duration (in milliseconds) the xPico embedded
device server should abandon attempting a connection to the
host list.
Host Information
Host Address Enter or modify the host’s IP address.
Port Enter the target port number.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Channel 1 and 2 Configuration
The Channel 1 and Channel 2 configuration define how the serial ports respond to network
and serial communication.
Note: Directions for configuring Channel 1 serial settings and connection apply for
Channel 2 configuration, except where indicated.
Serial Settings channel 1 Disable Sena‘ Pun ponsemnus Pmlncul R5232 v F‘owcnnlvo‘ EIaudRate 9500 v Datants a v Parity None v smums PackCnmrnl El Enable Packmg Idle Gan Txme Match 2 Byte Sequence yes No Send Frame \mmemme w; Nu Malch EMes 3:):l El":l senuTramnu Bytes Nnne One Two ex Flush Mnue Flush Input Buner Flush output Elmer With Auwe Carmen Ow; ® Nu th Actwe Cunnecl Oyes G) No w‘m Passwe Carmen Owes (9 Nu Wllh Passwe Cnnnecl ova; ® No Amme uvnuseunnen 0y“ (9 Nu Amme mesmnned ova; (9 No Channel 1 proxocols, Channel 2: R5232 only
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 27
Serial Settings
To configure the channel’s serial settings:
1. On the main menu, click Serial Settings (under Channel 1) to display the Serial Settings
window.
Figure 4-6. Channel Serial Settings
2. In the available fields, enter the following information:
Channel 1
Disable Serial Port When selected, disables communication through the serial port.
The serial port is enabled by default.
Note: This checkbox only applies to Channel 2.
Port Settings
Protocol From the drop-down menu, select the protocol type for the
selected channel.
Channel 1: RS232, RS422/RS485 – 4 wire or RS485 – 2 wire
protocols.
Channel 2: RS232 only
Flow Control Flow control manages data flow between devices in a network to
ensure it is processed efficiently. Too much data arriving before a
device is prepared to manage it causes lost or retransmitted data.
None is the default.
0 Channel1: None‘ Xon/Xoff‘ Xon/Xoff Pass Chars to Host or CTS/RTS (hardware). Channel 2: None‘ Xon/Xoff or Xon/Xoff Pass Chars to Host Enable Packing Select to enable packing on the xPico embedded device server. Idle Gap Time Select the maxlmum time for inactwlty. The default time is Match 2 Byte Sequence Use to lndlcate the end of a senes of data to be sent as one Match Bytes Use to lndlcate the end of a senes of data to be sent as one Send Frame Immediate Afler the detectlon of the byte sequenoe‘ indicates whether to Send Trailing Bytes Select the number of bytes to send after the end-of-sequence ®
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 28
Channel 1: None, Xon/Xoff, Xon/Xoff Pass Chars to Host or
CTS/RTS (hardware).
Channel 2: None, Xon/Xoff or Xon/Xoff Pass Chars to Host
Baud Rate The unit and attached serial device, such as a modem, must
agree on a speed or baud rate to use for the serial connection.
Valid baud rates are 300, 600, 1200, 2400, 4800, 9600 (default),
19200, 38400, 57600, 115200, or 230400, 460800, or 921600
Note: It is recommended to use hardware flow control for baud
rates of 38400 and higher or it could result in data loss. Baud
rates 460800 and 921600 are available for selection only when
CPU performance mode is set to High.
Data Bits Indicates the number of bits in a transmitted data package. The
default is 8.
Parity Checks for the parity bit. The default is None.
Stop Bits The stop bit follows the data and parity bits in serial
communication. It indicates the end of transmission. The default
is 1.
Pack Control
Enable Packing
Select to enable packing on the xPico embedded device server.
Two firmware-selectable packing algorithms define how and
when packets are sent to the network.
The standard algorithm is optimized for applications in which the
unit is used in a local environment, allowing for very small delays
for single characters, while keeping the packet count low.
The alternate packing algorithm minimizes the packet count on
the network and is especially useful in applications in a routed
Wide Area Network (WAN). Adjusting parameters in this mode
can economize the network data stream.
Disabled by default.
Idle Gap Time
Select the maximum time for inactivity. The default time is
12 milliseconds.
Match 2 Byte Sequence
Use to indicate the end of a series of data to be sent as one
group. The sequence must occur sequentially to indicate end of
the data collection to the xPico embedded device server. The
default is No.
Match Bytes
Use to indicate the end of a series of data to be sent as one
group. Set this value to 00 if specific functions are not needed.
Send Frame Immediate
After the detection of the byte sequence, indicates whether to
send the data frame or the entire buffer. Select Yes to send only
the data frame. The default setting is No.
Send Trailing Bytes
Select the number of bytes to send after the end-of-sequence
characters. The default is None.
Flush Input Buffer (Serial to Network)
With Active Connect
Select
Yes
to clear the input buffer with a connection that is
initiated from the device to the network. The default is No.
With Passive Connect Select Yes to clear the input buffer with a connection initiated
from the nelwork lo the dewce. The default is No rs
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 29
from the network to the device. The default is No.
At Time of Disconnect Select Yes to clear the input buffer when the network connection
to or from the device is disconnected. The default is No.
Flush Output Buffer (Network to Serial)
With Active Connect Select Yes to clear the output buffer with a connection that is
initiated from the device to the network. The default is No.
With Passive Connect Select Yes to clear the output buffer with a connection initiated
from the network to the device. The default is No.
At Time of Disconnect Select Yes to clear the output buffer when the network connection
to or from the device is disconnected. The default is No.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Connection Settings Channel 1 connect Pvmocnl F'm1ucul comm Mona Passwa cmnemlnm mm Cnnnscihn: 2:31:11" Oves @Nu Slanchavaclev [ID (m Hex) pmm : mamas Muuem Escape sequence Pass ShoWIF' AumessAner Wong" @ws ONu RING @ves ONO Enunuim Cnnfiwr Lucal PM [I Am: Incremennur acme cunnecl Ramote For! E Ramnla Hnst no u u Cmnmm 0minns: TelnetcnmPnnCnul cannecmespnnse Use mmuama |:| eves ®~o Disconnect Made on Mum_cm_m Dmn OYes ® Nu Ham Disconnact ®yg5 0ND Che:kEOT(Cm-D) Om (9Nu \naniwtyTimEuul El: Elm"; 52:5)
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 30
Connection Settings - TCP
To configure a channel’s TCP settings:
1. On the main menu, click Connection. The Connection Settings window for the channel
displays.
Figure 4-7. TCP Connection Settings
Protocol From the drop-down menu‘ select TCPt Accept Incoming Select Yes to accept incoming connections The default is Req u i red Determines whether a password is required for an incoming Password If Password Required was set to Yes, enter the password for Active Connect With Any :2 character is With Activ requests 0 asserted With Stan Character: Attempts to con receives a specific start character from default start character is carriage reiu Manual Connection: Attempts to co by a command string received from Auto Start: Automatically connects address and port after booting up. Start Character This field 15 available for configuration only when Active Connect 15 set to None. Select Enable to permit Telnet ®
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 31
2. In the available fields, enter or modify the following information:
Connect Protocol
Protocol
From the drop-down menu, select TCP.
Connect Mode: Passive Connection
Accept Incoming
Select Yes to accept incoming connections. The default is
Yes.
Required
Determines whether a password is required for an incoming
passive connection. This field is not available when a
password is set for Telnet mode.
Password
If Password Required was set to Yes, enter the password for
passive connections.
Connect Mode: Active Connection
Active Connect
Select None to disable Active Connect. Otherwise, indicate
the connection type from the drop-down list:
With Any Character: Attempts to connect when any
character is received from the serial port.
With Active Mdm Ctrl In: Accepts external connection
requests only when the Modem Control In input is
asserted.
With Start Character: Attempts to connect when it
receives a specific start character from the serial port. The
default start character is carriage return.
Manual Connection: Attempts to connect when directed
by a command string received from the serial port.
Auto Start: Automatically connects to the remote IP
address and port after booting up.
Start Character
If Active Connect is set to With Start Character, enter the
start character in this field.
Modem Mode Indicates the on-screen response type when in Modem Mode
(if Modem Mode is enabled).
Show IP Address After
Ring
Indicates whether to display the remote IP address upon
connection. The default setting is Yes.
Endpoint Configuration
Local Port Enter the local port number.
Auto increment for
active connect
Select to auto-increment the local port number for new
outgoing connections. The range of auto-incremented port
numbers is 50,000 to 59,999 and loops back to the beginning
when the maximum range is reached.
Remote Port Enter the remote port number.
Remote Host Enter the IP address of the remote device.
Common Options
Telnet Com Port Cntrl
This field is available for configuration only when Active
Connect is set to None. Select Enable to permit Telnet
communication to the unit. The Telnet Com Port Cnlrl (a)
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 32
communication to the unit. The Telnet Com Port Cntrl
feature is used in conjunction with the Com Port Redirector
(CPR) utility. (See the CPR online Help for details.)
Terminal Name This field is available for configuration only when Telnet Mode
is set to Enable.
Use the terminal name for the Telnet terminal type. Enter only
one name. When this option is enabled, the unit also reacts to
the end of record (EOR) and binary options, which can be
used for applications such as terminal emulation to IBM hosts.
Connect Response A single character is transmitted to the serial port when there
is a change in connection state. Default setting is None.
Use Hostlist If this option is set to True, the device server scrolls through
the host list until it connects to a device listed in the host list
table. Once it connects, the unit stops trying to connect to any
others. If this connection fails, the unit continues to scroll
through the table until it connects to another IP in the host list.
The host list is disabled for Manual Mode and for Modem
Mode. The unit will not accept a data connection from a
remote device when the host list option is enabled.
LED Select Blink for the status LEDs to blink upon connection or
None for no LED output.
Disconnect Mode
On Mdm_Ctrl_In Drop Set to Yes for the network connection to or from the serial port
to disconnect (drop) when Modem Control In transitions from
an asserted state to not asserted state. The default setting is
No.
Hard Disconnect When set to Yes, the TCP connection closes even if the
remote site does not acknowledge the disconnect request.
Check EOT (Ctrl-D) Select Yes to drop the connection when Ctrl-D or Hex 04 is
detected. Both Telnet Com Port Cntrl and Check EOT
(Ctrl+ D) must be enabled for Disconnect with EOT to
function properly. Ctrl+D is only detected going from the serial
port to the network. The default setting is No.
