Short form catalog 2018
Power semiconductors for industrial and consumer applications
www.infineon.com/power
IGBT modules Tmfimaw W 3991mm Q5 (ifileon
Reference book
IGBT Modules
Technologies, Driver and Application
IGBT Modules – Technologies, Driver and Applications
Andreas Volke (Author), Michael Hornkamp (Author),
Jost Wendt (Translator)
ISBN: 978-3-00-040134-3
For further information please visit our website:
www.infineon.com/igbt-book
Bare dies
IGBT bare dies
Diode bare dies 
Discretes 
IGBT Selection Tree 
Discrete IGBT with anti-parallel diode 
Discrete IGBT without anti-parallel diode 
 V /  V ultra soft diode 
 V Rapid  and Rapid  Diode 
IGBT modules 
IGBT package overview 
IGBT modules up to  V 
IGBT modules up to  V 
IGBT modules up to  V 
IGBT modules up to  V 
IGBT modules up to  V 
Silicon Carbide (SiC) 
CoolSiC™ MOSFET 
CoolSiC™ Schottky Diode 
CoolSiC™ Hybrid Modules 
IPMs & Digital Motor Controller 
Intelligent power modules (IPMs) 
Digital Motor Controller (iMOTION™) 
Gate Driver ICs 
High Side Gate Driver ICs 
Low Side Gate Driver ICs 
High and Low Side Gate Driver ICs 
Half Bridge Gate Driver ICs 
Three Phase Gate Driver ICs 
Gate Driver Support ICs 
Driver Boards 
Stacks & Boards 
IGBT Stacks & IGBT Assemblies 
Boards 
Thyristor / diode discs 
Solution tree 
Thyristor discs 
Welding diodes 
Fast Rectifier diodes 
IGCT / IGBT freewheeling diodes 
Rectifier diodes 
Accessories 
Thyristor / diode modules 
Thyristor Soft Starter Modules 
Thyristor / diode modules 
Bridge rectifier and AC-switches 
Accessories 
Solid State Relay 
Photovoltaic Isolators 
Photovoltaic Relays 
Contents
3
4
The TRENCHSTOP™ IGBT combines the unique Trench- and Fieldstop-Technology and is a benchmark in the Industry.
The portfolio includes the voltage range from 600 V up to 1700 V with several different versions, and is optimized for a
wide range of applications like Drives, Renewable Energy, Welding and Power Supplies.
Emitter Controlled-Diode is Infineon unique Fast Recovery Diode technology. The Ultrathin wafer and field-stop
technology makes the Emitter Controlled-Diode from Infineon ideally suited for consumer & industry applications as
it lower the turn-on losses of the IGBT with soft recovery. The Emitter Controlled-Diode is optimized for the Infineon
IGBT technology.
Bare dies
IGBTs and diodes
5
Bare dies
Product Product Status VCE max
[V]
IC max
[A]
Technology VCE(sat) max
[V]
VGE(th) min
[V]
VGE(th) max
[V]
Operating
Temperature min
[°C]
Operating
Temperature max
[°C]
IGBT bare dies
600 V
SIGC100T60R3E active and preferred 600 200 IGBT3 1.85 5 6.5 -40 175
SIGC156T60SNR2C active and preferred 600 200 IGBT2 Fast 2.5 3 5 -55 150
SIGC156T60NR2C active and preferred 600 200 IGBT2 2.5 4.5 6.5 -55 150
SIGC76T60R3E active and preferred 600 150 IGBT3 1.85 5 6.5 -40 175
SIGC121T60NR2C active and preferred 600 150 IGBT2 2.5 4.5 6.5 -55 150
SIGC54T60R3E active and preferred 600 100 IGBT3 1.85 5 6.5 -40 175
SIGC81T60SNC active and preferred 600 100 IGBT2 Fast 2.5 3 5 -55 150
SIGC81T60NC active and preferred 600 100 IGBT2 2.5 4.5 6.5 -55 150
SIGC39T60E active and preferred 600 75 IGBT3 1.85 5 6.5 -40 175
SIGC40T60R3E active and preferred 600 75 IGBT3 1.85 5 6.5 -40 175
SIGC61T60NC active and preferred 600 75 IGBT2 2.5 4.5 6.5 -55 150
SIGC28T60E active and preferred 600 50 IGBT3 1.85 5 6.5 -40 175
SIGC42T60UN active and preferred 600 50 IGBT2 HighSpeed 3.15 3 5 -55 150
SIGC42T60SNC active and preferred 600 50 IGBT2 Fast 2.5 3 5 -55 150
SIGC42T60NC active and preferred 600 50 IGBT2 2.5 4.5 6.5 -55 150
SIGC19T60SE active and preferred 600 40 IGBT3 Fast 1.97 4.2 5.6 -40 150
SIGC15T60SE active and preferred 600 30 IGBT3 Fast 2.05 4.1 5.7 -40 150
SIGC15T60E active and preferred 600 30 IGBT3 1.9 5 6.5 -40 175
SIGC25T60UN active and preferred 600 30 IGBT2 HighSpeed 3.15 3 5 -55 150
SIGC25T60SNC active and preferred 600 30 IGBT2 Fast 2.5 3 5 -55 150
SIGC25T60NC active and preferred 600 30 IGBT2 2.5 4.5 6.5 -55 150
SIGC10T60SE active and preferred 600 20 IGBT3 Fast 2.05 4.1 5.7 -40 150
SIGC10T60E active and preferred 600 20 IGBT3 1.9 5 6.5 -40 175
SIGC18T60UN active and preferred 600 20 IGBT2 HighSpeed 3.15 3 5 -55 150
SIGC18T60SNC active and preferred 600 20 IGBT2 Fast 2.5 3 5 -55 150
SIGC18T60NC active and preferred 600 20 IGBT2 2.5 4.5 6.5 -55 150
IGC10R60DE active and preferred 600 15 IGBT3 RC Drives 5.7 4.3 5.7 -40 175
SIGC08T60SE active and preferred 600 15 IGBT3 Fast 2.05 4.1 5.7 -40 150
6
Bare dies
Product Product Status VCE max
[V]
IC max
[A]
Technology VCE(sat) max
[V]
VGE(th) min
[V]
VGE(th) max
[V]
Operating
Temperature min
[°C]
Operating
Temperature max
[°C]
600 V
SIGC08T60E active and preferred 600 15 IGBT3 1.9 5 6.5 -40 175
SIGC15T60UN active and preferred 600 15 IGBT2 HighSpeed 3.15 3 5 -55 150
SIGC14T60SNC active and preferred 600 15 IGBT2 Fast 2.5 3 5 -55 150
SIGC14T60NC active and preferred 600 15 IGBT2 2.5 4.5 6.5 -55 150
IGC07R60DE active and preferred 600 10 IGBT3 RC Drives 2.1 4.3 5.7 -40 175
SIGC06T60GE active and preferred 600 10 IGBT3 1.9 5 6.5 -40 175
SIGC06T60E active and preferred 600 10 IGBT3 1.9 5 6.5 -40 175
SIGC12T60SNC active and preferred 600 10 IGBT2 Fast 2.5 3 5 -55 150
SIGC11T60SNC active and preferred 600 10 IGBT2 Fast 2.4 3 5 -55 150
SIGC12T60NC active and preferred 600 10 IGBT2 2.5 4.5 6.5 -55 150
SIGC11T60NC active and preferred 600 10 IGBT2 2.5 4.5 6.5 -55 150
IGC06R60DE active and preferred 600 8 IGBT3 RC Drives 2.1 4.3 5.7 -40 175
IGC05R60DE active and preferred 600 6 IGBT3 RC Drives 2.1 4.3 5.7 -40 175
SIGC04T60GSE active and preferred 600 6 IGBT3 Fast 2.05 4.1 5.7 -40 150
SIGC04T60GE active and preferred 600 6 IGBT3 1.9 5 6.5 -40 175
SIGC04T60E active and preferred 600 6 IGBT3 1.9 5 6.5 -40 175
SIGC07T60UN active and preferred 600 6 IGBT2 HighSpeed 3.15 3 5 -55 150
SIGC07T60SNC active and preferred 600 6 IGBT2 Fast 2.5 3 5 -55 150
SIGC07T60NC active and preferred 600 6 IGBT2 2.5 4.5 6.5 -55 150
IGC04R60DE active and preferred 600 4 IGBT3 RC Drives 2.1 4.3 5.7 -40 175
SIGC03T60SE active and preferred 600 4 IGBT3 Fast 2.05 4.1 5.7 -40 150
SIGC03T60E active and preferred 600 4 IGBT3 1.9 5 6.5 -40 175
SIGC05T60SNC active and preferred 600 4 IGBT2 Fast 2 3 5 -55 150
IGC03R60DE active and preferred 600 2.5 IGBT3 RC Drives 2.1 4.3 5.7 -40 175
SIGC03T60SNC active and preferred 600 2 IGBT2 Fast 2.5 3 5 -55 150
7
Bare dies
IGBT bare dies
650 V
SIGC100T65R3E active and preferred 650 200 IGBT3 1.2 5.1 6.4 -40 175
IGC100T65T8RM active and preferred 650 200 IGBT3 Medium Power 1.23 5.1 6.4 -40 175
SIGC78T65R3E active and preferred 650 150 IGBT3 1.54 5.1 6.4 -40 175
SIGC76T65R3E active and preferred 650 150 IGBT3 1.2 5.1 6.4 -40 175
IGC76T65T8RM active and preferred 650 150 IGBT3 Medium Power 1.23 5.1 6.4 -40 175
IGC54T65R3QE active and preferred 650 100 IGBT HighSpeed 3 2.22 4.2 5.6 -40 175
SIGC54T65R3E active and preferred 650 100 IGBT3 1.77 5.1 6.4 -40 175
IGC54T65T8RM active and preferred 650 100 IGBT3 Medium Power 1.82 5.1 6.4 -40 175
IGC39T65QE active and preferred 650 75 IGBT HighSpeed 3 2.22 4.2 5.6 -40 175
SIGC39T65E active and preferred 650 75 IGBT3 1.77 5.1 6.4 -40 175
SIGC40T65R3E active and preferred 650 75 IGBT3 1.77 5.1 6.4 -40 175
IGC39T65T8M active and preferred 650 75 IGBT3 Medium Power 1.82 5.1 6.4 -40 175
IGC31T65QE active and preferred 650 60 IGBT HighSpeed 3 2.22 4.2 5.6 -40 175
IGC28T65QE active and preferred 650 50 IGBT HighSpeed 3 2.22 4.2 5.6 -40 175
SIGC28T65E active and preferred 650 50 IGBT3 1.77 5.1 6.4 -40 175
IGC28T65T8M active and preferred 650 50 IGBT3 Medium Power 1.82 5.1 6.4 -40 175
IGC19T65QE active and preferred 650 40 IGBT HighSpeed 3 2.32 4.2 5.6 -40 175
IGC15T65QE active and preferred 650 30 IGBT HighSpeed 3 2.32 4.2 5.6 -40 175
SIGC15T65E active and preferred 650 30 IGBT3 1.87 5.1 6.4 -40 175
IGC10T65QE active and preferred 650 20 IGBT HighSpeed 3 2.32 4.2 5.6 -40 175
SIGC10T65E active and preferred 650 20 IGBT3 1.87 5.1 6.4 -40 175
SIGC08T65E active and preferred 650 15 IGBT3 1.87 5.1 6.4 -40 175
SIGC06T65E active and preferred 650 10 IGBT3 1.87 5.1 6.5 -40 175
SIGC06T65GE active and preferred 650 10 IGBT3 1.87 5.1 6.4 -40 175
SIGC04T65E active and preferred 650 6 IGBT3 1.87 5.1 6.5 -40 175
Product Product Status VCE max
[V]
IC max
[A]
Technology VCE(sat) max
[V]
VGE(th) min
[V]
VGE(th) max
[V]
Operating
Temperature min
[°C]
Operating
Temperature max
[°C]
8
Bare dies
1200 V
IGC193T120T8RM active and preferred 1200 200 IGBT4 Medium Power 1.3 5.3 6.3 -40 175
IGC189T120T8RL active and preferred 1200 200 IGBT4 Low Power 2.05 5.3 6.3 -40 175
IGC142T120T8RH active and preferred 1200 150 IGBT4 High Power 1.26 5.1 6.4 -40 175
IGC142T120T8RM active and preferred 1200 150 IGBT4 Medium Power 1.74 5.3 6.3 -40 175
IGC142T120T8RL active and preferred 1200 150 IGBT4 Low Power 1.74 5.3 6.3 -40 175
SIGC158T120R3E active and preferred 1200 150 IGBT3 2.1 5 6.5 -40 150
SIGC158T120R3LE active and preferred 1200 150 IGBT3 2.1 5 6.5 -40 150
IGC99T120T8RH active and preferred 1200 100 IGBT4 High Power 1.92 5.1 6.4 -40 175
IGC99T120T8RM active and preferred 1200 100 IGBT4 Medium Power 1.97 5.1 6.4 -40 175
IGC99T120T8RL active and preferred 1200 100 IGBT4 Low Power 1.97 5.1 6.4 -40 175
IGC99T120T8RQ active and preferred 1200 100 IGBT HighSpeed 3 2.42 5.1 6.4 -40 175
SIGC109T120R3E active and preferred 1200 100 IGBT3 2.1 5 6.5 -40 150
SIGC109T120R3LE active and preferred 1200 100 IGBT3 2.1 5 6.5 -40 150
IGC70T120T8RM active and preferred 1200 75 IGBT4 Medium Power 2.07 5.3 6.3 -40 175
IGC70T120T8RL active and preferred 1200 75 IGBT4 Low Power 2.07 5.3 6.3 -40 175
IGC70T120T8RQ active and preferred 1200 75 IGBT HighSpeed 3 2.42 5.3 6.3 -40 175
SIGC84T120R3LE active and preferred 1200 75 IGBT3 2.1 5 6.5 -40 150
SIGC84T120R3E active and preferred 1200 75 IGBT3 2.1 5 6.5 -40 150
IGC50T120T8RL active and preferred 1200 50 IGBT4 Low Power 2.07 5.3 6.3 -40 175
IGC50T120T8RQ active and preferred 1200 50 IGBT HighSpeed 3 2.42 5.3 6.3 -40 175
SIGC57T120R3LE active and preferred 1200 50 IGBT3 2.1 5 6.5 -40 150
SIGC57T120R3E active and preferred 1200 50 IGBT3 2.1 5 6.5 -40 150
IGC41T120T8Q active and preferred 1200 40 IGBT HighSpeed 3 2.42 5.3 6.3 -40 175
SIGC41T120R3LE active and preferred 1200 40 IGBT3 2.1 5 6.5 -40 150
IGC36T120T8L active and preferred 1200 35 IGBT4 Low Power 2.07 5.3 6.3 -40 175
SIGC41T120R3E active and preferred 1200 35 IGBT3 2.1 5 6.5 -40 150
IGC27T120T8L active and preferred 1200 25 IGBT4 Low Power 2.07 5.3 6.3 -40 175
IGC27T120T8Q active and preferred 1200 25 IGBT HighSpeed 3 2.42 5.3 6.3 -40 175
Product Product Status VCE max
[V]
IC max
[A]
Technology VCE(sat) max
[V]
VGE(th) min
[V]
VGE(th) max
[V]
Operating
Temperature min
[°C]
Operating
Temperature max
[°C]
9
Bare dies
1200 V
SIGC32T120R3E active and preferred 1200 25 IGBT3 2.1 5 6.5 -40 150
SIGC32T120R3LE active and preferred 1200 25 IGBT3 2.1 5 6.5 -40 150
IGC18T120T8L active and preferred 1200 15 IGBT4 Low Power 2.07 5.3 6.3 -40 175
IGC18T120T8Q active and preferred 1200 15 IGBT HighSpeed 3 2.42 5.3 6.3 -40 175
SIGC20T120E active and preferred 1200 15 IGBT3 2.1 5 6.5 -40 150
SIGC20T120LE active and preferred 1200 15 IGBT3 2.1 5 6.5 -40 150
IGC13T120T8L active and preferred 1200 10 IGBT4 Low Power 2.07 5.3 6.3 -40 175
IGC11T120T8L active and preferred 1200 8 IGBT4 Low Power 2.07 5.3 6.3 -40 175
SIGC12T120E active and preferred 1200 8 IGBT3 2.1 5 6.5 -40 150
SIGC12T120LE active and preferred 1200 8 IGBT3 2.1 5 6.5 -40 150
IGC07T120T8L active and preferred 1200 4 IGBT4 Low Power 2.02 5.3 6.3 -40 175
1700 V
IGC168T170S8RH active and preferred 1700 150 IGBT3 High Power 2.15 5.2 6.4 -40 150
IGC168T170S8RM active and preferred 1700 150 IGBT3 Medium Power 2.2 5.2 6.4 -40 150
SIGC186T170R3E active and preferred 1700 150 IGBT3 2.4 5.2 6.4 -55 150
SIGC158T170R3E active and preferred 1700 125 IGBT3 2.4 5.2 6.4 -55 150
IGC136T170S8RH2 active and preferred 1700 117.5 IGBT3 High Power 1.3 5.3 6.3 -40 150
IGC114T170S8RH active and preferred 1700 100 IGBT3 High Power 2.15 5.2 6.4 -40 150
IGC114T170S8RM active and preferred 1700 100 IGBT3 Medium Power 2.2 5.2 6.4 -40 150
SIGC128T170R3E active and preferred 1700 100 IGBT3 2.4 5.2 6.4 -55 150
IGC89T170S8RM active and preferred 1700 75 IGBT3 Medium Power 2.2 5.2 6.4 -40 150
SIGC101T170R3E active and preferred 1700 75 IGBT3 2.4 5.2 6.4 -55 150
SIGC68T170R3E active and preferred 1700 50 IGBT3 2.4 5.2 6.4 -55 150
SIGC42T170R3GE active and preferred 1700 29 IGBT3 2.4 5.2 6.4 -55 150
IGBT bare dies
Product Product Status VCE max
[V]
IC max
[A]
Technology VCE(sat) max
[V]
VGE(th) min
[V]
VGE(th) max
[V]
Operating
Temperature min
[°C]
Operating
Temperature max
[°C]
10
Bare dies
Product Product Status VDS max
[V]
IF max
[A]
I(FSM) max
[A]
VF
[V]
IR max
[A]
Diode bare dies
Emitter Controlled Diode High Efficiency
SIDC105D120H8 active and preferred 1200 200 400 1.29 2.6
SIDC14D120H8 active and preferred 1200 25 50 1.6 27
SIDC07D60AF6 active and preferred 600 22.5 45 1.5 250
Emitter Controlled Diode 4 High Power
IDC73D120T8H active and preferred 1200 - - 1.35 26
IDC73D120T6H active and preferred 1200 150 300 1.9 26
IDC73D120T6H active and preferred 1200 150 300 1.9 26
IDC51D120T8H active and preferred 1200 - - 1.9 18
IDC51D120T6H active and preferred 1200 100 200 1.9 18
IDC40D120T8H active and preferred 1200 - - 1.9 14
IDC40D120T6H active and preferred 1200 75 150 1.9 14
Emitter Controlled Diode 4 Medium Power
IDC73D120T8M active and preferred 1200 - - 1.25 26
IDC51D120T8M active and preferred 1200 - - 1.7 18
IDC51D120T6M active and preferred 1200 100 200 1.7 18
IDC40D120T8M active and preferred 1200 - - 1.7 14
IDC40D120T6M active and preferred 1200 75 - 1.7 14
IDC28D120T8M active and preferred 1200 - - 1.7 10
IDC28D120T6M active and preferred 1200 50 100 1.7 10
IDC21D120T8M active and preferred 1200 - - 1.7 7.7
IDC21D120T6M active and preferred 1200 35 70 1.7 7.7
IDC15D120T8M active and preferred 1200 - - 1.7 5.2
IDC15D120T6M active and preferred 1200 25 50 1.7 5.2
IDC10D120T8M active and preferred 1200 - - 1.7 3.5
IDC08D120T8M active and preferred 1200 - - 1.7 2.7
IDC08D120T6M active and preferred 1200 10 30 1.7 2.7
IDC10D120T6M active and preferred 1200 15 - 1.7 3.5
11
Bare dies
Diode bare dies
Product Product Status VDS max
[V]
IF max
[A]
I(FSM) max
[A]
VF
[V]
IR max
[A]
Emitter Controlled Diode 3
SIDC161D170H active and preferred 1700 300 600 1.8 250
SIDC112D170H active and preferred 1700 205 410 1.9 20
SIDC110D170H active and preferred 1700 200 400 1.8 250
SIDC85D170H active and preferred 1700 150 300 1.8 250
SIDC78D170H active and preferred 1700 150 300 1.8 250
SIDC59D170H active and preferred 1700 100 200 1.8 250
SIDC46D170H active and preferred 1700 75 150 1.8 250
SIDC32D170H active and preferred 1700 50 100 1.8 250
SIDC50D65C8 active and preferred 650 200 1.17 2.4
SIDC38D65C8 active and preferred 650 150 300 1.17 1.8
SIDC26D65C8 active and preferred 650 100 200 1.17 1.2
SIDC20D65C8 active and preferred 650 75 150 1.55 0.9
SIDC14D65C8 active and preferred 650 50 100 1.55 0.6
SIDC08D65C8 active and preferred 650 30 60 1.55 0.36
SIDC06D65C8 active and preferred 650 20 40 1.55 0.24
SIDC05D65C8 active and preferred 650 15 30 1.55 0.18
SIDC03D65C8 active and preferred 650 10 20 1.55 0.14
SIDC02D65C8 active and preferred 650 6 12 1.55 0.1
SIDC50D60C8 active and preferred 600 200 400 1.6 27
SIDC38D60C8 active and preferred 600 150 300 1.6 27
SIDC26D60C8 active and preferred 600 100 200 1.6 27
SIDC20D60C8 active and preferred 600 75 150 1.6 27
SIDC14D60C8 active and preferred 600 50 100 1.6 27
SIDC08D60C8 active and preferred 600 30 60 1.6 27
SIDC06D60C8 active and preferred 600 20 40 1.6 27
SIDC05D60C8 active and preferred 600 15 30 1.6 27
SIDC03D60C8 active and preferred 600 10 20 1.6 27
SIDC02D60C8 active and preferred 600 6 12 1.6 27
12
Bare dies
Emitter Controlled Diode Fast
SIDC130D170H active and preferred 1700 235 470 1.35 11
SIDC81D120H8 active and preferred 1200 150 300 1.6 27
SIDC81D120F6 active and preferred 1200 100 200 2.1 250
SIDC53D120H8 active and preferred 1200 100 200 1.6 27
SIDC56D120F6 active and preferred 1200 75 150 2.1 250
SIDC42D120H8 active and preferred 1200 75 150 1.6 27
SIDC42D120F6 active and preferred 1200 50 100 2.1 250
SIDC30D120H8 active and preferred 1200 50 100 1.6 27
SIDC30D120F6 active and preferred 1200 35 70 2.1 250
SIDC23D120H8 active and preferred 1200 35 70 1.6 27
SIDC23D120F6 active and preferred 1200 25 50 2.1 250
SIDC14D120F6 active and preferred 1200 15 30 2.1 250
SIDC10D120H8 active and preferred 1200 15 30 1.6 27
SIDC08D120H8 active and preferred 1200 10 20 1.6 27
SIDC06D120H8 active and preferred 1200 7.5 15 1.6 27
SIDC08D120F6 active and preferred 1200 7 14 2.1 250
SIDC03D120H8 active and preferred 1200 3 6 1.6 27
SIDC06D120F6 active and preferred 1200 5 10 2.1 250
SIDC03D120F6 active and preferred 1200 2 4 2.1 250
Emitter Controlled Diode
SIDC73D170E6 active and preferred 1700 100 200 2.15 375
SIDC56D170E6 active and preferred 1700 75 150 2.15 375
SIDC42D170E6 active and preferred 1700 50 100 2.15 375
Product Product Status VDS max
[V]
IF max
[A]
I(FSM) max
[A]
VF
[V]
IR max
[A]
13
Bare dies
14
Market leadership through groundbreaking innovation and application focus
Striving for the highest standards in performance and quality, Infineon offers a comprehensive application specific
discrete IGBT portfolio that is second to none.
Discretes
IGBTs and diodes
15
Discretes
RC-drives (monolythic) TRENCHSTOP™ Performance Soft turn-off
TRENCHSTOP™ 5 (S5)
HighSpeed 3
(H3)
TRENCHSTOP™ 5
H5/F5
RC TRENCHSTOP™ 5
(WR5)
Low VCE(sat)
TRENCHSTOP™ 5 (L5)
TRENCHSTOP™ IGBT6
NEW!
Diode commutation
IGBT
Frequency range
Voltage range
Part number
Applications
Induction cooking
Microwave
Multifunction printers
Half-bridge resonant
(Current resonance < 650 V)
Single switch
(Voltage resonance > 650 V)
Conduction loss optimized
Solar inverter
Asymmetrical bridge
Symmetrical full-bridge
3-level type I or 3-level type II converter
Motor control
Three-phase inverter
Full-bridge inverter
Uninterruptable power supply
UPS bridge
3-level type II converter
Major home appliances
Symmetrical full-bridge
PFC
Battery charger
Welding
UPS
Solar
Energy storage
SMPS
Air conditioning
HVDC (Telecom/data centers)
PFC
Welding inverter
Full-brigde
Half-bridge
Two transistor forward
UPS
3-level NPC1 and
NPC2 topology,
inner switches
Solar
3-level NPC1 and
NPC2 topology,
inner switches
Welding
AC output
(Al/Mag welding)
UPS
Energy storage
Battery charger
Welding
Solar Inverter
IKpccN60R
IKpccN60RF
IKpccN60T
IKpccN60dTP
IKpccT120…
IGpccN60T
IGpccN60TP
IGpccT120
IGpccN120T2
IKpccN60H3
IKpccN120H3
IGpccN60H3
IGpccN120H3
IKpccN65H5
IKpccN65F5
IGpccN65H5
IGpccN65F5
IKpccN65dR5 IKpccN65dL5
IGpccN65L5
IKpccN65dS5
600 V, 650 V, 1100 V, 1200 V,
1350 V, 1600 V 600 V 600 V, 1200 V
IKpccN65dT6
650 V 650 V 650 V 650 V 650 V600 V, 1200 V
8 kHz – 60 kHz
RC series (monolythic)
Soft Hard/no diode for IG** parts
IHpccNvvvR2
IHpccNvvvR3
IHpccN60R/RF
IHpccNvvvR5
IHpccNvvvE1
NEW!
2 kHz – 30 kHz 10 kHz – 40 kHz
medium speed
> 18 kHz – 60 kHz
high speed
10 kHz – 100 kHz
high speed
> 18 kHz – 60 kHz
high speed
50 Hz – 20 kHz
low speed
IGBT Selection Tree
16
Discretes
Discrete IGBT with anti-parallel diode
Product Product Status Switching
Frequency
min
[kHz]
Switching
Frequency
max
[kHz]
Package Voltage
Class
max
[V]
ICpuls
max
[A]
Ptot
max
[W]
VCE(sat)
[V]
Eon
[mJ]
td(on)
[ns]
tr
[ns]
td(off)
[ns]
tf
[ns]
QGate
[nC]
IF max
[A]
IFpuls max
[A]
VF
[V]
Qrr
[nC]
Irrm
[A]
IC @
100°
max
[A]
IC @
25°
max
[A]
Eoff Hard
Switching
[mJ]
Eoff Soft
Switching
[mJ]
IGBT TRENCHSTOP™ Advanced Isolation
IKFW50N60DH3 active and preferred 18 60 PG-TO247-3-AI 600 160 145 1.85 1.22 25 35 212 22 210 40 160 1.45 0.51 11.7 - 53 0.62 -
IKFW60N60DH3E active and preferred 18 60 PG-TO247-3-AI 600 150 141 2.2 1.57 23 39 170 19 210 40 150 2.2 0.55 12 - 53 0.72 -
IKFW50N60DH3E active and preferred 18 60 PG-TO247-3-AI 600 120 130 2.2 1.28 21 39 174 18 160 40 120 1.5 0.51 11.7 - 40 0.56 -
IKFW40N60DH3E active and preferred 18 60 PG-TO247-3-AI 600 90 111 2.3 0.87 18 34 144 16 107 35 90 1.6 0.4 9.9 - 34 0.36 -
IGBT TRENCHSTOP™ 6
IKA15N65ET6 active and preferred 5 30 PG-TO220-3 FP 650 57.5 45 1.5 0.23 30 22 117 42 37 17 57.5 1.5 0.21 5.1 11 17 0.11 -
IKA10N65ET6 active and preferred 5 30 PG-TO220-3 FP 650 42.5 40 1.5 0.2 30 18 106 46 27 14 42.5 1.45 0.21 5.7 9 15 0.07 -
IKA08N65ET6 active and preferred 5 30 PG-TO220-3 FP 650 25 33 1.5 0.11 20 12 59 53 17 14 25 1.28 0.15 5.9 7 11 0.04 -
IGBT TRENCHSTOP™ 5 F5
IKW50N65F5 active and preferred 60 120 TO-247 650 150 305 1.6 0.49 21 15 175 18 120 40 150 1.45 550 16.5 56 80 0.16 -
IKB40N65EF5 active and preferred 40 100 PG-TO263-3 650 120 250 1.60 1.12 19 37 154 58 95 46 160 1.45 0.89 14.5 46 74 0.48 -
IKW40N65F5 active and preferred 60 120 TO-247 650 120 255 1.6 0.36 19 13 160 16 95 36 120 1.45 450 12.4 46 74 0.1 -
IKP40N65F5 active and preferred 60 120 TO-220 650 120 255 1.6 0.36 19 13 160 16 95 36 120 1.45 450 12.4 46 74 0.1 -
IKP30N65F5 active and preferred 60 120 TO-220 650 90 188 1.6 0.28 18 4 174 15 70 36 90 1.35 410 14.4 35 55 0.07 -
IKP20N65F5 active and preferred 60 120 TO-220 650 60 125 1.6 0.16 18 3 170 30 48 20 60 1.65 280 10.25 21 42 0.06 -
IKA15N65F5 active and preferred 60 120 TO-220-3 FP 650 45 33.3 1.6 0.13 150 7 150 16 38 12.3 45 1.45 190 8 8.5 14 0.04 -
IKP15N65F5 active and preferred 60 120 TO-220 650 45 105 1.6 0.13 17 7 150 16 38 20 45 1.45 190 8 18 30 0.04 -
IKA08N65F5 active and preferred 60 120 TO-220-3 FP 650 24 31.2 1.6 0.07 10 5 116 20 22 12.3 24 1.45 140 6.6 6.8 10.8 0.02 -
IKP08N65F5 active and preferred 60 120 TO-220 650 24 70 1.6 0.07 116 5 116 20 22 20 24 1.45 140 6.6 11 18 0.02 -
IGBT TRENCHSTOP™ 5 H5
IKW75N65EH5 active and preferred 30 100 TO-247 650 300 395 1.65 2.3 28 33 174 41 160 90 300 1.35 1330 20.5 75 90 0.9 -
IKZ75N65EH5 active and preferred 30 100 TO-247-4 650 300 395 1.65 0.68 26 11 347 15 166 95 300 1.35 1020 29 75 90 0.43 -
IKZ75N65NH5 active and preferred 30 100 TO-247-4 650 300 395 1.65 0.88 52 19 412 19 166 95 219 1.6 570 26 75 90 0.52 -
IKW50N65EH5 active and preferred 30 100 TO-247 650 200 275 1.65 1.5 25 29 172 35 120 80 200 1.35 1100 17 50 80 0.5 -
IKZ50N65EH5 active and preferred 30 100 TO-247-4 650 200 273 1.65 0.41 20 7 250 21 109 95 200 1.35 820 24 54 85 0.19 -
IKZ50N65NH5 active and preferred 30 100 TO-247-4 650 200 273 1.65 0.35 22 8 252 23 109 79 200 1.6 490 22 54 85 0.2 -
17
Discretes
Discrete IGBT with anti-parallel diode
Product Product Status Switching
Frequency
min
[kHz]
Switching
Frequency
max
[kHz]
Package Voltage
Class
max
[V]
ICpuls
max
[A]
Ptot
max
[W]
VCE(sat)
[V]
Eon
[mJ]
td(on)
[ns]
tr
[ns]
td(off)
[ns]
tf
[ns]
QGate
[nC]
IF max
[A]
IFpuls max
[A]
VF
[V]
Qrr
[nC]
Irrm
[A]
IC @
100°
max
[A]
IC @
25°
max
[A]
Eoff Hard
Switching
[mJ]
Eoff Soft
Switching
[mJ]
IGBT TRENCHSTOP™ 5 H5
IKW50N65H5 active and preferred 30 100 TO-247 650 150 305 1.65 0.52 21 15 180 18 120 40 150 1.45 570 16.7 56 80 0.18 -
IKB40N65EH5 active and preferred 30 100 PG-TO263-3 650 120 250 1.65 0.39 22 12 165 13 95 40 160 1.45 450 12.5 46 74 0.12 -
IKB30N65EH5 active and preferred 30 100 PG-TO263-3 650 120 188 1.65 0.86 24 28 159 25 70 40 90 1.45 500 12 25 55 0.30 -
IKP40N65H5 active and preferred 30 100 TO-220 650 120 255 1.65 0.39 22 12 165 13 95 36 120 1.45 450 12.5 46 74 0.12 -
IKW40N65H5 active and preferred 30 100 TO-247 650 120 255 1.65 0.39 22 12 165 13 95 36 120 1.45 450 12.5 46 74 0.12 -
IKP30N65H5 active and preferred 30 100 TO-220 650 90 188 1.65 0.28 18 4 180 22 70 36 90 1.35 410 14.3 35 55 0.1 -
IKW30N65H5 active and preferred 30 100 TO-247 650 90 188 1.65 0.28 20 11 190 19 70 30 54 1.55 410 11.5 35 55 0.1 -
IKB20N65EH5 active and preferred 30 100 PG-TO263-3 650 80 125 1.65 0.56 19 21 160 23 48 40 60 1.45 500 8.5 25 38 0.13 -
IKP20N65H5 active and preferred 30 100 TO-220 650 60 125 1.65 0.17 16 3 168 36 48 20 60 1.65 270 10.04 21 42 0.06 -
IKA15N65H5 active and preferred 30 100 TO-220-3 FP 650 45 33.3 1.65 0.12 17 7 160 10 38 12.3 45 1.45 200 8 8.5 14 0.05 -
IKB15N65EH5 active and preferred 30 100 PG-TO263-3 650 45 105 1.65 0.40 16 17 145 27 38 32 45 1.45 500 10 30 18 0.08 -
IKP15N65H5 active and preferred 30 100 TO-220 650 45 105 1.65 0.12 17 7 160 10 38 20 45 1.45 200 8 18 30 0.05 -
IKA08N65H5 active and preferred 30 100 TO-220-3 FP 650 24 31.2 1.65 0.07 11 5 115 15 22 12.3 24 1.45 130 6.8 6.8 10.8 0.03 -
IKP08N65H5 active and preferred 30 100 TO-220 650 24 70 1.65 0.07 11 5 115 15 22 20 24 1.45 130 6.8 11 18 0.03 -
IGBT TRENCHSTOP™ 5 L5
IKW75N65EL5 active and preferred 50 20 TO-247 650 300 536 1.1 1.61 40 11 275 50 436 90 300 1.4 1370 29 80 80 3.2 -
IKZ75N65EL5 active and preferred 0.05 20 TO-247-4 650 300 536 1.1 1.57 120 23 275 50 436 90 300 1.4 1300 37 100 100 3.2 -
IKW30N65EL5 active and preferred 0.05 20 TO-247 650 120 227 1.05 0.47 33 11 308 51 168 50 120 1.35 910 21 62 85 1.35 -
IKW30N65NL5 active and preferred 0.05 20 TO-247 650 120 227 1.05 0.56 59 20 283 67 168 50 120 1.65 480 18 62 85 1.35 -
IGBT TRENCHSTOP™ 5 R5
IHW50N65R5 active and preferred 20 150 TO-247 650 150 282 1.35 1.5 30 20 210 8 230 37 150 1.7 2750 37 50 80 0.45 -
IHW40N65R5 active and preferred 20 150 TO-247 650 120 230 1.35 1.1 34 25 260 13 193 32 120 1.7 2750 37.2 40 80 0.37 -
IHW30N65R5 active and preferred 20 150 TO-247 650 90 176 1.35 0.85 29 17 220 8 153 23 42 1.7 1900 28 30 60 0.24 -
IHW20N65R5 active and preferred 20 150 TO-247 650 60 150 1.35 0.54 23 16 250 7 97 19 60 1.7 1550 29 20 40 0.16 -
18
Discretes
Product Product Status Switching
Frequency
min
[kHz]
Switching
Frequency
max
[kHz]
Package Voltage
Class
max
[V]
ICpuls
max
[A]
Ptot
max
[W]
VCE(sat)
[V]
Eon
[mJ]
td(on)
[ns]
tr
[ns]
td(off)
[ns]
tf
[ns]
QGate
[nC]
IF max
[A]
IFpuls max
[A]
VF
[V]
Qrr
[nC]
Irrm
[A]
IC @
100°
max
[A]
IC @
25°
max
[A]
Eoff Hard
Switching
[mJ]
Eoff Soft
Switching
[mJ]
IGBT TRENCHSTOP™ 5 S5
IKW75N65ES5 active and preferred 10 30 TO-247 650 300 395 1.42 2.4 40 46 144 41 164 80 300 1.5 1800 31 80 80 0.95 -
IKZ75N65ES5 active and preferred 15 40 TO-247-3 650 300 395 1.42 1.5 46 25 405 22 164 80 300 1.5 1000 36 80 300 1.3 -
IKW50N65ES5 active and preferred 10 30 TO-247 650 200 274 1.35 1.23 20 27 127 34 120 80 5 1.45 1250 25 60.5 80 0.55 -
IKZ50N65ES5 active and preferred 15 40 TO-247-3 650 200 274 1.35 0.77 26 22 294 32 120 50 200 1.45 1400 38.5 60.5 200 0.88 -
IKB40N65ES5 active and preferred 10 40 PG-TO263-3 650 160 188 1.35 0.84 19 18 130 23 95 40 160 1.45 1100 23 46 70 0.40 -
IKW40N65ES5 active and preferred 10 30 TO-247 650 160 230 1.35 0.86 19 18 130 23 95 79 160 1.45 1100 23 50 79 0.4 -
IKB30N65ES5 active and preferred 10 40 PG-TO263-3 650 120 188 1.35 0.56 17 12 124 30 70 40 120 1.45 500 18 39.5 62 0.32 -
IKW30N65ES5 active and preferred 10 30 TO-247 650 120 188 1.35 0.56 17 12 124 30 70 40 120 1.45 830 18 39.5 62 0.32 -
IGBT TRENCHSTOP™ 5 WR5
IKW50N65WR5 active and preferred 20 60 TO-247 650 150 282 1.4 1.85 46 33 400 20 230 37 150 1.4 1800 29 50 80 0.7 -
IKW40N65WR5 active and preferred 20 60 TO-247 650 120 230 1.4 1.4 40 29 402 11 193 32 120 1.4 1650 27 40 80 0.42 -
IKW30N65WR5 active and preferred 20 60 TO-247 650 90 185 1.4 0.99 39 12 367 9 155 24 45 1.4 1250 22 30 60 0.33 -
IGBT TRENCHSTOP™ Performance
IKW50N60DTP active and preferred 2 30 TO-247 600 150 319.2 1.6 2.25 21 34 277 55 249 62 150 1.45 2150 18.8 61 80 1.39 -
IKW40N60DTP active and preferred 2 30 TO-247 600 120 246 1.6 1.63 19 30 273 47 177 58 120 1.45 1520 18.3 48 67 1.05 -
IKW30N60DTP active and preferred 2 30 TO-247 600 90 200 1.6 0.99 15 23 220 59 130 39 90 1.45 1230 16.6 38 53 0.74 -
IGBT TRENCHSTOP™ 2
IKQ75N120CT2 active and preferred 2 20 TO-247-3 1200 300 938 1.75 6.7 37 49 326 46 370 75 300 1.9 5100 29 75 150 4.1 -
IKQ50N120CT2 active and preferred 2 20 TO-247-3 1200 300 652 1.75 3.8 34 46 312 50 235 50 200 1.9 3900 22 50 100 3.3 -
IKQ40N120CT2 active and preferred 2 20 TO-247-3 1200 160 500 1.75 3.1 32 43 328 51 190 40 160 1.9 3100 18 40 80 2.9 -
IKW40N120T2 active and preferred 2 20 TO-247 1200 160 480 2.3 4.5 32 28 405 195 192 75 160 1.75 3300 31 40 75 3.8 -
IKW25N120T2 active and preferred 2 20 TO-247 1200 100 349 2.2 2.25 25 24 340 164 120 40 100 1.65 2050 24 25 50 2.05 -
IKW15N120T2 active and preferred 2 20 TO-247 1200 60 235 2.2 1.5 31 30 450 176 93 25 60 1.75 1300 13 15 30 1.3 -
IKW15T120 active and preferred 2 20 TO-247 1200 45 110 2.2 2 50 35 600 120 85 30 45 1.7 1900 17 15 30 2.1 -
19
Discretes
Discrete IGBT with anti-parallel diode
Product Product Status Switching
Frequency
min
[kHz]
Switching
Frequency
max
[kHz]
Package Voltage
Class
max
[V]
ICpuls
max
[A]
Ptot
max
[W]
VCE(sat)
[V]
Eon
[mJ]
td(on)
[ns]
tr
[ns]
td(off)
[ns]
tf
[ns]
QGate
[nC]
IF max
[A]
IFpuls max
[A]
VF
[V]
Qrr
[nC]
Irrm
[A]
IC @
100°
max
[A]
IC @
25°
max
[A]
Eoff Hard
Switching
[mJ]
Eoff Soft
Switching
[mJ]
IGBT TRENCHSTOP™
IKW40T120 active and preferred 2 20 TO-247 1200 105 270 2.3 5 52 40 580 120 203 80 105 1.75 3800 2.8 40 75 5.4 -
IKW25T120 active and preferred 2 20 TO-247 1200 75 190 2.2 3 50 32 660 130 155 50 105 1.75 2300 21 25 50 4 -
IKW08T120 active and preferred 2 20 TO-247 1200 24 70 2.2 1.08 40 26 570 140 53 16 24 1.7 1000 13 8 16 1.2 -
IKQ120N60T active and preferred 2 20 TO-247PLUS-3 600 480 833 1.5 6.2 50 75 565 68 703 160 480 1.65 3400 26.5 120 160 5.9 -
IKQ100N60T active and preferred 2 20 TO-247PLUS-3 600 400 714 1.5 3.1 30 38 290 31 610 160 400 1.65 2800 23 100 160 2.5 -
IKW75N60T active and preferred 2 20 TO-247 600 225 428 1.5 2.9 33 36 330 35 470 80 225 1.65 2400 38.5 75 80 2.9 -
IKW50N60T active and preferred 2 20 TO-247 600 150 333 1.5 1.2 26 29 299 29 310 100 150 1.65 1.8 27.7 50 80 1.4 -
IHW30N60T active 2 20 TO-247 600 90 187 1.5 23 21 254 46 167 13 30 1.1 30 60 0.8 -
IKW30N60T active and preferred 2 20 TO-247 600 90 187 1.5 1 23 21 254 46 167 60 90 1.65 920 16.3 39 45 1.1 -
IKB20N60T active and preferred 2 20 D2PAK (TO-263) 600 60 166 1.5 0.31 18 14 199 42 120 30 45 1.65 310 10.4 15 30 0.46 -
IKP20N60T active and preferred 2 20 TO-220 600 60 166 1.5 0.31 18 14 199 42 120 41 60 1.65 310 13.3 28 41 0.46 -
IKW20N60T active and preferred 2 20 TO-247 600 60 166 1.5 0.31 18 14 199 42 120 40 60 1.65 310 13.3 28 41 0.46 -
IKA15N60T active and preferred 2 20 TO-220 600 45 35.7 1.5 0.22 17 11 188 50 87 15.5 45 1.65 240 10.4 8.9 14.7 0.35 -
IKB15N60T active and preferred 2 20 D2PAK (TO-263) 600 45 130 1.5 0.22 17 11 188 50 87 30 45 1.65 240 10.4 23 26 0.35 -
IKP15N60T active and preferred 2 20 TO-220 600 45 130 1.5 0.22 17 11 188 50 87 26 45 1.65 240 10.4 23 26 0.35 -
IKA10N60T active and preferred 2 20 TO-220 600 30 30 1.5 0.16 12 8 215 35 67 11.9 30 1.6 380 13 7.2 11.7 0.27 -
IKB10N60T active and preferred 2 20 D2PAK (TO-263) 600 30 110 1.5 0.16 12 8 215 38 62 20 30 1.6 380 10 18 24 0.27 -
IKP10N60T active and preferred 2 20 TO-220 600 30 110 1.5 0.16 12 8 215 38 67 24 30 1.6 380 10 18 24 0.27 -
IKA06N60T active and preferred 2 20 TO-220 600 18 28 1.5 0.09 9 6 130 58 42 10.2 18 0.1 500 5.3 6.2 10 0.11 -
IKB06N60T active and preferred 2 20 D2PAK (TO-263) 600 18 88 1.5 0.09 9 6 130 58 42 12 18 1.6 190 5.3 6 12 0.11 -
IKP06N60T active and preferred 2 20 TO-220 600 18 88 1.5 0.09 9 6 130 58 42 12 18 1.6 190 5.3 6 12 0.11 -
IKP04N60T active and preferred 2 20 TO-220 600 12 42 1.5 0.06 14 7 164 43 27 8 mA 12 1.65 79 5.3 4 8 0.08 -
20
Discretes
Product Product Status Switching
Frequency
min
[kHz]
Switching
Frequency
max
[kHz]
Package Voltage
Class
max
[V]
ICpuls
max
[A]
Ptot
max
[W]
VCE(sat)
[V]
Eon
[mJ]
td(on)
[ns]
tr
[ns]
td(off)
[ns]
tf
[ns]
QGate
[nC]
IF max
[A]
IFpuls max
[A]
VF
[V]
Qrr
[nC]
Irrm
[A]
IC @
100°
max
[A]
IC @
25°
max
[A]
Eoff Hard
Switching
[mJ]
Eoff Soft
Switching
[mJ]
IGBT HighSpeed 3
IKQ75N120CH3 active and preferred 18 60 TO-247-3 1200 300 938 2 6.4 34 47 282 29 370 75 300 1.9 5100 25 75 150 2.8 -
IKY75N120CH3 active and preferred 18 60 TO-247-3 1200 300 938 2 3.4 38 32 303 32 370 75 300 1.9 4900 41 75 150 2.9 -
IKQ50N120CH3 active and preferred 18 60 TO-247-3 1200 200 652 2 3 34 32 297 30 235 50 200 1.9 3500 34 50 100 1.9 -
IKY50N120CH3 active and preferred 18 60 TO-247-3 1200 200 652 2 2.3 32 28 296 29 235 25 200 1.9 3400 33 50 100 1.9 -
IKQ40N120CH3 active and preferred 18 60 TO-247-3 1200 160 500 2 3.3 30 46 300 46 190 40 160 1.9 3600 19 40 80 1.3 -
IKW40N120H3 active and preferred 20 100 TO-247 1200 160 483 2.05 3.2 30 57 290 16 185 40 160 2.4 1900 12.8 40 80 1.2 -
IKY40N120CH3 active and preferred 18 60 TO-247-3 1200 160 500 2 2.18 30 29 280 26 190 40 160 1.9 3000 22 40 80 1.3 -
IKW25N120H3 active and preferred 20 100 TO-247 1200 100 326 2.05 1.8 26 35 277 17 115 25 100 2.4 1200 10.4 25 50 0.85 -
IKW15N120H3 active and preferred 20 100 TO-247 1200 60 217 2.05 1.1 21 34 260 14 75 15 60 2.4 800 7.7 15 30 0.45 -
IKW75N60H3 active and preferred 20 100 TO-247 600 225 428 1.85 3 31 60 265 27 470 80 150 1.65 1800 19 75 80 1.7 -
IKW50N60H3 active and preferred 20 100 TO-247 600 200 333 1.85 1.45 23 37 235 24 315 60 200 1.65 880 16.9 50 100 0.91 -
IKW60N60H3 active and preferred 20 100 TO-247 600 180 416 1.85 2.1 25 39 291 23 375 80 90 1.65 1200 23 60 80 1.13 -
IKW40N60H3 active and preferred 20 100 TO-247 600 160 306 1.95 1.1 19 33 197 21 223 40 160 1.65 810 13.6 40 80 0.58 -
IKW30N60H3 active and preferred 20 100 TO-247 600 120 187 1.95 0.94 21 33 207 22 165 30 120 1.65 320 12 30 60 0.44 -
IKB20N60H3 active and preferred 20 100 D2PAK (TO-263) 600 80 170 1.95 0.45 16 20 194 11 120 20 80 1.65 390 14.2 20 40 0.24 -
IKP20N60H3 active and preferred 20 100 TO-220 600 80 170 1.95 0.45 16 20 194 11 120 20 80 1.65 390 11 20 40 0.24 -
IKW20N60H3 active and preferred 20 100 TO-247 600 80 170 1.95 0.56 17 11 194 11 120 20 80 1.65 390 11 20 40 0.24 -
IGBT RC Soft Switching
IHW30N160R2 active and preferred 8 60 TO-247 1600 90 312 2.35 - - - 564 111 94 30 90 2 - - 30 60 4.37 -
IHW40N135R5 active and preferred 8 60 TO-247 1350V 120 394 1.65 - - - 410 90 305 80 120 1.95 - - 40 80 2.00 0.30
IHW40N135R3 active and preferred 8 60 TO-247 1350 120 429 1.65 - - - 343 43 365 80 120 1.65 - - 40 80 2.5 0.55
IHW30N135R5 active and preferred 8 60 TO-247 1350V 90 330 1.65 - - - 340 95 235 60 90 1.85 - - 30 60 1.50 0.17
IHW30N135R3 active and preferred 8 60 TO-247 1350 90 349 1.65 - - - 337 47 263 60 90 1.65 - - 30 60 1.93 0.41
IHW20N135R5 active and preferred 8 60 TO-247 1350 60 288 1.65 - - - 235 50 170 40 60 1.65 - - 20 40 0.95 -
IHW20N135R3 active 8 60 TO-247 1350 60 310 1.6 - - - 335 50 195 40 60 1.6 - 34 20 40 1.3 -
IHW40N120R5 active and preferred 8 60 TO-247 1200V 120 394 1.55 - - - 420 20 310 80 120 1.9 - - 40 80 1.60 0.22
IHW40N120R3 active and preferred 8 60 TO-247 1200 120 429 1.55 - - - 336 38 335 80 120 1.6 - - 40 80 2.02 0.48
IHW30N120R5 active and preferred 8 60 TO-247 1200V 90 330 1.55 - - - 330 33 235 60 90 1.8 - - 30 60 1.10 0.12
21
Discretes
Discrete IGBT with anti-parallel diode
Product Product Status Switching
Frequency
min
[kHz]
Switching
Frequency
max
[kHz]
Package Voltage
Class
max
[V]
ICpuls
max
[A]
Ptot
max
[W]
VCE(sat)
[V]
Eon
[mJ]
td(on)
[ns]
tr
[ns]
td(off)
[ns]
tf
[ns]
QGate
[nC]
IF max
[A]
IFpuls max
[A]
VF
[V]
Qrr
[nC]
Irrm
[A]
IC @
100°
max
[A]
IC @
25°
max
[A]
Eoff Hard
Switching
[mJ]
Eoff Soft
Switching
[mJ]
IGBT Gen 7
IRG7PH42UD active 8 30 TO-247 1200 90 320 1.7 2.11 25 32 229 63 157 120 - 2 - - 45 85 1.18 -
IRG7PH35UD active 8 30 TO-247 1200 60 180 1.9 1.06 30 15 160 80 85 80 - 2.8 - 40 25 50 0.62 -
IGBT RC Drives
IKD15N60R active and preferred 2 20 DPAK (TO-252) 600 45 250 1.65 0.37 16 10 183 136 90 30 45 1.7 760 27 15 30 0.53 -
IKD10N60R active and preferred 2 20 DPAK (TO-252) 600 30 150 1.65 0.21 14 10 192 139 64 20 30 1.7 560 20.3 10 20 0.38 -
IKD06N60R active and preferred 2 20 DPAK (TO-252) 600 18 100 1.65 0.11 12 7 127 152 48 12 18 1.7 370 12 6 12 0.22 -
IKD04N60R active and preferred 2 20 DPAK (TO-252) 600 12 75 1.65 0.09 14 8 146 171 27 8 12 1.7 220 11 4 8 0.15 -
IGBT RC Drives Fast
IKD15N60RF active and preferred 4 30 DPAK (TO-252) 600 45 250 2.2 0.27 13 15 160 17 90 30 45 2.1 420 13.2 15 30 0.25 -
IKD10N60RF active and preferred 4 30 DPAK (TO-252) 600 30 150 2.2 0.19 12 15 168 18 64 20 30 2.1 270 9.1 10 20 0.16 -
IKD06N60-RF active and preferred 4 30 DPAK (TO-252) 600 18 100 2.2 0.09 7 8 106 22 48 12 18 2.1 160 7.4 6 12 0.09 -
IKD04N60RF active and preferred 4 30 DPAK (TO-252) 600 12 75 2.2 0.06 12 7 116 37 27 8 12 2.1 90 4.6 4 8 0.05 -
IKD03N60RF active and preferred 4 30 DPAK (TO-252) 600 7.5 53.6 2.2 0.05 9 8 142 123 17.1 5 7.5 2.1 60 6.2 2.5 5 0.04 -
IGBT RC Soft Switching
IHW30N120R3 active and preferred 8 60 TO-247 1200 90 349 1.55 - - - 326 39 263 60 90 1.6 - - 30 60 1.47 0.34
IHW25N120E1 active and preferred 8 60 TO-247 1200 75 231 1.5 - - - 240 1764 147 50 75 2.35 - - 25 50 - 0.08
IHW25N120R2 active 8 60 TO-247 1200 75 365 1.6 - - - 373 55.8 60.7 25 75 1.8 - - 25 50 2.54 -
IHW20N120R5 active and preferred 8 60 TO-247 1200 60 288 1.55 - - - 350 90 170 40 60 1.6 - - 20 40 0.75 -
IHW20N120R3 active 8 60 TO-247 1200 60 310 1.48 - 0 0 387 25 211 40 40 1.55 0 0 20 40 0.95 -
IHW15N120E1 active and preferred 8 60 TO-247 1200 45 156 1.5 - - - 140 1800 90 30 45 2.35 - - 15 30 - 0.03
IHW15N120R3 active 8 60 TO-247 1200 45 254 1.48 - - - 300 46 165 30 45 1.55 - - 15 30 0.7 -
IHW30N110R3 active and preferred 8 60 TO-247 1100 90 333 1.55 - - - 350 16 180 60 90 1.35 - - 30 60 1.15 -
IHW40N60R active and preferred 8 60 TO-247 600 120 305 1.65 0 0 0 193 24 223 40 120 1.65 - - 40 80 0.75 -
IHW40N60RF active and preferred 20 100 TO-247 600 120 305 1.85 - - - 175 14 220 80 120 1.75 - - 40 80 0.56 -
22
Discretes
Product Product Status Switching
Frequency
min
[kHz]
Switching
Frequency
max
[kHz]
Package Voltage
Class
max
[V]
ICpuls
max
[A]
Ptot
max
[W]
VCE(sat)
[V]
Eon
[mJ]
td(on)
[ns]
tr
[ns]
td(off)
[ns]
tf
[ns]
QGate
[nC]
IF max
[A]
IFpuls max
[A]
VF
[V]
Qrr
[nC]
Irrm
[A]
IC @
100°
max
[A]
IC @
25°
max
[A]
Eoff Hard
Switching
[mJ]
Eoff Soft
Switching
[mJ]
IGBT Fast
SKB02N120 active and preferred 10 40 D2PAK (TO-263) 1200 9.6 62 3.7 0.27 26 14 290 85 11 4.5 9 2 100 4.2 2.8 6.2 0.11 -
SKP02N120 active and preferred 10 40 TO-220 1200 9.6 62 3.7 0.27 26 14 290 85 11 4.5 9 2 0.1 4.2 2.8 6.2 0.11 -
IGBT Gen 6.2
IRGPS46160D active and preferred 8 30 Super-247 (TO-274) 600 360 750 1.7 5.75 80 70 190 40 240 480 - 2.4 - 36 160 240 3.43 -
IRGP4066D active and preferred 8 30 TO-247 600 225 454 1.7 2.465 50 70 200 60 150 300 - 2.23 - 27 90 140 2.155 -
IRGP4063D active and preferred 8 30 TO-247 600 200 330 1.65 0.625 60 40 145 32 95 192 - 1.95 - 40 48 96 1.275 -
IRGP4660D active and preferred 8 30 TO-247 600 144 330 1.6 0.625 60 40 145 35 95 192 - 1.95 - 40 60 100 1.275 -
IRGP4068D active and preferred 8 30 TO-247 600 144 330 1.65 0.625 145 35 165 45 95 192 - 0.96 - - 48 96 1.275 -
IRGP4650D active and preferred 8 30 TO-247 600 105 268 1.6 0.39 46 33 105 44 69 140 - 2 - 25 50 76 0.632 -
IRGP4069D active and preferred 8 30 TO-247 600 105 268 1.6 0.39 46 33 105 44 69 140 - 2.2 - 25 50 76 0.632 -
IRGSL4062D active and preferred 8 30 I2PAK (TO-262) 600 72 250 1.6 0.115 41 22 104 29 50 96 - 1.8 - 37 24 48 0.6 -
IRGP4640D active and preferred 8 30 TO-247 600 72 250 1.6 0.115 41 22 104 29 50 96 - 1.8 - 37 40 65 0.6 -
IRGB4062D active and preferred 8 30 TO-220 600 72 250 1.6 0.115 41 22 104 29 50 96 - 1.8 - 37 24 48 0.6 -
IRGS4062D active and preferred 8 30 D2PAK (TO-263) 600 72 250 1.6 0.115 41 22 104 29 50 96 - 1.8 - 37 24 48 0.6 -
IRGP4062D active and preferred 8 30 TO-247 600 72 250 1.6 0.115 41 22 104 29 50 69 - 1.8 - 37 24 48 0.6 -
IRGB4061D active and preferred 8 30 TO-220 600 72 206 1.65 0.095 40 25 105 25 35 72 - 2.3 - 23 18 36 0.35 -
IRGB4630D active and preferred 8 30 TO-220 600 54 206 1.65 0.095 40 25 105 25 35 72 - 2.3 - 23 30 47 0.35 -
IRGB4056D active and preferred 8 30 TO-220 600 48 140 1.55 0.075 31 17 83 24 25 48 - 2.1 - 19 12 24 0.225 -
IRGB4620D active and preferred 8 30 TO-220 600 36 140 1.55 0.075 31 17 83 24 25 48 - 2.1 - 19 20 16 0.225 -
IRGB4060D active and preferred 8 30 TO-220 600 32 99 1.55 0.07 30 15 95 20 19 32 - 1.8 - 14 8 16 0.145 -
23
Discretes
Discrete IGBT without anti-parallel diode
Product Product Status Switching
Frequency
min [kHz]
Switching
Frequency
max [kHz]
Package Voltage Class
max
[V]
ICpuls
max
[A]
Ptot max
[W]
VCE(sat)
[V]
Eon
[mJ]
td(on)
[ns]
tr
[ns]
td(off)
[ns]
tf
[ns]
QGate
[nC]
IC @ 100°
max
[A]
IC @ 25°
max
[A]
Eoff Hard
Switching
[mJ]
IGBT TRENCHSTOP™ 5 F5
IGW50N65F5 active and preferred 60 120 TO-247 650 150 305 1.6 0.49 21 15 175 18 120 56 80 0.16
IGP40N65F5 active and preferred 60 120 TO-220 650 120 255 1.6 0.36 19 13 160 16 95 46 74 0.1
IGW40N65F5 active and preferred 60 120 TO-247 650 120 255 1.6 0.36 19 13 160 16 95 46 74 0.1
IGP30N65F5 active and preferred 60 120 TO-220 650 90 188 1.6 0.28 18 4 174 15 70 35 55 0.07
IGP20N65F5 active and preferred 60 120 TO-220 650 60 125 1.6 0.16 18 3 170 30 48 21 42 0.06
IGBT TRENCHSTOP™ Perf.
IGW50N60TP active and preferred 2 30 TO-247 600 150 319.2 1.6 2.25 21 34 277 55 249 61 80 1.39
IGW40N60TP active and preferred 2 30 TO-247 600 120 246 1.6 1.63 19 30 273 47 177 48 67 1.05
IGW30N60TP active and preferred 2 30 TO-247 600 90 200 1.6 0.99 15 23 220 59 130 38 53 0.74
IGBT TRENCHSTOP™ 5 S5
IGB50N65S5 active and preferred 10 40 D2PAK (TO-263) 650 200 270 1.35 1.23 20 30 139 60 120 63 80 0.74
IGB20N65S5 active and preferred 10 40 D2PAK (TO-263) 650 80 125 1.35 0.36 13 14 115 22 48 28 40 0.15
IGB15N65S5 active and preferred 10 40 D2PAK (TO-263) 650 60 105 1.35 0.25 12 14 117 30 38 23 35 0.14
IGBT TRENCHSTOP™ 5 L5
IGW30N65L5 active and preferred 0.05 20 TO-247 650 120 227 1.05 0.47 33 11 308 51 168 62 85 1.35
IGBT TRENCHSTOP™ 5 H5
IGZ100N65H5 active and preferred 30 100 TO-247-4 650 400 536 1.65 0.85 30 9 421 15 210 101 161 0.77
IGW75N65H5 active and preferred 30 100 TO-247 650 300 395 1.65 2.25 28 33 174 41 160 75 120 0.95
IGZ75N65H5 active and preferred 30 100 TO-247-4 650 300 395 1.65 0.68 26 11 347 15 166 75 119 0.43
IGZ50N65H5 active and preferred 30 100 TO-247-4 650 200 273 1.65 0.41 20 7 250 21 109 54 85 0.19
IGB50N65H5 active and preferred 30 100 D2PAK (TO-263) 650 150 270 1.65 1.56 23 31 173 40 120 53.7 80 0.75
IGW50N65H5 active and preferred 30 100 TO-247 650 150 305 1.65 0.52 21 15 180 18 120 56 80 0.18
IGP40N65H5 active and preferred 30 100 TO-220 650 120 255 1.6 0.36 19 13 160 16 95 46 74 0.1
IGW40N65H5 active and preferred 30 100 TO-247 650 120 255 1.65 0.39 22 12 165 13 95 46 74 0.12
IGP30N65H5 active and preferred 30 100 TO-220 650 90 188 1.65 0.28 18 4 180 22 70 35 55 0.1
IGP20N65H5 active and preferred 30 100 TO-220 650 60 125 1.65 0.17 16 3 168 36 48 21 42 0.06
24
Discretes
Product Product Status Switching
Frequency
min [kHz]
Switching
Frequency
max [kHz]
Package Voltage Class
max
[V]
ICpuls
max
[A]
Ptot max
[W]
VCE(sat)
[V]
Eon
[mJ]
td(on)
[ns]
tr
[ns]
td(off)
[ns]
tf
[ns]
QGate
[nC]
IC @ 100°
max
[A]
IC @ 25°
max
[A]
Eoff Hard
Switching
[mJ]
IGBT TRENCHSTOP™
IGW60T120 active and preferred 2 20 TO-247 1200 150 375 2.3 6.4 50 45 600 130 280 60 100 9.4
IGW40T120 active and preferred 2 20 TO-247 1200 105 270 2.3 5 52 40 580 120 203 40 75 5.4
IGW25T120 active and preferred 2 20 TO-247 1200 75 190 2.2 3 50 32 660 130 155 25 50 4
IGW15T120 active and preferred 2 20 TO-247 1200 45 110 2.2 2 50 35 600 120 85 15 30 2.1
IGW08T120 active and preferred 2 20 TO-247 1200 24 70 2.2 1.08 40 26 570 140 53 8 16 1.2
IGW30N100T active and preferred 2 20 TO-247 1000 90 412 1.55 2.2 33 21 535 34 217 30 60 1.6
IGW75N60T active and preferred 2 20 TO-247 600 225 428 1.5 2 33 36 330 35 470 75 150 2.5
IGB50N60T active and preferred 2 20 D2PAK (TO-263) 600 150 333 1.5 1.2 26 29 299 29 310 90 64 1.4
IGP50N60T active and preferred 2 20 TO-220 600 150 333 1.5 1.2 26 29 299 29 310 64 90 1.4
IGW50N60T active and preferred 2 20 TO-247 600 150 333 1.5 1.2 26 29 299 29 310 64 90 1.4
IGB30N60T active and preferred 2 20 D2PAK (TO-263) 600 90 187 1.5 0.69 23 21 254 46 167 39 45 0.77
IGW30N60T active and preferred 2 20 TO-247 600 90 187 1.5 0.69 23 21 254 46 167 39 45 0.77
IGB15N60T active and preferred 2 20 D2PAK (TO-263) 600 45 130 1.5 0.22 17 11 188 50 87 23 26 0.35
IGP15N60T active and preferred 2 20 TO-220 600 45 130 1.5 0.22 17 11 188 50 87 23 26 0.35
IGB10N60T active and preferred 2 20 D2PAK (TO-263) 600 30 110 1.5 0.16 10 11 233 63 62 18 24 0.27
IGP10N60T active and preferred 2 20 TO-220 600 30 110 1.5 0.16 12 8 215 38 62 18 24 0.27
IGD06N60T active and preferred 2 20 DPAK (TO-252) 600 18 88 1.5 0.09 9 6 130 6 42 6 12 0.11
IGP06N60T active and preferred 2 20 TO-220 600 18 88 1.5 0.09 9 6 130 58 42 6 12 0.11
IGU04N60T active and preferred 2 20 TO-251 600 12 42 1.5 0.061 14 7 164 43 27 4 8 0.084
25
Discretes
Discrete IGBT without anti-parallel diode
Product Product Status Switching
Frequency
min [kHz]
Switching
Frequency
max [kHz]
Package Voltage Class
max
[V]
ICpuls
max
[A]
Ptot max
[W]
VCE(sat)
[V]
Eon
[mJ]
td(on)
[ns]
tr
[ns]
td(off)
[ns]
tf
[ns]
QGate
[nC]
IC @ 100°
max
[A]
IC @ 25°
max
[A]
Eoff Hard
Switching
[mJ]
IGBT Fast
SGB15N120 active and preferred 10 40 D2PAK (TO-263) 1200 52 198 3.7 1.9 38 30 652 31 130 15 30 1.5
SGP15N120 active and preferred 10 40 TO-220 1200 52 198 3.7 1.9 38 30 652 31 130 15 30 1.5
SGB07N120 active and preferred 10 40 D2PAK (TO-263) 1200 27 125 3.7 1 30 26 490 30 70 7.9 16.5 0.7
SGP07N120 active and preferred 10 40 TO-220 1200 27 125 3.7 1 30 26 490 30 70 7.9 16.5 0.7
SGB02N120 active and preferred 10 40 D2PAK (TO-263) 1200 9.6 62 3.7 0.27 26 14 290 85 11 2.8 6.2 0.11
SGD02N120 active and preferred 10 40 DPAK (TO-252) 1200 9.6 62 3.7 0.27 26 14 290 85 11 2.8 6.2 0.11
SGP02N120 active and preferred 10 40 TO-220 1200 9.6 62 3.7 0.27 26 14 290 85 11 2.8 6.2 0.11
IGBT HighSpeed 3
IGW40N120H3 active and preferred 20 100 TO-247 1200 160 483 2.05 3.2 30 57 290 16 185 40 80 1.2
IGW25N120H3 active and preferred 20 100 TO-247 1200 100 326 2.05 1.8 27 41 277 17 115 25 50 0.85
IGW15N120H3 active and preferred 20 100 TO-247 1200 60 217 2.05 1.1 21 34 260 14 75 15 30 0.45
IGW100N60H3 active and preferred 20 100 TO-247 600 300 714 1.85 3.7 30 47 265 30 625 120 140 1.9
IGW75N60H3 active and preferred 20 100 TO-247 600 225 428 1.85 3 31 60 265 27 470 75 140 1.7
IGW50N60H3 active and preferred 20 100 TO-247 600 200 333 1.85 1.45 23 37 235 24 315 50 100 0.91
IGW60N60H3 active and preferred 20 100 TO-247 600 180 416 1.85 2.1 27 44 252 27 375 60 80 1.13
IGW40N60H3 active and preferred 20 100 TO-247 600 160 306 1.95 1.1 19 33 197 21 223 40 80 0.58
IGB30N60H3 active and preferred 20 100 D2PAK (TO-263) 600 120 187 1.95 0.73 18 22 207 22 165 30 60 0.44
IGP30N60H3 active and preferred 20 100 TO-220 600 120 187 1.95 0.73 18 22 207 22 165 30 60 0.44
IGW30N60H3 active and preferred 20 100 TO-247 600 120 187 1.95 0.94 20 30 239 23 165 30 60 0.6
IGB20N60H3 active and preferred 20 100 D2PAK (TO-263) 600 80 170 1.95 0.45 16 20 194 11 120 20 40 0.24
IGP20N60H3 active and preferred 20 100 TO-220 600 80 170 1.95 0.45 16 194 194 11 120 20 40 0.24
IGW20N60H3 active and preferred 20 100 TO-247 600 80 170 1.95 0.56 17 23 194 11 120 20 40 0.24
26
Discretes
600 V / 1200 V ultra soft diode
Product Product Status Package name IF max
[A]
IF [A] I(FSM)
max
[A]
VF
[V]
VF max
[V]
IR max
[A]
Irrm
[A]
Qrr
[nC]
trr
[ns]
Ptot
max
[W]
RthJC
max
[K/W]
Operating
Temperature min
[°C]
Operating
Temperature max
[°C]
Mounting
1200 - Single
IDB30E120 active and preferred PG-TO263-3 50 30 102 1.65 1.65 100 23.7 2630 243 138 0.9 -55 °C 150 °C SMT
IDP30E120 active and preferred PG-TO220-2 50 30 102 1.65 1.65 100 23.7 2630 243 138 0.9 -55 °C 150 °C THT
IDP18E120 active and preferred PG-TO220-2 31 18 78 1.65 1.65 100 20.2 1880 195 113 1.1 -55 °C 150 °C THT
IDP12E120 active and preferred PG-TO220-2 28 12 63 1.65 1.65 100 17 1200 150 96 1.3 -55 °C 150 °C THT
600 V - Single
IDW100E60 active and preferred PG-TO247-3 150 100 400 1.65 1.65 40 3.6 120 375 0.4 -55 175 THT
IDW75E60 active and preferred PG-TO247-3 120 75 220 1.65 1.65 40 2400 121 300 0.5 -55 175 THT
IDW30E60 active and preferred PG-TO247-3 120 75 150 1.65 40 13 1200 143 143 1.05 -40 175 THT
IDW50E60 active and preferred PG-TO247-3 80 50 240 1.65 1.65 40 30 1500 115 187 0.8 -40 175 THT
IDP45E60 active and preferred PG-TO220-2 71 45 162 1.5 1.5 50 23 1400 140 187 0.8 -55 175 THT
IDB30E60 active and preferred PG-TO263-3 52.3 30 117 1.5 1.5 50 19 1100 126 142.9 1.05 -55 175 SMT
IDP30E60 active and preferred PG-TO220-2 52.3 30 117 1.5 1.5 50 19 1100 126 142.9 1.05 -55 175 THT
IDD15E60 active and preferred PG-TO252-3 29.2 15 60 1.5 2 50 13.7 595 87 83.3 1.8 -40 175 SMT
IDP15E60 active and preferred PG-TO220-2 29.2 15 60 1.5 1.5 50 13.7 595 87 83.3 1.8 -55 175 THT
IDB15E60 active and preferred PG-TO263-3 29.2 15 60 1.5 1.5 50 13.7 595 87 83.3 1.8 -55 175 SMT
IDD09E60 active and preferred PG-TO252-3 19.3 9 40 1.5 1.5 50 10.2 343 75 57.7 2.6 -55 175 SMT
IDD06E60 active and preferred PG-TO252-3 14.7 6 29 1.5 1.5 50 6.5 240 70 46.8 3.2 -55 175 SMT
27
Discretes
650 V Rapid 1 and Rapid 2 Diode
Product Product Status Package name IF max
[A]
IF [A] I(FSM)
max
[A]
VF max
[V]
VF
[V]
IR max
[A]
Irrm
[A]
Qrr
[C]
trr
[ns]
Ptot
max
[W]
RthJC
max
[K/W]
Operating
Temperature min
[°C]
Operating
Temperature max
[°C]
Mounting
650 V - Common Cathode
IDW80C65D1 active and preferred PG-TO247-3 80 40 320 1.7 1.35 40 6.9 0.49 129 179 0.84 -40 175 THT
IDW80C65D2 active and preferred PG-TO247-3 80 40 250 2.2 1.6 40 3.6 0.18 68 180 0.84 -40 175 THT
IDW60C65D1 active and preferred PG-TO247-3 60 30 240 1.7 1.35 40 5.4 0.45 115 142 1.06 -40 175 THT
IDW30C65D1 active and preferred PG-TO247-3 30 15 120 1.7 1.35 40 3.4 0.28 114 92 1.64 -40 175 THT
IDP30C65D2 active and preferred PG-TO220-3 30 15 100 2.2 1.6 40 5.4 0.16 42 92 1.63 -40 175 THT
IDW30C65D2 active and preferred PG-TO247-3 30 15 100 2.2 1.6 40 3.3 0.12 51 86 1.75 -40 175 THT
IDP20C65D2 active and preferred PG-TO220-3 20 10 60 2.2 1.6 40 4.3 0.13 50 68 2.2 -40 175 THT
IDW20C65D2 active and preferred PG-TO247-3 20 10 60 2.2 1.6 40 4.3 0.13 50 68 2.2 -40 175 THT
650 V - Dual Anode
IDW75D65D1 active and preferred PG-TO247-3 150 75 580 1.7 1.35 40 6.4 0.48 127 326 0.46 -40 175 THT
650 V - Single
IDW40E65D1 active and preferred PG-TO247-3 80 40 320 1.35 1.35 40 6.9 0.49 129 ns 179 0.84 -40 175 THT
IDW40E65D2 active and preferred PG-TO247-3 80 40 320 1.6 1.6 40 2.9 0.13 75 ns 180 0.84 -40 175 THT
IDP40E65D2 active and preferred PG-TO220-2 80 40 250 1.6 1.6 40 2.9 0.13 75 ns 200 0.75 -40 175 THT
IDW30E65D1 active and preferred PG-TO247-3 60 30 240 1.35 1.35 40 5.4 0.45 115 ns 142 1.06 -40 175 THT
IDP30E65D1 active and preferred PG-TO220-2 60 30 180 1.7 1.35 40 7 0.51 95 ns 143 1.05 -40 175 THT
IDP30E65D2 active and preferred PG-TO220-2 60 30 180 2.2 1.6 40 5.7 0.25 70 ns 143 1.05 -40 175 THT
IDFW40E65D1E active and preferred PG-TO247-3-AI 42 40 120 2.1 1.7 40 11 0.57 76 ns 78 1.92 -40 175 THT
IDP20E65D2 active and preferred PG-TO220-2 40 20 120 2.2 1.6 40 6.3 0.19 43 ns 120 1.25 -40 175 THT
IDV30E65D2 active and preferred PG-TO220-2 30 17.5 180 2.2 1.6 40 5.7 0.25 70 ns 47 3.2 -40 175 THT
IDP15E65D1 active and preferred PG-TO220-2 30 15 120 1.35 1.35 40 3.4 0.28 114 ns 92 1.64 -40 175 THT
IDP15E65D2 active and preferred PG-TO220-2 30 15 100 1.6 1.6 40 3.3 0.07 47 ns 92 1.63 -40 175 THT
IDW15E65D2 active and preferred PG-TO247-3 30 15 100 1.6 1.6 40 3.3 0.07 nC 47 ns 85.7 1.75 -40 175 THT
IDV20E65D1 active and preferred PG-TO220-2 28 15 120 1.7 1.35 40 7.6 0.31 65 ns 38 4 -40 175 THT
IDP08E65D1 active and preferred PG-TO220-2 16 8 64 1.35 1.35 40 2.8 0.17 80 ns 56 2.69 -40 175 THT
IDP08E65D2 active and preferred PG-TO220-2 16 8 60 1.6 1.6 40 2.5 0.08 40 ns 56 2.69 -40 175 THT
IDV15E65D2 active and preferred PG-TO220-2 15 15 100 1.6 1.6 40 3.3 0.07 47 ns 34 4.4 -40 175 THT
IDV08E65D2 active and preferred PG-TO220-2 8 8 60 1.6 1.6 40 2.5 0.08 40 ns 27.3 5.5 -40 175 THT
28
Discretes
29
Discretes
, 'HEIH” I u , ulnnlmnuum nm-mnmrlml mmlmgumml mllll”| mmm , IlmllH .Wu
30
We offer module concepts providing electrical performance and highest reliability without limiting
the design flexibility.