Inactivity Timeout Use this parameter to set an inactivity timeout. The unit drops
the connection if there is no activity on the serial line before
the set time expires. Enter time in the format mm:ss, where m
is the number of minutes and s is the number of seconds. To
disable the inactivity timeout, enter
00:00
.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Connection Settings channel 1 connect Pnnucul Pmlm‘u‘ UDP v Datagram Mme: Datagvamwue CID v Acwmmcummg‘ Ennpmm Cnnfluumtinn: Local PM Remnla Port Remme Husl use Bvoadcast Mn. Dwndm Nu. Dwnddr
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 33
Connection Settings - UDP
To configure a channel’s UDP settings:
1. On the main menu, click Connection. The Connection Settings window for the selected
channel displays.
2. In the available fields, enter or modify the following information:
Figure 4-8. UDP Connection Settings
Connect Protocol
Protocol
Select
UDP
from the drop-down menu.
Datagram Mode
Datagram Type
Configures the remote IP or network broadcast address and
the remote port. Enter 01 for directed or broadcast UDP. The
default setting is 00.
Accept Incoming
Select
Yes
to accept incoming UDP datagrams.
Endpoint Configuration
Local Port Enter the local port number.
Remote Port Enter the port number of the remote device.
Configurable Pin Settings cp ruminn Dirzuinn 1mm Laval 1 Geneva‘ Purpose I/O v ©mput OOutpul @Low Oman 2 @‘nput Oomum ®Luw OHIgh 3 ‘GEnEva‘ Puvpuse I/O V‘ @‘nput Ooumm @Low OHIgh 4 ®mput Oomum ®Low OHIgh 5 W @mput Oeumm @an OHIgh 6 ©mput Ooumu' ©Low Oman 7 @‘nput 00mm @Luw OHIgh 8 Geneva‘ Purpose I/O v ©mput Ooutpul ©Low OHIgh
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 34
Remote Host Enter the IP address of the remote device.
Use Broadcast Select to broadcast the UDP datagram. The default is not to
broadcast.
Note: Datagrams are sent as subnet-directed broadcasts.
Device Address Table The table is enabled when Datagram Type is set to FD. Enter
values between 1 and 255 to identify units on the local
network of device servers.
Note: Lantronix Tech Support supports Datagram type 01.
Datagram Type FD is for OEM use.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Configurable Pin Settings
There are eight configurable hardware pins on the xPico unit. For each pin, configure the pin
function, communication direction, and activity level. For more information, see Chapter 9:
GPIO Interface.
To configure the xPico embedded device server’s Configurable Pins:
1. On the main menu, click Configurable Pins. The Configurable Pins page opens.
Figure 4-9. Configurable Pins Settings
2. Configure or modify the following fields for each pin:
Function
From the drop-down menu, select the purpose of the
specified pin. See Configurable Pin Functions (below) for
a description of each available function.
Direction Select whether the pin inputs or outputs.
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 35
Active Level Select the signal active level (Low or High).
Configurable Pin Functions
General Purpose I/O Monitors input using the 77F0 port or controls output by the
77F0 port.
Modem Ctrl Channel 1 In For DTE device configuration this would be the DCD control
line.
Modem Ctrl Channel 1 Out For DTE device configuration this would be the DTR control
line.
RS485 Select Channel 1 Optional control signal that enables toggling between RS232
and RS485 on OEM hardware design.
RS485 2-Wire Channel 1 Optional control signal that enables toggling between RS485
2-wire and 4-wire mode on OEM hardware design.
Serial Channel 1 Status LED Indicates channel 1 status and extended diagnostics.
Serial Channel 2 Status LED Indicates channel 2 status and extended diagnostics.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Apply Settings
1. To save and apply the configuration changes to the device server, click the Apply
Settings button.
Note: Clicking OK on each page does not change the configuration on the device.
Clicking the OK button tells the xPico embedded device server what changes to use;
the Apply Settings button makes the changes permanent and reboots the xPico
embedded device server.
Apply Defaults
1. Click the Apply Defaults button to set the device server back to the default settings. For
details see Default Settings on page 65.
2. Click Yes to set factory settings or click No to cancel.
xPico“ LANRONIX° Device sums "mm Snrvm Srnal Tunne‘ H , Channnl 1 r... m :wmfi - - van 04 nv-swzms m!" nmAWm—As anmurammns Wm Amy Semmj: < home=""> 1121911114: 172mm ”2.19.1.1 mo App‘y 9mm nsm, mm, a. Nnm,1,Mnn- Rsm, 9mm. 5, Mm. 1‘ None
4: Configuration Using Web Manager
xPico® Embedded Device Server User Guide 36
Figure 4-10. Apply Settings and Apply Defaults
xPico® Embedded Device Server User Guide 37
5. Configuration via Telnet or Serial Port
(Setup Mode)
You must configure the unit so that it can communicate on a network with your serial device.
As an alternative to using a web browser, as described in the previous chapter, you can use
the following procedures remotely or locally:
Use a Telnet connection to configure the unit over the network.
Use a terminal or terminal emulation program to access the serial port locally.
The series of prompts at which you enter configuration settings is called Setup Mode.
Note: Detailed information about other setup methods is available from your
Lantronix Sales Associate.
The unit’s configuration is stored in nonvolatile memory and is retained without power. You
can change the configuration at any time. The unit performs a reset after the configuration
has been changed and stored.
This chapter tells you how to access Setup Mode and the general procedure for using it. To
complete the configuration, continue with Chapter 6: Setup Mode: Server Configuration,
Chapter 7: Setup Mode: Channel Configuration, and Chapter 8: Setup Mode: Advanced
Settings.
Note: The menus in the configuration chapters show a typical device. Your device
may have different configuration options.
Accessing Setup Mode
Telnet Connection
To configure the unit over the network, establish a Telnet connection to port 9999.
Note: You can also use DeviceInstaller to access Telnet. Select the device from the
main window list, and click the Telnet Configuration tab. Skip steps 1 and 2.
rs
5: Configuration via Telnet or Serial Port (Setup Mode)
xPico® Embedded Device Server User Guide 38
To establish a Telnet connection:
1. From the Windows Start menu, click Run and type the following command, where x.x.x.x
is the IP address, and 9999 is the unit’s fixed network configuration port number:
Windows: telnet x.x.x.x 9999
UNIX: telnet x.x.x.x:9999
2. Click OK. The following information displays.
Figure 5-1. xPico MAC Address
MAC address 0080A397C3A9
Software version V6.11.0.4 (160907) XPICO
AES library version 1.8.2.1
Press Enter for Setup Mode
Figure 5-2. xPico SMT MAC Address
MAC address DC82F6000116
Software version V6.11.0.4 (160907) XPICO-SMT
AES library version 1.8.2.1
Press Enter for Setup Mode
3. To enter Setup Mode, press Enter within 5 seconds. The configuration settings display,
followed by the Change Setup menu.
Figure 5-3. Setup Menu Options
Change Setup:
0 Server
1 Channel 1
2 Channel 2
5 Expert
6 Security
7 Defaults
8 Exit without save
9 Save and exit Your choice ?
5: Configuration via Telnet or Serial Port (Setup Mode)
xPico® Embedded Device Server User Guide 39
4. Select an option on the menu by entering the number of the option in the Your choice ?
field and pressing Enter.
5. To enter a value for a parameter, type the value and press Enter, or to confirm a current
value, just press Enter.
6. When you are finished, save the new configuration (option 9). The unit reboots.
Serial Port Connection
To configure the unit through a serial connection:
1. Connect a console terminal or PC running a terminal emulation program to your unit's
serial port.
2. Set the terminal emulator serial port settings to 9600 baud, 8 bits, no parity, 1 stop bit, no
flow control.
Note: The xPico embedded device server always uses these serial port settings on
boot-up.
3. Reset the xPico unit by cycling the unit's power (turning the power off and back on).
Immediately upon resetting the device, enter three lowercase x characters (xxx).
Note: The easiest way to enter Setup Mode is to hold down the x key at the terminal
(or emulation) while resetting the unit. You must do this within three seconds of
resetting the xPico embedded device server.
At this point, the screen display is the same as when you use a Telnet connection. To
continue, go to step 4, above, in the section, Telnet Connection.
Exiting Setup Mode
To exit setup mode:
You have two options:
To save all changes and reboot the device, select option 9 Save and exit from the
Change Setup menu. All values are stored in nonvolatile memory.
To exit the configuration mode without saving any changes or rebooting, select option 8
Exit without save from the Change Setup menu.
AumlP DHCP BomP
xPico® Embedded Device Server User Guide 40
6. Setup Mode: Server Configuration
This chapter explains how to configure the network settings.
Note: Current values appear in parentheses.
Server Configuration (Option 0)
The unit’s basic network parameters display when you select Server configuration (option
0). The IP Address, Set Gateway IP Address, and Netmask fields display the current
values.
IP Address : (000) .(000) .(000) .(000)
Set Gateway IP Address (N) ?
Netmask: Number of Bits for Host Part (0=default) (0)
Set DNS Server IP addr (N) ?
Change Telnet/Web Manager password (N) ?
Change DHCP device name (not set) ? (N) ?
Enable DHCP FQDN option : (N) ?
IP Address
If DHCP is not used to assign IP addresses, enter the IP address manually. The IP address
must be set to a unique value in the network. Enter each octet and press Enter between
each section. The current value displays in parentheses.
IP Address : ( 0) ( 0) ( 0) ( 0) _
If DHCP is used, the third octet of the IP address sets the BootP/DHCP/AutoIP options. The
following table shows the bits you can manually configure to force the xPico embedded
device server to disable AutoIP, DHCP, or BootP. To disable an option, set the appropriate
bit.
Table 6-1. BootP/DHCP/AutoIP Options
Options
Bit
AutoIP
0
DHCP
1
BootP
2
6: Setup Mode: Server Configuration
xPico® Embedded Device Server User Guide 41
For example, if the third octet is 0.0.5.0, the AutoIP and BootP options are disabled; only
DHCP is enabled. (The value 5 results from adding the binary equivalents of 0 and 2.) This is
the most common setting when using DHCP.
A 24 255.0 0.0 B 16 255.2550 0 C 8 255255255 0
6: Setup Mode: Server Configuration
xPico® Embedded Device Server User Guide 42
Set Gateway IP Address
The gateway address, or router, allows communication to other LAN segments. The gateway
address should be the IP address of the router connected to the same LAN segment as the
unit. The gateway address must be within the local network. The default is N (No), meaning
the gateway address has not been set. To set the gateway address, type Y and enter the
address.
Set Gateway IP Address (N) ? Y
Gateway IP addr ( 0) ( 0) ( 0) ( 0)_
Netmask: Number of Bits for Host Part
A netmask defines the number of bits taken from the IP address that are assigned for the
host part.