IGBT modules
Low, medium and high power IGBT modules
31
IGBT
modules
o 5 we MD 1500
IGBT package overview
1 2 3 4 6 8 10 15 25 30 40 50 75 100 150 200 400 500 600 800 1000 2000 3000
IC[A]
P[kW]
3600
450 900 1500
20
TO-252 DPAK
600 V
TO-251
IPAK
600 V
TO-263 D2PAK
600 V 1200 V
TO-220
600 V 650 V 1200 V
TO-247, TO-247PLUS 3pin, TO-247PLUS 4pin
600 V 650 V 1100 V 1200 V 1350 V 1600 V
EasyPIM™/EasyPACK
600 V 650 V 1200 V
SmartPIM/SmartPack
600 V 1200 V
MIPAQ™
1200 V
EconoPACK™4
600 V 1200 V 1700 V
EconoPACK™ +
600 V 1700 V
EconoDUAL™
600 V 650 V 1200 V 1700 V
34 mm
600 V 1200 V 1700 V
62 mm
600 V 650 V 1200 V 1700 V
PrimePACK™
1200 V 1700 V
IHM
1200 V 1600 V 1700 V
XHP™3
3300 V 4500 V 6500 V
IHV
3300 V 4500 V 6500 V
EconoPIM™/EconoPACK™
600 V 650V 1200 V 1700 V
TO-220 FullPAK
600 V 650 V
32
IGBT
modules
IGBT modules up to 650 V
62 mm
FD300R06KE3 active and preferred Chopper 600 300 IGBT3 - E3 62 mm 1.45 1.55 106.4 61.4 -
FF400R06KE3 active and preferred Dual 600 400 IGBT3 - E3 62 mm 1.45 1.55 106.4 61.4 -
FF400R07KE4 active and preferred Dual 650 400 IGBT4 - E4 62 mm 1.55 1.55 106.4 61.4 -
FF300R06KE3_B2 active and preferred Dual 600 300 IGBT3 - E3 62 mm 1.45 1.55 106.4 61.4 M5 power terminals
FF300R06KE3 active and preferred Dual 600 300 IGBT3 - E3 62 mm 1.45 1.55 106.4 61.4 -
FF300R07KE4 active and preferred Dual 650 300 IGBT4 - E4 62 mm 1.55 1.55 106.4 61.4 -
FF200R06KE3 active and preferred Dual 600 200 IGBT3 - E3 62 mm 1.45 1.55 106.4 61.4 -
EasyPACK™ 1B
F3L50R06W1E3_B11 active and preferred 3-level 600 50 IGBT3 - E3 EasyPACK™ 1B 1.45 1.55 48 33.8 Phase leg, PressFIT
DF100R07W1H5FP_B54 active and preferred Booster with NTC 650 100 TRENCHSTOP™ 5 EasyPACK™ 1B 1.35 1.6 48 33.8 SiC Schottky diode,
TIM, PressFIT
DF100R07W1H5FP_B53 active and preferred Booster with NTC 650 100 TRENCHSTOP™ 5 EasyPACK™ 1B 1.35 1.6 48 33.8 SiC Schottky diode,
TIM, PressFIT
F4-75R06W1E3 active and preferred Fourpack 600 75 IGBT3 - E3 EasyPACK™ 1B 1.45 1.55 48 33.8 -
FS50R06W1E3 active and preferred Sixpack 600 50 IGBT3 - E3 EasyPACK™ 1B 1.45 1.55 48 33.8 -
FS50R06W1E3_B11 active and preferred Sixpack 600 50 IGBT3 - E3 EasyPACK™ 1B 1.45 1.55 48 33.8 PressFIT
FS30R06W1E3 active and preferred Sixpack 600 30 IGBT3 - E3 EasyPACK™ 1B 1.55 1.6 48 33.8 -
FS30R06W1E3_B11 active and preferred Sixpack 600 30 IGBT3 - E3 EasyPACK™ 1B 1.55 1.6 48 33.8 PressFIT
FS20R06W1E3 active and preferred Sixpack 600 20 IGBT3 - E3 EasyPACK™ 1B 1.55 1.6 48 33.8 -
FS20R06W1E3_B11 active and preferred Sixpack 600 20 IGBT3 - E3 EasyPACK™ 1B 1.55 1.6 48 33.8 PressFIT
Product Product Status Configuration Voltage Class
[V]
IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
33
IGBT
modules
IGBT modules up to 650 V
EasyPIM™ 1B
FB30R06W1E3 active PIM Single Phase Input Rectifier 600 30 A IGBT3 - E3 EasyPIM™ 1B 1.55 1.6 48 33.8 -
FB20R06W1E3 active PIM Single Phase Input Rectifier 600 20 A IGBT3 - E3 EasyPIM™ 1B 1.55 1.6 48 33.8 -
FB20R06W1E3_B11 active PIM Single Phase Input Rectifier 600 20 A IGBT3 - E3 EasyPIM™ 1B 1.55 1.6 48 33.8 PressFIT
FP30R06W1E3 active and preferred PIM Three Phase Input Rectifier 600 30 A IGBT3 - E3 EasyPIM™ 1B 1.55 1.6 48 33.8 -
FP30R06W1E3_B11 active and preferred PIM Three Phase Input Rectifier 600 30 A IGBT3 - E3 EasyPIM™ 1B 1.55 1.6 48 33.8 PressFIT
FP20R06W1E3 active and preferred PIM Three Phase Input Rectifier 600 20 A IGBT3 - E3 EasyPIM™ 1B 1.55 1.6 48 33.8 -
FP20R06W1E3_B11 active and preferred PIM Three Phase Input Rectifier 600 20 A IGBT3 - E3 EasyPIM™ 1B 1.55 1.6 48 33.8 PressFIT
FP15R06W1E3 active and preferred PIM Three Phase Input Rectifier 600 15 A IGBT3 - E3 EasyPIM™ 1B 1.55 1.6 48 33.8 -
FP15R06W1E3_B11 active and preferred PIM Three Phase Input Rectifier 600 15 A IGBT3 - E3 EasyPIM™ 1B 1.55 1.6 48 33.8 PressFIT
FP10R06W1E3 active and preferred PIM Three Phase Input Rectifier 600 10 A IGBT3 - E3 EasyPIM™ 1B 1.55 1.6 48 33.8 -
FP10R06W1E3_B11 active and preferred PIM Three Phase Input Rectifier 600 10 A IGBT3 - E3 EasyPIM™ 1B 1.55 1.6 48 33.8 PressFIT
EasyPIM™ 2B
FP50R06W2E3 active and preferred PIM Three Phase Input Rectifier 600 50 A IGBT3 - E3 EasyPIM™ 2B 1.45 1.55 56.7 48 -
FP50R06W2E3_B11 active and preferred PIM Three Phase Input Rectifier 600 50 A IGBT3 - E3 EasyPIM™ 2B 1.45 1.55 56.7 48 PressFIT
Product Product Status Configuration Voltage Class
[V]
IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
EasyPACK™ 2B
F3L100R07W2E3_B11 active and preferred 3-level 650 100 IGBT3 - E3 EasyPACK™ 2B 1.45 1.55 56.7 48 Phase leg, PressFIT
F3L150R07W2E3_B11 active and preferred 3-level 650 150 IGBT3 - E3 EasyPACK™ 2B 1.45 1.55 56.7 48 Phase leg, PressFIT
F3L75R07W2E3_B11 active and preferred 3-level 650 75 IGBT3 - E3 EasyPACK™ 2B 1.45 1.55 56.7 48 Phase leg, PressFIT
FS3L50R07W2H3F_B11 active and preferred 3-level 650 50 IGBT HighSpeed 3 EasyPACK™ 2B 1.45 1.6 56.7 48 SiC Schottky diode,
Full-bridge, PressFIT
F3L225R07W2H3P_B63 active and preferred 3-level phase leg with NTC 650 225 IGBT HighSpeed 3 EasyPACK™ 2B 1.4 1.55 56.7 48 TIM, Phase leg,
PressFIT
F4-75R07W2H3_B51 active and preferred Fourpack 650 75 IGBT High Speed 3 EasyPACK™ 2B 1.35 1.45 56.7 48 SiC Schottky diode,
PressFIT
F4-3L50R07W2H3F_B11 active and preferred Fourpack 650 50 IGBT3 - E3 EasyPACK™ 2B 1.45 1.6 56.7 48 SiC Schottky diode,
PressFIT
34
IGBT
modules
EconoDUAL™ 3
F3L400R07ME4_B22 active and preferred 3-level 650 400 A IGBT4 - E4 EconoDUAL™ 3 1.55 1.55 152 62 Phase leg
F3L400R07ME4_B23 active and preferred 3-level 650 400 A IGBT4 - E4 EconoDUAL™ 3 1.55 1.55 152 62 Phase leg
FD600R06ME3_S2 active and preferred Chopper 600 600 A IGBT3 - E3 EconoDUAL™ 3 1.3 1.15 152 62 -
FF600R07ME4_B11 active and preferred Dual 650 600 A IGBT4 - E4 EconoDUAL™ 3 1.55 1.55 152 62 PressFIT
FF450R07ME4_B11 active and preferred Dual 650 450 A IGBT4 - E4 EconoDUAL™ 3 1.55 1.55 152 62 PressFIT
FF300R07ME4_B11 active and preferred Dual 650 300 A IGBT4 - E4 EconoDUAL™ 3 1.55 1.55 152 62 PressFIT
EconoPACK™ 2
FS100R07N2E4 active and preferred Sixpack 650 100 A IGBT4 - E4 EconoPACK™ 2 1.55 1.55 107.5 45 -
FS100R07N2E4_B11 active and preferred Sixpack 650 100 A IGBT4 - E4 EconoPACK™ 2 1.55 1.55 107.5 45 PressFIT
FS75R07N2E4 active and preferred Sixpack 650 75 A IGBT4 - E4 EconoPACK™ 2 1.55 1.55 107.5 45 -
FS75R07N2E4_B11 active and preferred Sixpack 650 75 A IGBT4 - E4 EconoPACK™ 2 1.55 1.55 107.5 45 PressFIT
FS75R06KE3 active and preferred Sixpack 650 75 A IGBT3 - E3 EconoPACK™ 2 1.45 1.55 107.5 45 -
FS50R07N2E4 active and preferred Sixpack 650 50 A IGBT4 - E4 EconoPACK™ 2 1.55 1.55 107.5 45 -
FS50R06KE3 active and preferred Sixpack 650 50 A IGBT3 - E3 EconoPACK™ 2 1.45 1.55 107.5 45 -
EconoPACK™ 3
F5-75R06KE3_B5 active and preferred Fourpack 600 75 A IGBT3 - E3 EconoPACK™ 3 1.45 1.55 122 62 PressFIT
FS200R07N3E4R active and preferred Sixpack 650 200 A IGBT4 - E4 EconoPACK™ 3 1.55 1.55 122 62 -
FS200R07N3E4R_B11 active and preferred Sixpack 650 200 A IGBT4 - E4 EconoPACK™ 3 1.55 1.55 122 62 PressFIT
FS200R06KE3 active and preferred Sixpack 600 200 A IGBT3 - E3 EconoPACK™ 3 1.45 1.55 122 62 -
FS150R07N3E4 active and preferred Sixpack 650 150 A IGBT4 - E4 EconoPACK™ 3 1.55 1.55 122 62 -
FS150R07N3E4_B11 active and preferred Sixpack 650 150 A IGBT4 - E4 EconoPACK™ 3 1.55 1.55 122 62 PressFIT
FS150R06KE3 active and preferred Sixpack 600 150 A IGBT3 - E3 EconoPACK™ 3 1.45 1.55 122 62 -
FS100R07N3E4 active and preferred Sixpack 650 100 A IGBT4 - E4 EconoPACK™ 3 1.55 1.55 122 62 -
FS100R07N3E4_B11 active and preferred Sixpack 650 100 A IGBT4 - E4 EconoPACK™ 3 1.55 1.55 122 62 PressFIT
FS100R06KE3 active and preferred Sixpack 600 100 A IGBT3 - E3 EconoPACK™ 3 1.45 1.55 122 62 -
Product Product Status Configuration Voltage Class
[V]
IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
35
IGBT
modules
IGBT modules up to 650 V
EconoPIM™ 3
FP150R07N3E4 active and preferred PIM Three Phase Input Rectifier 650 150 IGBT4 - E4 EconoPIM™ 3 1.55 1.55 122 62 -
FP150R07N3E4_B11 active and preferred PIM Three Phase Input Rectifier 650 150 IGBT4 - E4 EconoPIM™ 3 1.55 1.55 122 62 PressFIT
FP100R07N3E4 active and preferred PIM Three Phase Input Rectifier 650 100 IGBT4 - E4 EconoPIM™ 3 1.55 1.55 122 62 -
FP100R07N3E4_B11 active and preferred PIM Three Phase Input Rectifier 650 100 IGBT4 - E4 EconoPIM™ 3 1.55 1.55 122 62 PressFIT
FP100R06KE3 active and preferred PIM Three Phase Input Rectifier 600 100 IGBT3 - E3 EconoPIM™ 3 1.45 1.55 122 62 -
FP75R06KE3 active and preferred PIM Three Phase Input Rectifier 600 75 IGBT3 - E3 EconoPIM™ 3 1.45 1.55 122 62 -
SmartPACK 1
FS75R07U1E4 active and preferred Sixpack 650 75 IGBT4 - E4 SmartPACK 1 1.55 1.55 69.5 44 PressFIT
Product Product Status Configuration Voltage Class
[V]
IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
EconoPIM™ 2
FP75R07N2E4 active and preferred PIM Three Phase Input Rectifier 650 75 IGBT4 - E4 EconoPIM™ 2 1.55 1.55 107 45 -
FP75R07N2E4_B11 active and preferred PIM Three Phase Input Rectifier 650 75 IGBT4 - E4 EconoPIM™ 2 1.55 1.55 107 45 PressFIT
FP50R07N2E4 active and preferred PIM Three Phase Input Rectifier 650 50 IGBT4 - E4 EconoPIM™ 2 1.55 1.55 107 45 -
FP50R07N2E4_B11 active and preferred PIM Three Phase Input Rectifier 650 50 IGBT4 - E4 EconoPIM™ 2 1.55 1.55 107 45 PressFIT
FP50R06KE3 active and preferred PIM Three Phase Input Rectifier 600 50 IGBT3 - E3 EconoPIM™ 2 1.45 1.55 107 45 -
FP30R06KE3 active and preferred PIM Three Phase Input Rectifier 600 30 IGBT3 - E3 EconoPIM™ 2 1.55 1.6 107 45 -
EconoPACK™ 4
F3L300R07PE4 active and preferred 3-level 650 300 IGBT4 - E4 EconoPACK™ 4 1.55 1.55 130 70.6 Phase leg
F3L300R07PE4P active and preferred 3-level 650 300 IGBT4 - E4 EconoPACK™ 4 1.55 1.55 130 70.6 Phase leg
F3L200R07PE4 active and preferred 3-level 650 200 IGBT4 - E4 EconoPACK™ 4 1.55 1.55 130 70.6 Phase leg
FD400R07PE4R_B6 active and preferred Chopper 650 400 IGBT4 - E4 EconoPACK™ 4 1.55 1.55 130 70.6 -
DF300R07PE4_B6 active and preferred Chopper 650 300 IGBT4 - E4 EconoPACK™ 4 1.55 1.55 130 70.6 -
FD300R07PE4_B6 active and preferred Chopper 650 300 IGBT4 - E4 EconoPACK™ 4 1.55 1.55 130 70.6 -
FS200R07PE4 active and preferred Sixpack 650 200 IGBT4 - E4 EconoPACK™ 4 1.55 1.55 130 70.6 PressFIT
FS150R07PE4 active and preferred Sixpack 650 150 IGBT4 - E4 EconoPACK™ 4 1.55 1.55 130 70.6 PressFIT
FS100R07PE4 active and preferred Sixpack 650 100 IGBT4 - E4 EconoPACK™ 4 1.55 1.55 130 70.6 PressFIT
36
IGBT
modules
62 mm
DF400R12KE3 active and preferred Chopper 400 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
FD400R12KE3 active and preferred Chopper 400 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
DF300R12KE3 active and preferred Chopper 300 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
FD300R12KE3 active and preferred Chopper 300 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
FD300R12KS4 active Chopper 300 IGBT2 Fast 62 mm 3.2 2 106.4 61.4 -
DF200R12KE3 active and preferred Chopper 200 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
FD200R12KE3 active and preferred Chopper 200 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
FD200R12KE3P active and preferred Chopper 200 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 TIM
FF600R12KE4_E active and preferred Common Emitter 600 IGBT4 - E4 62 mm 1.75 1.7 106.4 61.4 -
FF450R12KE4_E active and preferred Common Emitter 450 IGBT4 - E4 62 mm 1.75 1.7 106.4 61.4 -
FF400R12KT3_E active Common Emitter 400 IGBT3 - T3 62 mm 1.7 1.65 106.4 61.4 Phase leg
FF400R12KT3P_E active and preferred Common Emitter 400 IGBT3 - T3 62 mm 1.7 1.65 106.4 61.4 TIM, Phase lag
FF300R12KE4_E active and preferred Common Emitter 300 IGBT4 - E4 62 mm 1.75 1.65 106.4 61.4 -
FF300R12KT3_E active Common Emitter 300 IGBT3 - T3 62 mm 1.7 1.65 106.4 61.4 Phase leg
FF300R12KT3P_E active and preferred Common Emitter 300 IGBT3 - T3 62 mm 1.7 1.65 106.4 61.4 Phase leg
FF200R12KT3_E active Common Emitter 200 IGBT3 - T3 62 mm 1.7 1.65 106.4 61.4 Phase leg
FF600R12KE4 active and preferred Dual 600 IGBT4 - E4 62 mm 1.75 1.7 106.4 61.4 -
FF450R12KE4 active and preferred Dual 450 IGBT4 - E4 62 mm 1.75 1.7 106.4 61.4 -
FF450R12KE4P active and preferred Dual 450 IGBT4 - E4 62 mm 1.75 1.7 106.4 61.4 TIM
FF450R12KT4 active and preferred Dual 450 IGBT4 - T4 62 mm 1.75 1.7 106.4 61.4 -
FF450R12KT4P active and preferred Dual 450 IGBT4 - T4 62 mm 1.75 1.7 106.4 61.4 TIM
FF400R12KT4P active and preferred Dual 400 IGBT4 - T4 62 mm 1.65 1.65 106.4 61.4 -
IGBT modules up to 1200 V
34 mm
FD150R12RT4 active and preferred Chopper 150 IGBT4 - T4 34 mm 1.75 1.75 94 34 -
DF150R12RT4 active and preferred Chopper 150 IGBT4 - T4 34 mm 1.75 1.75 94 34 -
FF150R12RT4 active and preferred Dual 150 IGBT4 - T4 34 mm 1.75 1.75 94 34 -
FF100R12RT4 active and preferred Dual 100 IGBT4 - T4 34 mm 1.75 1.75 94 34 -
FF75R12RT4 active and preferred Dual 75 IGBT4 - T4 34 mm 1.85 1.7 94 34 -
FF50R12RT4 active and preferred Dual 50 IGBT4 - T4 34 mm 1.85 1.75 94 34 -
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
37
IGBT
modules
IGBT modules up to 1200 V
62 mm
FF400R12KE3 active Dual 400 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
FF400R12KE3_B2 active Dual 400 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 M5 power terminals
FF400R12KT3 active Dual 400 IGBT3 - T3 62 mm 1.7 1.65 106.4 61.4 -
FF300R12KE4 active and preferred Dual 300 IGBT4 - E4 62 mm 1.75 1.65 106.4 61.4 -
FF300R12KE4P active and preferred Dual 300 IGBT4 - E4 62 mm 1.75 1.65 106.4 61.4 TIM
FF300R12KE4_B2 active and preferred Dual 300 IGBT4 - E4 62 mm 1.75 1.65 106.4 61.4 M5 power terminals
FF300R12KT4 active and preferred Dual 300 IGBT4 - T4 62 mm 1.75 1.65 106.4 61.4 -
FF300R12KT4P active and preferred Dual 300 IGBT4 - T4 62 mm 1.75 1.65 106.4 61.4 TIM
FF300R12KE3 active Dual 300 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
FF300R12KT3 active Dual 300 IGBT3 - T3 62 mm 1.7 1.65 106.4 61.4 -
FF300R12KS4 active Dual 300 IGBT2 Fast 62 mm 3.2 2 106.4 61.4 -
FF300R12KS4P active and preferred Dual 300 IGBT2 Fast 62 mm 3.2 2 106.4 61.4 TIM
FF200R12KE4 active and preferred Dual 200 IGBT4 - E4 62 mm 1.75 1.65 106.4 61.4 -
FF200R12KE4P active and preferred Dual 200 IGBT4 - E4 62 mm 1.75 1.65 106.4 61.4 TIM
FF200R12KT4 active and preferred Dual 200 IGBT4 - T4 62 mm 1.75 1.65 106.4 61.4 -
FF200R12KE3 active Dual 200 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
FF200R12KT3 active Dual 200 IGBT3 - T3 62 mm 1.7 1.65 106.4 61.4 -
FF200R12KS4 active Dual 200 IGBT2 Fast 62 mm 3.2 2 106.4 61.4 -
FF150R12KE3G active Dual 150 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
FF150R12KT3G active Dual 150 IGBT3 - T3 62 mm 1.7 1.65 106.4 61.4 -
FF150R12KS4 active Dual 150 IGBT2 Fast 62 mm 3.2 2 106.4 61.4 -
FF150R12KS4_B2 active Dual 150 IGBT2 Fast 62 mm 3.2 2 106.4 61.4 M5 power terminals
FF100R12KS4 active Dual 100 IGBT2 Fast 62 mm 3.2 2 106.4 61.4 -
FZ900R12KE4 active and preferred Single switch 900 IGBT4 - E4 62 mm 1.75 1.9 106.4 61.4 -
FZ900R12KP4 active and preferred Single switch 900 IGBT4 - P4 62 mm 1.7 1.9 106.4 61.4 -
FZ800R12KE3 active Single switch 800 IGBT3 - E3 62 mm 1.7 2.2 106.4 61.4 -
FZ600R12KE4 active and preferred Single switch 600 IGBT4 - E4 62 mm 1.75 1.8 106.4 61.4 -
FZ600R12KP4 active and preferred Single switch 600 IGBT4 - P4 62 mm 1.7 1.8 106.4 61.4 -
FZ600R12KE3 active Single switch 600 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
FZ600R12KS4 active Single switch 600 IGBT2 Fast 62 mm 3.2 2 106.4 61.4 -
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
38
IGBT
modules
62 mm
FZ400R12KE4 active and preferred Single switch 400 IGBT4 - E4 62 mm 1.75 1.65 106.4 61.4 -
FZ400R12KP4 active and preferred Single switch 400 IGBT4 - P4 62 mm 1.7 1.65 106.4 61.4 -
FD400R12KE3_B5 active Single switch 400 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
FZ400R12KE3 active Single switch 400 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
FZ400R12KE3B1 active Single switch 400 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
FZ400R12KS4 active Single switch 400 IGBT2 Fast 62 mm 3.2 2 106.4 61.4 -
FZ400R12KS4P active and preferred Single switch 400 IGBT2 Fast 62 mm 3.2 2 61.4 106.4 -
FZ300R12KE3G active Single switch 300 IGBT3 - E3 62 mm 1.7 1.65 106.4 61.4 -
FD300R12KS4_B5 active Single switch 300 IGBT2 Fast 62 mm 3.2 2 106.4 61.4 -
EasyPACK™ 1B
F3L75R12W1H3_B11 active and preferred 3-level 75 IGBT HighSpeed 3 EasyPACK™ 1B 1.45 2.15 48 33.8 Phase leg, PressFIT
F3L75R12W1H3_B27 active and preferred 3-level 75 IGBT HighSpeed 3 EasyPACK™ 1B 1.45 1.85 48 33.8 Phase leg, PressFIT
F3L25R12W1T4_B27 active 3-level 25 IGBT4 - T4 EasyPACK™ 1B 1.85 1.35 48 33.8 Phase leg, PressFIT
DF200R12W1H3F_B11 active and preferred Booster with NTC 200 IGBT HighSpeed 3 EasyPACK™ 1B 1.3 1.6 48 33.8 SiC Schottky diode, PressFIT
DF200R12W1H3_B27 active Booster with NTC 200 IGBT HighSpeed 3 EasyPACK™ 1B 1.3 2 48 33.8 PressFIT
DF75R12W1H4F_B11 active and preferred Chopper 75 IGBT HighSpeed 2 EasyPACK™ 1B 2.1 1.6 48 33.8 SiC Schottky diode, PressFIT
FS35R12W1T4 active and preferred Sixpack 35 IGBT4 - T4 EasyPACK™ 1B 1.85 1.65 48 33.8 -
FS35R12W1T4_B11 active and preferred Sixpack 35 IGBT4 - T4 EasyPACK™ 1B 1.85 1.65 48 33.8 PressFIT
FS25R12W1T4 active and preferred Sixpack 25 IGBT4 - T4 EasyPACK™ 1B 1.85 1.75 48 33.8 -
FS25R12W1T4_B11 active and preferred Sixpack 25 IGBT4 - T4 EasyPACK™ 1B 1.85 1.75 48 33.8 PressFIT
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
39
IGBT
modules
IGBT modules up to 1200 V
EasyPACK™ 2B
F3L200R12W2H3_B11 active and preferred 3-level phase leg with NTC 200 IGBT HighSpeed 3 EasyPACK™ 2B 1.55 1.65 56.7 48 Phase leg, PressFIT
F3L150R12W2H3_B11 active and preferred 3-level phase leg with NTC 150 IGBT HighSpeed 3 EasyPACK™ 2B 1.55 1.45 56.7 48 Phase leg, PressFIT
F3L100R12W2H3_B11 active and preferred 3-level phase leg with NTC 100 IGBT HighSpeed 3 EasyPACK™ 2B 1.55 1.35 56.7 48 Phase leg, PressFIT
FS3L25R12W2H3_B11 active and preferred 3-level full-bridge with NTC 25 IGBT HighSpeed 3 EasyPACK™ 2B 2.05 1.75 56.7 48 PressFIT
F3L15R12W2H3_B27 active and preferred 3-level full-bridge with NTC 15 IGBT HighSpeed 3 EasyPACK™ 2B 2.05 1.75 56.7 48 Full-bridge, PressFIT
DF160R12W2H3F_B11 active and preferred Booster with NTC 160 IGBT HighSpeed 3 EasyPACK™ 2B 1.55 1.6 56.7 48 SiC Schottky diode, PressFIT
DF120R12W2H3_B27 active and preferred Booster with NTC 120 IGBT HighSpeed 3 EasyPACK™ 2B 2.05 2 56.7 48 PressFIT
DF80R12W2H3F_B11 active and preferred Booster with NTC 80 IGBT HighSpeed 3 EasyPACK™ 2B 1.55 1.6 56.7 48 SiC Schottky diode, PressFIT
FS75R12W2T4 active and preferred Sixpack 75 IGBT4 - T4 EasyPACK™ 2B 1.85 1.7 56.7 48 -
FS75R12W2T4_B11 active and preferred Sixpack 75 IGBT4 - T4 EasyPACK™ 2B 1.85 1.7 56.7 48 PressFIT
FS50R12W2T4 active and preferred Sixpack 50 IGBT4 - T4 EasyPACK™ 2B 1.85 1.7 56.7 48 -
FS50R12W2T4_B11 active and preferred Sixpack 50 IGBT4 - T4 EasyPACK™ 2B 1.85 1.7 56.7 48 PressFIT
EasyPIM™ 1B
FP15R12W1T4 active and preferred PIM Three Phase Input Rectifier 15 IGBT4 - T4 EasyPIM™ 1B 1.85 2 48 33.8 -
FP15R12W1T4P active and preferred PIM Three Phase Input Rectifier 15 IGBT4 - T4 EasyPIM™ 1B 1.85 2 48 33.8 -
FP15R12W1T4_B11 active and preferred PIM Three Phase Input Rectifier 15 IGBT4 - T4 EasyPIM™ 1B 1.85 2 48 33.8 PressFIT
FP15R12W1T4P_B11 active and preferred PIM Three Phase Input Rectifier 15 IGBT4 - T4 EasyPIM™ 1B 1.85 2 48 33.8 TIM, PressFIT
FP15R12W1T4_B3 active PIM Three Phase Input Rectifier 15 IGBT4 - T4 EasyPIM™ 1B 1.85 2 48 33.8 -
FP10R12W1T4 active and preferred PIM Three Phase Input Rectifier 10 IGBT4 - T4 EasyPIM™ 1B 1.85 1.75 48 33.8 -
FP10R12W1T4P active and preferred PIM Three Phase Input Rectifier 10 IGBT4 - T4 EasyPIM™ 1B 1.85 1.75 48 33.8 -
FP10R12W1T4_B11 active and preferred PIM Three Phase Input Rectifier 10 IGBT4 - T4 EasyPIM™ 1B 1.85 1.75 48 33.8 PressFIT
FP10R12W1T4P_B11 active and preferred PIM Three Phase Input Rectifier 10 IGBT4 - T4 EasyPIM™ 1B 1.85 1.75 48 33.8 TIM, PressFIT
FP10R12W1T4_B3 active PIM Three Phase Input Rectifier 10 IGBT4 - T4 EasyPIM™ 1B 1.85 1.75 48 33.8 -
FP06R12W1T4_B3 active PIM Three Phase Input Rectifier 6 IGBT4 - T4 EasyPIM™ 1B 1.5 1.45 48 33.8 -
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
40
IGBT
modules
EasyPIM™ 2B
FP35R12W2T4 active and preferred PIM Three Phase Input Rectifier 35 IGBT4 - T4 EasyPIM™ 2B 1.85 1.65 56.7 48 -
FP35R12W2T4P active and preferred PIM Three Phase Input Rectifier 35 IGBT4 - T4 EasyPIM™ 2B 1.85 1.65 56.7 48 TIM
FP35R12W2T4_B11 active and preferred PIM Three Phase Input Rectifier 35 IGBT4 - T4 EasyPIM™ 2B 1.85 1.65 56.7 48 PressFIT
FP35R12W2T4P_B11 active and preferred PIM Three Phase Input Rectifier 35 IGBT4 - T4 EasyPIM™ 2B 1.85 1.65 56.7 48 TIM, PressFIT
FP25R12W2T4 active and preferred PIM Three Phase Input Rectifier 25 IGBT4 - T4 EasyPIM™ 2B 1.85 1.75 56.7 48 -
FP25R12W2T4P active and preferred PIM Three Phase Input Rectifier 25 IGBT4 - T4 EasyPIM™ 2B 1.85 1.75 56.7 48 -
FP25R12W2T4_B11 active and preferred PIM Three Phase Input Rectifier 25 IGBT4 - T4 EasyPIM™ 2B 1.85 1.75 56.7 48 PressFIT
FP25R12W2T4P_B11 active and preferred PIM Three Phase Input Rectifier 25 IGBT4 - T4 EasyPIM™ 2B 1.85 1.75 56.7 48 TIM, PressFIT
FP15R12W2T4 active and preferred PIM Three Phase Input Rectifier 15 IGBT4 - T4 EasyPIM™ 2B 1.85 1.75 56.7 48 -
EconoDUAL™ 3
F3L300R12ME4_B22 active and preferred 3-level 300 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 Phase leg
F3L300R12ME4_B23 active and preferred 3-level 300 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 Phase leg
F3L300R12MT4_B22 active and preferred 3-level 300 IGBT4 - T4 EconoDUAL™ 3 1.75 1.65 152 62 Phase leg
F3L300R12MT4P_B22 active and preferred 3-level 300 IGBT4 - T4 EconoDUAL™ 3 1.75 1.65 152 62 TIM, Phase leg
F3L300R12MT4_B23 active and preferred 3-level 300 IGBT4 - T4 EconoDUAL™ 3 1.75 1.65 152 62 Phase leg
F3L300R12MT4P_B23 active and preferred 3-level 300 IGBT4 - T4 EconoDUAL™ 3 1.75 1.65 152 62 TIM, Phase leg
FF600R12ME4E_B11 active and preferred Common Emitter 600 IGBT - E4 EconoDUAL™ 3 1.75 1.65 152 62 PressFIT
FF450R12ME4E_B11 active and preferred Common Emitter 450 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 PressFIT
FF600R12ME4 active Dual 600 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 -
FF600R12ME4P active Dual 600 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 TIM
FF600R12ME4_B11 active Dual 600 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 PressFIT
FF600R12ME4P_B11 active and preferred Dual 600 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 TIM, PressFIT
FF600R12ME4C active Dual 600 IGBT4 - E4 EconoDUAL™ 3 1.75 1.9 152 62 -
FF600R12ME4C_B11 active and preferred Dual 600 IGBT4 - E4 EconoDUAL™ 3 1.75 1.9 152 62 PressFIT
FF600R12ME4_B73 active and preferred Dual 600 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 -
FF600R12ME4_B72 active and preferred Dual 600 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 -
FF600R12ME4A_B11 active and preferred Dual 600 IGBT4 - E3 EconoDUAL™ 3 1.75 1.9 152 62 PressFIT
IFF600B12ME4S8P_B11 active and preferred Dual 600 IGBT4 - E4 EconoDUAL™ 3 1.75 1.9 152 62 TIM, PressFIT
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
41
IGBT
modules
IGBT modules up to 1200 V
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
EconoPACK™ + D
FS450R12OE4 active and preferred Sixpack 450 IGBT4 - E4 EconoPACK™ + D 1.75 1.65 162 150 PressFIT
FS450R12OE4P active and preferred Sixpack 450 IGBT4 - E4 EconoPACK™ + D 1.75 1.65 162 150 TIM, PressFIT
FS300R12OE4 active and preferred Sixpack 300 IGBT4 - E4 EconoPACK™ + D 1.75 1.65 162 150 PressFIT
FS300R12OE4P active and preferred Sixpack 300 IGBT4 - E4 EconoPACK™ + D 1.75 1.65 162 150 TIM, PressFIT
FS225R12OE4 active and preferred Sixpack 225 IGBT4 - E4 EconoPACK™ + D 1.85 1.65 162 150 PressFIT
FS225R12OE4P active and preferred Sixpack 225 IGBT4 - E4 EconoPACK™ + D 1.85 1.65 162 150 TIM, PressFIT
EconoDUAL™ 3
IFF600B12ME4P_B11 active and preferred Dual 600 IGBT4 - E4 EconoDUAL™ 3 1.75 1.8 152 62 TIM, PressFIT
FF450R12ME4 active Dual 450 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 -
FF450R12ME4P active Dual 450 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 TIM
FF450R12ME4_B11 active and preferred Dual 450 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 PressFIT
FF450R12ME4P_B11 active and preferred Dual 450 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 TIM, PressFIT
IFF450B12ME4P_B11 active and preferred Dual 450 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 TIM, PressFIT
IFF450B12ME4S8P_B11 active and preferred Dual 450 IGBT4 - E4 EconoDUAL™ 3 1.75 1.95 152 62 TIM, PressFIT
FF300R12ME4 active Dual 300 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 -
FF300R12ME4_B11 active and preferred Dual 300 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 PressFIT
FF300R12ME4P_B11 active and preferred Dual 300 IGBT4 - E4 EconoDUAL™ 3 1.75 1.65 152 62 TIM, PressFIT
FF300R12MS4 active and preferred Dual 300 IGBT2 Fast EconoDUAL™ 3 3.2 2 152 62 -
FF225R12ME4 active Dual 225 IGBT4 - E4 EconoDUAL™ 3 1.85 1.65 152 62 -
FF225R12ME4P active and preferred Dual 225 IGBT4 - E4 EconoDUAL™ 3 1.85 1.65 152 62 TIM
FF225R12ME4_B11 active and preferred Dual 225 IGBT4 - E4 EconoDUAL™ 3 1.85 1.65 152 62 PressFIT
FF225R12ME4P_B11 active and preferred Dual 225 IGBT4 - E4 EconoDUAL™ 3 1.85 1.65 152 62 TIM, PressFIT
FF225R12MS4 active and preferred Dual 225 IGBT2 Fast EconoDUAL™ 3 3.2 2 152 62 -
FF150R12MS4G active and preferred Dual 150 IGBT2 Fast EconoDUAL™ 3 3.2 2 152 62 -
42
IGBT
modules
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
EconoPACK™ 2
F4-75R12KS4 active and preferred Fourpack 75 IGBT2 Fast EconoPACK™ 2 3.2 2 107.5 45 -
F4-75R12KS4_B11 active and preferred Fourpack 75 IGBT2 Fast EconoPACK™ 2 3.2 2 107.5 45 PressFIT
F4-50R12KS4 active and preferred Fourpack 50 IGBT2 Fast EconoPACK™ 2 3.2 2 107.5 45 -
F4-50R12KS4_B11 active and preferred Fourpack 50 IGBT2 Fast EconoPACK™ 2 3.2 2 107.5 45 PressFIT
FS100R12KT4 active and preferred Sixpack 100 IGBT4 - T4 EconoPACK™ 2 1.75 1.7 107.5 45 -
FS75R12KT4_B11 active and preferred Sixpack 75 IGBT4 - T4 EconoPACK™ 2 1.85 1.7 107.5 45 PressFIT
FS75R12KT4_B15 active and preferred Sixpack 75 IGBT4 - T4 EconoPACK™ 2 1.85 1.7 107.5 45 -
FS75R12KE3 active and preferred Sixpack 75 IGBT3 - E3 EconoPACK™ 2 1.7 1.65 107.5 45 -
FS75R12KT3 active and preferred Sixpack 75 IGBT3 - T3 EconoPACK™ 2 1.7 1.65 107.5 45 -
FS75R12KE3_B9 active and preferred Sixpack 75 IGBT3 - E3 EconoPACK™ 2 1.7 1.65 107.5 45 -
FS50R12KT4_B11 active and preferred Sixpack 50 IGBT4 - T4 EconoPACK™ 2 1.85 1.7 107.5 45 PressFIT
FS50R12KT4P_B11 active and preferred Sixpack 50 IGBT4 - T4 EconoPACK™ 2 1.85 1.7 107.5 45 TIM, PressFIT