Netmask: Number of Bits for Host Part (0=default) (0) _
Note: Class A: 24 bits; Class B: 16 bits; Class C: 8 bits
The unit prompts for the number of host bits to be entered, then calculates the netmask,
which appears in standard decimal-dot notation (for example, 255.255.255.0) when the saved
parameters display.
Table 6-2. Standard IP Network Netmasks
Network Class
Host Bits
Netmask
A
24
255.0.0.0
B
16
255.255.0.0
C
8
255.255.255.0
Set DNS Server IP Address
The DNS server allows the name of a remote machine to be resolved automatically. The
default is N (No), indicating the DNS server address has not been set. To set the DNS server
address, type Y. At the prompt, enter the DNS server address. If the device is DHCP
enabled, the DHCP server provides the DNS server IP address, which will override this
configured value.
Note: This setting is applicable only in Manual Connection mode.
Set DNS Server IP addr <N> ?
®
6: Setup Mode: Server Configuration
xPico® Embedded Device Server User Guide 43
Change Telnet/Web Manager Password
Setting the Telnet/Web Manager password prevents unauthorized access to the setup menu
through a Telnet connection to port 9999 or through web pages.
Please protect your device from unauthorized access and follow the instructions below:
Always select Y to enable Telnet/Web Manager password
Enable the enhanced password setting and create a strong 16-character password. For
details, see Security Settings (Option 6) on page 61.
Note: We do not recommend that you only use the 4-character basic password as it
does not offer sufficient security. Using no password is very dangerous.
Change Telnet/Web Manager password (N) ? _
DHCP Name
If a DHCP server has automatically assigned the IP address and network settings, you can
discover the unit by using the DeviceInstaller network search feature.
There are three methods for assigning DHCP names to the unit.
Default DHCP Name: If you do not change the DHCP name, and you are using an IP of
0.0.0.0, then the DHCP name defaults to CXXXXXX (XXXXXX is the last 6 digits of the MAC
address shown on the label on the bottom/side of the unit). For example, if the MAC address
is 00-20-4A-12-34-56, then the default DHCP name is C123456.
Custom DHCP Name: You can create your own DHCP name. If you are using an IP
address of 0.0.0.0, then the last option in Server configuration is Change DHCP device
name. This option allows you to change the DHCP name to an alphanumeric name (LTX in
our example).
Change DHCP device name (not set) ? (N) Y
Enter new DHCP device name : LTX
Numeric DHCP Name: You can change the DHCP name by specifying the last octet of the
IP address. When you use this method, the DHCP name is LTXYY where YY is what you
chose for the last octet of the IP address. If the IP address you specify is 0.0.0.12, then the
DHCP name is LTX12. This method only works with 2 digit numbers (01-99).
xPico® Embedded Device Server User Guide 44
7. Setup Mode: Channel Configuration
This chapter explains how to configure the serial port.
Channel 1 (Option 1) or Channel 2 (Option 2)
Select Channel 1 (option 1) or Channel 2 (option 2) from the Change Setup menu to define
how the serial port responds to network and serial communications. The following sections
describe the configurable parameters within the Channel configuration menu.
Figure 7-1. Serial Port Parameters
Baudrate (9600) ?
I/F Mode (4C) ?
Flow (00) ?
Port No (10001) ?
ConnectMode (C0) ?
Send '+++' in Modem Mode (Y) ?
Show IP addr after 'RING' (Y) ?
Auto increment source port (N) ?
Remote IP Address : (000) .(000) .(000) .(000)
Remote Port (0) ?
DisConnMode (00) ?
FlushMode (00) ?
DisConnTime (00:00) ?:
SendChar 1 (00) ?
SendChar 2 (00) ?
Baudrate
The unit and attached serial device, such as a modem, must agree on a speed or baud rate
to use for the serial connection. Valid baud rates are 300, 600, 1200, 2400, 4800, 9600
(default), 19200, 38400, 57600, 115200, and 230400 bits per second. xPico embedded
device server also supports high-performance baud rates of 460800 and 921600 bits per
second. (See CPU Performance on page 60).
Baudrate (9600) ? _
12572320 “1 R87422/485 R8485 27wire 7 Bi‘ 8 Bi‘ No Pari‘y 0 0 Even Pari‘y 1 1 Odd Pari1y 0 1 1 smp bi‘ 0 1 2 mp bus “I 1 1 RSVZSZC, Brbn‘ No Pari‘y‘ 1 smp bi‘ 01001100 4C RSVZSZC, 77bi1‘ Even Pari‘y‘ 1 smp bi: 01111000 78 (a)
7: Setup Mode: Channel Configuration
xPico® Embedded Device Server User Guide 45
I/F (Interface) Mode
The Interface (I/F) Mode is a bit-coded byte entered in hexadecimal notation.
I/F Mode (4C) ? _
The following table displays available I/F Mode options:
Note: All bit positions in the table that are blank represent “don’t care” bits for that
particular option, which can be set to either a 0 or 1 value.
Table 7-1. Interface Mode Options
I/F Mode Option
7
6
5
4
3
2
1
0
RS-232C (1)
0
0
RS-422/485
0
1
RS-485 2-wire
1
1
7 Bit
1
0
8 Bit
1
1
No Parity
0
0
Even Parity
1
1
Odd Parity
0
1
1 stop bit
0
1
2 stop bits (1)
1
1
(1) 2 stop bits are implemented by the software. This might influence performance.
The following table demonstrates how to build some common Interface Mode settings:
Table 7-2. RS232 Interface Mode Settings
Common I/F Mode Setting
Binary
Hex
RS-232C, 8-bit, No Parity, 1 stop bit
0100 1100
4C
RS-232C, 7-bit, Even Parity, 1 stop bit
0111 1000
78
Flow
Flow control sets the local handshaking method for stopping serial input/output.
Flow (00) ? _
No flow comrol XON/XOFF flow comrol Hardware handshake wirh RTS/CTS lines XON/XOFF pass charamers m host 00 O1 02 05 Reserved (well known pons) 1 r 1 024 9999 1400044009 30704 30718 Telner serup Reserved for Redirecror Reserved (77F0h) Reserved (77FEh)
7: Setup Mode: Channel Configuration
xPico® Embedded Device Server User Guide 46
Use the following table to select flow control options:
Table 7-3. Flow Control Options
Flow Control Option
Hex
No flow control
00
XON/XOFF flow control
01
Hardware handshake with RTS/CTS lines
02
XON/XOFF pass characters to host
05
Port Number
The setting represents the source port number in TCP connections. It is the number that
identifies the channel for remote initiating connections.
Port No (10001) ? _
The default setting for Port 1 is 10001. The default setting for Port 2 is 10002. The range is
1-65535, except for the following reserved port numbers:
Table 7-4. Reserved Port Numbers
Port Numbers
Reserved for
1 – 1024
Reserved (well known ports)
9999
Telnet setup
14000-14009
Reserved for Redirector
30704
Reserved (77F0h)
30718
Reserved (77FEh)
WARNING: We recommend that you not use the reserved port numbers for this
setting as incorrect operation may result.
Use Port 0 for the outgoing local port to change with each connection. The port range is
50,000 to 59,999. Each subsequent connection increments the number by 1 (it wraps back
around to 50,000).
Only use this automatic port increment feature to initiate a connection using TCP. Set the port
to a non-zero value when the unit is in a passive mode or when using UDP instead of TCP.
Connect Mode
Connect Mode defines how the unit makes a connection, and how it reacts to incoming
connections over the network.
ConnectMode (C0) ? _
a) Incoming Connection Never accept incoming O O 0 Accept with active Modem Control In 0 1 0 Aiways Accept 1 1 0 b) Response Nothing (quiet) 0 Character response (C:connect, D:disconnect, c) Active Sta rtu p No active starlup With any character With active Modem Controi In oooo With a specific start character Manual connection oooooo Autostarl Hosii ist O O 1 0 d) Datag ram Type Directed UDP 1 1 O 0 e) Modem Mode No Echo Data Echo 8. Modern Response (Numeric) Data Echo 8. Modern Response (Verbose) oooo Modem Response Oniy (Numeric) Modem Response Oniy (Verbose) 0 0 1 1 1 0 Accept with active Modem Accepts externai connection requests only when the Modem
7: Setup Mode: Channel Configuration
xPico® Embedded Device Server User Guide 47
Enter Connect Mode options in hexadecimal notation.
Note: All bit positions in the table that are blank represent “don’t care” bits, for that
particular option, which can be set to either a 0 or 1 value.
Table 7-5. Connect Mode Options
Connect Mode Option
7
6
5
4
3
2
1
0
a) Incoming Connection
Never accept incoming
0
0
0
Accept with active Modem Control In
0
1
0
Always Accept
1
1
0
b) Response
Nothing (quiet)
0
Character response (C=connect, D=disconnect,
N=unreachable) 1
c) Active Startup
No active startup
0
0
0
0
With any character
0
0
0
1
With active Modem Control In
0
0
1
0
With a specific start character
0
0
1
1
Manual connection
0
1
0
0
Autostart
0
1
0
1
Hostlist
0
0
1
0
d) Datagram Type
Directed UDP
1
1
0
0
e) Modem Mode
No Echo
0
0
1
1
Data Echo & Modem Response (Numeric)
0
1
1
1
1
Data Echo & Modem Response (Verbose)
0
1
1
1
0
Modem Response Only (Numeric)
0
0
1
1
1
1
Modem Response Only (Verbose)
0
0
1
1
1
0
a) Incoming Connection
Never Accept Incoming Rejects all external connection attempts.
Accept with active Modem
Accepts external connection requests only when the Modem
Control In Control In \npul \s assened. Cannot be used wilh Modem (a)
7: Setup Mode: Channel Configuration
xPico® Embedded Device Server User Guide 48
Control In
Control In input is asserted. Cannot be used with Modem
Mode.
Always Accept Accepts any incoming connection when a connection is not
already established. Default setting.
b) Response
Character Response A single character is transmitted to the serial port when there is a
change in connection state:
C = connected, D = disconnected, N = host unreachable.
The IP address of the host connecting to the CoBos device will
be provided when you use verbose mode.
This option is overridden when the Active Start Modem Mode
or Active Start Host List is in effect. Default setting is Nothing
(quiet).
c) Active Startup
No Active Startup Does not attempt to initiate a connection under any
circumstance. Default setting.
With Any Character Attempts to connect when any character is received from the
serial port.
With active Modem Control
In
Attempts to connect when the Modem Control In input changes
from not asserted to asserted.
With a Specific Start
Character
Attempts to connect when it receives a specific start character
from the serial port. The default start character is carriage return.