FS50R12KT4_B15 active and preferred Sixpack 50 IGBT4 - T4 EconoPACK™ 2 1.85 1.7 107.5 45 -
FS50R12KE3 active and preferred Sixpack 50 IGBT3 - E3 EconoPACK™ 2 1.7 1.65 107.5 45 -
FS50R12KT3 active and preferred Sixpack 50 IGBT3 - T3 EconoPACK™ 2 1.7 1.65 107.5 45 -
FS35R12KT3 active and preferred Sixpack 35 IGBT3 - T3 EconoPACK™ 2 1.7 1.65 107.5 45 -
FS35R12KE3G active and preferred Sixpack 35 IGBT3 - E3 EconoPACK™ 2 1.7 1.65 107.5 45 -
FS25R12KT3 active and preferred Sixpack 25 IGBT3 - T3 EconoPACK™ 2 1.7 1.65 107.5 45 -
FS25R12KE3G active and preferred Sixpack 25 IGBT3 - E3 EconoPACK™ 2 1.7 1.65 107.5 45 -
EconoPACK™ 3
IFF300B12N2E4P_B11 active and preferred Dual 300 IGBT4 - E4 EconoPACK™ 3 1.75 1.7 122 62 Current sense shunts
F4-150R12KS4 active and preferred Fourpack 150 IGBT2 Fast EconoPACK™ 3 3.2 2.3 122 62 -
F4-100R12KS4 active and preferred Fourpack 100 IGBT2 Fast EconoPACK™ 3 3.2 2 122 62 -
IFS200B12N3E4_B31 active and preferred Sixpack 200 IGBT4 - E4 EconoPACK™ 3 1.75 1.7 122 62 Current sense shunts
FS200R12KT4R active and preferred Sixpack 200 IGBT4 - T4 EconoPACK™ 3 1.75 1.7 122 62 -
FS200R12KT4R_B11 active and preferred Sixpack 200 IGBT4 - T4 EconoPACK™ 3 1.75 1.7 122 62 PressFIT
IFS150B12N3E4_B31 active and preferred Sixpack 150 IGBT4 - E4 EconoPACK™ 3 1.75 1.7 122 62 Current sense shunts
FS150R12KT4 active and preferred Sixpack 150 IGBT4 - T4 EconoPACK™ 3 1.75 1.7 122 62 -
43
IGBT
modules
IGBT modules up to 1200 V
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
EconoPACK™ 4
F3L400R12PT4_B26 active and preferred 3-level 400 IGBT4 - T4 EconoPACK™ 4 1.75 1.8 130 70.6 Phase leg, PressFIT
F3L400R12PT4P_B26 active and preferred 3-level 400 IGBT4 - T4 EconoPACK™ 4 1.75 1.55 130 70.6 TIM, Phase leg, PressFIT
F3L300R12PT4_B26 active and preferred 3-level 300 IGBT4 - T4 EconoPACK™ 4 1.75 1.65 130 70.6 Phase leg, PressFIT
DF200R12PT4_B6 active and preferred Chopper 200 IGBT4 - T4 EconoPACK™ 4 1.75 1.75 130 70.6 -
FD200R12PT4_B6 active and preferred Chopper 200 IGBT4 - T4 EconoPACK™ 4 1.75 1.75 130 70.6 -
IFS200V12PT4 active Sixpack 200 IGBT4 - T4 EconoPACK™ 4 1.75 1.7 130 70.6 Integrated drivers, Plug n Play
FS200R12PT4 active and preferred Sixpack 200 IGBT4 - T4 EconoPACK™ 4 1.75 1.7 130 70.6 PressFIT
FS200R12PT4P active and preferred Sixpack 200 IGBT4 - T4 EconoPACK™ 4 1.75 1.7 130 70.6 TIM, PressFIT
FS150R12PT4 active and preferred Sixpack 150 IGBT4 - T4 EconoPACK™ 4 1.75 1.7 130 70.6 PressFIT
IFS100V12PT4 active Sixpack 100 IGBT4 - T4 EconoPACK™ 4 1.75 1.7 130 70.6 Integrated drivers, Plug n Play
FS100R12PT4 active and preferred Sixpack 100 IGBT4 - T4 EconoPACK™ 4 1.75 1.7 130 70.6 PressFIT
EconoPACK™ 3
FS150R12KT4_B11 active and preferred Sixpack 150 IGBT4 - T4 EconoPACK™ 3 1.75 1.4 122 62 PressFIT
FS150R12KT4_B9 active and preferred Sixpack 150 IGBT4 - T4 EconoPACK™ 3 1.75 1.7 122 62 -
FS150R12KE3 active and preferred Sixpack 150 IGBT3 - E3 EconoPACK™ 3 1.7 1.65 122 62 -
FS150R12KT3 active and preferred Sixpack 150 IGBT3 - T3 EconoPACK™ 3 1.7 1.65 122 62 -
IFS100B12N3E4_B31 active and preferred Sixpack 100 IGBT4 - E4 EconoPACK™ 3 1.75 1.7 122 62 Current sense shunts
FS100R12KT4G active and preferred Sixpack 100 IGBT4 - T4 EconoPACK™ 3 1.75 1.7 122 62 -
FS100R12KT4G_B11 active and preferred Sixpack 100 IGBT4 - T4 EconoPACK™ 3 1.75 1.7 122 62 PressFIT
FS100R12KE3 active and preferred Sixpack 100 IGBT3 - E3 EconoPACK™ 3 1.7 1.65 122 62 -
FS100R12KT3 active and preferred Sixpack 100 IGBT3 - T3 EconoPACK™ 3 1.7 1.65 122 62 -
FS100R12KS4 active and preferred Sixpack 100 IGBT2 Fast EconoPACK™ 3 3.2 2 122 62 -
IFS75B12N3E4_B31 active and preferred Sixpack 75 IGBT4 - E4 EconoPACK™ 3 1.85 1.7 122 62 Current sense shunts
FS75R12KE3G active and preferred Sixpack 75 IGBT3 - E3 EconoPACK™ 3 1.7 1.65 122 62 -
FS75R12KT3G active and preferred Sixpack 75 IGBT3 - T3 EconoPACK™ 3 1.7 1.65 122 62 -
F12-25R12KT4G active and preferred Twelvepack 25 IGBT4 - T4 EconoPACK™ 3 1.85 1.75 122 62 -
44
IGBT
modules
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
EconoPIM™ 3
FP150R12KT4 active and preferred PIM Three Phase Input Rectifier 150 IGBT4 - T4 EconoPIM™ 3 1.75 1.7 122 62 -
FP150R12KT4P active and preferred PIM Three Phase Input Rectifier 150 IGBT4 - T4 EconoPIM™ 3 1.75 1.7 122 62 TIM
FP150R12KT4_B11 active and preferred PIM Three Phase Input Rectifier 150 IGBT4 - T4 EconoPIM™ 3 1.75 1.7 122 62 PressFIT
FP150R12KT4P_B11 active and preferred PIM Three Phase Input Rectifier 150 IGBT4 - T4 EconoPIM™ 3 1.75 1.7 122 62 TIM, PressFIT
FP100R12KT4 active and preferred PIM Three Phase Input Rectifier 100 IGBT4 - T4 EconoPIM™ 3 1.75 1.7 122 62 -
FP100R12KT4_B11 active and preferred PIM Three Phase Input Rectifier 100 IGBT4 - T4 EconoPIM™ 3 1.75 1.7 122 62 PressFIT
FP75R12KT4 active and preferred PIM Three Phase Input Rectifier 75 IGBT4 - T4 EconoPIM™ 3 1.85 1.7 122 62 -
FP75R12KT4P active and preferred PIM Three Phase Input Rectifier 75 IGBT4 - T4 EconoPIM™ 3 1.85 1.7 122 62 TIM
FP75R12KT4_B11 active and preferred PIM Three Phase Input Rectifier 75 IGBT4 - T4 EconoPIM™ 3 1.85 1.7 122 62 PressFIT
EconoPIM™ 2
FP50R12KT4 active and preferred PIM Three Phase Input Rectifier 50 IGBT4 - T4 EconoPIM™ 2 1.85 1.7 107 45 -
FP50R12KT4P active and preferred PIM Three Phase Input Rectifier 50 IGBT4 - T4 EconoPIM™ 2 1.85 1.7 107 45 TIM
FP50R12KT4_B11 active and preferred PIM Three Phase Input Rectifier 50 IGBT4 - T4 EconoPIM™ 2 1.85 1.7 107 45 PressFIT
FP40R12KE3 active and preferred PIM Three Phase Input Rectifier 40 IGBT3 - E3 EconoPIM™ 2 1.8 1.75 107 45 -
FP40R12KT3 active and preferred PIM Three Phase Input Rectifier 40 IGBT3 - T3 EconoPIM™ 2 1.8 1.75 107 45 -
FP35R12KT4 active and preferred PIM Three Phase Input Rectifier 35 IGBT4 - T4 EconoPIM™ 2 1.85 1.7 107 45 -
FP35R12KT4P active and preferred PIM Three Phase Input Rectifier 35 IGBT4 - T4 EconoPIM™ 2 1.85 1.7 107 45 TIM
FP35R12KT4_B11 active and preferred PIM Three Phase Input Rectifier 35 IGBT4 - T4 EconoPIM™ 2 1.85 1.7 107 45 PressFIT
FP35R12KT4_B15 active and preferred PIM Three Phase Input Rectifier 35 IGBT4 - T4 EconoPIM™ 2 1.85 1.7 107 45 -
FP25R12KT4 active and preferred PIM Three Phase Input Rectifier 25 IGBT4 - T4 EconoPIM™ 2 1.85 1.75 107 45 -
FP25R12KT4_B11 active and preferred PIM Three Phase Input Rectifier 25 IGBT4 - T4 EconoPIM™ 2 1.85 1.75 107 45 PressFIT
FP25R12KT4_B15 active and preferred PIM Three Phase Input Rectifier 25 IGBT4 - T4 EconoPIM™ 2 1.85 1.75 107 45 -
FP25R12KE3 active and preferred PIM Three Phase Input Rectifier 25 IGBT3 - E3 EconoPIM™ 2 1.7 1.65 107 45 -
FP25R12KT3 active and preferred PIM Three Phase Input Rectifier 25 IGBT3 - T3 EconoPIM™ 2 1.7 1.65 107 45 -
FP25R12KS4C active and preferred PIM Three Phase Input Rectifier 25 IGBT2 Fast EconoPIM™ 2 3.2 2.05 107 45 -
FP15R12KE3G active and preferred PIM Three Phase Input Rectifier 15 IGBT3 - E3 EconoPIM™ 2 1.7 1.65 107 45 -
FP15R12KT3 active and preferred PIM Three Phase Input Rectifier 15 IGBT3 - T3 EconoPIM™ 2 1.7 1.65 107 45 -
FP15R12KS4C active and preferred PIM Three Phase Input Rectifier 15 IGBT2 Fast EconoPIM™ 2 3.2 1.75 107 45 -
45
IGBT
modules
IGBT modules up to 1200 V
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
IHM B
DD1200S12H4 active and preferred Diodes 1200 Diode IHM B 1.8 130 140 -
FZ3600R12HP4 active and preferred Single switch 3600 IGBT4 - P4 IHM B 1.7 1.8 190 140 -
FZ2400R12HE4_B9 active and preferred Single switch 2400 IGBT4 - E4 IHM B 1.75 1.8 190 140 -
FZ2400R12HE4P_B9 active and preferred Single switch 2400 IGBT4 - E4 IHM B 1.75 1.8 190 140 TIM
FZ2400R12HP4 active and preferred Single switch 2400 IGBT4 - P4 IHM B 1.7 1.8 130 140 -
FZ2400R12HP4_B9 active and preferred Single switch 2400 IGBT4 - P4 IHM B 1.7 1.8 190 140 -
FZ1800R12HE4_B9 active and preferred Single switch 1800 IGBT4 - E4 IHM B 1.75 1.8 190 140 -
FZ1800R12HP4_B9 active and preferred Single switch 1800 IGBT4 - P4 IHM B 1.7 1.8 190 140 -
FZ1600R12HP4 active and preferred Single switch 1600 IGBT4 - P4 IHM B 1.7 1.8 130 140 -
FZ1200R12HE4 active and preferred Single switch 1200 IGBT4 - E4 IHM B 1.75 1.8 130 140 -
FZ1200R12HE4P active and preferred Single switch 1200 IGBT4 - E4 IHM B 1.75 1.8 130 140 TIM
FZ1200R12HP4 active and preferred Single switch 1200 IGBT4 - P4 IHM B 1.7 1.8 130 140 -
IHM
FF1200R12KE3 active Dual 1200 IGBT3 - E3 IHM 1.7 2.2 130 140 -
FF800R12KE3 active Dual 800 IGBT3 - E3 IHM 1.7 2.2 130 140 -
EconoPIM™ 3
FP75R12KT4P_B11 active and preferred PIM Three Phase Input Rectifier 75 IGBT4 - T4 EconoPIM™ 3 1.85 1.7 122 62 TIM, PressFIT
FP75R12KT4_B15 active and preferred PIM Three Phase Input Rectifier 75 IGBT4 - T4 EconoPIM™ 3 1.85 1.7 122 62 -
FP75R12KE3 active and preferred PIM Three Phase Input Rectifier 75 IGBT3 - E3 EconoPIM™ 3 1.7 1.65 122 62 -
FP75R12KT3 active and preferred PIM Three Phase Input Rectifier 75 IGBT3 - T3 EconoPIM™ 3 1.7 1.65 122 62 -
FP50R12KT4G active and preferred PIM Three Phase Input Rectifier 50 IGBT4 - T4 EconoPIM™ 3 1.85 1.7 122 62 -
FP50R12KE3 active and preferred PIM Three Phase Input Rectifier 50 IGBT3 - E3 EconoPIM™ 3 1.7 1.65 122 62 -
FP50R12KT3 active and preferred PIM Three Phase Input Rectifier 50 IGBT3 - T3 EconoPIM™ 3 1.7 1.65 122 62 -
FP50R12KS4C active and preferred PIM Three Phase Input Rectifier 50 IGBT2 Fast EconoPIM™ 3 3.2 1.75 122 62 -
FP40R12KE3G active and preferred PIM Three Phase Input Rectifier 40 IGBT3 - E3 EconoPIM™ 3 1.8 1.75 122 62 -
FP40R12KT3G active and preferred PIM Three Phase Input Rectifier 40 IGBT3 - T3 EconoPIM™ 3 1.8 1.75 122 62 -
46
IGBT
modules
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
PrimePACK™ 2
DF900R12IP4D active and preferred Chopper 900 IGBT4 - P4 PrimePACK™ 2 1.7 1.65 172 89 -
FD900R12IP4D active and preferred Chopper 900 IGBT4 - P4 PrimePACK™ 2 1.7 1.65 172 89 -
DF900R12IP4DV active and preferred Chopper 900 IGBT4 - P4 PrimePACK™ 2 1.7 1.65 172 89 -
FD900R12IP4DV active and preferred Chopper 900 IGBT4 - P4 PrimePACK™ 2 1.7 1.65 172 89 -
DF600R12IP4D active and preferred Chopper 600 IGBT4 - P4 PrimePACK™ 2 1.7 1.65 172 89 -
FF1200R12IE5 active and preferred Dual 1200 IGBT5 - E5 PrimePACK™ 2 1.7 1.9 172 89 .XT Technology
FF1200R12IE5P active and preferred Dual 1200 IGBT5 - E5 PrimePACK™ 2 1.9 1.9 172 89 .XT Technology, TIM
FF900R12IE4 active and preferred Dual 900 IGBT4 - E4 PrimePACK™ 2 1.75 1.9 172 89 -
FF900R12IE4P active and preferred Dual 900 IGBT4 - E4 PrimePACK™ 2 1.75 1.9 172 89 TIM
FF900R12IE4V active and preferred Dual 900 IGBT4 - E4 PrimePACK™ 2 1.75 1.9 172 89 -
FF900R12IE4VP active and preferred Dual 900 IGBT4 - E4 PrimePACK™ 2 1.75 1.9 172 89 TIM
FF900R12IP4 active and preferred Dual 900 IGBT4 - P4 PrimePACK™ 2 1.7 1.9 172 89 -
FF900R12IP4P active and preferred Dual 900 IGBT4 - P4 PrimePACK™ 2 1.7 1.9 172 89 TIM
FF900R12IP4V active and preferred Dual 900 IGBT4 - P4 PrimePACK™ 2 1.7 1.9 172 89 -
FF900R12IP4D active and preferred Dual 900 IGBT4 - P4 PrimePACK™ 2 1.7 1.65 172 89 -
FF900R12IP4DV active and preferred Dual 900 IGBT4 - P4 PrimePACK™ 2 1.7 1.65 172 89 -
FF600R12IE4 active and preferred Dual 600 IGBT4 - E4 PrimePACK™ 2 1.75 1.8 172 89 -
FF600R12IE4V active and preferred Dual 600 IGBT4 - E4 PrimePACK™ 2 1.75 1.8 172 89 -
FF600R12IP4 active and preferred Dual 600 IGBT4 - P4 PrimePACK™ 2 1.7 1.8 172 89 -
FF600R12IP4V active and preferred Dual 600 IGBT4 - P4 PrimePACK™ 2 1.7 1.8 172 89 -
FF450R12IE4 active and preferred Dual 450 IGBT4 - E4 PrimePACK™ 2 1.75 1.9 172 89 -
47
IGBT
modules
IGBT modules up to 1200 V
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
PrimePACK™ 3
DF1400R12IP4D active and preferred Chopper 1400 IGBT4 - P4 PrimePACK™ 3 1.75 1.65 250 89 -
FD1400R12IP4D active and preferred Chopper 1400 IGBT4 - P4 PrimePACK™ 3 1.75 1.65 250 89 -
FF1400R12IP4 active and preferred Dual 1400 IGBT4 - P4 PrimePACK™ 3 1.75 1.9 250 89 -
FF1400R12IP4P active and preferred Dual 1400 IGBT4 - P4 PrimePACK™ 3 1.75 1.9 250 89 TIM
PrimePACK™ 3+
FF1800R12IE5 active and preferred Dual 1800 IGBT5 - E5 PrimePACK™ 3+ 1.7 1.9 250 89 .XT Technology
FF1500R12IE5 active and preferred Dual 1500 IGBT5 - E5 PrimePACK™ 3+ 1.7 1.95 224 89 .XT Technology
SmartPIM 1
FP25R12U1T4 active and preferred PIM Three Phase Input Rectifier 25 IGBT4 - T4 SmartPIM 1 1.85 1.75 69.5 44 PressFIT
48
IGBT
modules
IGBT modules up to 1700 V
62 mm
FF400R17KE4_E active and preferred Common Emitter 400 IGBT4 - E4 62 mm 1.95 1.8 106.4 61.4 -
DZ800S17K3 active Diodes 800 Diode 62 mm 1.8 106.4 61.4 -
FF500R17KE4 active and preferred Dual 500 IGBT4 - E4 62 mm 1.95 1.95 106.4 61.4 -
FF400R17KE4 active and preferred Dual 400 IGBT4 - E4 62 mm 1.95 1.8 106.4 61.4 -
FF300R17KE4 active and preferred Dual 300 IGBT4 - E4 62 mm 1.95 1.8 106.4 61.4 -
FF300R17KE4P active and preferred Dual 300 IGBT4 - E4 62 mm 1.95 1.8 106.4 61.4 TIM
FF300R17KE3 active Dual 300 IGBT3 - E3 62 mm 2 1.8 106.4 61.4 -
FF200R17KE4 active and preferred Dual 200 IGBT4 - E4 62 mm 1.95 1.8 106.4 61.4 -
FF200R17KE3 active Dual 200 IGBT3 - E3 62 mm 2 1.8 106.4 61.4 -
FF150R17KE4 active and preferred Dual 150 IGBT4 - E4 62 mm 1.95 1.65 106.4 61.4 -
FZ600R17KE4 active and preferred Single switch 600 IGBT4 - E4 62 mm 1.95 1.8 106.4 61.4 -
FZ600R17KE3 active Single switch 600 IGBT3 - E3 62 mm 2 1.8 106.4 61.4 -
FZ600R17KE3_S4 active Single switch 600 IGBT3 - E3 62 mm 2 1.8 106.4 61.4 -
FZ400R17KE4 active and preferred Single switch 400 IGBT4 - E4 62 mm 1.95 1.8 106.4 61.4 -
FZ400R17KE3 active Single switch 400 IGBT3 - E3 62 mm 2 1.8 106.4 61.4 -
EconoDUAL™ 3
FF600R17ME4 active Dual 600 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 -
FF600R17ME4P active Dual 600 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 TIM
FF600R17ME4_B11 active and preferred Dual 600 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 PressFIT
FF600R17ME4P_B11 active and preferred Dual 600 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 TIM, PressFIT
FF450R17ME4 active Dual 450 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 -
FF450R17ME4P active Dual 450 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 TIM
FF450R17ME4_B11 active and preferred Dual 450 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 PressFIT
FF450R17ME4P_B11 active and preferred Dual 450 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 TIM, PressFIT
FF300R17ME4 active Dual 300 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 -
FF300R17ME4P active and preferred Dual 300 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 TIM
FF300R17ME4_B11 active and preferred Dual 300 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 PressFIT
FF300R17ME4P_B11 active and preferred Dual 300 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 TIM, PressFIT
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
49
IGBT
modules
IGBT modules up to 1700 V
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
EconoPACK™ 4
FS150R17PE4 active and preferred Sixpack 150 IGBT4 - E4 EconoPACK™ 4 1.95 1.8 130 70.6 PressFIT
FS100R17PE4 active and preferred Sixpack 100 IGBT4 - E4 EconoPACK™ 4 1.95 1.8 130 70.6 PressFIT
EconoPACK™ 3
F4-200R17N3E4 active and preferred Fourpack 200 IGBT4 - E4 EconoPACK™ 3 1.95 1.8 122 62 -
FS150R17N3E4 active and preferred Sixpack 150 IGBT4 - E4 EconoPACK™ 3 1.95 1.8 122 62 -
FS150R17N3E4_B11 active and preferred Sixpack 150 IGBT4 - E4 EconoPACK™ 3 1.95 1.8 122 62 PressFIT
IFS150B17N3E4P_B11 active and preferred Sixpack 150 IGBT4 - E4 EconoPACK™ 3 1.95 1.8 122 62 Current sense shunts, PressFIT
FS100R17N3E4 active and preferred Sixpack 100 IGBT4 - E4 EconoPACK™ 3 1.95 1.8 122 62 -
FS100R17N3E4_B11 active and preferred Sixpack 100 IGBT4 - E4 EconoPACK™ 3 1.95 1.8 122 62 PressFIT
FS100R17KE3 active and preferred Sixpack 100 IGBT3 - E3 EconoPACK™ 3 2 1.8 122 62 -
FS75R17KE3 active and preferred Sixpack 75 IGBT3 - E3 EconoPACK™ 3 2 1.8 122 62 -
EconoPACK™ + D
FS500R17OE4D active and preferred Sixpack 500 IGBT4 - E4 EconoPACK™ + D 1.95 1.7 162 150 PressFIT
FS500R17OE4DP active and preferred Sixpack 500 IGBT4 - E4 EconoPACK™ + D 1.95 1.7 162 150 TIM, PressFIT
FS450R17OE4 active and preferred Sixpack 450 IGBT4 - E4 EconoPACK™ + D 1.95 1.8 162 150 PressFIT
FS450R17OE4P active and preferred Sixpack 450 IGBT4 - E4 EconoPACK™ + D 1.95 1.8 162 150 TIM, PressFIT
FS300R17OE4 active and preferred Sixpack 300 IGBT4 - E4 EconoPACK™ + D 1.95 1.8 162 150 PressFIT
FS225R17OE4 active and preferred Sixpack 225 IGBT4 - E4 EconoPACK™ + D 1.95 1.8 162 150 PressFIT
EconoDUAL™ 3
FF225R17ME4 active Dual 225 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 -
FF225R17ME4P active and preferred Dual 225 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 TIM
FF225R17ME4_B11 active and preferred Dual 225 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 PressFIT
FF225R17ME4P_B11 active and preferred Dual 225 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 TIM, PressFIT
F4-250R17MP4_B11 active and preferred H-Bridge 250 IGBT4 - P4 EconoDUAL™ 3 1.8 1.8 152 62 PressFIT
F4-150R17ME4_B11 active and preferred H-Bridge 150 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 PressFIT
F4-100R17ME4_B11 active and preferred H-Bridge 100 IGBT4 - E4 EconoDUAL™ 3 1.95 1.8 152 62 PressFIT
50
IGBT
modules
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
IHM B
FD1600/1200R17HP4_B2 active Chopper 1600 IGBT4 - P4 IHM B 1.9 1.65 190 140 Enlarged Diode
FD1600/1200R17HP4-K_B2 active and preferred Chopper 1600 IGBT4 - P4 IHM B 1.9 1.65 190 140 Enlarged Diode
FD1200R17HP4-K_B2 active and preferred Chopper 1200 IGBT4 - P4 IHM B 1.9 1.65 130 140 Enlarged Diode
FD800R17HP4-K_B2 active and preferred Chopper 800 IGBT4 - P4 IHM B 1.9 1.65 130 140 Enlarged Diode
DD1200S17H4_B2 active and preferred Diodes 1200 Diode IHM B 1.8 130 140 -
DD800S17H4_B2 active and preferred Diodes 800 Diode IHM B 1.8 130 140 -
FZ3600R17HE4 active and preferred Single switch 3600 IGBT4 - E4 IHM B 1.95 1.8 190 140 -
FZ3600R17HE4P active and preferred Single switch 3600 IGBT4 - E4 IHM B 1.95 1.8 190 140 TIM
FZ3600R17HP4 active and preferred Single switch 3600 IGBT4 - P4 IHM B 1.9 1.8 190 140 -
FZ3600R17HP4_B2 active and preferred Single switch 3600 IGBT4 - P4 IHM B 1.9 1.65 190 140 Enlarged Diode
FZ2400R17HE4_B9 active and preferred Single switch 2400 IGBT4 - E4 IHM B 1.95 1.8 190 140 -
FZ2400R17HE4P_B9 active and preferred Single switch 2400 IGBT4 - E4 IHM B 1.95 1.8 190 140 TIM
FZ2400R17HP4 active and preferred Single switch 2400 IGBT4 - P4 IHM B 1.9 1.8 130 140 -
FZ2400R17HP4_B2 active and preferred Single switch 2400 IGBT4 - P4 IHM B 1.9 1.65 130 140 Enlarged Diode
FZ2400R17HP4_B9 active Single switch 2400 IGBT4 - P4 IHM B 1.9 1.8 190 140 -
FZ2400R17HP4_B28 active and preferred Single switch 2400 IGBT4 - P4 IHM B 1.9 1.8 190 140 -
IHM
FD600R17KE3_B2 active Chopper 600 IGBT3 - E3 IHM 2 1.6 130 140 Enlarged Diode
FF1200R17KP4_B2 active Dual 1200 IGBT4 - P4 IHM 1.9 1.65 130 140 Enlarged Diode
FF1200R17KE3 active Dual 1200 IGBT3 - E3 IHM 2 1.8 130 140 -
FF800R17KP4_B2 active Dual 800 IGBT4 - P4 IHM 1.9 1.55 130 140 Enlarged Diode
FF800R17KE3 active Dual 800 IGBT3 - E3 IHM 2 1.8 130 140 -
FF600R17KE3 active Dual 600 IGBT3 - E3 IHM 2 1.8 130 140 -
FF600R17KE3_B2 active Dual 600 IGBT3 - E3 IHM 2 1.6 130 140 Enlarged Diode
EconoPIM™ 3
FP75R17N3E4 active and preferred PIM Three Phase Input Rectifier 75 IGBT4 - E4 EconoPIM™ 3 1.95 1.8 122 62 -
FP75R17N3E4_B11 active and preferred PIM Three Phase Input Rectifier 75 IGBT4 - E4 EconoPIM™ 3 1.95 1.8 122 62 PressFIT
51
IGBT
modules
IGBT modules up to 1700 V
PrimePACK™ 2
DF650R17IE4 active Chopper 650 IGBT4 - E4 PrimePACK™ 2 2 1.85 172 89 -
FD650R17IE4 active and preferred Chopper 650 IGBT4 - E4 PrimePACK™ 2 2 1.85 172 89 -
FF1200R17IP5 active and preferred Dual 1200 IGBT5 - P5 PrimePACK™ 2 1.75 1.8 172 89 .XT Technology
FF650R17IE4 active and preferred Dual 650 IGBT4 - E4 PrimePACK™ 2 2 1.85 172 89 -
FF650R17IE4P active and preferred Dual 650 IGBT4 - E4 PrimePACK™ 2 2 1.85 172 89 TIM
FF650R17IE4D_B2 active and preferred Dual 650 IGBT4 - E4 PrimePACK™ 2 2 1.7 172 89 -
FF650R17IE4DP_B2 active and preferred Dual 650 IGBT4 - E4 PrimePACK™ 2 2 1.7 172 89 TIM
FF650R17IE4V active and preferred Dual 650 IGBT4 - E4 PrimePACK™ 2 2 1.85 172 89 -
FF450R17IE4 active and preferred Dual 450 IGBT4 - E4 PrimePACK™ 2 2 1.85 172 89 -
IHM B
FZ2400R17HP4_B29 active and preferred Single switch 2400 IGBT4 - P4 IHM B 1.9 1.65 190 140 Enlarged Diode
FZ1800R17HE4_B9 active Single switch 1800 IGBT4 - E4 IHM B 1.95 1.8 190 140 -
FZ1800R17HP4_B9 active Single switch 1800 IGBT4 - P4 IHM B 1.9 1.8 190 140 -
FZ1800R17HP4_B29 active Single switch 1800 IGBT4 - P4 IHM B 1.9 1.65 190 140 Enlarged Diode
FZ1600R17HP4 active and preferred Single switch 1600 IGBT4 - P4 IHM B 1.9 1.8 130 140 -
FZ1600R17HP4_B2 active and preferred Single switch 1600 IGBT4 - P4 IHM B 1.9 1.65 130 140 Enlarged Diode
FZ1600R17HP4_B21 active and preferred Single switch 1600 IGBT4 - P4 IHM B 1.9 1.8 130 140 -
FZ1200R17HE4 active and preferred Single switch 1200 IGBT4 - E4 IHM B 1.95 1.8 130 140 -
FZ1200R17HE4P active and preferred Single switch 1200 IGBT4 - E4 IHM B 1.95 1.8 130 140 TIM
FZ1200R17HP4 active and preferred Single switch 1200 IGBT4 - P4 IHM B 1.9 1.8 130 140 -
FZ1200R17HP4_B2 active and preferred Single switch 1200 IGBT4 - P4 IHM B 1.9 1.65 130 140 Enlarged Diode
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
52
IGBT
modules
PrimePACK™ 3+
FF1800R17IP5 active and preferred Dual 1800 IGBT5 - P5 PrimePACK™ 3+ 1.75 1.75 250 89 .XT Technology
FF1800R17IP5P active and preferred Dual 1800 IGBT5 - P5 PrimePACK™ 3+ 1.75 1.75 250 89 .XT Technology, TIM
FF1500R17IP5 active and preferred Dual 1500 IGBT5 - P5 PrimePACK™ 3+ 1.75 1.75 224 89 .XT Technology
PrimePACK™ 3
DF1000R17IE4 active and preferred Chopper 1000 IGBT4 - E4 PrimePACK™ 3 2 1.85 250 89 -
FD1000R17IE4 active and preferred Chopper 1000 IGBT4 - E4 PrimePACK™ 3 2 1.85 250 89 -
DF1000R17IE4D_B2 active and preferred Chopper 1000 IGBT4 - E4 PrimePACK™ 3 2 1.7 250 89 -
FD1000R17IE4D_B2 active Chopper 1000 IGBT4 - E4 PrimePACK™ 3 2 1.7 250 89 -
FF1400R17IP4 active and preferred Dual 1400 IGBT4 - P4 PrimePACK™ 3 1.75 1.75 250 89 -
FF1400R17IP4P active and preferred Dual 1400 IGBT4 - P4 PrimePACK™ 3 1.75 1.75 250 89 TIM
FF1000R17IE4 active and preferred Dual 1000 IGBT4 - E4 PrimePACK™ 3 2 1.85 250 89 -
FF1000R17IE4P active and preferred Dual 1000 IGBT4 - E4 PrimePACK™ 3 2 1.85 250 89 TIM
FF1000R17IE4D_B2 active and preferred Dual 1000 IGBT4 - E4 PrimePACK™ 3 2 1.7 250 89 -
FF1000R17IE4DP_B2 active and preferred Dual 1000 IGBT4 - E4 PrimePACK™ 3 2 1.7 250 89 TIM
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
53
IGBT
modules
IGBT modules up to 3300 V
XHP™ 3
FF450R33T3E3 active and preferred Dual 450 IGBT3 - E3 XHP™ 3 2.55 3.1 140 99.8 Phase leg
IHV B
FD1000R33HE3-K active and preferred Chopper 1000 IGBT3 - E3 IHV B 2.55 3.1 190 140 -
FD1000R33HL3-K active and preferred Chopper 1000 IGBT3 - L3 IHV B 2.4 2.25 190 140 -
DD1000S33HE3 active and preferred Diodes 1000 Diode IHV B - 3.1 130 140 -
DD500S33HE3 active and preferred Diodes 500 Diode IHV B - 3.1 130 140 -
FZ1500R33HE3 active and preferred Single switch 1500 IGBT3 - E3 IHV B 2.55 3.1 190 140 -
FZ1500R33HL3 active and preferred Single switch 1500 IGBT3 - L3 IHV B 2.4 2.25 190 140 -
FZ1200R33HE3 active Single switch 1200 IGBT3 - E3 IHV B 2.7 3.25 190 140 -
FZ1000R33HE3 active and preferred Single switch 1000 IGBT3 - E3 IHV B 2.55 3.1 130 140 -
FZ1000R33HL3 active and preferred Single switch 1000 IGBT3 - L3 IHV B 2.4 2.25 130 140 -
IHV
FD800R33KF2C active Chopper 800 IGBT2 IHV 3.4 2.8 190 140 -
FD800R33KF2C-K active Chopper 800 IGBT2 IHV 3.4 2.8 190 140 -
FD400R33KF2C active Chopper 400 IGBT2 IHV 3.4 2.8 130 140 -
FD400R33KF2C-K active Chopper 400 IGBT2 IHV 3.4 2.8 130 140 -
DD1200S33K2C active Diodes 1200 Diode IHV - 2.8 130 140 -
DD800S33K2C active Diodes 800 Diode IHV - 2.8 130 140 -
DD400S33K2C active Diodes 400 Diode IHV - 2.8 130 140 -
DD400S33KL2C active Diodes 400 Diode IHV - 2.6 73 140 -
DD200S33K2C active Diodes 200 Diode IHV - 2.8 73 140 -
FF400R33KF2C active Dual 400 IGBT2 IHV 3.4 2.8 130 140 -
FF200R33KF2C active Dual 200 IGBT2 IHV 3.4 2.8 73 140 -
FZ1200R33KF2C active Single switch 1200 IGBT2 IHV 3.4 2.8 190 140 -
FZ800R33KF2C active Single switch 800 IGBT2 IHV 3.4 2.8 130 140 -
FZ400R33KL2C_B5 active Single switch 400 IGBT2 Low Loss IHV 3 2.6 73 140 10.2kV isolation
Product Product Status Configuration IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
54
IGBT
modules
IGBT modules up to 6500 V
IHV
FD800R45KL3-K_B5 active and preferred Chopper 4500 800 IGBT3 - L3 IHV 2.5 2.5 190 140 10.2kV isolation
FD500R65KE3-K active and preferred Chopper 6500 500 IGBT3 - E3 IHV 3 3 190 140 10.2kV isolation
FD250R65KE3-K active and preferred Chopper 6500 250 IGBT3 - E3 IHV 3 3 130 140 10.2kV isolation
DD1200S45KL3_B5 active and preferred Diodes 4500 1200 Diode IHV - 2.5 130 140 10.2kV isolation
DD800S45KL3_B5 active and preferred Diodes 4500 800 Diode IHV - 2.5 130 140 10.2kV isolation
DD750S65K3 active and preferred Diodes 6500 750 Diode IHV - 3 130 140 10.2kV isolation
DD600S65K3 active and preferred Diodes 6500 600 Diode IHV - 3 130 140 10.2kV isolation
DD500S65K3 active and preferred Diodes 6500 500 Diode IHV - 3 130 140 10.2kV isolation
DD400S45KL3_B5 active and preferred Diodes 4500 400 Diode IHV - 2.5 130 140 10.2kV isolation
DD250S65K3 active and preferred Diodes 6500 250 Diode IHV - 3 130 140 10.2kV isolation
FZ1200R45KL3_B5 active and preferred Single switch 4500 1200 IGBT3 - L3 IHV 2.5 2.5 190 140 10.2kV isolation
FZ800R45KL3_B5 active and preferred Single switch 4500 800 IGBT3 - L3 IHV 2.5 2.5 130 140 10.2kV isolation
FZ750R65KE3 active and preferred Single switch 6500 750 IGBT3 - E3 IHV 3 3 190 140 10.2kV isolation
FZ600R65KE3 active Single switch 6500 600 IGBT3 - E3 IHV 3 3 190 140 10.2kV isolation
FZ500R65KE3 active and preferred Single switch 6500 500 IGBT3 - E3 IHV 3 3 130 140 10.2kV isolation
FZ400R65KE3 active Single switch 6500 400 IGBT3 - E3 IHV 3 3 130 140 10.2kV isolation
FZ250R65KE3 active and preferred Single switch 6500 250 IGBT3 - E3 IHV 3 3 73 140 10.2kV isolation
IHV B
FZ1200R45HL3 active and preferred Single switch 4500 1200 IGBT3 - L3 IHV B 2.35 2.5 190 140 -
XHP™ 3
FF225R65T3E3 active and preferred Dual 6500 225 IGBT3 - E3 XHP™ 3 3.2 3.3 140 99.8 Phase leg
Product Product Status Configuration Voltage Class
[V]
IC(nom)/ IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions
length [mm]
Dimensions
width
[mm]
Features
55
IGBT
modules
5656
Silicon Carbide (SiC) devices belong to the so-called wide band gap semiconductor group, which offers a number
of attractive characteristics for high voltage power semiconductors when compared to commonly used silicon (Si).