If you enable ‘his op‘ion, me device server scro‘ls :hrough Ihe hos‘lis‘ unfil i‘ Connems m a device lis‘ed in me hos‘lis: :able. Once i: cannec‘s, me uni‘ smps :rying m connect m any omers. rs
7: Setup Mode: Channel Configuration
xPico® Embedded Device Server User Guide 49
Manual Connection Attempts to connect when directed by a command string
received from the serial port. The first character of the command
string must be a C (ASCII 0x43), and the last character must be
either a carriage return (ASCII 0x0D) or a line feed (0x0A). No
blanks or space characters may be in the command string.
Between the first and last command string characters must be a
full or partial destination IP address and may be a destination
port number.
The IP address must be in standard decimal-dot notation and
may be a partial address, representing the least significant 1, 2,
or 3 bytes of the remote IP address. The period is required
between each pair of IP address numbers.
If present, the port number must follow the IP address, must be
presented as a decimal number in the range 1-65535, and must
be preceded by a forward slash (ASCII 0x2F). The slash
separates the IP address and the port number. If you omit the
port number from a command string, the internally stored remote
port number starts a connection.
If a partial IP address is presented in a command string, it is
interpreted to be the least significant bytes of the IP address and
uses the internally stored remote IP address to provide the most
significant bytes of the IP address. If the IP address entered is
0.0.0.0/0, the device server enters Monitor Mode.
For example, if the remote IP address already configured in the
unit is 129.1.2.3, then an example command string would be
C3/7. (This would connect to 129.1.2.3 and port 7.) You may
also use a different ending for the connection string. For
example, C50.1/23 would connect you to 129.1.50.1 and port 23.
If an IP address does not follow the first command string
character (which is "C"), the subsequent character string is
interpreted as the host name and domain to be used in DNS
lookup. This character string can include a destination port
number as well. The port number can be preceded by either a
forward slash (/) or a colon ( : ).
Table 7-6. Manual Connection Address Example
Command String
Result if remote IP is 129.1.2.3 and remote port is 1234
C121.2.4.5/1 Complete override; connection is started with host 121.2.4.5,
port 1
C5 Connects to 129.1.2.5, port 1234
C28.10/12 Connects to 129.1.28.10, port 12
C0.0.0.0/0 Enters Monitor Mode
Cwww.lantronix.com/80 Tries to connect to the Lantronix web server if the
<hostname:domain> (www.lantronix.com) is configured in the
DNS server database.
Autostart (Automatic
Connection)
If you enable Autostart, the unit automatically connects to the
remote IP address and remote port specified when the firmware
starts.
Hostlist If you enable this option, the device server scrolls through the
hostlist until it connects to a device listed in the hostlist table.
Once it connects, the unit stops trying to connect to any others.
IHhis cannecfion fails, me uni: cominues Io scrou :hrough me rs
7: Setup Mode: Channel Configuration
xPico® Embedded Device Server User Guide 50
Command String
Result if remote IP is 129.1.2.3 and remote port is 1234
If this connection fails, the unit continues to scroll through the
table until it is able to connect to another IP in the hostlist.
Hostlist supports a minimum of 1 and a maximum of 12 entries.
Each entry contains the IP address and the port number.
The hostlist is disabled for Manual and Modem Modes. The unit
does not accept a data connection from a remote device when
the hostlist option is enabled.
Figure 7-2. Hostlist Option
Baudrate (9600) ?
I/F Mode (4C) ?
Flow (00) ?
Port No (10001) ?
ConnectMode (C0) ? 25
Send '+++' in Modem Mode (Y) ?
Show IP addr after 'RING' (Y) ?
Auto increment source port (N) ?
Hostlist :
01. IP : 172.019.205.011 Port : 00001
02. IP : 172.019.205.012 Port : 00002
03. IP : 172.019.205.013 Port : 00003
Change Hostlist ? (N) ?
Hostlist Retrycounter (3) ?
Hostlist Retrytimeout (250) ?
DisConnMode (00) ?
FlushMode (00) ?
DisConnTime (00:00) ?:
SendChar 1 (00) ?
SendChar 2 (00) ?
®
7: Setup Mode: Channel Configuration
xPico® Embedded Device Server User Guide 51
To enable the hostlist:
1. Enter a Connect Mode of 0x20 (2X), where X is any digit. The menu shows you a list of
current entries already defined in the product.
2. To delete, modify, or add an entry, select Yes. If you enter an IP address of 0.0.0.0, that
entry and all others after it are deleted.
3. After completing the hostlist, repeat the previous step if necessary to edit the hostlist
again.
4. For Retrycounter, enter the number of times the Lantronix unit should try to make a
good network connection to a hostlist entry that it has successfully ARPed. The range is
1-15, with the default set to 3.
5. For Retrytimeout, enter the number of seconds the unit should wait before failing an
attempted connection. The time is stored as units of milliseconds in the range of 10-
65535. The default is 250.
d) Datagram Type
Directed UDP When selecting this option, you are prompted for the Datagram type.
Enter 01 for directed or broadcast UDP. Datagrams of type 01 can be
sent as a broadcast by enabling the Send as Broadcast option. The
default is not to broadcast.
When the UDP option is in effect, the unit never attempts to initiate a
TCP connection because it uses UDP datagrams to send and receive
data.
e) Modem Mode
In Modem (Emulation) Mode, the unit presents a modem interface to the attached serial
device. It accepts AT-style modem commands and handles the modem signals correctly.
Normally, there is a modem connected to a local PC and a modem connected to a remote
machine. A user must dial from the local PC to the remote machine, accumulating phone
charges for each connection. Modem Mode allows you to replace modems with xPico
embedded device servers, and to use an Ethernet connection instead of a phone call. By not
having to change communications applications, you avoid potentially expensive phone calls.
To select Modem Mode, set the Connect Mode to C6 (no echo), D6 (echo with full verbose),
D7 (echo with numeric response), CF (modem responses only, numeric response), or CE
(modem responses only, full verbose).
Note: If the unit is in Modem Mode, and the serial port is idle, the unit can still accept
network TCP connections to the serial port if Connect Mode is set to C6 (no echo),
D6 (echo with full verbose), D7 (echo with numeric response, CF (modem responses
only, numeric response), or CE (modem responses only, full verbose).
Without Echo In Modem Mode, echo refers to the echo of all of the characters
entered in command mode; it does not mean to echo data that is
transferred. Quiet Mode (without echo) refers to the modem not
sending an answer to the commands received (or displaying what
was typed).
rs
7: Setup Mode: Channel Configuration
xPico® Embedded Device Server User Guide 52
Data Echo & Modem
Response
Full Verbose: The unit echoes modem commands and responds to a
command with a message string shown in the table below.
Numeric Response: The unit echoes modem commands and
responds to a command with a numeric response.
Modem Responses Only
Full Verbose
: The unit does not echo modem commands and
responds to a command with a message string shown in the table
below.
Numeric Response: The unit does not echo modem commands and
responds to a command with a numeric response.
Table 7-7. Modem Mode Messages
Message
Meaning
Full Verbose
OK Command was executed without error.
CONNECT A network connection has been established.
NO CARRIER A network connection has been closed.
RING n.n.n.n. A remote device, having IP address n.n.n.n, is connecting to this
device.
Numeric Response
0 OK
1 Connected
2 Ring
3 No Carrier
4 Error
Received commands must begin with the two-character sequence AT and be terminated with
a carriage return character.
The unit ignores any character sequence received not starting with AT, and only recognizes
and processes single AT-style commands. The unit treats compound AT commands as
unrecognized commands.
If the Full Verbose option is in effect, the unit responds to an unrecognized command string
that is otherwise formatted correctly (begins with AT and ends with carriage return) with the
"OK" message and takes no further action.
If the Numeric Response option is in effect, the unit responds to an unrecognized command
string that is otherwise formatted correctly with the "OK" message and takes no further action.
When an active connection is in effect, the unit transfers data and does not process
commands received from the serial interface.
When a connection is terminated or lost, the unit reverts to command mode.
When an active connection is in effect, the unit terminates the connection if it receives the
following sequence from the attached serial device:
Modem Mode Comma Funcuon ATDTx x.x.x‘pppp. ATH Hangs up Ine conneclron (Enlered as +++ATH) Enab‘es or drsab‘es conneclions from the network going «1 me serial Enab‘es or drsab‘es characler echo and responses. Enab‘es numerrc response or M verbose.
7: Setup Mode: Channel Configuration
xPico® Embedded Device Server User Guide 53
No serial data is received for one second.
The character sequence +++ is received, with no more than one second between each
two characters.
No serial data is received for one second after the last + character. At this time, the unit
responds affirmatively per the selected echo/response mode.
The character string ATH is received, terminated with a carriage return. The unit
responds affirmatively according to the selected echo/response mode and drops the
network connection. The serial interface reverts to accepting command strings.
If this sequence is not followed, the unit remains in data transfer mode.
Table 7-8. Modem Mode Commands
Modem Mode Command
Function
ATDTx.x.x.x,pppp,
ATDTx.x.x.x/pppp, or
ATDTx.x.x.x:pppp
Makes a connection to an IP address (x.x.x.x) and a remote port
number (pppp).
ATDTx.x.x.x
Makes a connection to an IP address (x.x.x.x) and the remote port
number defined within the unit.
ATD0.0.0.0
Forces the unit into Monitor Mode if a remote IP address and port
number are defined within the unit.
ATD or ATDT Forces the unit into Monitor Mode if a remote IP address and port
number are not defined within the unit.
ATDx.x.x.x
Makes a connection to an IP address (x.x.x.x) and the remote port
number defined within the unit.
ATH
Hangs up the connection (Entered as +++ATH ).
ATS0=n
Enables or disables connections from the network going to the serial
port.
n=0 disables the ability to make a connection from the network to the
serial port.
n=1-9 enables the ability to make a connection from the network to
the serial port.
n>1-9 is invalid.
ATEn
Enables or disables character echo and responses.
n=0 disables character echo and responses.
n=1 enables character echo and responses.
ATVn
Enables numeric response or full verbose.
n=0 enables numeric response.
n=1 enables full verbose.
Note: The unit recognizes these AT commands as single commands such as ATE0
or ATV1; it does not recognize compound commands such as ATE0V.
7: Setup Mode: Channel Configuration
xPico® Embedded Device Server User Guide 54
Send the Escape Sequence (+++) in Modem Mode
Send ‘+++’ in Modem Mode (Y) ? _
Disable or enable the xPico embedded device server’s ability to send the escape sequence.
The default is Y (Yes) (send the escape sequence).
Show IP addr after 'RING'
Show IP addr after 'RING' (Y)
Disable or enable the xPico embedded device server's ability to show the IP address after
RING in Modem Mode. The default is Y (Yes), to show the IP address.
Auto Increment Source Port
Auto increment source port (N) ? _
Y (Yes) auto increment the source port. The xPico embedded device server increments the
port number used with each new connection.
Remote IP Address
This is the destination IP address used with an outgoing connection.
Remote IP Address : (000) (000) (000) (000)_
Note: This option does not display when Hostlist is enabled from the ConnectMode
prompt (see Connect Mode on page 46 for more information).
Remote Port
You must set the remote TCP port number for the unit to make outgoing connections. This
parameter defines the port number on the target host to which a connection is attempted.
Remote Port (0) ? _
To connect an ASCII terminal to a host using the unit for login purposes, use the remote port
number 23 (Internet standard port number for Telnet services).
Note: This option does not display when Hostlist is enabled from the ConnectMode
prompt (see Connect Mode on page 46 for more information).
(a)
7: Setup Mode: Channel Configuration
xPico® Embedded Device Server User Guide 55
DisConnMode
This setting determines the conditions under which the unit will cause a network connection
to terminate.
DisConnMode (00) ? _
Notes:
In DisConnMode (Disconnect Mode), Modem Control In drop either drops the connection
or is ignored.
All bit positions in the table that are blank represent “don’t care” bits, for that particular
option, which can be set to either a 0 or 1 value.
Table 7-9. Disconnect Mode Options
Disconnect Mode Option
7
6
5
4
3
2
1
0
Disconnect when Modem Control In is not asserted
(6)
1
Ignore Modem Control In
0
Telnet Com Port Cntrl and terminal type setup
(1)
1
Channel (port) password
(2)
1
Hard disconnect
(3)
0
Disable hard disconnect
1
State LED off with connection
(4)
1
Disconnect with EOT (^D)
(5)
1
(1) The Telnet Com Port Control feature is used in conjunction with Com Port Redirector. The unit
sends the Terminal Type upon an outgoing connection.
(2) A password is required for a connection to the serial port from the network.
(3) The TCP connection closes even if the remote site does not acknowledge the disconnection.
(4) When there is a network connection to or from the serial port, the state LED turns off instead of
blinking.
(5) When Ctrl+D or Hex 04 is detected, the connection is dropped. Both Telnet Com Port Cntrl and
Disconnect with EOT must be enabled for Disconnect with EOT to function properly. Ctrl+D is only
detected going from the serial port to the network.
(6) When Modem Control In transitions from a high state to a low state, the network connection to or
from the serial port drops.
rs
7: Setup Mode: Channel Configuration
xPico® Embedded Device Server User Guide 56
Flush Mode (Buffer Flushing)
Using this parameter, you can control line handling and network buffers with connection
startup and disconnect.
FlushMode (00) ? _
You can also select between two different packing algorithms.
Note: All bit positions in the table that are blank represent “don’t care” bits, for that
particular option, which can be set to either a 0 or 1 value.
Table 7-10. Flush Mode Options
Function
7
6
5
4
3
2
1
0
Input Buffer (Serial to Network)
Clear with a connection initiated from the device to the network
1
Clear with a connection initiated from the network to the device
1
Clear when the network connection to or from the device is disconnected
1
Output Buffer (Network to Serial)
Clear with a connection initiated from the device to the network
1
Clear with a connection initiated from the network to the device
1
Clear when the network connection to or from the device is disconnected
1
Alternate Packing Algorithm (Pack Control)
Enable
1
Pack Control
The packing algorithms define how and when packets are sent to the network. The standard
algorithm is optimized for applications in which the unit is used in a local environment,
allowing for very small delays for single characters, while keeping the packet count low. The
alternate packing algorithm minimizes the packet count on the network and is especially
useful in applications in a routed Wide Area Network (WAN). Adjusting parameters in this
mode can economize the network data stream.
Pack control settings are enabled in Flush Mode. Set this value to 00 if you do not need
specific functions.
Note: All bit positions in the table that are blank represent “don’t care” bits, for that
particular option, which can be set to either a 0 or 1 value.
Table 7-11. Pack Control Options
Option
7
6
5
4
3
2
1
0
Packing Interval
Trailing Characters
7: Setup Mode: Channel Configuration
xPico® Embedded Device Server User Guide 57
Option
7
6
5
4
3
2
1
0
Interval: 12ms
0
0
Interval: 52ms
0
1
Interval: 250ms
1
0
Interval: 5sec
1
1
Trailing Characters
None
0
0
One
0
1
Two
1
0
Send Characters
2-Byte Send Character Sequence
1
Send Immediately After Send chars
1
Packing Interval
Packing Interval defines how long the unit should wait before sending accumulated
characters. This wait period is between successive network segments containing data. For
alternate packing, the default interval is 12 ms.
Trailing Characters
In some applications, CRC, Checksum, or other trailing characters follow the end-of-
sequence character; this option helps to adapt frame transmission to the frame boundary.
Send Characters
If 2-Byte Send Character Sequence is enabled, the unit interprets the sendchars as a 2-
byte sequence; if this option is not enabled, the unit interprets them independently.
If Send Immediately After Characters is not set, any characters already in the serial
buffer are included in the transmission after a "transmit" condition is found. If this option is
set, the unit sends immediately after recognizing the transmit condition (sendchar or
timeout).
Note: A transmission might occur if status information needs to be exchanged or an
acknowledgment needs to be sent.
DisConnTime (Inactivity Timeout)
Use this parameter to set an inactivity timeout. The unit drops the TCP connection to the local
port if there is no activity on the serial line before the set time expires. Enter time in the format
mm:ss, where m is the number of minutes and s is the number of seconds.
DisConnTime (00:00) ?:
7: Setup Mode: Channel Configuration
xPico® Embedded Device Server User Guide 58
To disable the inactivity timeout, enter 00:00. Range is 0 (disabled) to 5999 seconds (99
minutes, 59 seconds). Default is 0.
Send Characters
Enter up to two characters in hexadecimal representation in sendchar.
SendChar 1 ( 0) ? _
SendChar 2 ( 0) ? _
If the unit receives a character on the serial line that matches one of these characters, it
sends the character immediately, along with any awaiting characters, to the TCP connection.
This action minimizes the response time for specific protocol characters on the serial line (for
example, ETX, EOT). Setting the first sendchar to 00 disables the recognition of the
characters. Alternatively, the unit can interpret two characters as a sequence (see Pack
Control on page 56).
Telnet Terminal Type
This parameter displays only if you enabled the terminal type option in Disconnect Mode.
With this option enabled, you can use the terminal name for the Telnet terminal type. Enter
only one name.
With terminal type option enabled, the unit also reacts to the EOR (end of record) and binary
options, useful for applications like terminal emulation to IBM hosts.
Channel (Port) Password
This parameter appears only if the channel (port) password option is enabled in Disconnect
Mode. With this option enabled, you can set a password on the serial port.
CAUTION:
xPico® Embedded Device Server User Guide 59
8. Setup Mode: Advanced Settings
Expert Settings (Option 5)
Note: You can change the Enable alternate MAC setting using telnet or serial
connections only. It is not available through the Web Manager.
CAUTION: Only an expert should change these parameters. You must definitely
know the consequences the changes might have.
Figure 8-1. Expert Settings
TCP Keepalive time in s (1s - 65s; 0s=disable): (45) ?
ARP Cache timeout in s (0s - 600s) : (600) ?
CPU performance (0=Regular, 1=Low, 2=High): (0) ?
Disable Monitor Mode @ bootup (N) ?
HTTP Port Number : (80) ?
MTU Size (512 - 1400): (1400) ?
TCP Re-transmission Timeout (500 - 4000) (ms): (500) ?
Enable alternate MAC (N) ?
Ethernet connection type: (0) ?
The default settings are listed below:
TCP Keepalive time in s
(1s – 65s; 0s=disable)
45
ARP Cache timeout in s
(0s – 600s; 0s=disable)
600
CPU Performance Regular
Disable Monitor Mode @ bootup No
HTTP Port Number
(1-65535)
80
MTU Size (512 – 1400) 0 (resulting in an operational value of 1400)
TCP Re-transmission Timeout 0 (resulting in an operational value of 500)
Enable alternate MAC No (OEM use only)
Ethernet connection type 0 (resulting in auto-negotiation)
8: Setup Mode: Advanced Settings
xPico® Embedded Device Server User Guide 60
TCP Keepalive time in seconds
This option allows you to change how many seconds the unit waits during a silent connection
before attempting to see if the currently connected network device is still on the network. If
the unit gets no response, it drops that connection.
TCP Keepalive time in s (1s – 65s; 0s=disable): (45)? _
ARP Cache timeout in seconds
Whenever the unit communicates with another device on the network, it adds an entry into its
ARP table. The ARP Cache timeout option allows you to define how many seconds (1-600)
the unit will wait before timing out this table. Entering 0 disables this feature.
ARP Cache timeout in s (0s - 600s) : (600) ?
CPU Performance
This option allows you to increase the CPU performance required to use the higher baud
rates on the serial interface (460800 bps and 921600 bps). The standard CPU performance
mode supports up to 230400 bps.
CPU performance (0=Regular, 1=Low, 2=High): (0) ?
Notes:
If a baud rate of 460 Kbps or 920 Kbps is set and the high performance mode is disabled,
the operation of the serial channel would be out of the specified error tolerance, thereby
leading to inconsistent speed settings on the two ends of the serial channel.
Increasing CPU clock speed consumes more power and generates more heat. This
reduces the maximum operating temperature specification. See the appropriate product
brief for details.
Disable Monitor Mode at bootup
This option allows you to disable all entries into Monitor Mode during startup, except for the
‘xxx’ sequence. This prevents entry using yyy, zzz, xx1, and yy1 key sequences (only during
the bootup sequence). The default for Monitor Mode at bootup is N (No). (See Chapter 11:
Monitor Mode.)
Disable Monitor Mode @ bootup (N) ? _
HTTP Port Number
This option allows the configuration of the web server port number. The valid range is 1-
65535. The default HTTP port number is 80.
HTTP Port Number : (80) ? _
CAUTION (a)
8: Setup Mode: Advanced Settings
xPico® Embedded Device Server User Guide 61
MTU Size
The Maximum Transmission Unit (MTU) is the largest physical packet size a network can
transmit for TCP and UDP. Enter between 512 and 1400 bytes. The default is 1400 bytes.
MTU Size: (1400) ? _
TCP Re-Transmission Timeout
The TCP Re-Transmission Timeout is the interval to wait for acknowledgement of transmitted
TCP segments before re-transmitting them. Enter between 500 and 4000 ms. The default is
500 ms.
TCP Re-transmission Timeout (500 - 4000) (ms): (500) ?
Enable alternate MAC
If necessary, enable the alternate MAC address (if specified in the OEM setup record).