In particular, the much higher breakdown field strength and thermal conductivity of SiC allow creating devices which
outperform by far the corresponding Si ones, and enable reaching otherwise unattainable efficiency levels.
CoolSiC™ - The Future of Power Semiconductors
The use of SiC based power semiconductor solutions has shown a huge increase over the last years, it is a revolution
to rely on. Driving forces behind this market development are the following trends: energy saving, size reduction,
system integration and improved reliability. The combination of a fast silicon based switch with a SiC Diode – is often
termed a “hybrid” solution. In recent years Infineon has manufactured several million hybrid modules and has seen
them installed in various customer products.
The increase of switching frequency for a converter using unipolar SiC transistors can result in dramatically reduced
volume and weight of the magnetic components. From an analysis carried out by Infineon, a converter built on SiC
devices is a third of the size and 25 percent of the weight compared to a current Si based reference solution. Thanks to
the significant reduction in volume and weight, the system costs can also be reduced by more than 20 percent.
Silicon Carbide (SiC)
Silicon Carbide
57
Silicon
Carbide (SiC)
CoolSiC™ MOSFET
Product Product Status Voltage Class
[V]
Configuration RDS(on)
[m]
IC(nom)/ IF(nom)
[A]
Technology
Housing
[mm]
Dimensions length
[mm]
Dimensions width
[mm]
Features
CoolSiC™ MOSFET Modules
FF11MR12W1M1_B11 active and preferred 1200 V Dual 11 m 100 A CoolSiC™ MOSFET EasyDUAL™ 1B 62.8 mm 33.8 mm PressFIT
FF23MR12W1M1_B11 active and preferred 1200 V Dual 23 m 50 A CoolSiC™ MOSFET EasyDUAL™ 1B 62.8 mm 33.8 mm PressFIT
DF11MR12W1M1_B11 active and preferred 1200 V Booster 23 m 100 A CoolSiC™ MOSFET EasyDUAL™ 1B 62.8 mm 33.8 mm PressFIT
DF23MR12W1M1_B11 active and preferred 1200 V Booster 45 m 50 A CoolSiC™ MOSFET EasyDUAL™ 1B 62.8 mm 33.8 mm PressFIT
Discrete CoolSiC™ MOSFET
IMW120R045M1 active and preferred 1200 V Single 45 m 36 CoolSiC™ MOSFET TO-247 3pin - - -
IMZ120R045M1 active and preferred 1200 V Single 45 m 36 CoolSiC™ MOSFET TO-247 4pin - - Kelvin connection
58
Silicon
Carbide (SiC)
CoolSiC™ Schottky Diode
Product Product Status Technology VDC min [V] IF max [A] VF [V]
QC
[nC] Package I(FSM) max [A] IR [A] CT [pF]
Ptot max
[W] RthJC [K/W]
D2PAK real 2pin
IDK12G65C5 active and preferred CoolSiC™ G5 650 V 12 A 1.5 V 18 nC D2PAK (TO-263-2) 97 A 0.65 A 360 pF 104 W 0.9 K/W
IDK10G65C5 active and preferred CoolSiC™ G5 650 V 10 A 1.5 V 15 nC D2PAK (TO-263-2) 82 A 0.5 A 300 pF 89 W 1 K/W
IDK09G65C5 active and preferred CoolSiC™ G5 650 V 9 A 1.5 V 14 nC D2PAK (TO-263-2) 75 A 0.45 A 270 pF 82 W 1.1 K/W
IDK08G65C5 active and preferred CoolSiC™ G5 650 V 8 A 1.5 V 13 nC D2PAK (TO-263-2) 68 A 0.4 A 250 pF 76 W 1.2 K/W
IDK06G65C5 active and preferred CoolSiC™ G5 650 V 6 A 1.5 V 10 nC D2PAK (TO-263-2) 54 A 0.3 A 190 pF 62 W 1.5 K/W
IDK05G65C5 active and preferred CoolSiC™ G5 650 V 5 A 1.5 V 8 nC D2PAK (TO-263-2) 46 A 0.25 A 160 pF 55 W 1.7 K/W
IDK04G65C5 active and preferred CoolSiC™ G5 650 V 4 A 1.5 V 7 nC D2PAK (TO-263-2) 38 A 0.2 A 130 pF 48 W 1.9 K/W
IDK03G65C5 active and preferred CoolSiC™ G5 650 V 3 A 1.5 V 5 nC D2PAK (TO-263-2) 31 A 0.15 A 100 pF 42 W 2.2 K/W
IDK02G65C5 active and preferred CoolSiC™ G5 650 V 2 A 1.5 V 4 nC D2PAK (TO-263-2) 23 A 0.1 A 70 pF 36 W 2.6 K/W
DPAK (TO-252)
IDD12SG60C active and preferred CoolSiC™ G3 600 V 12 A 1.8 V 19 nC DPAK (TO-252) 59 A 1 A 310 pF 125 W -
IDD10SG60C active and preferred CoolSiC™ G3 600 V 10 A 1.8 V 16 nC DPAK (TO-252) 51 A 0.8 A 290 pF 120 W -
IDD09SG60C active and preferred CoolSiC™ G3 600 V 9 A 1.8 V 15 nC DPAK (TO-252) 49 A 0.7 A 280 pF 115 W -
IDD08SG60C active and preferred CoolSiC™ G3 600 V 8 A 1.8 V 12 nC DPAK (TO-252) 42 A 0.6 A 240 pF 100 W -
IDD06SG60C active and preferred CoolSiC™ G3 600 V 6 A 2.1 V 8 nC DPAK (TO-252) 32 A 0.5 A 130 pF 71 W -
IDD05SG60C active and preferred CoolSiC™ G3 600 V 5 A 2.1 V 6 nC DPAK (TO-252) 26 A 0.4 A 110 pF 56 W -
IDD04SG60C active and preferred CoolSiC™ G3 600 V 4 A 2.1 V 4.5 nC DPAK (TO-252) 18 A 0.3 A 80 pF 43 W -
IDD03SG60C active and preferred CoolSiC™ G3 600 V 3 A 2.1 V 3.2 nC DPAK (TO-252) 11.5 A 0.23 A 60 pF 38 W -
DPAK real 2pin
IDM10G120C5 active and preferred CoolSiC™ G5 1200 V 10 A 1.5 V 41 nC DPAK (TO-252-2) 99 A 4 A 525 pF 223 W 0.5 K/W
IDM08G120C5 active and preferred CoolSiC™ G5 1200 V 8 A 1.65 V 28 nC DPAK (TO-252-2) 70 A 3 A 365 pF 167 W 0.7 K/W
IDM05G120C5 active and preferred CoolSiC™ G5 1200 V 5 A 1.5 V 24 nC DPAK (TO-252-2) 59 A 2.5 A 301 pF 144 W 0.8 K/W
IDM02G120C5 active and preferred CoolSiC™ G5 1200 V 2 A 1.4 V 14 nC DPAK (TO-252-2) 37 A 1.2 A 182 pF 98 W 1.2 K/W
59
Silicon
Carbide (SiC)
CoolSiC™ Schottky Diode
Product Product Status Technology VDC min [V] IF max [A] VF [V]
QC
[nC] Package I(FSM) max [A] IR [A] CT [pF]
Ptot max
[W] RthJC [K/W]
TO-220 real 2pin
IDH20G120C5 active and preferred CoolSiC™ G5 1200 V 20 A 1.5 V 82 nC TO-220 real 2pin 198 A 8.5 A 1050 pF 330 W 0.35 K/W
IDH16G120C5 active and preferred CoolSiC™ G5 1200 V 16 A 1.65 V 57 nC TO-220 real 2pin 140 A 5.5 A 730 pF 250 W 0.46 K/W
IDH10G120C5 active and preferred CoolSiC™ G5 1200 V 10 A 1.5 V 41 nC TO-220 real 2pin 99 A 4 A 525 pF 165 W 0.7 K/W
IDH08G120C5 active and preferred CoolSiC™ G5 1200 V 8 A 1.65 V 28 nC TO-220 real 2pin 70 A 3 A 365 pF 126 W 0.92 K/W
IDH05G120C5 active and preferred CoolSiC™ G5 1200 V 5 A 1.5 V 24 nC TO-220 real 2pin 59 A 2.5 A 301 pF 109 W 1.06 K/W
IDH02G120C5 active and preferred CoolSiC™ G5 1200 V 2 A 1.4 V 14 nC TO-220 real 2pin 37 A 1.2 A 182 pF 75 W 1.54 K/W
IDH20G65C6 active and preferred CoolSiC™ G6 650 V 20 A 1.25 V 26.8 nC TO-220 real 2pin 99 A 2 A 970 pF 108 W 0.8 K/W
IDH20G65C5 active CoolSiC™ G5 650 V 20 A 1.5 V 29 nC TO-220 real 2pin 142 A 1.1 A 590 pF 157 W 0.6 K/W
IDH16G65C6 active and preferred CoolSiC™ G6 650 V 16 A 1.25 V 21.5 nC TO-220 real 2pin 82 A 1.6 A 783 pF 97 W 0.9 K/W
IDH16G65C5 active CoolSiC™ G5 650 V 16 A 1.5 V 23 nC TO-220 real 2pin 124 A 0.85 A 470 pF 129 W 0.7 K/W
IDH12G65C6 active and preferred CoolSiC™ G6 650 V 12 A 1.25 V 17.1 nC TO-220 real 2pin 64 A 1.2 A 594 pF 81 W 1.1 K/W
IDH12G65C5 active CoolSiC™ G5 650 V 12 A 1.5 V 18 nC TO-220 real 2pin 97 A 0.65 A 360 pF 104 W 0.9 K/W
IDH10G65C6 active and preferred CoolSiC™ G6 650 V 10 A 1.25 V 14.7 nC TO-220 real 2pin 55 A 1 A 495 pF 72 W 1.3 K/W
IDH10G65C5 active CoolSiC™ G5 650 V 10 A 1.5 V 15 nC TO-220 real 2pin 82 A 0.5 A 300 pF 89 W 1 K/W
IDH09G65C5 active CoolSiC™ G5 650 V 9 A 1.5 V 14 nC TO-220 real 2pin 75 A 0.45 A 270 pF 82 W 1.1 K/W
IDH08G65C6 active and preferred CoolSiC™ G6 650 V 8 A 1.25 V 12.2 nC TO-220 real 2pin 47 A 0.8 A 401 pF 63 W 1.4 K/W
IDH08G65C5 active CoolSiC™ G5 650 V 8 A 1.5 V 13 nC TO-220 real 2pin 68 A 0.4 A 250 pF 76 W 1.2 K/W
IDH06G65C6 active and preferred CoolSiC™ G6 650 V 6 A 1.25 V 9.6 nC TO-220 real 2pin 38 A 0.6 A 302 pF 54 W 1.7 K/W
IDH06G65C5 active CoolSiC™ G5 650 V 6 A 1.5 V 10 nC TO-220 real 2pin 54 A 0.3 A 190 pF 62 W 1.5 K/W
IDH05G65C5 active CoolSiC™ G5 650 V 5 A 1.5 V 8 nC TO-220 real 2pin 46 A 0.3 A 160 pF 55 W 1.7 K/W
IDH04G65C6 active and preferred CoolSiC™ G6 650 V 4 A 1.25 V 6.9 nC TO-220 real 2pin 29 A 0.4 A 205 pF 45 W 2 K/W
IDH04G65C5 active CoolSiC™ G5 650 V 4 A 1.5 V 7 nC TO-220 real 2pin 38 A 0.2 A 130 pF 48 W 1.9 K/W
ThinPAK
IDL12G65C5 active and preferred CoolSiC™ G5 650 V 12 A 1.5 V 18 nC ThinPAK 8x8 57 A 0.65 A 360 pF 138 W 0.7 K/W
IDL10G65C5 active and preferred CoolSiC™ G5 650 V 10 A 1.5 V 15 nC ThinPAK 8x8 50 A 0.5 A 300 pF 113 W 0.8 K/W
IDL08G65C5 active and preferred CoolSiC™ G5 650 V 8 A 1.5 V 13 nC ThinPAK 8x8 43 A 0.4 A 250 pF 96 W 1 K/W
IDL06G65C5 active and preferred CoolSiC™ G5 650 V 6 A 1.5 V 10 nC ThinPAK 8x8 36 A 0.3 A 190 pF 78 W 1.2 K/W
IDL04G65C5 active and preferred CoolSiC™ G5 650 V 4 A 1.5 V 7 nC ThinPAK 8x8 29 A 0.2 A 130 pF 62 W 1.6 K/W
IDL02G65C5 active and preferred CoolSiC™ G5 650 V 2 A 1.5 V 4 nC ThinPAK 8x8 21 A 0.1 A 70 pF 46 W 2.1 K/W
60
Silicon
Carbide (SiC)
Product Product Status Technology VDC min [V] IF max [A] VF [V]
QC
[nC] Package I(FSM) max [A] IR [A] CT [pF]
Ptot max
[W] RthJC [K/W]
TO-247
IDW40G120C5B active and preferred CoolSiC™ G5 1200 V 40 A 1.4 V 202 nC TO-247 290 A 23 A 2592 pF 402 W 0.3 K/W
IDW30G120C5B active and preferred CoolSiC™ G5 1200 V 30 A 1.4 V 154 nC TO-247 240 A 17 A 1980 pF 332 W 0.35 K/W
IDW20G120C5B active and preferred CoolSiC™ G5 1200 V 20 A 1.4 V 106 nC TO-247 190 A 12 A 1368 pF 250 W 0.45 K/W
IDW15G120C5B active and preferred CoolSiC™ G5 1200 V 15 A 1.4 V 82 nC TO-247 170 A 8 A 1050 pF 200 W 0.6 K/W
IDW10G120C5B active and preferred CoolSiC™ G5 1200 V 10 A 1.4 V 57 nC TO-247 140 A 6 A 730 pF 148 W 0.8 K/W
IDW40G65C5 active and preferred CoolSiC™ G5 650 V 40 A 1.5 V 55 nC TO-247 182 A 2.2 A 1140 pF 183 W 0.6 K/W
IDW30G65C5 active and preferred CoolSiC™ G5 650 V 30 A 1.5 V 42 nC TO-247 165 A 1.6 A 860 pF 150 W 0.8 K/W
IDW40G65C5B active and preferred CoolSiC™ G5 650 V 20 A 1.5 V 29 nC TO-247 103 A 1.1 A 590 pF 112 W 1 K/W
IDW20G65C5 active and preferred CoolSiC™ G5 650 V 20 A 1.5 V 29 nC TO-247 103 A 1.1 A 590 pF 112 W 1 K/W
IDW32G65C5B active and preferred CoolSiC™ G5 650 V 16 A 1.5 V 23 nC TO-247 95 A 0.8 A 470 pF 188 W 1.2 K/W
IDW16G65C5 active and preferred CoolSiC™ G5 650 V 16 A 1.5 V 23 nC TO-247 95 A 0.8 A 470 pF 94 W 1.2 K/W
IDW24G65C5B active and preferred CoolSiC™ G5 650 V 12 A 1.5 V 18 nC TO-247 71 A 0.6 A 360 pF 152 W 1.5 K/W
IDW12G65C5 active and preferred CoolSiC™ G5 650 V 12 A 1.5 V 18 nC TO-247 71 A 0.6 A 360 pF 76 W 1.5 K/W
IDW20G65C5B active and preferred CoolSiC™ G5 650 V 10 A 1.5 V 15 nC TO-247 58 A 0.5 A 300 pF 130 W 1.8 K/W
IDW10G65C5 active and preferred CoolSiC™ G5 650 V 10 A 1.5 V 15 nC TO-247 58 A 0.5 A 300 pF 65 W 1.8 K/W
TO-220 real 2pin
IDH03G65C5 active CoolSiC™ G5 650 V 3 A 1.5 V 5 nC TO-220 real 2pin 31 A 0.2 A 100 pF 42 W 2.2 K/W
IDH02G65C5 active CoolSiC™ G5 650 V 2 A 1.5 V 4 nC TO-220 real 2pin 23 A 0.1 A 70 pF 36 W 2.6 K/W
IDH12SG60C active and preferred CoolSiC™ G3 600 V 12 A 1.8 V 19 nC TO-220 real 2pin 59 A 1 A 310 pF 125 W -
IDH10SG60C active and preferred CoolSiC™ G3 600 V 10 A 1.8 V 16 nC TO-220 real 2pin 51 A 0.8 A 290 pF 120 W -
IDH09SG60C active and preferred CoolSiC™ G3 600 V 9 A 1.8 V 15 nC TO-220 real 2pin 49 A 0.7 A 280 pF 115 W -
IDH08SG60C active and preferred CoolSiC™ G3 600 V 8 A 1.8 V 12 nC TO-220 real 2pin 42 A 0.6 A 240 pF 100 W -
IDH06SG60C active and preferred CoolSiC™ G3 600 V 6 A 2.1 V 8 nC TO-220 real 2pin 32 A 0.5 A 130 pF 71 W -
IDH05SG60C active and preferred CoolSiC™ G3 600 V 5 A 2.1 V 6 nC TO-220 real 2pin 26 A 0.4 A 110 pF 56 W -
IDH04SG60C active and preferred CoolSiC™ G3 600 V 4 A 2.1 V 4.5 nC TO-220 real 2pin 18 A 0.3 A 80 pF 43 W -
IDH03SG60C active and preferred CoolSiC™ G3 600 V 3 A 2.1 V 3.2 nC TO-220 real 2pin 11.5 A 0.23 A 60 pF 38 W -
61
Silicon
Carbide (SiC)
CoolSiC™ Hybrid Modules
650 V
FS3L50R07W2H3F_B11 active and preferred 650 V 3-level 50 A IGBT HighSpeed 3 EasyPACK™ 2B 1.45 V 1.6 V 56.7 mm 48 mm Full-bridge, PressFIT
FS3L30R07W2H3F_B11 active and preferred 650 V 3-level 30 A IGBT HighSpeed 3 EasyPACK™ 2B 1.5 V 1.6 V 56.7 mm 48 mm Full-bridge, PressFIT
DF100R07W1H5FP_B53 active and preferred 650 V Booster with NTC 100 A TRENCHSTOP™ 5 EasyPACK™ 1B 1.35 V 1.6 V 48 mm 33.8 mm SiC Schottky diode,
PressFIT
DF100R07W1H5FP_B54 active and preferred 650 V Booster with NTC 100 A TRENCHSTOP™ 5 EasyPACK™ 1B 1.35 V 1.6 V 48 mm 33.8 mm SiC Schottky diode,
PressFIT
F4-75R07W2H3_B51 active and preferred 650 V Fourpack 75 A IGBT High Speed 3 EasyPACK™ 2B 1.35 V 1.45 V 56.7 mm 48 mm PressFIT
F4-3L50R07W2H3F_B11 active and preferred 650 V Fourpack 50 A IGBT3 - E3 EasyPACK™ 2B 1.45 V 1.6 V 56.7 mm 48 mm PressFIT
1200 V
DF200R12W1H3F_B11 active and preferred 1200 V Booster with NTC 200 A IGBT HighSpeed 3 EasyPACK™ 1B 1.3 V 1.6 V 48 mm 33.8 mm PressFIT
DF160R12W2H3F_B11 active and preferred 1200 V Booster with NTC 160 A IGBT HighSpeed 3 EasyPACK™ 2B 1.55 V 1.6 V 56.7 mm 48 mm PressFIT
DF80R12W2H3F_B11 active and preferred 1200 V Booster with NTC 80 A IGBT HighSpeed 3 EasyPACK™ 2B 1.55 V 1.6 V 56.7 mm 48 mm PressFIT
DF75R12W1H4F_B11 active and preferred 1200 V Chopper 75 A IGBT HighSpeed 2 EasyPACK™ 1B 2.1 V 1.6 V 48 mm 33.8 mm PressFIT
Product Product Status Voltage Class
[V]
Configuration IC(nom) / IF(nom)
[A]
Technology Housing
VCE(sat) Tvj=25°C typ
[V]
VF Tvj=25°C typ
[V]
Dimensions length
[mm]
Dimensions width
[mm]
Features
62
Silicon
Carbide (SiC)
63
Silicon
Carbide (SiC)
6464
Infineon offers a variety of semiconductors in different packages and different voltage- and current classes.
These IPMs are separated in CIPOS™ Nano, CIPOS™ Micro and CIPOS™ Mini families.
The CIPOS™IPMs are families of highly integrated, compact power modules designed to drive motors in applications
ranging from home appliances, fans, pumps to general purpose drives.
These energy-efficient intelligent power modules integrate the latest power semiconductor and control ICs
technology leveraging Infineon’s advanced IGBTs, MOSFETs, next-generation Gate Driver ICs and state-of-the-art
thermo-mechanical technology. The modules improve system performance and energy efficiency by delivering
increased power density, enhanced system ruggedness and reliability.
A broad selection of modules is offered to enable optimum PCB design, size and system costs. This simplifies the
motor drive design, improves reliabilities and lowers component counts while significantly reducing time to market.