Enable alternate MAC (N) ? _
Ethernet Connection Type
The xPico embedded device server allows for the Ethernet speed and duplex to be manually
configured. Enter 0 for auto-negotiation (default). To select the speed and duplex, enter one
of the following: 2 (10 MB/half duplex), 3 (10 MB/full duplex), 4 (100 MB/half duplex), or 5
(100 MB/full duplex).
Ethernet connection type: (0) ? _
Security Settings (Option 6)
Note: You can change security settings by means of Telnet or serial connections
only, not on the Web Manager. We recommend that you set security over the
dedicated network or over the serial setup to prevent eavesdropping.
CAUTION: Disabling both Telnet Setup and Port 77FE will prevent users from
accessing the setup menu from the network. Disabling Port 77FE also disables
the Web from configuring the device.
Select 7 to configure security settings.
Figure 8-2. Security Settings
Disable SNMP (N) ?
SNMP Community Name (public):
(a)
8: Setup Mode: Advanced Settings
xPico® Embedded Device Server User Guide 62
Disable Telnet Setup (N) ?
Disable TFTP Firmware Update (N) ?
Disable Port 77FEh (N) ?
77FEh Access Mode (0=Read & Write, 1=Read Only): (0) ? _
Disable Web Server (N) ?
Disable Web Setup (N) ?
Disable ECHO ports (Y) ?
Enable Encryption (N) ?
Enable Enhanced Password (N) ?
Disable Port 77F0h (N) ?
Disable SNMP
This setting allows you to disable the SNMP protocol on the unit for security reasons.
Disable SNMP (N) ? _
SNMP Community Name
The SNMP Community Name is a required field for NMS to read or write to a device. Enter a
string of 1 to 13 characters.
SNMP Community Name (public): _
The default entry is public. The current value is displayed in parentheses.
Disable Telnet Setup
Note: If you choose to disable this option, keep in mind that disabling both Telnet
Setup and Port 77FE will prevent users from accessing the setup menu from the
network.
This setting defaults to the N (No) option. The Y (Yes) option disables access to Setup Mode
by Telnet (port 9999). It only allows access locally using the web pages and the serial port of
the unit.
Disable Telnet Setup (N) ? _
(a)
8: Setup Mode: Advanced Settings
xPico® Embedded Device Server User Guide 63
Disable TFTP Firmware Upgrade
This setting defaults to the N (No) option. The Y (Yes) option disables the use of TFTP to
perform network firmware upgrades. With this option, you can download firmware upgrades
over the serial port using DeviceInstaller’s Recover Firmware procedure. (See Chapter 10:
Firmware Upgrades.)
Disable TFTP Firmware Update (N) : _
Disable Port 77FE (Hex)
Note: If you choose to disable this option, keep in mind that disabling both Telnet
Setup and Port 77FE will prevent users from accessing the setup menu from the
network.
Port 77FE is a setting that allows DeviceInstaller, Web Manager, and custom programs to
configure the unit remotely. You may wish to disable this capability for security purposes.
Disable Port 77FEh (N) ? _
The default setting is the N (No) option, which enables remote configuration. You can
configure the unit by using DeviceInstaller, web pages, Telnet, or serial configuration.
The Y (Yes) option disables remote configuration and web sites.
Note: The Y (Yes) option disables many of the GUI tools for configuring the unit,
including the embedded Web Manager tool.
77FEh Access Mode
Configuring this setting is available if port 77FE is enabled. This option will not be listed if
port 77FE is disabled.
Set 0 for Read & Write mode, and 1 for Read Only mode. Default value of this setting is
Read-Write(0).
If access mode is Read-only, then read operation can be done through port 77FE, if Read-
Write access is selected, then both read and write of data can be done through port 77FE.
77FEh Access Mode (0=Read & Write, 1=Read Only): (0) ? _
Disable Web Server
This setting defaults to the N (option). The Y (Yes) option disables the web server.
Disable Web Server (N) ? _
Disable Web Setup
The Y (Yes) option disables configuration using the Web Manager. This setting defaults to
the N (option).
Enable Encryptlan (N) Y Key length in Inca can: 123 Change Keys (N) Y Enter Keys: fit_fif.«k4£f_fit_xk_£f_ttAxfi_#f_t34tfi_fix_xfi_tfi_fif
8: Setup Mode: Advanced Settings
xPico® Embedded Device Server User Guide 64
Disable Web Setup (N) ? _
Disable ECHO Ports
This setting controls whether port 7 echoes characters it receives.
Disable ECHO ports (Y) ? _
Enable Encryption
Rijndael is the block cipher algorithm chosen by the National Institute of Science and
Technology (NIST) as the Advanced Encryption Standard (AES) to be used by the US
government. The xPico embedded device server supports 128-, 192-, and 256-bit encryption
key lengths.
Note: Configuring encryption should be done through a local connection to the serial
port of the xPico embedded device server, or via a secured network connection.
Initial configuration information, including the encryption key, is sent in clear text over
the network.
To configure AES encryption on the xPico embedded device server:
1. When prompted to enable encryption, select Y.
2. When prompted, enter the encryption key length. The xPico embedded device server
supports 128-, 192-, and 256-bit encryption key lengths.
3. When prompted to change keys, select Y.
4. At the Enter Keys prompt, enter your encryption key. The encryption keys are entered in
hexadecimal. The hexadecimal values are echoed as asterisks to prevent onlookers from
seeing the key. Hexadecimal values are 0-9 and A-F.
For a 128-bit key length, enter 32 hexadecimal characters.
For a 192-bit key length, enter 48 hexadecimal characters.
For a 256-bit key length, enter 64 hexadecimal characters
5. Continue pressing Enter until you return to the Change Setup menu.
6. From the Change Setup menu, select option 9 to save and exit.
Encryption only applies to the port selected for data tunneling (default 10001 for Channel 1
and 10002 for Channel 2), regardless of whether you are using TCP or UDP.
Secure Com Pon Redrrecmr provides an encrypted connec based applrcations to the xPico embedded devrce server. | www.Iantronxx.com/device-networkrng/utilities-tools/scgr Note: wwaantronix. com/dewoe-networking/utihties-tools na ®
8: Setup Mode: Advanced Settings
xPico® Embedded Device Server User Guide 65
Generally, one of these situations applies:
Encrypted xPico-to-xPico embedded device server communication. Be sure to
configure both modules with the same encryption key.
Third-party application to xPico embedded device server-encrypted communication:
xPico embedded device server uses standard AES encryption protocols. To
communicate successfully, products and applications on the peer side must use the
same protocols and the same encryption key as the xPico embedded device server.
Lantronix Secure Com Port Redirector provides an encrypted connection from
Windows-based applications to the xPico embedded device server. Information about
SCPR is at www.lantronix.com/device-networking/utilities-tools/scpr
A 30-day trial version of SCPR is available.
Note: Developers can license the Lantronix Encryption Library Suite. See
www.lantronix.com/device-networking/utilities-tools.
Enable Enhanced Password
The Enhanced Password setting allows you to set a password of up to 16 characters for
protecting Telnet and Web Page access. We recommend that you select the Y (Yes) option
and enable the enhanced password setting.
Avoid using either the 4 character basic password setting or no password at all as they are
not secure options.
Enable Enhanced Password (Y) ? _
Disable Port 77F0 (Hex)
Port 77F0 is a setting that allows a custom application to query or set the eight xPico
embedded device server configurable pins when they are functioning as general purpose I/O
(GPIO). You may want to disable this capability for security purposes. The default setting is
the N (No) option, which enables GPIO control. The Y (Yes) option disables the GPIO control
interface.
Disable Port 77F0h ? _
Default Settings (Option 7)
Select 7 to reset the unit’s Channel 1 and Channel 2 configuration and expert settings to the
default settings. The server configuration settings for IP address, gateway IP address, and
netmask remain unchanged. The configurable pins’ settings also remain unchanged. The
specific settings that this option changes are listed below:
Channel 1 and Channel 2 Configuration Defaults
Baudrate 9600
8: Setup Mode: Advanced Settings
xPico® Embedded Device Server User Guide 66
I/F Mode 4C (1 stop bit, no parity, 8 bit, RS-232C)
Flow
00
Note: Flow control option only available for
Channel 1 configuration.
Port number 10001 for Channel 1
10002 for Channel 2
Connect Mode C0 (always accept incoming connection; no active
connection startup)
Send '+++' in Modem Mode Enabled
Show IP addr after 'RING' Enabled
Auto increment source port Disable
Hostlist retry counter 3
Hostlist retry timeout
250 (msec)
Start character for serial channel 1 (or
channel 2)
0x0D (CR)
All other parameters 0
Expert Settings Defaults
TCP Keepalive time in s
45
ARP Cache timeout in s 600
CPU Performance 0 (Regular)
Monitor Mode @ bootup
Enabled
HTTP Port Number
(1-65535)
80
MTU Size (512 – 1400) 0 (resulting in an operational value of 1400)
TCP Re-transmission timeout (ms) 500 (msec)
Alternate MAC
Disabled (for OEM use only)
Ethernet Connection Type 0 (auto-negotiate)
Security Settings Defaults
Disable SNMP No
SNMP community name public
Disable Telnet setup No
Disable TFTP Firmware Update No
(a)
8: Setup Mode: Advanced Settings
xPico® Embedded Device Server User Guide 67
Disable Port 77FEh No
77FEh Access Mode
0 (Read & Write)
Disable Web Server No
Disable Web Setup No
Disable ECHO ports
Yes
Enable Encryption
No
Enable Enhanced Password No
Disable Port 77F0h No
xPico® Embedded Device Server User Guide 68
9. GPIO Interface
Configurable Pins
The xPico embedded device server has eight pins (CP1-8) that you can configure for General
Purpose I/O (GPIO).
Note: You can also configure the pins for serial port control lines, such as hardware
control, modem control (CTS, RTS, DTR, and DCD), and diagnostic outputs to LED,
using DeviceInstaller.
You can use these GPIO pins to control devices such as relays, servers, lights, monitor
switches, sensors, and even processes such as data transfer.
You can set the functions for the eight pins independently and in any combination. The initial
directions (input/output) and active levels (active low or high) at boot up can also be
configured through 77FE, for example, by using DeviceInstaller.
This chapter describes how the directions, active levels, and states can be dynamically
controlled and probed through special port 77F0.
The configurable pins default configuration is:
Function: General Purpose Input
Active Level: Active Low
Features
TCP and UDP can be used.
The protocol supports up to 32 GPIO for future products.
Function configuration can be retrieved.
Input or output selection can be retrieved and controlled.
Active low or high selection can be retrieved and controlled.
Active or inactive selection can be retrieved and controlled.
77F0 can be disabled.
Every change of state (active/inactive) requires a command over TCP or UDP, and thus is
not very fast. If you use this port for data transfer, the throughput is low, usually up to 1 Kbps.
Command Parameter 1 Parame‘erz O 1 2 3 4 S 6 Command Parame‘er 1 0 1 2 3 4 (a?
9: GPIO Interface
xPico® Embedded Device Server User Guide 69
Control Protocol
The GPIO control protocol is a simple, proprietary protocol.
Guidelines
The GPIO control protocol is described from the PC side. Send means from PC to xPico
embedded device server. Response comes from xPico embedded device server to PC.
The protocol allows for control of up to 32 GPIOs. How many are actually available depends
on the product. xPico embedded device server has only eight.
The parameters are four bytes long and represent GPIOs 0-31, with GPIO0 in bit 0 of the first
byte (Little Endian). Parameter bits for configurable pins not configured as GPIOs are
undefined for Get commands and ignored on Set commands.
Every command consists of nine bytes: one command type of one byte and two parameters
of four bytes each.
Command
Parameter 1
Parameter 2
0
1
2
3
4
5
6
7
8
On some commands, one or all parameters are ignored.
For UDP, command type and parameters need to be in the same datagram.
Responses to valid commands are always five bytes long, consisting of the returned
command byte and as parameters in the current or updated values. In case of an invalid
command, only one byte with value 0FFh is returned.
Command
Parameter 1
0
1
2
3
4
When sending a command (TCP and UDP), wait for the response before sending the next
command.
Commands
Byte 0 Command Types
10h Get functions
11h Get directions (input or output)
12h
Get active levels
(high active or low active)
13h Get current states (active or not active)
19h Set directions
1Ah Set active levels
1Bh Set current states
9: GPIO Interface
xPico® Embedded Device Server User Guide 70
There is no Set functions command. Since the pin’s function depends on the hardware in
which the xPico embedded device server is embedded, that configuration is only allowed
using 77FE. Settings changed by any of the Set commands are not stored and are lost when
the unit is powered down or rebooted.
Command 10h, Get Functions
Send:
No parameters
Response:
1 parameter
Bytes 1-4: Functions
Bit X 1 means general purpose I/O available to the user.
0 means dedicated function (e.g., serial flow control, diagnostics) for
configurable pin X.
Command 11h, Get Directions
Send:
No parameters
Response:
1 parameter
Bytes 1-4: Directions
Bit X 1 means GPIO X is an output.
0 means it is an input.
Command 12h, Get Active Levels
Send:
No parameters
Response:
1 parameter
Bytes 1-4: Active levels
Bit X 1 means GPIO X is active low (0V when active, 3.3V when inactive).
0 means it is active high (3.3V when active, 0V when inactive).
Command 13h, Get Current States
Send:
No parameters
Response:
1 parameter
Bytes 1-4: States
Bit X 1 means GPIO X is active
0 means it is inactive.
9: GPIO Interface
xPico® Embedded Device Server User Guide 71
Command 19h, Set Directions
Send:
2 parameters
Bytes 1-4: Mask
Bit X 1 means the direction for GPIO X will be updated with the value in the
second parameter.
0 means the direction for that GPIO will not change.
Bytes 5-8: New Directions
Bit X 1 means GPIO X will become an output.
0 means it will become an input.
Response:
1 parameter
Bytes 1-4: The updated directions
Command 1Ah, Set Active Levels
Send:
2 parameters
Bytes 1-4: Mask
Bit X 1 means the direction for GPIO X will be updated with the value in the
second parameter.
0 means the active type for that GPIO will not change.
Bytes 5-8: New Active Levels
Bit X 1 means GPIO X will become active low.
0 means it will become active high.
Response:
1 parameter
Bytes 1-4: Updated active levels
Command 1Bh, Set States
Send:
2 parameters
Bytes 1-4: Mask
Bit X 1 means the state for GPIO X will be updated with the value in the
second parameter.
0 means the state for that GPIO will not change.
Bytes 5-8: New States
Bit X 1 means GPIO X will become active.
0 means it will become inactive.
Response:
1 parameter
Bytes 1-4: Updated states
9: GPIO Interface
xPico® Embedded Device Server User Guide 72
Examples
Example 1: PC sends command 10h to find out which configurable pins are available
as GPIO.
PC -> xPico: 10h, 00h, 00h, 00h, 00h, 00h, 00h, 00h, 00h
xPico -> PC: 10h, 03h, 00h, 00h, 00h
Command details:
10h = command 10h
00h, 00h, 00h, 00h = ignored
00h, 00h, 00h, 00h = ignored
Response details:
10h = response to command 10h
03h, 00h, 00h, 00h =
bits 0 and 1 are 1 →CP1 and CP2 are configured as GPIOs.
bit 2 is 0 → CP3 is configured as either serial control or diagnostics.
The other bits are ignored because there are only eight configurable pins on
the xPico.
Example 2: PC sends command 1Bh to change the current states of GPIO 0 and 1.
PC -> xPico: 1Bh, 01h, 00h, 00h, 00h, 00h, 00h, 00h, 00h
xPico -> PC: 1Bh, 05h, 00h, 00h, 00h
Command details:
1Bh = command 1Bh
01h, 00h, 00h, 00h = the mask that determines which GPIOs will be changed.
bit 0 is 1 → GPIO0 will be changed.
bit 1 is 0 → GPIO1 will remain the same.
00h, 00h, 00h, 00h = the new states
bit 0 is 0 → GPIO0 will become 0.
bit 1 is ignored since it is masked out.
Response details:
1Bh = response to command 1Bh
05h, 00h, 00h, 00h =
bit 0 is 1 → GPIO0 = 1
bit 1 is 0 → GPIO1 = 0
bit 2 is 1 → GPIO2 = 1
The other bits are ignored because there are only eight configurable pins on
the xPico.
You can obtain me most up-lo—da‘e firmware and web site (www.Iantronix.com[suQQortzdownloads fngantronixcom/gub)
xPico® Embedded Device Server User Guide 73
10. Firmware Upgrades
Obtaining Firmware
You can obtain the most up-to-date firmware and release notes for the unit from the Lantronix
web site (www.lantronix.com/support/downloads) or by using anonymous FTP
(ftp.lantronix.com/pub).
Reloading Firmware
There are several ways to update the unit's internal operational code (*.ROM): using
DeviceInstaller (the preferred way), using TFTP, or using the serial port. You can also update
the unit's internal Web interface (*.COB) using TFTP or DeviceInstaller.
Here are typical names for those files. Check the Lantronix web site for the latest versions
and release notes.
Table 10-1. Firmware Files
ROM File COB
xpico_6800.rom xpico_webm_1900.cob
Please refer to the DeviceInstaller online Help for information about reloading firmware using
DeviceInstaller. The other methods are discussed below.
Using TFTP: Graphical User Interface
To download new firmware from a computer:
1. Use a TFTP client to put a binary file to the unit (*.ROM to upgrade the unit's internal
operational code and *.COB to upgrade its internal web interface).
Note: TFTP requires the .rom (binary) version of the unit's internal operational code.
2. In the Host field, enter the IP address of the unit being upgraded.
3. In the Port field, enter 69.
4. Enter the full path of the firmware file in the Local File field.
5. In the Remote File field, enter the current internal operational code or WEB1 to WEB6
for the internal web interface.
CunanlDlrechly [W Browse Sewuineuace [m Shaw Du Tm: Suva! le Elem | DHEP :elvell Syxlng sewn] Lug vim] Has: [m Pul— LocalFie W3 4 Hemleib >
10: Firmware Upgrades
xPico® Embedded Device Server User Guide 74
Figure 10-1. TFTP Window
6. Click the Put button to transfer the file to the unit. The unit performs a power reset after
the firmware has been loaded and stored.
After the firmware has been loaded and stored, which takes approximately 8 seconds to
complete, the unit performs a power reset.
Using TFTP: Command Line Interface
To download new firmware from a computer:
1. Enter the following from a TFTP command line interface:
tftp –i <ip address> put <local filename> <destination file name>
The following examples demonstrate the TFTP command sequence to download the .rom file
and the .cob file:
tftp –i 192.168.1.111 put xpico_6800 X6
tftp –i 192.168.1.111 put xpico_webm_1900.cob WEB1
10: Firmware Upgrades
xPico® Embedded Device Server User Guide 75
Recovering the Firmware Using the Serial Port and DeviceInstaller
If for some reason the firmware is damaged, you can recover the firmware file by using
DeviceInstaller to download the *.ROM file over the serial port.
To recover firmware:
1. Start the DeviceInstaller® application. If your PC has more than one network adapter, a
message displays. Select an adapter and click OK.
2. From the Tools menu, select Advanced/Recover Firmware. The Serial Port Firmware
Upgrade window displays.
3. For Port on PC, enter the COM port on the PC that is connected to the serial port of the
Lantronix unit.
4. For Device Model, be sure the appropriate xPico module is shown (xPico).
5. For Firmware File, click the Browse button and go to the location where the firmware file
resides.
Note: Make sure the xPico embedded device server on which you are recovering
firmware is connected to this selected port on your PC.
6. Click OK to download the file.
7. When prompted, reset the device. Status messages and a progress bar at the bottom of
the screen show the progress of the file transfer. When the file transfer completes, the
message “Successful, Click OK to Close” appears.
8. Click the OK button to complete this procedure.
Note For more information, see Recovering Firmware in the DeviceInstaller online
Help.
xPico® Embedded Device Server User Guide 76
11. Monitor Mode
Monitor Mode is a command-line interface used for diagnostic purposes. There are two ways
to enter Monitor Mode: locally using the serial port or remotely using the network.
Entering Monitor Mode Using the Serial Port
To enter Monitor Mode locally:
1. Follow the same steps used for setting the serial configuration parameters
(see Serial Port on page 39).
2. Instead of typing three x keys, however:
3. Type zzz (or xx1) to enter Monitor Mode with network connections.
4. Type yyy (or yy1) to enter Monitor Mode without network connections.
A 0> prompt indicates that you have successfully entered Monitor Mode.
Entering Monitor Mode Using the Network Port
To enter Monitor Mode using a Telnet connection:
1. Establish a Telnet session to the configuration port (9999). The following appears:
MAC address 0080A366000E
Software version V6.8.0.0RC4 (120327) XPICO
AES library version 1.8.2.1
Press Enter for Setup Mode
2. Type M (upper case).
A 0> prompt indicates that you have successfully entered Monitor Mode.
Monitor Mode Commands
The following commands are available in Monitor Mode. Many commands have an IP
address as an optional parameter (xxx.xxx.xxx.xxx). If you enter the IP address, the
command is applied to another unit with that IP address. If you do not enter the IP address,
the command is executed locally.