IPMs & Digital Motor Controller
Intelligent power modules
65
IPMs & Digital
Motor Controller
Intelligent power modules (IPMs)
Product OPN Product Status Package name Green Halogen-
free
Product Group
Voltage Class
[V]
Rated Current
[A]
Built in
NTC
Configuration
Pmot 10kHz
[W]
RDS (on) 25C max
[]
IFCM10P60GD IFCM10P60GDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 10 A yes PFC Integrated - -
IFCM10S60GD IFCM10S60GDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 10 A yes PFC Integrated - -
IFCM15P60GD IFCM15P60GDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 15 A yes PFC Integrated - -
IFCM15S60GD IFCM15S60GDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 15 A yes PFC Integrated - -
IFCM20T65GD IFCM20T65GDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 650 V 20 A yes 2 Phase Interleaved PFC - -
IFCM20U65GD IFCM20U65GDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 650 V 20 A yes 3 Phase Interleaved PFC - -
IFCM30T65GD IFCM30T65GDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 650 V 30 A yes 2 Phase Interleaved PFC - -
IFCM30U65GD IFCM30U65GDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 650 V 30 A yes 3 Phase Interleaved PFC - -
IGCM04F60GA IGCM04F60GAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 4 A yes 3 Phase Open Emitter 600 W -
IGCM04F60HA IGCM04F60HAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 4 A no 3 Phase Open Emitter 600 W -
IGCM04G60GA IGCM04G60GAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 4 A yes 3 Phase Common Emitter 600 W -
IGCM04G60HA IGCM04G60HAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 4 A no 3 Phase Common Emitter 600 W -
IGCM06F60GA IGCM06F60GAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 6 A yes 3 Phase Open Emitter 800 W -
IGCM06F60HA IGCM06F60HAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 6 A no 3 Phase Open Emitter 800 W -
IGCM06G60GA IGCM06G60GAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 6 A yes 3 Phase Common Emitter 800 W -
IGCM06G60HA IGCM06G60HAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 6 A no 3 Phase Common Emitter 800 W -
IGCM10F60GA IGCM10F60GAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 10 A yes 3 Phase Open Emitter 1000 W -
IGCM10F60HA IGCM10F60HAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 10 A no 3 Phase Open Emitter 1000 W -
IGCM15F60GA IGCM15F60GAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 15 A yes 3 Phase Open Emitter 1200 W -
IGCM15F60HA IGCM15F60HAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 15 A no 3 Phase Open Emitter 1200 W -
IGCM20F60GA IGCM20F60GAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 20 A yes 3 Phase Open Emitter 1600 W -
IGCM20F60HA IGCM20F60HAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 20 A no 3 Phase Open Emitter 1600 W -
IKCM10H60GA IKCM10H60GAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 10 A yes 3 Phase Open Emitter 1000 W -
IKCM10H60HA IKCM10H60HAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 10 A no 3 Phase Open Emitter 1000 W -
IKCM10L60GA IKCM10L60GAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 10 A yes 3 Phase Open Emitter 1200 W -
IKCM10L60HA IKCM10L60HAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 10 A no 3 Phase Open Emitter 1200 W -
IKCM15F60GA IKCM15F60GAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 15 A yes 3 Phase Open Emitter 1600 W -
IKCM15F60HA IKCM15F60HAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 15 A no 3 Phase Open Emitter 1600 W -
66
IPMs & Digital
Motor Controller
Product OPN Product Status Package name Green Halogen-
free
Product Group
Voltage Class
[V]
Rated Current
[A]
Built in
NTC
Configuration
Pmot 10kHz
[W]
RDS (on) 25C max
[]
IKCM15H60GA IKCM15H60GAXKMA2 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 15 A yes 3 Phase Open Emitter 1200 W -
IKCM15H60HA IKCM15H60HAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 15 A no 3 Phase Open Emitter 1200 W -
IKCM15L60GA IKCM15L60GAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 15 A yes 3 Phase Open Emitter 1600 W -
IKCM15L60GD IKCM15L60GDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 15 A yes 3 Phase Open Emitter 2200 W -
IKCM15L60HA IKCM15L60HAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 15 A no 3 Phase Open Emitter 1600 W -
IKCM15L60HD IKCM15L60HDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 15 A no 3 Phase Open Emitter 2200 W -
IKCM15R60GD IKCM15R60GDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 15 A yes 2 Phase Switched Reluctance Drives 2200 W -
IKCM20L60GA IKCM20L60GAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 20 A yes 3 Phase Open Emitter 1800 W -
IKCM20L60GD IKCM20L60GDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 20 A yes 3 Phase Open Emitter 2400 W -
IKCM20L60HA IKCM20L60HAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 20 A no 3 Phase Open Emitter 1800 W -
IKCM20L60HD IKCM20L60HDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 20 A no 3 Phase Open Emitter 2400 W -
IKCM20R60GD IKCM20R60GDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 20 A yes 2 Phase Switched Reluctance Drives 2400 W -
IKCM30F60GA IKCM30F60GAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 30 A yes 3 Phase Open Emitter 2000 W -
IKCM30F60GD IKCM30F60GDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 30 A yes 3 Phase Open Emitter 2600 W -
IKCM30F60HA IKCM30F60HAXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 30 A no 3 Phase Open Emitter 2000 W -
IKCM30F60HD IKCM30F60HDXKMA1 active and preferred PG-MDIP-24 yes yes CIPOS™ Mini 600 V 30 A no 3 Phase Open Emitter 2600 W -
IRSM005-301MH IRSM005-301MH active and preferred QFN 7X8 27L yes yes CIPOS™ Nano 100 V - no Half-Bridge 165 W 0.02 
IRSM005-800MH IRSM005-800MH active and preferred QFN 7X8 27L yes yes CIPOS™ Nano 40 V - no Half-Bridge 165 W 0.005 
IRSM505-015DA IRSM505-015DA active and preferred DIP23 yes no CIPOS™ Micro 500 V - yes 3 Phase Open Source 50 W 6 
IRSM505-015PA IRSM505-015PA active and preferred SOP23 yes no CIPOS™ Micro 500 V - yes 3 Phase Open Source 50 W 6 
IRSM505-024DA IRSM505-024DA active and preferred DIP23 yes no CIPOS™ Micro 250 V - yes 3 Phase Open Source 40 W 2.2 
IRSM505-024PA IRSM505-024PA active and preferred SOP23 yes no CIPOS™ Micro 250 V - yes 3 Phase Open Source 40 W 2.2 
IRSM505-025DA IRSM505-025DA active and preferred DIP23 yes no CIPOS™ Micro 500 V - yes 3 Phase Open Source 60 W 4 
IRSM505-025PA IRSM505-025PA active and preferred SOP23 yes no CIPOS™ Micro 500 V - yes 3 Phase Open Source 60 W 4 
IRSM505-035DA IRSM505-035DA active and preferred DIP23 yes no CIPOS™ Micro 500 V - yes 3 Phase Open Source 75 W 2.2 
IRSM505-035PA IRSM505-035PA active and preferred SOP23 yes no CIPOS™ Micro 500 V - yes 3 Phase Open Source 75 W 2.2 
IRSM505-044DA IRSM505-044DA active and preferred DIP23 yes no CIPOS™ Micro 250 V - yes 3 Phase Open Source 65 W 1.05 
IRSM505-044PA IRSM505-044PA active and preferred SOP23 yes no CIPOS™ Micro 250 V - yes 3 Phase Open Source 65 W 1.05 
67
IPMs & Digital
Motor Controller
Intelligent power modules (IPMs)
Product OPN Product Status Package name Green Halogen-
free
Product Group
Voltage Class
[V]
Rated Current
[A]
Built in
NTC
Configuration
Pmot 10kHz
[W]
RDS (on) 25C max
[]
IRSM505-055DA IRSM505-055DA2 active and preferred DIP23 yes no CIPOS™ Micro 500 V - yes 3 Phase Open Source 85 W 1.7 
IRSM505-055PA IRSM505-055PA active and preferred SOP23 yes no CIPOS™ Micro 500 V - yes 3 Phase Open Source 85 W 1.7 
IRSM505-065DA IRSM505-065DA2 active and preferred DIP23 yes no CIPOS™ Micro 500 V - yes 3 Phase Open Source 85 W 1.3 
IRSM505-065PA IRSM505-065PA active and preferred SOP23 yes no CIPOS™ Micro 500 V - yes 3 Phase Open Source 85 W 1.3 
IRSM505-084DA IRSM505-084DA2 active and preferred DIP23 yes no CIPOS™ Micro 250 V - yes 3 Phase Open Source 95 W 0.45 
IRSM505-084PA IRSM505-084PA active and preferred SOP23 yes no CIPOS™ Micro 250 V - yes 3 Phase Open Source 95 W 0.45 
IRSM506-076DA IRSM506-076DA active and preferred DIP23 yes no CIPOS™ Micro 600 V 4 A yes 3 Phase Open Source 105 W -
IRSM506-076PA IRSM506-076PA active and preferred SOP23 yes no CIPOS™ Micro 600 V 4 A yes 3 Phase Open Source 105 W -
IRSM515-015DA IRSM515-015DA active and preferred DIP23 yes no CIPOS™ Micro 500 V - no 3 Phase Open Source 50 W 6 
IRSM515-015PA IRSM515-015PA active and preferred SOP23 yes no CIPOS™ Micro 500 V - no 3 Phase Open Source 50 W 6 
IRSM515-024DA IRSM515-024DA2 active and preferred DIP23 yes no CIPOS™ Micro 250 V - no 3 Phase Open Source 40 W 2.2 
IRSM515-024PA IRSM515-024PA active and preferred SOP23 yes no CIPOS™ Micro 250 V - no 3 Phase Open Source 40 W 2.2 
IRSM515-025DA IRSM515-025DA active and preferred DIP23 yes no CIPOS™ Micro 500 V - no 3 Phase Open Source 60 W 4 
IRSM515-025PA IRSM515-025PA active and preferred SOP23 yes no CIPOS™ Micro 500 V - no 3 Phase Open Source 60 W 4 
IRSM515-035DA IRSM515-035DA active and preferred DIP23 yes no CIPOS™ Micro 500 V - no 3 Phase Open Source 75 W 2.2 
IRSM515-035PA IRSM515-035PA active and preferred SOP23 yes no CIPOS™ Micro 500 V - no 3 Phase Open Source 75 W 2.2 
IRSM515-044DA IRSM515-044DA active and preferred DIP23 yes no CIPOS™ Micro 250 V - no 3 Phase Open Source 65 W 1.05 
IRSM515-044PA IRSM515-044PA active and preferred SOP23 yes no CIPOS™ Micro 250 V - no 3 Phase Open Source 65 W 1.05 
IRSM515-055DA IRSM515-055DA active and preferred DIP23 yes no CIPOS™ Micro 500 V - no 3 Phase Open Source 85 W 1.7 
IRSM515-055PA IRSM515-055PA active and preferred SOP23 yes no CIPOS™ Micro 500 V - no 3 Phase Open Source 85 W 1.7 
IRSM515-065DA IRSM515-065DA2 active and preferred DIP23 yes no CIPOS™ Micro 500 V - no 3 Phase Open Source 85 W 1.3 
IRSM515-065PA IRSM515-065PA active and preferred SOP23 yes no CIPOS™ Micro 500 V - no 3 Phase Open Source 85 W 1.3 
IRSM515-084DA IRSM515-084DA active and preferred DIP23 yes no CIPOS™ Micro 250 V - no 3 Phase Open Source 95 W 0.45 
IRSM515-084PA IRSM515-084PA active and preferred SOP23 yes no CIPOS™ Micro 250 V - no 3 Phase Open Source 95 W 0.45 
IRSM516-076DA IRSM516-076DA active and preferred DIP23 yes no CIPOS™ Micro 600 V 4 A no 3 Phase Open Source 105 W -
IRSM516-076PA IRSM516-076PA active and preferred SOP23 yes no CIPOS™ Micro 600 V 4 A no 3 Phase Open Source 105 W -
IRSM807-045MH IRSM807-045MHTR active and preferred QFN 9X8 31L yes yes CIPOS™ Nano 500 V - no Half-Bridge 130 W 1.7 
IRSM807-105MH IRSM807-105MHTR active and preferred QFN 8X9 31L yes yes CIPOS™ Nano 500 V - no Half-Bridge 205 W 0.8 
68
IPMs & Digital
Motor Controller
Product OPN Product Status Package name Green Halogen-
free
Product Group
Voltage Class
[V]
Rated Current
[A]
Built in
NTC
Configuration
Pmot 10kHz
[W]
RDS (on) 25C max
[]
IRSM808-105MH IRSM808-105MH active and preferred QFN 8X9 31L yes yes CIPOS™ Nano 500 V - no Half-Bridge 205 W 0.8 
IRSM808-204MH IRSM808-204MHTR active and preferred QFN 9X8 31L yes yes CIPOS™ Nano 250 V - no Half-Bridge 205 W 0.15 
IRSM836-015MA IRSM836-015MA active and preferred QFN 12X12 36L yes yes CIPOS™ Nano 500 V - no 3 Phase Open Source 50 W 6 
IRSM836-024MA IRSM836-024MATR active and preferred QFN 12X12 36L yes yes CIPOS™ Nano 250 V - no 3 Phase Open Source 40 W 2.2 
IRSM836-025MA IRSM836-025MATR active and preferred QFN 12X12 36L yes yes CIPOS™ Nano 500 V - no 3 Phase Open Source 55 W 4 
IRSM836-035MA IRSM836-035MA active and preferred QFN 12X12 36L yes yes CIPOS™ Nano 500 V - no 3 Phase Common Source 70 W 2.2 
IRSM836-035MB IRSM836-035MB active and preferred QFN 12X12 27L yes yes CIPOS™ Nano 500 V - no 3 Phase Common Source 70 W 2.2 
IRSM836-044MA IRSM836-044MATR active and preferred QFN 12X12 36L yes yes CIPOS™ Nano 250 V - no 3 Phase Open Source 60 W 1.05 
IRSM836-045MA IRSM836-045MA active and preferred QFN 12X12 37L yes yes CIPOS™ Nano 500 V - no 3 Phase Open Source 80 W 1.7 
IRSM836-084MA IRSM836-084MA active and preferred QFN 12X12 36L yes yes CIPOS™ Nano 250 V - no 3 Phase Open Source 85 W 0.45 
69
IPMs & Digital
Motor Controller
Digital Motor Controller (iMOTION™)
Product Product Status Moisture Sensitivity Level Package Integration Level Control Option
Description
Type of Memory
IMC102T-F064 active and preferred 3 PG-LQFP-64-26 MCE 1 motor + PFC MCE 2.0 with scripting, boost / totem pole PFC Flash
IMC101T-Q048 active and preferred 3 PG-VQFN-48-73 MCE 1 motor MCE 2.0 with scripting, smallest footprint Flash
IMC101T-F064 active and preferred 3 PG-LQFP-64-26 MCE 1 motor MCE 2.0 with scripting, high pin count Flash
IMC101T-T038 active and preferred 3 PG-TSSOP-38-9 MCE 1 motor MCE 2.0 with scripting, lowest cost package Flash
IRMCF171 active and preferred 3 LQFP48 MCE+MCU 1 motor small package Flash
IRMCF183M active and preferred 2 QFN32 MCE+MCU 1 motor smallest package Flash
IRMCK099M active and preferred 2 QFN32 MCE 1 motor MCE stand-alone OTP
IRMCF188 active and preferred 3 LQFP64 MCE+MCU 1 motor + PFC Dedicated PFC PWM for digital PFC control Flash
IRDM983-025MB active and preferred 3 Power-QFN 12x12 mm SmartIPM 1 motor for three phase PMSM fan two hall sensors 500V / 2A ROM
IRMCF343 active 3 QFP64 MCE+MCU 1 motor + PFC Dedicated PFC PWM for digital PFC control, external EEPROM required RAM
IRMCK171 active 3 LQFP48 MCE+MCU 1 motor small package OTP
IRMCF311 active 3 QFP64 MCE+MCU 2 motor + PFC Dual motor control plus digital PFC control, external EEPROM required RAM
IRMCK341 active 3 QFP64 MCE+MCU 1 motor Supports incremental encoder with Hall OTP
IRMCK343 active 3 QFP64 MCE+MCU 1 motor + PFC Dedicated PFC PWM for digital PFC control OTP
IRMCK311 active 3 QFP64 MCE+MCU 2 motor + PFC Dual motor control plus digital PFC control OTP
IRMCK371 active 3 LQFP48 MCE+MCU 1 motor small package OTP
IRDM982-035MB active 3 Power-QFN 12x12 mm SmartIPM 1 motor for three phase PMSM fan three hall sensors 500V / 3A ROM
IRMCF143 active 3 LQFP64 MCE+MCU 1 motor, Servo Supports incremental encoder with Hall Flash
IRMCF341 active 3 QFP64 MCE+MCU 1 motor Supports incremental encoder with Hall, external EEPROM required RAM
IRMCF371 active 3 LQFP48 MCE+MCU 1 motor small package, external EEPROM required RAM
70
IPMs & Digital
Motor Controller
71
IPMs & Digital
Motor Controller
72
Leveraging the application expertise and advanced technologies of Infineon and International Rectifier, the gate driver
ICs are well suited for many application such as automotive, major home appliances, industrial motor drives, solar
inverters, UPS, switched-mode power supplies, and high-voltage lighting.
Infineon offers a comprehensive portfolio with a variety of configurations, voltage classes, isolation levels, protection
features, and package options. These flexible gate driver ICs are complementary to Infineon IGBTs, silicon and silicon
carbide MOSFETs (e.g. CoolMOS™ and CoolSiC™), or as part of integrated power modules. Every switch needs a driver.
Gate Driver ICs
Gate Driver ICs
73
Gate
Driver ICs
High Side Gate Driver ICs
1ED020I12-B2 active and preferred 1200 Basic Isolation 2 2 High Side (Single) 5.5 4.1 3.8 170 165 PG-DSO-16
1ED020I12-BT active and preferred 1200 Basic Isolation 2 2 High Side (Single) 5.5 4.1 3.8 1750 1750 PG-DSO-16
1ED020I12-F2 active and preferred 1200 Galvanic Isolation 2 2 High Side (Single) 5.5 4.1 3.8 170 165 PG-DSO-16
1ED020I12-FT active and preferred 1200 Galvanic Isolation 2 2 High Side (Single) 5.5 4.1 3.8 1750 1750 PG-DSO-16
1EDC05I12AH active and preferred 1200 Galvanic Isolation 0.9 1.3 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8-59
1EDC10I12MH active and preferred 1200 Galvanic Isolation 2.3 2.2 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDC20H12AH active and preferred 1200 Galvanic Isolation 3.5 4 High Side (Single) 17 2.85 2.75 120 125 PG-DSO-8
1EDC20I12AH active and preferred 1200 Galvanic Isolation 3.5 4 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDC20I12MH active and preferred 1200 Galvanic Isolation 4.1 4.4 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDC30I12MH active and preferred 1200 Galvanic Isolation 6.2 5.9 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDC40I12AH active and preferred 1200 Galvanic Isolation 6.8 7.5 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDC60H12AH active and preferred 1200 Galvanic Isolation 9.4 10 High Side (Single) 17 2.85 2.75 120 125 PG-DSO-8
1EDC60I12AH active and preferred 1200 Galvanic Isolation 9.4 10 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDI05I12AF active and preferred 1200 Galvanic Isolation 0.9 1.3 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDI05I12AH active and preferred 1200 Galvanic Isolation 0.9 1.3 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDI10I12MF active and preferred 1200 Galvanic Isolation 2.3 2.2 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDI10I12MH active and preferred 1200 Galvanic Isolation 2.3 2.2 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDI20H12AH active and preferred 1200 Galvanic Isolation 3.5 4 High Side (Single) 17 2.85 2.75 120 125 PG-DSO-8
1EDI20I12AF active and preferred 1200 Galvanic Isolation 3.5 4 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDI20I12AH active and preferred 1200 Galvanic Isolation 3.5 4 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDI20I12MF active and preferred 1200 Galvanic Isolation 4.1 4.4 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDI20I12MH active and preferred 1200 Galvanic Isolation 4.1 4.4 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDI20N12AF active and preferred 1200 Galvanic Isolation 3.5 4 High Side (Single) 17 2.85 2.75 115 120 PG-DSO-8
1EDI30I12MF active and preferred 1200 Galvanic Isolation 6.2 5.9 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDI30I12MH active and preferred 1200 Galvanic Isolation 6.2 5.9 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDI30J12CP active and preferred 1200 Galvanic Isolation 4 4 High Side (Single) 17.5 - - 80 80 PG-DSO-19
1EDI40I12AF active and preferred 1200 Galvanic Isolation 6.8 7.5 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDI40I12AH active and preferred 1200 Galvanic Isolation 6.8 7.5 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDI60H12AH active and preferred 1200 Galvanic Isolation 9.4 10 High Side (Single) 17 2.85 2.75 120 125 PG-DSO-8
1EDI60I12AF active and preferred 1200 Galvanic Isolation 9.4 10 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
Product Product status Voltage Class
[V]
Isolation type Output Current
Sink typ.
[A]
Output Current
Source typ.
[A]
Configuration
Input Vcc
Max
[V]
Input UVLO
On typ.
[V]
Input UVLO
Off typ.
[V]
Propagation Delay
Turn On typ.
[ns]
Propagation Delay
Turn Off typ.
[ns]
Package
74
Gate
Driver ICs
1EDI60I12AH active and preferred 1200 Galvanic Isolation 9.4 10 High Side (Single) 17 2.85 2.75 300 300 PG-DSO-8
1EDI60N12AF active and preferred 1200 Galvanic Isolation 9.4 10 High Side (Single) 17 2.85 2.75 120 125 PG-DSO-8
IR2117 active 600 Functional levelshift 0.5 0.25 High Side (Single) 20 8.6 8.2 125 105 PDIP8
IR2117S active 600 Functional levelshift 0.5 0.25 High Side (Single) 20 8.6 8.2 125 105 SOIC 8N
IR2118 active 600 Functional levelshift 0.5 0.25 High Side (Single) 20 8.6 8.2 125 105 PDIP8
IR2118S active 600 Functional levelshift 0.5 0.25 High Side (Single) 20 8.6 8.2 125 105 SOIC 8N
IR2127 active 600 Functional levelshift 0.5 0.25 High Side (Single) 20 - - 200 150 PDIP8
IR21271 active 600 Functional levelshift 0.5 0.25 High Side (Single) 20 - - 200 150 PDIP8
IR21271S active 600 Functional levelshift 0.5 0.25 High Side (Single) 20 - - 200 150 SOIC 8N
IR2127S active 600 Functional levelshift 0.5 0.25 High Side (Single) 20 - - 200 150 SOIC 8N
IR2128 active 600 Functional levelshift 0.5 0.25 High Side (Single) 20 - - 200 150 PDIP8
IR2128S active 600 Functional levelshift 0.5 0.25 High Side (Single) 20 - - 200 150 SOIC 8N
IRS2117 active and preferred 600 Functional levelshift 0.6 0.29 High Side (Single) 20 8.6 8.2 125 105 PDIP8
IRS2117S active and preferred 600 Functional levelshift 0.6 0.29 High Side (Single) 20 8.6 8.2 125 105 SOIC 8N
IRS2118 active and preferred 600 Functional levelshift 0.6 0.29 High Side (Single) 20 8.6 8.2 125 105 PDIP8
IRS2118S active and preferred 600 Functional levelshift 0.6 0.29 High Side (Single) 20 8.6 8.2 125 105 SOIC 8N
IRS2127 active and preferred 600 Functional levelshift 0.6 0.29 High Side (Single) 20 - - 150 150 PDIP8
IRS21271 active and preferred 600 Functional levelshift 0.6 0.29 High Side (Single) 20 - - 150 150 PDIP8
IRS21271S active and preferred 600 Functional levelshift 0.6 0.29 High Side (Single) 20 - - 150 150 SOIC 8N
IRS2127S active and preferred 600 Functional levelshift 0.6 0.29 High Side (Single) 20 - - 150 150 SOIC 8N
IRS25752L active and preferred 600 Functional levelshift 0.24 0.16 High Side (Single) 18 9 8 140 215 SOT23
IR2125 active and preferred 500 Functional levelshift 3.3 1.6 High Side (Single) 18 8.9 8 170 200 PDIP8
IR2125S active and preferred 500 Functional levelshift 3.3 1.6 High Side (Single) 18 8.9 8 170 200 SOIC 16W
IRS20752L active and preferred 200 Functional levelshift 0.24 0.16 High Side (Single) 18 9 8 140 215 SOT23
IRS10752L active and preferred 100 Functional levelshift 0.24 0.16 High Side (Single) 18 9 8 140 215 SOT23
2ED020I12-F2 active and preferred 1200 Galvanic Isolation 2 2 High Side (Dual) 5.5 4.1 3.8 170 165 PG-DSO-36
Product Product status Voltage Class
[V]
Isolation type Output Current
Sink typ.
[A]
Output Current
Source typ.
[A]
Configuration
Input Vcc
Max
[V]
Input UVLO
On typ.
[V]
Input UVLO
Off typ.
[V]
Propagation Delay
Turn On typ.
[ns]
Propagation Delay
Turn Off typ.
[ns]
Package
75
Gate
Driver ICs
Low Side Gate Driver ICs
Product Product status Voltage Class
[V]
Isolation type Output Current
Sink typ.
[A]
Output Current
Source typ.
[A]
Configuration
Input Vcc
Max
[V]
Input UVLO
On typ.
[V]
Input UVLO
Off typ.
[V]
Propagation Delay
Turn On typ.
[ns]
Propagation Delay
Turn Off typ.
[ns]
Package
IR44252L active and preferred 25 Non-Isolated 0.55 0.3 Low Side (Single) 18 - - 50 50 SOT23
IR44272L active and preferred 25 Non-Isolated 1.5 1.7 Low Side (Single) 18 - - 50 50 SOT23
IR44273L active and preferred 25 Non-Isolated 1.5 1.7 Low Side (Single) 18 - - 50 50 SOT23
IRS44273L active and preferred 25 Non-Isolated 1.5 1.5 Low Side (Single) 20 10.2 9.2 50 50 SOT23
IR2121 active and preferred 5 Non-Isolated 3.3 1.6 Low Side (Single) 18 8.9 8 150 200 PDIP8
IR25600 active 25 Non-Isolated 3.3 2.3 Low Side (Dual) 20 - - 85 65 PDIP8
IR25600S active 25 Non-Isolated 3.3 2.3 Low Side (Dual) 20 - - 85 65 SOIC 8N
IR4426 active 25 Non-Isolated 3.3 2.3 Low Side (Dual) 20 - - 85 65 PDIP8
IR4426S active 25 Non-Isolated 3.3 2.3 Low Side (Dual) 20 - - 85 65 SOIC 8N
IR4427 active 25 Non-Isolated 3.3 2.3 Low Side (Dual) 20 - - 85 65 PDIP8
IR4427S active 25 Non-Isolated 3.3 2.3 Low Side (Dual) 20 - - 85 65 SOIC 8N
IRS44262S active and preferred 25 Non-Isolated 3.3 2.3 Low Side (Dual) 20 10.2 9.2 50 50 SOIC 8N
IRS4426S active and preferred 25 Non-Isolated 3.3 2.3 Low Side (Dual) 20 - - 50 50 SOIC 8N
IRS4427 active and preferred 25 Non-Isolated 3.3 2.3 Low Side (Dual) 20 - - 50 50 PDIP8
IRS4427S active and preferred 25 Non-Isolated 3.3 2.3 Low Side (Dual) 20 - - 50 50 SOIC 8N
IRS4428S active 25 Non-Isolated 3.3 2.3 Low Side (Dual) 20 - - 50 50 SOIC 8N
76
Gate
Driver ICs
High and Low Side Gate Driver ICs
Product Product status Voltage Class
[V]
Isolation type Output Current
Sink typ.
[A]
Output Current
Source typ.
[A]
Configuration
Input Vcc
Max
[V]
Input UVLO
On typ.
[V]
Input UVLO
Off typ.
[V]
Propagation Delay
Turn On typ.
[ns]
Propagation Delay
Turn Off typ.
[ns]
Package
IR2213 active and preferred 1200 Functional levelshift 2.5 2 High-side and low-side 20 10.2 9.3 280 225 PDIP14
IR2213S active and preferred 1200 Functional levelshift 2.5 2 High-side and low-side 20 10.2 9.3 280 225 SOIC 16W
IR7106S active and preferred 700 Functional levelshift 0.35 0.22 High-side and low-side 20 8.9 8.2 220 200 SOIC 8N
2EDL05I06BF active and preferred 600 Functional levelshift 0.7 0.36 High-side and low-side 17.5 12.5 11.6 420 400 PG-DSO-8
IR2101 active 600 Functional levelshift 0.36 0.21 High-side and low-side 20 8.9 8.2 160 150 PDIP8
IR2101S active 600 Functional levelshift 0.36 0.21 High-side and low-side 20 8.9 8.2 160 150 SOIC 8N
IR2102 active and preferred 600 Functional levelshift 0.36 0.21 High-side and low-side 20 8.9 8.2 160 150 PDIP8
IR2102S active and preferred 600 Functional levelshift 0.36 0.21 High-side and low-side 20 8.9 8.2 160 150 SOIC 8N
IR2106 active 600 Functional levelshift 0.35 0.2 High-side and low-side 20 8.9 8.2 220 200 PDIP8
IR21064 active 600 Functional levelshift 0.35 0.2 High-side and low-side 20 8.9 8.2 220 200 PDIP14
IR21064S active 600 Functional levelshift 0.35 0.2 High-side and low-side 20 8.9 8.2 220 200 SOIC 14N
IR2106S active 600 Functional levelshift 0.35 0.2 High-side and low-side 20 8.9 8.2 220 200 SOIC 8N
IR2112 active 600 Functional levelshift 0.5 0.25 High-side and low-side 20 8.6 8.2 125 105 PDIP14
IR2112S active 600 Functional levelshift 0.5 0.25 High-side and low-side 20 8.6 8.2 125 105 SOIC 16W
IR2113 active 600 Functional levelshift 2.5 2.5 High-side and low-side 20 8.5 8.2 120 94 PDIP14
IR2113S active 600 Functional levelshift 2.5 2.5 High-side and low-side 20 8.5 8.2 120 94 SOIC 16W
IR2181 active 600 Functional levelshift 2.3 1.9 High-side and low-side 20 8.9 8.2 180 220 PDIP8
IR21814 active 600 Functional levelshift 2.3 1.9 High-side and low-side 20 8.9 8.2 180 220 PDIP14
IR21814S active 600 Functional levelshift 2.3 1.9 High-side and low-side 20 8.9 8.2 180 220 SOIC 14N
IR2181S active 600 Functional levelshift 2.3 1.9 High-side and low-side 20 8.9 8.2 180 220 SOIC 8N
IR2301 active 600 Functional levelshift 0.35 0.2 High-side and low-side 20 4.1 3.8 220 200 PDIP8
IR2301S active 600 Functional levelshift 0.35 0.2 High-side and low-side 20 4.1 3.8 220 200 SOIC 8N
IR25604S active 600 Functional levelshift 0.35 0.2 High-side and low-side 20 8.9 8.2 220 200 SOIC 8N
IR25607S active 600 Functional levelshift 2.5 2.5 High-side and low-side 20 8.5 8.2 120 94 SOIC 16W
IRS2101 active and preferred 600 Functional levelshift 0.6 0.29 High-side and low-side 20 8.9 8.2 160 150 PDIP8
IRS2101S active and preferred 600 Functional levelshift 0.6 0.29 High-side and low-side 20 8.9 8.2 160 150 SOIC 8N
IRS2106 active and preferred 600 Functional levelshift 0.6 0.29 High-side and low-side 20 8.9 8.2 220 200 PDIP8
IRS21064 active and preferred 600 Functional levelshift 0.6 0.29 High-side and low-side 20 8.9 8.2 220 200 PDIP14
IRS21064S active and preferred 600 Functional levelshift 0.6 0.29 High-side and low-side 20 8.9 8.2 220 200 SOIC 14N
IRS2106S active and preferred 600 Functional levelshift 0.6 0.29 High-side and low-side 20 8.9 8.2 220 200 SOIC 8N
77
Gate
Driver ICs
High and Low Side Gate Driver ICs
IRS2112 active and preferred 600 Functional levelshift 0.6 0.29 High-side and low-side 20 8.6 8.2 135 130 PDIP14
IRS2112S active and preferred 600 Functional levelshift 0.6 0.29 High-side and low-side 20 8.6 8.2 135 130 SOIC 16W
IRS2113 active and preferred 600 Functional levelshift 2.5 2.5 High-side and low-side 20 8.5 8.2 130 120 PDIP14
IRS2113M active and preferred 600 Functional levelshift 2.5 2.5 High-side and low-side 20 8.5 8.2 130 120 MLPQ 4X4 14L
IRS2113S active and preferred 600 Functional levelshift 2.5 2.5 High-side and low-side 20 8.5 8.2 130 120 SOIC 16W
IRS2181 active and preferred 600 Functional levelshift 2.3 1.9 High-side and low-side 20 8.9 8.2 180 220 PDIP8
IRS21814 active and preferred 600 Functional levelshift 2.3 1.9 High-side and low-side 20 8.9 8.2 180 220 PDIP14
IRS21814M active and preferred 600 Functional levelshift 2.3 1.9 High-side and low-side 20 8.9 8.2 180 220 MLPQ 4X4 14L
IRS21814S active and preferred 600 Functional levelshift 2.3 1.9 High-side and low-side 20 8.9 8.2 180 220 SOIC 14N
IRS2181S active and preferred 600 Functional levelshift 2.3 1.9 High-side and low-side 20 8.9 8.2 180 220 SOIC 8N
IRS2186 active and preferred 600 Functional levelshift 4 4 High-side and low-side 20 8.9 8.2 170 170 PDIP8
IRS21864 active and preferred 600 Functional levelshift 4 4 High-side and low-side 20 8.9 8.2 170 170 PDIP14
IRS21864S active and preferred 600 Functional levelshift 4 4 High-side and low-side 20 8.9 8.2 170 170 SOIC 14N
IRS21867S active and preferred 600 Functional levelshift 4 4 High-side and low-side 20 6 5.5 170 170 SOIC 8N
IRS2186S active and preferred 600 Functional levelshift 4 4 High-side and low-side 20 8.9 8.2 170 170 SOIC 8N
IRS2301S active and preferred 600 Functional levelshift 0.35 0.2 High-side and low-side 20 4.1 3.8 220 200 SOIC 8N
IR2110 active 500 Functional levelshift 2.5 2.5 High-side and low-side 20 8.5 8.2 120 94 PDIP14
IR2110S active 500 Functional levelshift 2.5 2.5 High-side and low-side 20 8.5 8.2 120 94 SOIC 16W
IRS2110 active and preferred 500 Functional levelshift 2.5 2.5 High-side and low-side 20 8.5 8.2 130 120 PDIP14
IRS2110S active and preferred 500 Functional levelshift 2.5 2.5 High-side and low-side 20 8.5 8.2 130 120 SOIC 16W
IR2010 active and preferred 200 Functional levelshift 3 3 High-side and low-side 20 8.6 8.2 95 65 PDIP14
IR2010S active and preferred 200 Functional levelshift 3 3 High-side and low-side 20 8.6 8.2 95 65 SOIC 16W
IR2011 active 200 Functional levelshift 1 1 High-side and low-side 20 9 8.2 80 75 PDIP8
IR2011S active 200 Functional levelshift 1 1 High-side and low-side 20 9 8.2 80 75 SOIC 8N
IRS2005M active and preferred 200 Functional levelshift 0.6 0.29 High-side and low-side 20 8.9 8.2 160 150 MLPQ 4X4 14L
IRS2005S active and preferred 200 Functional levelshift 0.6 0.29 High-side and low-side 20 8.9 8.2 160 150 SOIC 8N
IRS2011 active and preferred 200 Functional levelshift 1 1 High-side and low-side 20 9 8.2 60 60 PDIP8
IRS2011S active and preferred 200 Functional levelshift 1 1 High-side and low-side 20 9 8.2 60 60 SOIC 8N
Product Product status Voltage Class
[V]
Isolation type Output Current
Sink typ.
[A]
Output Current
Source typ.
[A]
Configuration
Input Vcc
Max
[V]
Input UVLO
On typ.
[V]
Input UVLO
Off typ.
[V]
Propagation Delay
Turn On typ.
[ns]
Propagation Delay
Turn Off typ.
[ns]
Package
78
Gate
Driver ICs
Half Bridge Gate Driver ICs
2ED020I12-FI active and preferred 1200 Galvanic Isolation 2.5 1.5 Half bridge 18 12 11 85 85 PG-DSO-18
IR2214SS active and preferred 1200 Functional levelshift 3 2 Half bridge 20 10.2 9.3 440 440 SSOP24
IR7184S active and preferred 700 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 680 270 SOIC 8N
IR7304S active and preferred 700 Functional levelshift 0.169 0.078 Half bridge 20 8.9 8.2 220 220 SOIC 8N
2ED020I06-FI active and preferred 650 Galvanic Isolation 2.5 1.5 Half bridge 18 12 11 85 85 PG-DSO-18
2EDL05I06PF active and preferred 600 Functional levelshift 0.7 0.36 Half bridge 17.5 12.5 11.6 420 400 PG-DSO-8
2EDL05I06PJ active and preferred 600 Functional levelshift 0.7 0.36 Half bridge 17.5 12.5 11.6 420 400 PG-DSO-14
2EDL05N06PF active and preferred 600 Functional levelshift 0.7 0.36 Half bridge 17.5 9.1 8.3 310 300 PG-DSO-8
2EDL05N06PJ active and preferred 600 Functional levelshift 0.7 0.36 Half bridge 17.5 9.1 8.3 310 300 PG-DSO-14
2EDL23I06PJ active and preferred 600 Functional levelshift 2.8 2.3 Half bridge 17.5 12.5 11.6 420 400 PG-DSO-14
2EDL23N06PJ active and preferred 600 Functional levelshift 2.8 2.3 Half bridge 17.5 9.1 8.3 310 300 PG-DSO-14
IR2103 active 600 Functional levelshift 0.36 0.21 Half bridge 20 8.9 8.2 680 150 PDIP8
IR2103S active 600 Functional levelshift 0.36 0.21 Half bridge 20 8.9 8.2 680 150 SOIC 8N
IR2104 active 600 Functional levelshift 0.36 0.21 Half bridge 20 8.9 8.2 680 150 PDIP8
IR2104S active 600 Functional levelshift 0.36 0.21 Half bridge 20 8.9 8.2 680 150 SOIC 8N
IR2108 active 600 Functional levelshift 0.35 0.2 Half bridge 20 8.9 8.2 220 200 PDIP8
IR21084 active 600 Functional levelshift 0.35 0.2 Half bridge 20 8.9 8.2 220 200 PDIP14
IR21084S active 600 Functional levelshift 0.35 0.2 Half bridge 20 8.9 8.2 220 200 SOIC 14N
IR2108S active 600 Functional levelshift 0.35 0.2 Half bridge 20 8.9 8.2 220 200 SOIC 8N
IR2109 active 600 Functional levelshift 0.35 0.2 Half bridge 20 8.9 8.2 750 200 PDIP8
IR21091 active 600 Functional levelshift 0.35 0.2 Half bridge 20 8.9 8.2 750 200 PDIP8
IR21091S active 600 Functional levelshift 0.35 0.2 Half bridge 20 8.9 8.2 750 200 SOIC 8N
IR21094 active 600 Functional levelshift 0.35 0.2 Half bridge 20 8.9 8.2 750 200 PDIP14
IR21094S active 600 Functional levelshift 0.35 0.2 Half bridge 20 8.9 8.2 750 200 SOIC 14N
IR2109S active 600 Functional levelshift 0.35 0.2 Half bridge 20 8.9 8.2 750 200 SOIC 8N
IR2111 active 600 Functional levelshift 0.5 0.25 Half bridge 20 8.6 8.2 750 150 PDIP8
IR2111S active 600 Functional levelshift 0.5 0.25 Half bridge 20 8.6 8.2 750 150 SOIC 8N
IR2114SS active and preferred 600 Functional levelshift 3 2 Half bridge 20 10.2 9.3 440 440 SSOP24
IR21531 active and preferred 600 Functional levelshift 0.26 0.18 Half bridge 15.6 9 8 - - PDIP8
IR21531D active and preferred 600 Functional levelshift 0.26 0.18 Half bridge 15.6 9 8 - - PDIP8
Product Product status Voltage Class
[V]
Isolation type Output Current
Sink typ.
[A]
Output Current
Source typ.
[A]
Configuration
Input Vcc
Max
[V]
Input UVLO
On typ.