Note: All commands must be in capital letters. Responses to some of the commands
are in Intel Hex format.
rs
11: Monitor Mode
xPico® Embedded Device Server User Guide 77
Table 11-1. Monitor Mode Commands
Command
Command Name
Function
VS x.x.x.x Version Queries software header record (16 bytes) of unit
with IP address x.x.x.x.
GC x.x.x.x Get Configuration Gets configuration of unit with IP address x.x.x.x as
hex records (120 bytes).
SC x.x.x.x Send Configuration Sets configuration of unit with IP address x.x.x.x
from hex records.
PI x.x.x.x Ping Pings unit with IP address x.x.x.x to check device
status.
AT ARP Table Shows the unit’s ARP table entries.
TT TCP Connection
Table
Shows all incoming and outgoing TCP connections.
NC Network Connection Shows the unit’s IP address, gateway, subnet
mask, and DNS server.
RS Reset Resets the unit’s power.
QU Quit Exits diagnostics mode.
G0, G1, ....,Ge, Gf Get configuration
from memory page
Gets a memory page of configuration information
from the device.
S0, S1,...,Se, Sf Set configuration to
memory page
Sets a memory page of configuration information
on the device.
GM Get MAC address Shows the unit's 6-byte MAC address.
SS Set Security record Sets the Security record without the encryption key
and length parameters. The entire record must still
be written, but the encryption-specific bytes do not
need to be provided (they can be null since they
are not overwritten).
SA Scan Initiates a wireless scan if the wireless interface is
enabled. Reports any stations found, including
BSSID, SSID, and RSSI. If SA is followed by a
string, the string is used to filter SSIDs before
reporting. If the BSS does not broadcast its SSID,
only the BSSID and RSSI are returned.
NS Network Status Reports the network interfaces’ statuses. Includes
potentially negotiated parameters like speed/duplex
for Ethernet or BSSID, encryption, authentication
for wireless interfaces.
co Set IP address,
hostbits, gateway ,
and DNS server IP
Example:
co 192.168.0.10 8 192.168.0.1 10001 192.168.1.10
with
192.168.0.10 = IP address of the xPico
8 = number of hostbits
serve se n UK
11: Monitor Mode
xPico® Embedded Device Server User Guide 78
Command
Command Name
Function
192.168.0.1 = gateway IP address
10001 = port number of the xPico Channel 1
192.168.1.10 = IP address of the DNS Server
The xPico embedded device server stores the
setup and performs a reset. It sends an X before
the reset if the command was
OK
.
VN Query full firmware
version
This command queries and displays full firmware
version in readable string format.
WC Flash write count This command shows serial flash write counts,
valid on serial flash products.
Note: Entering any of the commands listed above generates one of the following
command response codes:
Table 11-2. Command Response Codes
Response
Meaning
0> OK; no error
1> No answer from remote device
2> Cannot reach remote device or no answer
8> Wrong parameter(s)
9> Invalid command
rs
xPico® Embedded Device Server User Guide 79
12. Troubleshooting
This chapter discusses how you can diagnose and fix errors quickly without having to contact
a dealer or Lantronix. It helps to connect a terminal to the serial port while diagnosing an
error to view summary messages that may display. When troubleshooting, always ensure
that the physical connections (power cable, network cable, and serial cable) are secure.
Note: Some unexplained errors might be caused by duplicate IP addresses on the
network. Make sure that your unit's IP address is unique.
When troubleshooting the following problems, make sure that the xPico embedded device
server is powered up. Confirm that you are using a good network connection.
Problems and Error Messages
Problem/Message Reason Solution
When you issue the ARP –S
command in Windows, the
"ARP entry addition failed: 5"
message displays.
Your currently logged-in user
does not have the correct rights
to use this command on this
PC.
Have someone from your IT
department log you in with
sufficient rights.
When you attempt to assign an
IP address to the unit by the
ARP method, the "Press Enter
to go into Setup Mode" error
"(described below) message
displays. Now when you Telnet
to the device server, the
connection fails.
When you Telnet to port 1 on
the device server, you are only
assigning a temporary IP
address. When you Telnet into
port 9999 and do not press
Enter quickly, the device server
reboots, causing it to lose the IP
address.
Telnet back to Port 1. Wait for it
to fail, then Telnet to port 9999
again. Make sure you press
Enter quickly.
When you Telnet to port 9999,
the "Press Enter to go into
Setup Mode" message displays.
However, nothing happens
when you press Enter, or your
connection is closed.
You did not press Enter quickly
enough. You only have 5
seconds to press Enter before
the connection is closed.
Telnet to port 9999 again, but
press Enter as soon as you see
the "Press Enter to go into
Setup Mode" message.
When you Telnet to port 1 to
assign an IP address to the
device server, the Telnet
window does not respond for a
long time.
You may have entered the
Ethernet address incorrectly
with the ARP command.
Confirm that the Ethernet
address that you entered with
the ARP command is correct.
The Ethernet address may only
include numbers 0-9 and letters
A-F. In Windows and usually in
Unix, the segments of the
Ethernet address are separated
by dashes. In some forms of
Unix, the Ethernet address is
segmented with colons.
rs
12: Troubleshooting
xPico® Embedded Device Server User Guide 80
Problem/Message Reason Solution
The IP address you are trying to
assign is not on your logical
subnet.
Confirm that your PC has an IP
address and that it is in the
same logical subnet that you
are trying to assign to the
device server.
The device server may not be
plugged into the network
properly.
Make sure that the Link LED is
lit. If the Link LED is not lit, then
the device server is not properly
plugged into the network.
When you try to assign an IP
with DeviceInstaller, you get the
following :
"No response from device!
Verify the IP, Hardware
Address and Network Class.
Please try again."
The cause is most likely one of
the following:
The hardware address you
specified is incorrect.
The IP address you are trying to
assign is not a valid IP for your
logical subnet.
You did not choose the correct
subnet mask.
Double-check the parameters
that you specified.
Note: You cannot assign an IP
address to a device server
through a router.
The device server is not
communicating with the serial
device to which it is attached.
The most likely reason is the
wrong serial settings were
chosen.
The serial settings for the serial
device and the device server
must match. The default serial
settings for the device server
are RS-232, 9600 baud, 8
character bits, no parity, 1 stop
bit, no flow control.
When you try to enter the setup
mode on the device server
using the serial port, you get no
response.
The issue is most likely
something covered in the
previous problem, or possibly,
you have
Caps Lock
on.
Double-check everything in the
problem above. Confirm that
Caps Lock is not on.
You can ping the device server,
but not Telnet to the device
server on port 9999.
There may be an IP address
conflict on your network
You are not Telneting to port
9999.
The Telnet configuration port
(9999) is disabled within the
device server security settings.
Turn the device server off and
then issue the following
commands at the DOS prompt
of your computer:
ARP -D X.X.X.X (X.X.X.X is the
IP of the device server).
PING X.X.X.X (X.X.X.X is the IP
of the device server).
If you get a response, then
there is a duplicate IP address
on the network. If you do not
get a response, use the serial
port to verify that Telnet is not
disabled.
rs
12: Troubleshooting
xPico® Embedded Device Server User Guide 81
Problem/Message Reason Solution
The device server appears to
be set up correctly, but you are
not communicating with your
device attached to the device
server across the network.
If you are sure that the serial
port setting is correct, then you
may not be connecting to the
correct socket of the device
server.
Another possibility is that the
device server is not set up
correctly to make a good socket
connection to the network.
You can check to see whether
there is a socket connection to
or from the device server by
checking the state of CPx, if
one of the CPs has been
configured for Serial Channel
Status LED functionality.
If the state of CPx is blinking
consistently, then there is a
good socket connection.
If the state of CPx is low, use
the Connect Mode option C0 for
making a connection to the
device server from the network.
Use Connect Mode option C1
or C5 for a connection to the
network from the device server.
See the full list of Connect
Mode options in Connect Mode.
When connecting to the Web
Manager within the device
server, the "No Connection With
The Device Server" message
displays.
Your computer is not able to
connect to port 30718 (77FEh)
on the device server.
Make sure that port 30718
(77FEh) is not blocked with any
router that you are using on the
network. Also, make sure that
port 77FEh is not disabled
within the Security settings of
the device server.
Lantronix offers many resources 1 httg://www.Iantronix.com/support. To contact technical support or sales, look up httg://www.Iantronix.com/about/contact.html.
xPico® Embedded Device Server User Guide 82
A: Technical Support
Lantronix offers many resources to support our customers and products at
http://www.lantronix.com/support. For instance, ask a question, find firmware downloads,
access the FTP site and search through tutorials, FAQs, bulletins, warranty information,
extended support services, and product documentation.
To contact technical support or sales, look up your local office at
http://www.lantronix.com/about/contact.html. When you report a problem, please provide the
following information:
Your name, company name, address, and phone number
Lantronix product and model number
Lantronix MAC number or serial number
Firmware version and current configuration
Description of the problem
Status of the unit when the problem occurred (please try to include information on user
and network activity at the time of the problem).
mmummbmnao meNAo o 1 2 3 4 5 s 7 a 9 A B c D E F
xPico® Embedded Device Server User Guide 83
B: Binary to Hexadecimal Conversions
Many of the unit’s configuration procedures require assembling a series of options
(represented as bits) into a complete command (represented as a byte). Convert the resulting
binary value to a hexadecimal representation.
Converting Binary to Hexadecimal
Following are two simple ways to convert binary numbers to hexadecimals.
Conversion Table
Hexadecimal digits have values ranging from 0 to F, which are represented as 0-9, A (for 10),
B (for 11), etc. To convert a binary value (for example, 0100 1100) to a hexadecimal
representation, the upper and lower four bits are treated separately, resulting in a two-digit
hexadecimal number (in this case, 4C). Use the following table to convert values from binary
to hexadecimal.
Decimal
Binary
Hex
0
0000
0
1
0001
1
2
0010
2
3
0011
3
4
0100
4
5
0101
5
6
0110
6
7
0111
7
8
1000
8
9
1001
9
10
1010
A
11
1011
B
12
1100
C
13
1101
D
14
1110
E
15
1111
F
Scientific Calculator
Another simple way to convert binary to hexadecimals is to use a scientific calculator, such
as the one available on Windows’ operating systems. For example:
1. On the Windows’ Start menu, click Programs
Accessories
Calculator.
2. On the View menu, select Scientific. The scientific calculator displays.
3. Select Bin (Binary), and type the number to convert.
F F F F F F 777777 777777 777777 777777
B: Binary to Hexadecimal Conversions
xPico® Embedded Device Server User Guide 84
4. Click Hex. The hexadecimal value displays.