[V]
Input UVLO
Off typ.
[V]
Propagation Delay
Turn On typ.
[ns]
Propagation Delay
Turn Off typ.
[ns]
Package
79
Gate
Driver ICs
Half Bridge Gate Driver ICs
Product Product status Voltage Class
[V]
Isolation type Output Current
Sink typ.
[A]
Output Current
Source typ.
[A]
Configuration
Input Vcc
Max
[V]
Input UVLO
On typ.
[V]
Input UVLO
Off typ.
[V]
Propagation Delay
Turn On typ.
[ns]
Propagation Delay
Turn Off typ.
[ns]
Package
IR21531S Active and preferred 600 Functional levelshift 0.26 0.18 Half bridge 15.6 9 8 - - SOIC 8N
IR2183 active 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 180 220 PDIP8
IR21834 active 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 180 220 PDIP14
IR21834S active 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 180 220 SOIC 14N
IR2183S active 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 180 220 SOIC 8N
IR2184 active 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 680 270 PDIP8
IR21844 active 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 680 270 PDIP14
IR21844S active 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 680 270 SOIC 14N
IR2184S active 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 680 270 SOIC 8N
IR2302 active 600 Functional levelshift 0.35 0.2 Half bridge 20 4.1 3.8 750 200 PDIP8
IR2302S active 600 Functional levelshift 0.35 0.2 Half bridge 20 4.1 3.8 750 200 SOIC 8N
IR2304 active 600 Functional levelshift 0.169 0.078 Half bridge 20 8.9 8.2 220 220 PDIP8
IR2304S active 600 Functional levelshift 0.169 0.078 Half bridge 20 8.9 8.2 220 220 SOIC 8N
IR2308 active 600 Functional levelshift 0.35 0.2 Half bridge 20 8.9 8.2 220 200 PDIP8
IR2308S active 600 Functional levelshift 0.35 0.2 Half bridge 20 8.9 8.2 220 200 SOIC 8N
IR25601S active 600 Functional levelshift 0.169 0.078 Half bridge 20 8.9 8.2 220 220 SOIC 8N
IR25602S active 600 Functional levelshift 0.36 0.21 Half bridge 20 8.9 8.2 680 150 SOIC 8N
IR25603 active 600 Functional levelshift 0.26 0.18 Half bridge 15.6 9 8 - - PDIP8
IR25603S active 600 Functional levelshift 0.26 0.18 Half bridge 15.6 9 8 - - SOIC 8N
IR25606S active 600 Functional levelshift 0.35 0.2 Half bridge 20 8.9 8.2 220 200 SOIC 8N
IRS2103 active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 680 150 PDIP8
IRS2103S active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 680 150 SOIC 8N
IRS2104 active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 680 150 PDIP8
IRS2104S active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 680 150 SOIC 8N
IRS2108 active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 220 200 PDIP8
IRS21084 active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 220 200 PDIP14
IRS21084S active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 220 200 SOIC 14N
IRS2108S active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 220 200 SOIC 8N
IRS2109 active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 750 200 PDIP8
IRS21091 active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 750 200 PDIP8
80
Gate
Driver ICs
IRS21091S active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 750 200 SOIC 8N
IRS21094 active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 750 200 PDIP14
IRS21094S active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 750 200 SOIC 14N
IRS2109S active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 750 200 SOIC 8N
IRS2111 active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.6 8.2 750 150 PDIP8
IRS2111S active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.6 8.2 750 150 SOIC 8N
IRS21531D active and preferred 600 Functional levelshift 0.26 0.18 Half bridge 15.4 11 9 - - PDIP8
IRS21531DS active and preferred 600 Functional levelshift 0.26 0.18 Half bridge 15.4 11 9 - - SOIC 8N
IRS2153D active and preferred 600 Functional levelshift 0.26 0.18 Half bridge 15.4 11 9 - - PDIP8
IRS2153DS active and preferred 600 Functional levelshift 0.26 0.18 Half bridge 15.4 11 9 - - SOIC 8N
IRS2183 active and preferred 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 180 220 PDIP8
IRS21834 active and preferred 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 180 220 PDIP14
IRS21834S active and preferred 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 180 220 SOIC 14N
IRS2183S active and preferred 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 180 220 SOIC 8N
IRS2184 active and preferred 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 680 270 PDIP8
IRS21844 active and preferred 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 680 270 PDIP14
IRS21844M active and preferred 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 680 270 MLPQ 4X4 14L
IRS21844S active and preferred 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 680 270 SOIC 14N
IRS2184S active and preferred 600 Functional levelshift 2.3 1.9 Half bridge 20 8.9 8.2 680 270 SOIC 8N
IRS2302S active 600 Functional levelshift 0.35 0.2 Half bridge 20 4.1 3.8 650 200 SOIC 8N
IRS2304 active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 150 150 PDIP8
IRS2304S active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 150 150 SOIC 8N
IRS2308 active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 220 200 PDIP8
IRS2308S active and preferred 600 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 220 200 SOIC 8N
IRS2890DS active and preferred 600 Functional levelshift 0.48 0.22 Half bridge 20 8.9 7.7 500 500 SOIC 14N
IRS2003 active 200 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 680 150 PDIP8
IRS2003S active 200 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 680 150 SOIC 8N
IRS2004 active 200 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 680 150 PDIP8
IRS2004S active 200 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 680 150 SOIC 8N
IRS2008S active and preferred 200 Functional levelshift 0.6 0.29 Half bridge 20 8.9 8.2 680 150 SOIC 8N
IRS2007S active and preferred 100 Functional levelshift 6 0.29 Half bridge 20 8.9 8.2 160 150 SOIC 8N
Product Product status Voltage Class
[V]
Isolation type Output Current
Sink typ.
[A]
Output Current
Source typ.
[A]
Configuration
Input Vcc
Max
[V]
Input UVLO
On typ.
[V]
Input UVLO
Off typ.
[V]
Propagation Delay
Turn On typ.
[ns]
Propagation Delay
Turn Off typ.
[ns]
Package
81
Gate
Driver ICs
Three Phase Gate Driver ICs
Product Product status Voltage Class
[V]
Isolation type Output Current
Sink typ.
[A]
Output Current
Source typ.
[A]
Configuration
Input Vcc
Max
[V]
Input UVLO
On typ.
[V]
Input UVLO
Off typ.
[V]
Propagation Delay
Turn On typ.
[ns]
Propagation Delay
Turn Off typ.
[ns]
Package
IR2238Q active and preferred 1200 Functional levelshift 0.54 0.35 Three phase and single
low side
20 11.2 10.2 550 550 MQFP-64L
IR2233 active and preferred 1200 Functional levelshift 0.5 0.25 Three Phase 20 8.6 8.2 750 700 PDIP28
IR2233J active and preferred 1200 Functional levelshift 0.5 0.25 Three Phase 20 8.6 8.2 750 700 PLCC44
IR2233S active and preferred 1200 Functional levelshift 0.5 0.25 Three Phase 20 8.6 8.2 750 700 SOIC 28W
IR2235 active and preferred 1200 Functional levelshift 0.5 0.25 Three Phase 20 10.4 9.4 750 700 PDIP28
IR2235J active and preferred 1200 Functional levelshift 0.5 0.25 Three Phase 20 10.4 9.4 750 700 PLCC44
IR2235S active and preferred 1200 Functional levelshift 0.5 0.25 Three Phase 20 10.4 9.4 750 700 SOIC 28W
6ED003L06-C2 active and preferred 600 Functional levelshift 0.38 0.17 Three Phase 17.5 11.7 9.8 530 490 Chip
6ED003L06-F2 active and preferred 600 Functional levelshift 0.375 0.165 Three Phase 17.5 11.7 9.8 530 490 PG-DSO-28
6EDL04I06NC active and preferred 600 Functional levelshift 0.375 0.17 Three Phase 17.5 11.7 9.8 530 490 Chip
6EDL04I06NT active and preferred 600 Functional levelshift 0.375 0.165 Three Phase 17.5 11.7 9.8 530 490 PG-DSO-28
6EDL04I06PT active and preferred 600 Functional levelshift 0.375 0.165 Three Phase 17.5 11.7 9.8 530 490 PG-DSO-28
6EDL04N06PC active and preferred 600 Functional levelshift 0.375 0.17 Three Phase 17.5 9 8.1 530 530 Chip
6EDL04N06PT active and preferred 600 Functional levelshift 0.375 0.165 Three Phase 17.5 9 8.1 530 530 PG-DSO-28
IR2130 active 600 Functional levelshift 0.5 0.25 Three Phase 20 9 8.7 675 425 PDIP28
IR2130J active 600 Functional levelshift 0.5 0.25 Three Phase 20 9 8.7 675 425 PLCC44
IR2130S active 600 Functional levelshift 0.5 0.25 Three Phase 20 9 8.7 675 425 SOIC 28W
IR2131 active 600 Functional levelshift 0.5 0.25 Three Phase 20 8.7 8.3 1300 600 PDIP28
IR2131J active 600 Functional levelshift 0.5 0.25 Three Phase 20 8.7 8.3 1300 600 PLCC44
IR2131S active 600 Functional levelshift 0.5 0.25 Three Phase 20 8.7 8.3 1300 600 SOIC 28W
IR2132 active 600 Functional levelshift 0.5 0.25 Three Phase 20 9 8.7 675 425 PDIP28
IR2132J active 600 Functional levelshift 0.5 0.25 Three Phase 20 9 8.7 675 425 PLCC44
IR2132S active 600 Functional levelshift 0.5 0.25 Three Phase 20 9 8.7 675 425 SOIC 28W
IR2133 active and preferred 600 Functional levelshift 0.5 0.25 Three Phase 20 8.6 8.2 750 700 PDIP28
IR2133J active and preferred 600 Functional levelshift 0.5 0.25 Three Phase 20 8.6 8.2 750 700 PLCC44
IR2133S active and preferred 600 Functional levelshift 0.5 0.25 Three Phase 20 8.6 8.2 750 700 SOIC 28W
IR2135J active and preferred 600 Functional levelshift 0.5 0.25 Three Phase 20 10.4 9.4 750 700 PLCC44
IR2135S active and preferred 600 Functional levelshift 0.5 0.25 Three Phase 20 10.4 9.4 750 700 SOIC 28W
82
Gate
Driver ICs
IR2136 active and preferred 600 Functional levelshift 0.35 0.2 Three Phase 20 8.9 8.2 425 400 PDIP28
IR21363J active 600 Functional levelshift 0.35 0.2 Three Phase 20 11.1 10.9 425 400 PLCC44
IR21363S active 600 Functional levelshift 0.35 0.2 Three Phase 20 11.1 10.9 425 400 SOIC 28W
IR21364S active 600 Functional levelshift 0.35 0.2 Three Phase 20 10.4 9.4 500 530 SOIC 28W
IR21365S active 600 Functional levelshift 0.35 0.2 Three Phase 20 11.1 10.9 425 400 SOIC 28W
IR21366J active and preferred 600 Functional levelshift 0.35 0.2 Three Phase 20 11.1 10.9 425 400 PLCC44
IR21368S active 600 Functional levelshift 0.35 0.2 Three Phase 20 8.9 8.2 425 400 SOIC 28W
IR2136J active and preferred 600 Functional levelshift 0.35 0.2 Three Phase 20 8.9 8.2 425 400 PLCC44
IR2136S active and preferred 600 Functional levelshift 0.35 0.2 Three Phase 20 8.9 8.2 425 400 SOIC 28W
IRS2334M active 600 Functional levelshift 0.35 0.2 Three Phase 20 11.1 10.9 530 530 MLPQ 5X5 28L
IRS2334S active 600 Functional levelshift 0.35 0.2 Three Phase 20 11.1 10.9 530 530 SOIC 20W
IRS23364DJ active 600 Functional levelshift 0.35 0.2 Three Phase 20 11.1 10.9 530 530 PLCC44
IRS23364DS active 600 Functional levelshift 0.35 0.2 Three Phase 20 11.1 10.9 530 530 SOIC 28W
IRS23365DM active 600 Functional levelshift 0.35 0.2 Three Phase 20 8.9 8.2 530 530 MLPQ 7X7 34L
IRS2336DJ active 600 Functional levelshift 0.35 0.2 Three Phase 20 8.9 8.2 530 530 PLCC44
IRS2336DM active 600 Functional levelshift 0.35 0.2 Three Phase 20 8.9 8.2 530 530 MLPQ 7X7 34L
IRS2336DS active 600 Functional levelshift 0.35 0.2 Three Phase 20 8.9 8.2 530 530 SOIC 28W
IRS2336S active 600 Functional levelshift 0.35 0.2 Three Phase 20 8.9 8.2 530 530 SOIC 28W
6ED003L02-F2 active and preferred 200 Functional levelshift 0.375 0.165 Three Phase 17.5 11.7 9.8 530 490 PG-TSSOP-28
6EDL04N02PR active and preferred 200 Functional levelshift 0.375 0.165 Three Phase 17.5 9 8.1 530 530 PG-TSSOP-28
Product Product status Voltage Class
[V]
Isolation type Output Current
Sink typ.
[A]
Output Current
Source typ.
[A]
Configuration
Input Vcc
Max
[V]
Input UVLO
On typ.
[V]
Input UVLO
Off typ.
[V]
Propagation Delay
Turn On typ.
[ns]
Propagation Delay
Turn Off typ.
[ns]
Package
83
Gate
Driver ICs
Gate Driver Support ICs
Product Product status Voltage Class
[V]
Isolation type
Configuration
Input Vcc Max
[V]
Channels Package
IR22771S active 1200 Functional levelshift Current sense 20 1 16 Lead SOICWB
IR2277S active 1200 Functional levelshift Current sense 20 1 16 Lead SOICWB
IR2175 active 600 Functional levelshift Current sense 20 1 8 Lead PDIP
IR2175S active 600 Functional levelshift Current sense 20 1 8 Lead SOIC
IR21771S active 600 Functional levelshift Current sense 20 1 16 Lead SOICWB
IR2177S active 600 Functional levelshift Current sense 20 1 16 Lead SOICWB
IR25750L active and preferred 600 Functional levelshift Current sense - 1 5 Lead SOT23
IRS25751L active and preferred 480 Functional levelshift Start up - 1 5 Lead SOT23
84
Gate
Driver ICs
Driver Boards
2ED300C17-S active and preferred 1700 Reinforced Isolation - - Half Bridge Driver
Boards
16.5 10.9 -9.3 670 580 AG-EICE-45
2ED300C17-ST active and preferred 1700 Reinforced Isolation - - Half Bridge Driver
Boards
16.5 10.9 -9.3 670 580 AG-EICE-45
Product Product status Voltage Class
[V]
Isolation type Output Current
Sink typ.
[A]
Output Current
Source typ.
[A]
Configuration
Input Vcc
Max
[V]
Input UVLO
On typ.
[V]
Input UVLO
Off typ.
[V]
Propagation Delay
Turn On typ.
[ns]
Propagation Delay
Turn Off typ.
[ns]
Package
85
Gate
Driver ICs
8686
Our reliable and highest quality stacks and assemblies offer optimized thermal management. These advanced
systems provide design support and help to optimize system costs.
Set up laboratory experiments or a first prototype with Evaluation boards and Kits designed in several configurations
to drive IGBT modules, discrete IGBTs and MOSFETs. Please find optimized solutions with tailormade transformers
or high voltage gate driver ICs with either integrated coreless transformer or even SOI level shift technology.
Stacks & Boards
IGBT stacks and evaluation boards
87
Stacks &
Boards
IGBT Stacks & IGBT Assemblies
Product Product Status Rated AC Current
(ARMS)
Rated AC Voltage
(VRMS)
Configuration
Cooling
Housing Features
Implemented IGBT
Modules
Rated fSW
[kHz]
IFF2400P17LE4 active and preferred 1550.0 690.0 2-pack Liquid cooled MIPAQ™ Pro Smart Protection - 3.0
IFF2400P17AE4 active and preferred 650.0 690.0 2-pack Air cooled MIPAQ™ Pro Smart Protection - 3.0
6MS30017E43W34404 active 2050.0 690.0 6-pack Liquid cooled ModSTACK™ HD 3 incl. Capacitors FF1000R17IE4 3.0
6MS30017E43W40372 active 1800.0 690.0 6-pack Liquid cooled ModSTACK™ HD 3 incl. Capacitors FF1000R17IE4 3.0
6MS30017E43W38169 active 1800.0 690.0 6-pack Liquid cooled ModSTACK™ HD 3 incl. Capacitors FF1000R17IE4 3.0
6MS20017E43W38170 active 1200.0 690.0 6-pack Liquid cooled ModSTACK™ HD 3 incl. Capacitors FF1000R17IE4 3.0
6MS20017E43W37032 active 1200.0 690.0 6-pack Liquid cooled ModSTACK™ HD 3 incl. Capacitors FF1000R17IE4 3.0
6MS24017P43W41646 active and preferred 1175.0 690.0 6-pack Liquid cooled ModSTACK™ 3 incl. Capacitors FF1200R17KP4_B2 2.6
6MS24017P43W39872 active 1050.0 690.0 6-pack Liquid cooled ModSTACK™ 3 incl. Capacitors FF1200R17KP4_B2 3.0
6MS24017P43W39873 active 1050.0 690.0 6-pack Liquid cooled ModSTACK™ 3 incl. Capacitors FF1200R17KP4_B2 3.0
2PS13512E43W35222 active 900.0 400.0 2-pack Liquid cooled PrimeSTACK™ C3 - FF450R12KE4 5.0
6MS16017P43W40382 active 880.0 690.0 6-pack Liquid cooled ModSTACK™ 3 incl. Capacitors FF800R17KP4_B2 3.0
6MS16017P43W40383 active 880.0 690.0 6-pack Liquid cooled ModSTACK™ 3 incl. Capacitors FF800R17KP4_B2 3.0
6MS24017E33W32860 active 800.0 690.0 6-pack Air cooled ModSTACK™ 3 incl. Capacitors FF1200R17KE3_B2 2.5
6MS24017E33W32859 active 800.0 690.0 6-pack Air cooled ModSTACK™ 3 incl. Capacitors FF1200R17KE3_B2 2.5
6PS18012E4FG38393 active 800.0 400.0 6-pack Air cooled PrimeSTACK™ CF / 3 x C4 incl. Capacitors FF450R12KE4 3.0
2PS18012E44G40113 active and preferred 770.0 400.0 2-pack Air cooled PrimeSTACK™ C4 - FF450R12KE4 3.0
2PS18012E44G38553 active and preferred 770.0 400.0 2-pack Air cooled PrimeSTACK™ C4 incl. Capacitors FF450R12KE4 3.0
6MS10017E41W36460 active 600.0 690.0 6-pack Liquid cooled ModSTACK™ HD 1 incl. Capacitors FF1000R17IE4 3.0
2PS12017E44G35911 active 460.0 690.0 2-pack Air cooled PrimeSTACK™ C4 incl. Capacitors FF300R17KE4 3.0
6PS04512E43G37986 active 265.0 400.0 6-pack Air cooled PrimeSTACK™ C3 incl. Capacitors FF450R12KE4 5.0
4PS03012S43G30699 active 183.0 400.0 4-pack Air cooled PrimeSTACK™ C3 - FF300R12KS4 5.0
88
Stacks &
Boards
Boards
Product Product Status Promotion of Description
Evalboards for CoolSiC™ devices
EVAL-PS-E1BF12-SIC on request CoolSiC™ MOSFET Easy 1B halfbridge modules Evaluation Board for the FF11MR12W1M1_B11 and FF23MR12W1M1_B11 CoolSiC™ MOSFET modules.
EVAL-1EDC20H12AH-SIC active EiceDRIVER™ 1EDC20H12AH and CoolSiC™ MOSFET IZM120R045M1 Evaluation board developed to demonstrate the functionality and key features of the EiceDRIVER™ 1EDC20H12AH and
CoolSiC™ MOSFET IZM120R045M1.
EVAL-1EDI20H12AH-SIC active EiceDRIVER™ 1EDI20H12AH and CoolSiC™ MOSFET IZM120R045M1 Evaluation board developed to demonstrate the functionality and key features of the EiceDRIVER™ 1EDI20H12AH and
CoolSiC™ MOSFET IZM120R045M1.
EVAL-COOLSIC-MOSFET active CoolSiC™ MOSFET Evaluation Board CoolSiC™ MOSFETs
iMOTION™ Modular Application Design Kit
EVAL-M1-05-65D active and preferred CIPOS™ Micro This evaluation board is a complete power stage to drive 3-phase motor, powered by IRSM505-065DA2 CIPOS™ Micro
EVAL-M1-05-84D active and preferred CIPOS™ Micro This evaluation board is a complete power stage to drive 3-phase motor, powered by IRSM505-084DA2 CIPOS™ Micro
EVAL-M1-05F310 active and preferred IRSM005-310MH This evaluation board is a complete power stage, powerd by IRSM005-310MH. The board is purposed to drive 3-phase
motors in low voltage domain. It is equipped with MADK™ M1 20 pin interface connector.
EVAL-M1-05F804 active and preferred IRSM005-800MH This evaluation board is a complete power stage, powerd by IRSM005-800MH. The board is purposed to drive 3-phase
motors in low voltage domain. It is equipped with MADK™ M1 20 pin interface connector.
EVAL-M1-36-45A active and preferred IRSM836-045MA CIPOS™ Nano This evaluation board is a complete power stage to drive 3-phase motor, powered by IRSM836-045MA CIPOS™ Nano
EVAL-M1-36-84A active and preferred IRSM836-045MA CIPOS™ Nano This evaluation board is a complete power stage to drive 3-phase motor, powered by IRSM836-084MA CIPOS™ Nano
EVAL-M1-CM610N3 active and preferred IKCM10H60GA CIPOS™ Mini The evaluation board is based on the IKCM10H60GA from Infineon with power ratings of 600V/10A. In combination with
control-boards equipped with the M1 20pin interface connector, like EVAL-M1-1302 or EVAL-M1-099M
EVAL-M1-183M active and preferred IRMCF183M iMOTION™ Motor Control IC and 8-bit 8051 MCU Control Board for iMOTION™ Modular Application Design Kit (MADK) platform powered by IRMCF183M iMOTION™ Motor
Control IC featuring advanced Motor Control Engine (MCE)
EVAL-M1-099M-C active and preferred IRMCK099M iMOTION™ Motor Control IC "iMOTION™ MADK control card
EVAL-M1-1302 active and preferred C XMC 1302 ARM® Cortex® M0 High Performance Sensorless Motor Control Card
EVAL-M1-1302_05-65D active and preferred IRSM505-065DA2 CIPOS™ Micro and XMC 1302 This Kit is a compact and flexible 3-phase motor drive system solution platform with control card and power stage, powered
by IRSM505-065DA2 CIPOS™ Micro and XMC 1302
EVAL-M1-1302_05-84D active and preferred IRSM505-084DA2 CIPOS™ Micro and XMC 1302 This Kits is a compact and flexible 3-phase motor drive system solution platform with control card and power stage,
powered by IRSM505-084DA2 CIPOS™ Micro and XMC 1302
EVAL-M1-1302_36-45A active and preferred IRSM836-045MA CIPOS™ Nano and XMC 1302 This Kits is a compact and flexible 3-phase motor drive system solution platform with control card and power stage,
powered by IRSM836-045MA CIPOS™ Nano and XMC 1302.
EVAL-M1-1302_36-84A active and preferred IRSM836-084MA CIPOS™ Nano and XMC 1302 This Kits is a compact and flexible 3-phase motor drive system solution platform with control card and power stage,
powered by IRSM836-084MA CIPOS™ Nano and XMC 1302.
MCETOOLV2 active and preferred IRMCK099, IRMCx100, IRMCx300 Isolated Debugger Tool for configuring, programming and debugging of all IRMCK099, IRMCx100 and IRMCx300 series
iMOTION™ motor control Ics
89
Stacks &
Boards
Boards
Product Product Status Promotion of Description
Evalboards for IGBT Devices
EVAL-IGBT-650V-TO247-4 active and preferred 650 V IGBTs in TO-247 4pin package Adaptable double pulse tester for IGBTs in TO-247 4pin package
EVAL-IGBT-1200V-247 active 1200 V IGBTs in TO-247 4pin package Evaluation Board for 1200 V IGBTs in TO-247 4pin package
IRMDG62-1-D2 active IRGS4610DPBF Reference design power board designed to showcase our D2PAK IRGS4610DPBF IGBT in a motor drive application.
6ED100E12-F2 on request EconoPACK™+ Evaluation Board for EconoPACK™+ Modules (1200V)
F3L030E07-F-W2 on request EasyPACK 2B 3-level Evaluation Board for EasyPACK 2B 3-level in NPC-Topology (650V)
7ED020E12-FI-W2 on request EasyPIM™ 2B Evaluation Board for EasyPIM™ 2B PressFIT Modules (1200V)
7ED020E12-FI-U1 on request SmartPIM 1 Evaluation Board for SmartPIM 1 Modules (1200V)
2ED250E12-F on request PrimePACK™ Evaluation Driver Board for PrimePACK™ Modules (1200V)
F3L020E07-F-P on request EconoPACK™ 4 3-level Evaluation Driver Board for EconoPACK™ 4 3-Level Modules in NPC1-Topology (650V)
F3L2020E07-F-P on request EconoPACK™ 4 3-level Evaluation Driver Board for EconoPACK™ 4 3-Level Modules in NPC2-Topology (650V)
F3L2020E12-F-P_EVAL on request EconoPACK™ 4 3-level Evaluation Driver Board for EconoPACK™ 4 3-Level Modules in NPC2-Topology (1200V)
2ED300E17-SFO on request EiceDRIVER™ Safe Evaluation Board for 2ED300C17-S EiceDRIVER™ Safe Driver Boards (1700V)
2ED100E12-F2 on request EconoDUAL™ 3 Evaluation Board for EconoDUAL™3 Modules (1200V)
MA070E12 on request 62mm Modules Evaluation Adapter Board for 62mm Modules (1200V)
MA200E12 on request EconoDUAL™ 3 Evaluation Adapter Board for EconoDUAL™3 Modules (1200V)
MA300E12 on request PrimePACK™ Evaluation Adapter Board for PrimePACK™ Modules (1200V)
Evalboards for EiceDRIVER™ Driver Ics
EVAL-2ED020I12-F2 active and preferred EiceDRIVER™ Enhanced Evaluation Board for 2ED020I12-F2 EiceDRIVER™ Enhanced Driver ICs (600V/1200V)
EVAL-2EDL05I06PF active and preferred EiceDRIVER™ Compact -
EVAL-1ED020I12-BT active and preferred EiceDRIVER™ Enhanced Evaluation Board for 1ED020I12-BT EiceDRIVER™ Enhanced Driver ICs (1200V)
EVAL-6EDL04I06PT active and preferred EiceDRIVER™ Compact Evaluation Board for 6EDL04I06PT EiceDRIVER™ Compact Driver ICs (600V)
EVAL-6EDL04N02PR active and preferred EiceDRIVER™ Compact Evaluation Board for 6EDL04N02PR EiceDRIVER™ Compact Driver ICs (200V)
EVAL-1ED020I12-B2 active and preferred EiceDRIVER™ Enhanced Evaluation Board for 1ED020I12-B2 EiceDRIVER™ Enhanced Driver ICs (1200V)
EVAL-2EDL23I06PJ active and preferred EiceDRIVER™ Compact Evaluation Board for 2EDL23I06PJ EiceDRIVER™ Compact Driver ICs (600V)
EVAL-2EDL23N06PJ active and preferred EiceDRIVER™ Compact Evaluation Board for 2EDL23N06PJ EiceDRIVER™ Compact Driver ICs (600V)
EVAL-1EDS20I12SV active and preferred EiceDRIVER™ 1EDS20I12SV Evaluation board offering a reliable platform for evaluation of the product features provided by the EiceDRIVER™
1EDS20I12SV (“1EDS-SRC”) in combination with EconoDUAL™3 modules.
EVAL-1EDI60I12AF active and preferred EiceDRIVER™ 1EDI60I12AF Evaluation Board for 1EDI60I12AF 1200V single channel coreless transformer isolated gate driver ICs in half bridge
configuration for MOS-transistors or IGBTs
IRUCS1 active IR25750L Adapter board designed for easy and fast in-circuit evaluation of our RDS(on) or VCE(on) current sensing IC, the IR25750L.
90
Stacks &
Boards
Product Product Status Promotion of Description
Evaluation Boards for Intelligent power modules
IRMD836 active IRSM836-024MA, IRSM836-044MA, IRSM836-025MA, IRSM836-035MA Reference board including a three-phase module for motor drive application.
IRMD808 active IRSM808-105MH, IRSM807-105MH Reference board including three half-bridge modules for motor drive application.
Evalboards for IGBT Devices
MA300E17 on request PrimePACK™ Evaluation Adapter Board for PrimePACK™ Modules (1700V)
MA200E17 on request EconoDUAL™ 3 Evaluation Adapter Board for EconoDUAL™3 Modules (1700V)
MA070E17 on request 62mm Modules Evaluation Adapter Board for 62mm Modules (1700V)
MA3AE12 on request MIPAQ™ base Isolating amplifier for current measurement with MIPAQ™ base (1200V)
MA040E12 on request MIPAQ™ serve Isolated gate driver power supply and logic interface for MIPAQ™ serve (1200V)
MA400E17 on request IHM (130mm x 140mm) Evaluation Adapter Board for IHM IGBT Modules (1700V)
MA400E12 on request IHM (130mm x 140mm) Evaluation Adapter Board for IHM IGBT Modules (1200V)
MA401E17 on request IHM (140mm x 190mm) Evaluation Adapter Board for IHM IGBT Modules (1700V)
MA3L120E12_EVAL on request EconoPACK™ 4 3-level Evaluation Board for EconoPACK™ 4 3-Level Modules in NPC2-Topology (1200V)
MA401E12 on request IHM (140mm x 190mm) Evaluation Adapter Board for IHM IGBT Modules (1200V)
MA3L080E07 on request EconoPACK™ 4 3-level Evaluation Adapter Board for EconoPACK™ 4 3-Level Modules in NPC1-Topology (650V)
MA3L120E07 on request EconoPACK™ 4 3-level Evaluation Adapter Board for EconoPACK™ 4 3-Level Modules in NPC2-Topology (650V)
91
Stacks &
Boards
9292
Innovative technology with lower losses leading to higher efficiency
Our high-performance thyristors and diodes are used to boost efficiency significantly in many applications. They
have set standards in a power range from 10 kW to more than 10 GW and allow various design options using different
technologies. Infineon Technologies Bipolar is the only manufacturer providing high blocking voltage capability
up to 9,5 kV for thyristor discs.
New ultra-soft IGBT freewheeling diodes offer industry leading low losses
Infineon Technologies Bipolar launches a new diode family especially designed for modern IGBT applications:
Infineon® Prime Soft. This diode features an improved turn-off capability which now rates at 5 kA/s.
The new diodes in press-pack housings are available with 4.5 kV blocking voltage. The diodes come in three different
silicon diameters: D1600U45X122, D2700U45X122, and D4600U45X172. More information about Prime Soft is available
at www.infineon.com/primesoft.
Thyristor / diode discs
High Power Thyristor / Diode discs
93
Thyristor /
diode discs
Solution tree
Thyristors
8.5 kV ETTs (Electrically Triggered Thyristors)
› T1901N80TOH
› T2871N80TOH
› T7300N85X203
9.2 kV LTTs (LightTriggered Thyristors)
› T1503N80TOH
› T2563N80TOH
› T6900N92L204
Transmission & Distribution (T&D)
HVDC
LCC
(Line Commutated
Converters)
VSC
(Voltage Sourced
Converters)
SVC
(Static Var
Compensators)
STATCOM
(Static Synchronous
Compensators)
FACTS
Freewheeling Diodes (FWD)
› D1600U45X122
› D2700U45X122
› D4600U45X172
Protection Thyristors
› T1930N33T
› T1800N45T
› C3100N65X122
Rectifier diodes
› D3300H90X152
8 kV ETTs (Electrically Triggered Thyristors)
› T1901N80TOH
› T2871N80TOH
8 kV LTTs (LightTriggered Thyristors)
› T533N80TOH
› T1503N80TOH
› T2563N80TOH
Freewheeling Diodes (FWD)
› D1600U45X122
› D2700U45X122
› D4600U45X172
94
Thyristor /
diode discs
Thyristor discs
Product VDRM /
VRRM
[V]
tq
[s]
Tvj
[°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Housing Configuration ITAVM/TC
[A/°C]
@180° el sin
ITSM [A]
@10ms,
Tvj max
∫I2dt [A2s ·
103] @10ms,
Tvj max
VT/IT
[V/kA]
@Tvj max
VT0
[V] @Tvj
max max
rT [m]
@Tvj
max max
RthJC
[K/kW] @180°
el sin max
Ceramic discs up to 800V
T3710N06TOF VT 600 200 140 30 65 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 3710/85 60000 18000 1.50/15.0 0.75 0.048 12.5
T3710N04TOF VT 400 200 140 30 65 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 3710/85 60000 18000 1.50/15.0 0.75 0.048 12.5
T3710N02TOF VT 200 200 140 30 65 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 3710/85 60000 18000 1.50/15.0 0.75 0.048 12.5
T2510N06TOF VT 600 200 140 24 56 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2509/85 42000 8820 1.22/6.0 0.75 0.072 18.4
T2510N04TOF VT 400 200 140 24 56 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2509/85 42000 8820 1.22/6.0 0.75 0.072 18.4
T2510N02TOF VT 200 200 140 24 56 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2509/85 42000 8820 1.22/6.0 0.75 0.072 18.4
T1410N06TOF 600 200 140 12 24 Disc dia 58mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 1490/85 20000 2000 1.50/4.5 1 0.1 27
T1410N04TOF 400 200 140 12 24 Disc dia 58mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 1490/85 20000 2000 1.50/4.5 1 0.1 27
T1410N02TOF 200 200 140 12 24 Disc dia 58mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 1490/85 20000 2000 1.50/4.5 1 0.1 27
T1080N06TOF 600 150 140 8 16 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 1075/85 14500 1050 1.81/3.5 1.02 0.2 33
T1080N04TOF 400 150 140 8 16 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 1075/85 14500 1050 1.81/3.5 1.02 0.2 33
T1080N02TOF 200 150 140 8 16 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 1075/85 14500 1050 1.81/3.5 1.02 0.2 33
T920N06TOF 600 150 140 5.5 8 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 925/85 12000 720 1.65/2.5 1 0.23 39
T920N04TOF 400 150 140 5.5 8 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 925/85 12000 720 1.65/2.5 1 0.23 39
T920N02TOF 200 150 140 5.5 8 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 925/85 12000 720 1.65/2.5 1 0.23 39
T690N06TOF 600 200 140 4 8 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 694/85 6700 225 1.76/2.0 0.8 0.44 51
T690N04TOF 400 200 140 4 8 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 694/85 6700 225 1.76/2.0 0.8 0.44 51
T690N02TOF 200 200 140 4 8 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 694/85 6700 225 1.76/2.0 0.8 0.44 51
T580N06TOF 600 200 140 3 6 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 568/85 5500 151 1.63/1.5 1 0.4 62
T580N04TOF 400 200 140 3 6 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 568/85 5500 151 1.63/1.5 1 0.4 62
T580N02TOF 200 200 140 3 6 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 568/85 5500 151 1.63/1.5 1 0.4 62
Ceramic discs up to 1800V
T3160N18TOF VT 1800 250 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 3160/85 57000 16245 1.37/6.0 0.85 0.082 8.5
T3160N16TOF VT 1600 250 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 3160/85 57000 16245 1.37/6.0 0.85 0.082 8.5
T3160N14TOF VT 1400 250 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 3160/85 57000 16245 1.37/6.0 0.85 0.082 8.5
T3160N12TOF VT 1200 250 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 3160/85 57000 16245 1.37/6.0 0.85 0.082 8.5
T2180N18TOF VT 1800 250 125 30 65 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2180/85 36000 6480 2.05/8.0 0.9 0.106 12.5
T2180N16TOF VT 1600 250 125 30 65 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2180/85 36000 6480 2.05/8.0 0.9 0.106 12.5
95
Thyristor /
diode discs
Thyristor discs
Product VDRM /
VRRM
[V]
tq
[s]
Tvj
[°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Housing Configuration ITAVM/TC
[A/°C]
@180° el sin
ITSM [A]
@10ms,
Tvj max
∫I2dt [A2s ·
103] @10ms,
Tvj max
VT/IT
[V/kA]
@Tvj max
VT0
[V] @Tvj
max max
rT [m]
@Tvj
max max
RthJC
[K/kW] @180°
el sin max
Ceramic discs up to 1800V
T2180N14TOF VT 1400 250 125 30 65 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2180/85 36000 6480 2.05/8.0 0.9 0.106 12.5
T2180N12TOF VT 1200 250 125 30 65 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2180/85 36000 6480 2.05/8.0 0.9 0.106 12.5
T1500N18TOF VT 1800 240 125 24 56 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1500/85 33500 5611 2.10/7.0 0.9 0.15 18.4
T1500N16TOF VT 1600 240 125 24 56 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1500/85 33500 5611 2.10/7.0 0.9 0.15 18.4
T1500N14TOF VT 1400 240 125 24 56 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1500/85 33500 5611 2.10/7.0 0.9 0.15 18.4
T1500N12TOF VT 1200 240 125 24 56 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1500/85 33500 5611 2.10/7.0 0.9 0.15 18.4
T1190N18TOF VT 1800 240 125 16 32 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1190/85 22500 2530 2.05/5.4 0.9 0.19 23
T1190N16TOF VT 1600 240 125 16 32 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1190/85 22500 2530 2.05/5.4 0.9 0.19 23
T1190N14TOF VT 1400 240 125 16 32 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1190/85 22500 2530 2.05/5.4 0.9 0.19 23
T1190N12TOF VT 1200 240 125 16 32 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1190/85 22500 2530 2.05/5.4 0.9 0.19 23
T940N18TOF 1800 250 125 10.5 21 Disc dia 58mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 959/85 15500 1200 1.95/3.6 0.85 0.27 28
T880N18TOF 1800 250 125 10.5 21 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 879/85 15500 1200 1.95/3.6 0.85 0.27 32
T940N16TOF 1600 250 125 10.5 21 Disc dia 58mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 959/85 15500 1200 1.95/3.6 0.85 0.27 28
T880N16TOF 1600 250 125 10.5 21 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 879/85 15500 1200 1.95/3.6 0.85 0.27 32
T940N14TOF 1400 250 125 10.5 21 Disc dia 58mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 959/85 15500 1200 1.95/3.6 0.85 0.27 28
T880N14TOF 1400 250 125 10.5 21 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 879/85 15500 1200 1.95/3.6 0.85 0.27 32
T940N12TOF 1200 250 125 10.5 21 Disc dia 58mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 959/85 15500 1200 1.95/3.6 0.85 0.27 28
T880N12TOF 1200 250 125 10.5 21 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 879/85 15500 1200 1.95/3.6 0.85 0.27 32
T830N18TOF 1800 250 125 9 18 Disc dia 58mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 844/85 12500 781 1.94/3.0 0.85 0.3 30
T720N18TOF 1800 250 125 9 18 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 718/85 12500 781 1.94/3.0 0.85 0.35 38
T830N16TOF 1600 250 125 9 18 Disc dia 58mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 844/85 12500 781 1.94/3.0 0.85 0.3 30
T720N16TOF 1600 250 125 9 18 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 718/85 12500 781 1.94/3.0 0.85 0.35 38
T830N14TOF 1400 250 125 9 18 Disc dia 58mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 844/85 12500 781 1.94/3.0 0.85 0.3 30
T720N14TOF 1400 250 125 9 18 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 718/85 12500 781 1.94/3.0 0.85 0.35 38
T830N12TOF 1200 250 125 9 18 Disc dia 58mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 844/85 12500 781 1.94/3.0 0.85 0.3 30
T720N12TOF 1200 250 125 9 18 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 718/85 12500 781 1.94/3.0 0.85 0.35 38
T680N14TOF 1400 250 125 6 12 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 681/85 9500 451 1.75/2.0 0.8 0.42 39
T680N12TOF 1200 250 125 6 12 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 681/85 9500 451 1.75/2.0 0.8 0.42 39
T640N18TOF 1800 250 125 6 12 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 644/85 8000 320 2.15/2.4 0.8 0.5 39
T590N18TOF 1800 250 125 6 12 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 588/85 8000 320 2.15/2.4 0.8 0.5 45
96
Thyristor /
diode discs
Product VDRM /
VRRM
[V]
tq
[s]
Tvj
[°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Housing Configuration ITAVM/TC
[A/°C]
@180° el sin
ITSM [A]
@10ms,
Tvj max
∫I2dt [A2s ·
103] @10ms,
Tvj max
VT/IT
[V/kA]
@Tvj max
VT0
[V] @Tvj
max max
rT [m]
@Tvj
max max
RthJC
[K/kW] @180°
el sin max
Ceramic discs up to 1800V
T640N16TOF 1600 250 125 6 12 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 644/85 8000 320 2.15/2.4 0.8 0.5 39
T590N16TOF 1600 250 125 6 12 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 588/85 8000 320 2.15/2.4 0.8 0.5 45
T640N14TOF 1400 250 125 6 12 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 644/85 8000 320 2.15/2.4 0.8 0.5 39
T590N14TOF 1400 250 125 6 12 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 588/85 8000 320 2.15/2.4 0.8 0.5 45
T640N12TOF 1200 250 125 6 12 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 644/85 8000 320 2.15/2.4 0.8 0.5 39
T590N12TOF 1200 250 125 6 12 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 588/85 8000 320 2.15/2.4 0.8 0.5 45
T560N18TOF 1800 250 125 5 10 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 559/85 6900 238 1.92/1.6 0.8 0.6 44
T560N16TOF 1600 250 125 5 10 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 559/85 6900 238 1.92/1.6 0.8 0.6 44
T560N14TOF 1400 250 125 5 10 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 559/85 6900 238 1.92/1.6 0.8 0.6 44
T560N12TOF 1200 250 125 5 10 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 559/85 6900 238 1.92/1.6 0.8 0.6 44
T420N18TOF 1800 220 125 5 10 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 424/85 6400 205 2.10/1.5 0.9 0.75 56
T420N16TOF 1600 220 125 5 10 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 424/85 6400 205 2.10/1.5 0.9 0.75 56
T420N14TOF 1400 220 125 5 10 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 424/85 6400 205 2.10/1.5 0.9 0.75 56
T420N12TOF 1200 220 125 5 10 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 424/85 6400 205 2.10/1.5 0.9 0.75 56
T470N16TOF 1600 250 125 4 8 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 470/85 6350 202 1.85/1.2 0.8 0.75 51
T470N14TOF 1400 250 125 4 8 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 470/85 6350 202 1.85/1.2 0.8 0.75 51
T470N12TOF 1200 250 125 4 8 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 470/85 6350 202 1.85/1.2 0.8 0.75 51
T430N18TOF 1800 250 125 4 8 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 433/85 4600 106 2.07/1.2 0.85 0.9 51
T430N16TOF 1600 250 125 4 8 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 433/85 4600 106 2.07/1.2 0.85 0.9 51
T430N14TOF 1400 250 125 4 8 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 433/85 4600 106 2.07/1.2 0.85 0.9 51
T430N12TOF 1200 250 125 4 8 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 433/85 4600 106 2.07/1.2 0.85 0.9 51
T390N16TOF 1600 200 125 3 6 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 381/85 4250 91 2.00/1.1 0.85 0.9 62
T390N14TOF 1400 200 125 3 6 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 381/85 4250 91 2.00/1.1 0.85 0.9 62
T390N12TOF 1200 200 125 3 6 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 381/85 4250 91 2.00/1.1 0.85 0.9 62
T300N18TOF 1800 200 125 2.5 5 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 303/85 3400 58 2.20/0.8 0.9 1.35 69
T300N16TOF 1600 200 125 2.5 5 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 303/85 3400 58 2.20/0.8 0.9 1.35 69
T300N14TOF 1400 200 125 2.5 5 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 303/85 3400 58 2.20/0.8 0.9 1.35 69
T300N12TOF 1200 200 125 2.5 5 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 303/85 3400 58 2.20/0.8 0.9 1.35 69
T300N10TOF 1000 200 125 2.5 5 Disc dia 42mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 303/85 3400 58 2.20/0.8 0.9 1.35 69
97
Thyristor /
diode discs
Thyristor discs
Product VDRM /
VRRM
[V]
tq
[s]
Tvj
[°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Housing Configuration ITAVM/TC
[A/°C]
@180° el sin
ITSM [A]
@10ms,
Tvj max
∫I2dt [A2s ·
103] @10ms,
Tvj max
VT/IT
[V/kA]
@Tvj max
VT0
[V] @Tvj
max max
rT [m]
@Tvj
max max
RthJC
[K/kW] @180°
el sin max
Ceramic discs up to 3000V
T4771N28TOF PR 2800 250 125 63 91 Disc dia 150mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 4340/85 91000 41400 1.20/4.0 0.77 0.107 4.8
T4771N22TOF PR 2200 250 125 63 91 Disc dia 150mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 4340/85 91000 41400 1.20/4.0 0.77 0.107 4.8
T2810N22TOF VT 2200 300 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2810/85 50000 12500 2.35/11.0 0.9 0.112 8.5
T2810N20TOF VT 2000 300 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2810/85 50000 12500 2.35/11.0 0.9 0.112 8.5
T2810N18TOF VT 1800 300 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2810/85 50000 12500 2.35/11.0 0.9 0.112 8.5
T2810N16TOF VT 1600 300 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2810/85 50000 12500 2.35/11.0 0.9 0.112 8.5
T2480N28TOF VT 2800 400 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2480/85 43500 9460 1.43/3.0 0.95 0.154 8.5
T2480N26TOF VT 2600 400 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2480/85 43500 9460 1.43/3.0 0.95 0.154 8.5
T2480N24TOF VT 2400 400 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2480/85 43500 9460 1.43/3.0 0.95 0.154 8.5
T2480N22TOF VT 2200 400 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2480/85 43500 9460 1.43/3.0 0.95 0.154 8.5
T2160N28TOF VT 2800 400 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2400/85 40000 8000 2.65/8.8 1.05 0.154 8.5
T2160N26TOF VT 2600 400 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2400/85 40000 8000 2.65/8.8 1.05 0.154 8.5
T2160N24TOF VT 2400 400 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2400/85 40000 8000 2.65/8.8 1.05 0.154 8.5
T2160N22TOF VT 2200 400 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2400/85 40000 8000 2.65/8.8 1.05 0.154 8.5
T2160N20TOF VT 2000 400 125 42 95 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2400/85 40000 8000 2.65/8.8 1.05 0.154 8.5
T1960N22TOF VT 2200 300 125 30 65 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1960/85 35000 6125 2.20/8.0 0.9 0.15 12.5
T1960N20TOF VT 2000 300 125 30 65 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1960/85 35000 6125 2.20/8.0 0.9 0.15 12.5
T1960N18TOF VT 1800 300 125 30 65 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1960/85 35000 6125 2.20/8.0 0.9 0.15 12.5
T1590N28TOF VT 2800 400 125 30 65 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1590/85 28000 3920 2.45/5.0 1.1 0.237 12.5
T1590N26TOF VT 2600 400 125 30 65 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1590/85 28000 3920 2.45/5.0 1.1 0.237 12.5
T1590N24TOF VT 2400 400 125 30 65 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1590/85 28000 3920 2.45/5.0 1.1 0.237 12.5
T1590N22TOF VT 2200 400 125 30 65 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1590/85 28000 3920 2.45/5.0 1.1 0.237 12.5
T1330N22TOF VT 2200 300 125 20 45 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1329/85 23000 2645 1.13/1.0 0.9 0.234 18.4
T1330N20TOF VT 2000 300 125 20 45 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1329/85 23000 2645 1.13/1.0 0.9 0.234 18.4
T1330N18TOF VT 1800 300 125 20 45 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1329/85 23000 2645 1.13/1.0 0.9 0.234 18.4
T1220N28TOF VT 2800 350 125 20 45 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1220/85 22500 2531 1.38/1.0 1 0.275 18.4
T1220N26TOF VT 2600 350 125 20 45 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1220/85 22500 2531 1.38/1.0 1 0.275 18.4
T1220N24TOF VT 2400 350 125 20 45 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1220/85 22500 2531 1.38/1.0 1 0.275 18.4
98
Thyristor /
diode discs
Product VDRM /
VRRM
[V]
tq
[s]
Tvj
[°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Housing Configuration ITAVM/TC
[A/°C]
@180° el sin
ITSM [A]
@10ms,
Tvj max
∫I2dt [A2s ·
103] @10ms,
Tvj max
VT/IT
[V/kA]
@Tvj max
VT0
[V] @Tvj
max max
rT [m]
@Tvj
max max
RthJC
[K/kW] @180°
el sin max
Ceramic discs up to 3000V
T1220N22TOF VT 2200 350 125 20 45 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1220/85 22500 2531 1.38/1.0 1 0.275 18.4
T1220N20TOF VT 2000 350 125 20 45 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1220/85 22500 2531 1.38/1.0 1 0.275 18.4
T1040N22TOF VT 2200 300 125 16 32 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1039/85 18500 1711 1.53/2.0 0.9 0.3 23.1
T1040N20TOF VT 2000 300 125 16 32 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1039/85 18500 1711 1.53/2.0 0.9 0.3 23.1
T700N22TOF 2200 300 125 10.5 21 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 699/85 12200 744 2.32/2.85 0.95 0.45 32
T700N20TOF 2000 300 125 10.5 21 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 699/85 12200 744 2.32/2.85 0.95 0.45 32
T700N18TOF 1800 300 125 10.5 21 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 699/85 12200 744 2.32/2.85 0.95 0.45 32
T740N26TOF 2600 300 125 10.5 21 Disc dia 58mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 745/85 11500 660 2.53/2.85 1 0.5 28
T660N26TOF 2600 300 125 10.5 21 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 659/85 11500 660 2.53/2.85 1 0.5 33
T740N24TOF 2400 300 125 10.5 21 Disc dia 58mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 745/85 11500 660 2.53/2.85 1 0.5 28
T660N24TOF 2400 300 125 10.5 21 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 659/85 11500 660 2.53/2.85 1 0.5 33
T740N22TOF 2200 300 125 10.5 21 Disc dia 58mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 745/85 11500 660 2.53/2.85 1 0.5 28
T660N22TOF 2200 300 125 10.5 21 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 659/85 11500 660 2.53/2.85 1 0.5 33
T460N26TOF 2600 300 125 7.5 17.5 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 459/85 9000 405 2.75/2.0 1 0.84 45.5
T460N24TOF 2400 300 125 7.5 17.5 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 459/85 9000 405 2.75/2.0 1 0.84 45.5
T460N22TOF 2200 300 125 7.5 17.5 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 459/85 9000 405 2.75/2.0 1 0.84 45.5
T360N28TOF 2800 350 125 5 10 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 360/85 4500 101 2.88/1.1 1.1 1.6 44
T360N26TOF 2600 350 125 5 10 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 360/85 4500 101 2.88/1.1 1.1 1.6 44
T360N24TOF 2400 350 125 5 10 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 360/85 4500 101 2.88/1.1 1.1 1.6 44
T360N22TOF 2200 350 125 5 10 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 360/85 4500 101 2.88/1.1 1.1 1.6 44
T360N20TOF 2000 350 125 5 10 Disc dia 48mm height 14mm / Ceramic Electrical Triggered Phase Control Thyristor 360/85 4500 101 2.88/1.1 1.1 1.6 44
99
Thyristor /
diode discs
Thyristor discs
Product VDRM /
VRRM
[V]
tq
[s]
Tvj
[°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Housing Configuration ITAVM/TC
[A/°C]
@180° el sin
ITSM [A]
@10ms,
Tvj max
∫I2dt [A2s ·
103] @10ms,
Tvj max
VT/IT
[V/kA]
@Tvj max
VT0
[V] @Tvj
max max
rT [m]
@Tvj
max max
RthJC
[K/kW] @180°
el sin max
Ceramic discs up to 5500V
T4021N52TOH 5200 550 125 90 130 Disc dia 172mm height 35mm / Ceramic Electrical Triggered Phase Control Thyristor 3880/85 100000 50000 1.80/6.0 0.93 0.145 4.5
T4003N52TOH PR 5200 550 120 90 130 Disc dia 172mm height 40mm / Ceramic Light Triggered Phase Control Thyristor 3400/85 100000 50000 1.80/6.0 0.93 0.145 4.8
T4003NH52TOH 5200 550 120 90 130 Disc dia 172mm height 40mm / Ceramic Light Triggered Phase Control Thyristor 3400/85 100000 50000 1.80/6.0 0.93 0.145 4.8
T3801N36TOF VT 3600 300 125 63 91 Disc dia 150mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 3830/85 87000 37850 1.40/4.0 0.82 0.145 4.8
T3441N52TOH 5200 600 125 63 91 Disc dia 150mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 3200/85 79000 31000 1.70/4.0 0.77 0.235 4.8
T2851N52TOH 5200 600 125 63 91 Disc dia 150mm height 35mm / Ceramic Electrical Triggered Phase Control Thyristor 2980/85 79000 31000 1.70/4.0 0.77 0.235 5.4
T2851N48TOH 4800 600 125 63 91 Disc dia 150mm height 35mm / Ceramic Electrical Triggered Phase Control Thyristor 2980/85 79000 31000 1.70/4.0 0.77 0.235 5.4
T2851N42TOH 4200 600 125 63 91 Disc dia 150mm height 35mm / Ceramic Electrical Triggered Phase Control Thyristor 2980/85 79000 31000 1.70/4.0 0.77 0.235 5.4
T2351N52TOH 5200 450 125 45 65 Disc dia 120mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2250/85 54000 14600 1.85/3.0 0.81 0.36 6.5
T2161N52TOH 5200 450 125 36 52 Disc dia 120mm height 35mm / Ceramic Electrical Triggered Phase Control Thyristor 2070/85 54000 14600 1.85/3.0 0.81 0.36 7.5
T1601N36TOF 3600 300 125 36 52 Disc dia 120mm height 35mm / Ceramic Electrical Triggered Phase Control Thyristor 1900/85 44000 8400 1.50/2.0 1 0.25 9
T1601N35TOF 3500 300 125 36 52 Disc dia 120mm height 35mm / Ceramic Electrical Triggered Phase Control Thyristor 1900/85 44000 8400 1.50/2.0 1 0.25 9
T1551N52TOH PR 5200 450 125 36 52 Disc dia 120mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1770/85 43000 9250 1.70/2.0 0.92 0.37 9
T1451N52TOH 5200 450 125 36 52 Disc dia 120mm height 35mm / Ceramic Electrical Triggered Phase Control Thyristor 1660/85 43000 9250 1.70/2.0 0.92 0.37 9.7
T1800N42TOF PR 4200 900 125 36 52 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1800/85 41000 8405 1.65/2.0 0.85 0.4 8.5
T2001N36TOF 3600 300 125 36 52 Disc dia 120mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2060/85 41000 8400 1.50/2.0 1 0.25 8.7
T2001N34TOF 3400 300 125 36 52 Disc dia 120mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2060/85 41000 8400 1.50/2.0 1 0.25 8.7
T1930N38TOF VT 3800 450 125 40 65 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2180/85 37000 6850 2.90/8.0 1.08 0.2 8.5
T1930N36TOF VT 3600 450 125 40 65 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2180/85 37000 6850 2.90/8.0 1.08 0.2 8.5
T1930N34TOF VT 3400 450 125 40 65 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2180/85 37000 6850 2.90/8.0 1.08 0.2 8.5
T1930N32TOF VT 3200 450 125 40 65 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2180/85 37000 6850 2.90/8.0 1.08 0.2 8.5
T1401N42TOH 4200 350 125 36 52 Disc dia 120mm height 35mm / Ceramic Electrical Triggered Phase Control Thyristor 1590/85 36000 6480 1.95/2.0 1.29 0.33 9.7
T930N36TOF VT 3600 500 125 20 45 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 930/85 17500 1530 2.70/3.6 1 0.43 21.5
T930N34TOF VT 3400 500 125 20 45 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 930/85 17500 1530 2.70/3.6 1 0.43 21.5
T930N32TOF VT 3200 500 125 20 45 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 930/85 17500 1530 2.70/3.6 1 0.43 21.5
T901N36TOF 3600 300 125 15 24 Disc dia 76mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 940/85 17000 1445 1.75/1.2 1.16 0.494 18.5
T901N35TOF 3500 300 125 15 24 Disc dia 76mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 940/85 17000 1445 1.75/1.2 1.16 0.494 18.5
T901N32TOF 3200 300 125 15 24 Disc dia 76mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 940/85 17000 1445 1.75/1.2 1.16 0.494 18.5
100
Thyristor /
diode discs
Product VDRM /
VRRM
[V]
tq
[s]
Tvj
[°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Housing Configuration ITAVM/TC
[A/°C]
@180° el sin
ITSM [A]
@10ms,
Tvj max
∫I2dt [A2s ·
103] @10ms,
Tvj max
VT/IT
[V/kA]
@Tvj max
VT0
[V] @Tvj
max max
rT [m]
@Tvj
max max
RthJC
[K/kW] @180°
el sin max
Ceramic discs up to 5500V
T860N36TOF VT 3600 400 125 20 45 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 860/85 17000 1445 3.18/3.8 1.08 0.5 21
T860N32TOF VT 3200 400 125 20 45 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 860/85 17000 1445 3.18/3.8 1.08 0.5 21
T860N30TOF VT 3000 400 125 20 45 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 860/85 17000 1445 3.18/3.8 1.08 0.5 21
T731N44TOH 4400 500 125 15 24 Disc dia 76mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 870/85 16000 1280 1.86/1.2 1.08 0.65 18.5
T731N42TOF 4200 500 125 15 24 Disc dia 76mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 870/85 16000 1280 1.86/1.2 1.08 0.65 18.5
T731N36TOF 3600 500 125 15 24 Disc dia 76mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 870/85 16000 1280 1.86/1.2 1.08 0.65 18.5
T730N42TOF VT 4200 400 120 18 43 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 730/85 15800 1250 3.40/3.5 1.2 0.57 21.5
T730N40TOF VT 4000 400 120 18 43 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 730/85 15800 1250 3.40/3.5 1.2 0.57 21.5
T730N38TOF VT 3800 400 120 18 43 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 730/85 15800 1250 3.40/3.5 1.2 0.57 21.5
101
Thyristor /
diode discs
Thyristor discs
Product VDRM /
VRRM
[V]
tq
[s]
Tvj
[°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Housing Configuration ITAVM/TC
[A/°C]
@180° el sin
ITSM [A]
@10ms,
Tvj max
∫I2dt [A2s ·
103] @10ms,
Tvj max
VT/IT
[V/kA]
@Tvj max
VT0
[V] @Tvj
max max
rT [m]
@Tvj
max max
RthJC
[K/kW] @180°
el sin max
Ceramic discs up to 5500V
T2563N80TOH PR 8000 550 120 90 130 Disc dia 172mm height 40mm / Ceramic Light Triggered Phase Control Thyristor 2300/85 90000 40500 2.95/5.0 1.2 0.35 4.8
T2871N80TOH 8000 550 125 90 130 Disc dia 172mm height 35mm / Ceramic Electrical Triggered Phase Control Thyristor 2620/85 90000 40500 2.95/5.0 1.27 0.336 4.5
T2563NH80TOH 8000 550 120 90 130 Disc dia 172mm height 40mm / Ceramic Light Triggered Phase Control Thyristor 2300/85 90000 40500 2.95/5.0 1.2 0.35 4.8
T1901N80TOH 8000 550 125 63 91 Disc dia 150mm height 35mm / Ceramic Electrical Triggered Phase Control Thyristor 2100/85 65000 21100 3.0/4.0 1.24 0.44 5.4
T2251N80TOH 8000 550 125 63 91 Disc dia 150mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2260/85 65000 21100 3.0/4.0 1.24 0.44 4.8
T2251N70TOH 7000 550 125 63 91 Disc dia 150mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 2260/85 65000 21100 3.0/4.0 1.24 0.44 4.8
T1503N80TOH PR 8000 550 120 63 91 Disc dia 150mm height 40mm / Ceramic Light Triggered Phase Control Thyristor 1770/85 55000 15125 3.00/4.0 1.24 0.44 6.3
T1503NH80TOH 8000 550 120 63 91 Disc dia 150mm height 40mm / Ceramic Light Triggered Phase Control Thyristor 1770/85 55000 15125 3.00/4.0 1.24 0.44 6.3
T1503N75TOH 7500 550 120 63 91 Disc dia 150mm height 40mm / Ceramic Light Triggered Phase Control Thyristor 1770/85 55000 15125 3.00/4.0 1.24 0.44 6.3
T1651N70TOH PR 7000 600 125 45 65 Disc dia 120mm height 35mm / Ceramic Electrical Triggered Phase Control Thyristor 1670/85 50000 11500 2.65/3.0 1.22 0.49 7.5
T1851N70TOH 7000 600 125 45 65 Disc dia 120mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1830/85 48000 11500 2.65/3.0 1.22 0.49 6.5
T1851N65TOH PR 6500 600 125 45 65 Disc dia 120mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1830/85 48000 11500 2.65/3.0 1.22 0.49 6.5
T1851N60TOH 6000 600 125 45 65 Disc dia 120mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1830/85 48000 11500 2.65/3.0 1.22 0.49 6.5
T1081N70TOH 7000 600 125 26 52 Disc dia 120mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1300/85 34000 5780 2.7/2.0 1.18 0.759 8.6
T1081N65TOH 6500 600 125 26 52 Disc dia 120mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1300/85 34000 5780 2.7/2.0 1.18 0.759 8.6
T1081N60TOH 6000 600 125 26 52 Disc dia 120mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1300/85 34000 5780 2.7/2.0 1.18 0.759 8.6
T1620N65TOF PR 6500 1000 125 40 65 Disc dia 111mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1613/85 32000 5120 3.3/4.5 1.35 0.43 8.1
T1060N65TOF PR 6500 1000 125 27 45 Disc dia 100mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 1053/85 22500 2530 2.43/1.5 1.35 0.72 11
T501N70TOH 7000 600 125 15 24 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 640/85 13000 845 2.65/1.0 1.3 1.35 17
T600N95TOH PR 9500 900 125 15 24 Disc dia 75mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 590/85 12800 820 2.7/1.0 1.25 1.4 19
T533N80TOH PR 8000 650 120 15 24 Disc dia 76mm height 35mm / Ceramic Light Triggered Phase Control Thyristor 540/85 10500 550 2.75/1.0 1.26 1.47 20
T570N65TOF 6500 1000 125 13 23 Disc dia 76mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 540/85 10500 442 2.75/1.0 1.35 1.4 21
T280N65TOF 6500 1000 125 7 12 Disc dia 58mm height 27mm / Ceramic Electrical Triggered Phase Control Thyristor 280/85 5800 115 2.75/0.5 1.35 2.8 43
T201N70TOH PR 7000 600 125 7 12 Disc dia 58mm height 26mm / Ceramic Electrical Triggered Phase Control Thyristor 245/85 4200 88 3.4/0.5 1.29 4.22 40
102
Thyristor /
diode discs
Welding diodes
Product VRRM [V] Tvj [°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Housing Configuration IFAVM/TC [A/°C]
@180° el sin
IFSM [A] @10ms,
Tvj max
∫I2dt [A2s · 103]
@10ms, Tvj max
VF/IF [V/kA]
@Tvj max
VT0 [V] @Tvj
max max
rT [m] @Tvj
max max
RthJC [K/kW]
@180° el sin
max
65DN06 600 180 55 80 Disc dia 65mm height 5mm Rectifier diodes / Welding diodes 8470/98 95000 45000 0.99/4.5 0.7 0.03 4.7
56DN06B01 600 180 40 60 Disc dia 56mm height 5.0mm Rectifier diodes / Welding diodes 8400/110 70000 24500 0.99/4.5 0.66 0.04 5.8
46DN06 600 180 30 45 Disc dia 46mm height 4.0mm Rectifier diodes / Welding diodes 5100/118 52000 13500 0.99/4.5 0.7 0.05 9.35
38DN06 600 180 20 30 Disc dia 38mm height 4.,0mm Rectifier diodes / Welding diodes 3885/120 32300 5200 0.99/4.5 0.66 0.06 12.4
103
Thyristor /
diode discs
Fast Rectifier diodes
Product VRRM [V] Tvj [°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Housing Configuration IFAVM/TC
[A/°C]
@180°
el sin
IFSM [A]
@10ms,
Tvj max
∫I2dt
[A2s · 103]
@10ms,
Tvj max
VF/IF
[V/kA]
@Tvj max
VT0
[V]
@Tvj
max max
rT
[m]
@Tvj
max max
IRM [A] @IF
= IFAVM, di/
dt = 50 A/s
max
RthJC [K/kW]
@180° el sin
max
Fast Rectifier diodes up to 1400V
D650S14T QR 1400 150 6 14.5 Disc dia 58mm height 26mm / Ceramic Fast Rectifier diodes 650/96 10100 510 2.25/2.7 122 48 - 39
D650S14T 1400 150 6 14.5 Disc dia 58mm height 26mm / Ceramic Fast Rectifier diodes 650/96 10100 510 2.25/2.7 122 48 - 39
D650S12T 1200 150 6 14.5 Disc dia 58mm height 26mm / Ceramic Fast Rectifier diodes 650/96 10100 510 2.25/2.7 122 48 - 48
GTO - Freewheeling Diodes
D1461S45T 4500 140 27 45 Disc dia 100mm height 26mm / Ceramic GTO - Freewheeling Diodes 1460/85 28000 5120 2.5/2.5 840 12.5 - 18
D1381S45T 4500 140 27 35 Disc dia 100mm height 26mm / Ceramic GTO - Freewheeling Diodes 1380/85 28000 5120 2.6/2.5 700 12.5 - 39
D921S45T 4500 140 27 45 Disc dia 100mm height 26mm / Ceramic GTO - Freewheeling Diodes 1380/85 28000 2650 2.6/2.5 800 12.5 - 39
D1251S45T 4500 140 15 36 Disc dia 76mm height 14mm / Ceramic GTO - Freewheeling Diodes 1310/85 18000 1620 2.5/2.5 800 14 - 14
D721S45T 4500 125 15 36 Disc dia 75mm height 26mm / Ceramic GTO - Freewheeling Diodes 720/85 15000 1300 3.5/2.5 600 18 - 12.5
D721S35T VF 3500 125 15 36 Disc dia 75mm height 26mm / Ceramic GTO - Freewheeling Diodes 720/85 15000 1300 3.5/2.5 600 18 - 12.5
Fast Rectifier diodes up to 6000V
D371S45T 4500 125 10 16 Disc dia 58mm height 26mm / Ceramic Fast Rectifier diodes 330/85 6000 180 3.9/1.2 500 18 - 48
D291S45T 4500 125 9 13 Disc dia 58mm height 26mm / Ceramic Fast Rectifier diodes 290/85 4500 100 4.15/1.2 500 40 - 57
Fast Rectifier diodes up to 2600V
D690S26T 2600 150 10 24 Disc dia 58mm height 26mm / Ceramic Fast Rectifier diodes 690/100 11500 661 2.7/3.0 230 39 - 12.5
D690S24T 2400 150 10 24 Disc dia 58mm height 26mm / Ceramic Fast Rectifier diodes 690/100 11500 661 2.7/3.0 230 39 - 40
D690S22T 2200 150 10 24 Disc dia 58mm height 26mm / Ceramic Fast Rectifier diodes 690/100 11500 661 2.7/3.0 230 39 - 18
D690S20T 2000 150 10 24 Disc dia 58mm height 26mm / Ceramic Fast Rectifier diodes 690/100 11500 661 3.7/3.0 230 39 - 18
D450S20T 2000 150 3.2 7.6 Disc dia 42mm height 14mm / Ceramic Fast Rectifier diodes 443/100 4600 106 2.25/1.2 160 57 - 48
D450S16T 1600 150 3.2 7.6 Disc dia 42mm height 14mm / Ceramic Fast Rectifier diodes 443/100 4600 106 2.25/1.2 160 57 - 57
104
Thyristor /
diode discs
IGCT / IGBT freewheeling diodes
Product VRRM
[V]
Tvj
[°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Configuration Housing VR(D)
[kV]
@TC
= 25°
IFAVM/TC
[A/°C]
@180° el
sin
IFSM [A]
@10ms,
Tvj max
∫I<sup>2</sup>dt
[A<sup>2</sup>s ·
10<sup>3</sup>]
@10ms, Tvj max
VF/IF
[V/kA]
@Tvj
max
VT0 [V]
@Tvj
max
max
rT [m]
@Tvj
max
max
Qr [mAs] @di/
dt = 1000 A/s,
IFM = 2.5 kA,
Tvj max max
IRM [A] @di/dt
= 1000 A/s,
IFM = 2.5 kA,
Tvj max max
RthJC [K/kW] @
DC max
D4600U45X172 4500 140 50 130 IGCT/IGBT -
Freewheeling Diodes
Disc dia 172 mm height 26mm
/ Ceramic
2.8 4780/55 80000 32000 2.0/2.5 1.25 0.3 13 5500 3.3
D2700U45X122 4500 140 50 100 IGCT/IGBT -
Freewheeling Diodes
Disc dia 120mm height 26mm
/ Ceramic
2.8 2900/55 48000 11500 2.5/2.5 1.38 0.447 9.5 4200 5.6
D1600U45X122 4500 140 36 65 IGCT/IGBT -
Freewheeling Diodes
Disc dia 120mm height 26mm
/ Ceramic
2.8 1680/55 28000 3920 4.3/2.5 1.8 0.994 6 3600 7.5
D1961SH45T 4500 140 36 52 IGCT/IGBT -
Freewheeling Diodes
Disc dia 120mm height 26mm
/ Ceramic
2.8 1830/85 40000 8000 2.5/2.5 1.25 0.5 12 2250 7.5
D1331SH45T 4500 140 36 52 IGCT/IGBT -
Freewheeling Diodes
Disc dia 120mm height 26mm
/ Ceramic
2.8 1310/85 28000 3920 5.6/2.5 1.83 0.948 3.5 1500 7.5
D1031SH45T 4500 140 27 45 IGCT/IGBT -
Freewheeling Diodes
Disc dia 100mm height 26mm
/ Ceramic
2.8 1120/85 23000 2645 4.2/2.5 1.78 0.968 3.5 1500 10
D1131SH65T 6500 140 36 52 IGCT/IGBT -
Freewheeling Diodes
Disc dia 120mm height 26mm
/ Ceramic
3.2 1100/85 22000 2420 4,2/2,5 2.19 1.364 3.5 1200 7.5
D931SH65T 6500 140 27 45 IGCT/IGBT -
Freewheeling Diodes
Disc dia 100mm height 26mm
/ Ceramic
3.2 940/85 16000 1280 5.6/2.5 1.99 1.44 3.5 1300 11.1
105
Thyristor /
diode discs
Rectifier diodes
Product VRRM [V] Tvj [°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Housing Configuration IFAVM/TC [A/°C]
@180° el sin
IFSM [A]
@10ms, Tvj
max
∫I2dt [A2s ·
103] @10ms,
Tvj max
VF/IF [V/kA] @
Tvj max
VT0 [V] @Tvj
max max
rT [m] @Tvj
max max
RthJC [K/kW]
@180° el sin
max
Ceramic discs up to 800V
D8320N06T VF 600 180 40 80 Disc dia 100mm height 26mm / Ceramic Rectifier diodes 8320/56 95000 45000 0.94/10.0 0.7 0.02 12.5
D8320N04T VF 400 180 40 80 Disc dia 100mm height 26mm / Ceramic Rectifier diodes 8320/56 95000 45000 0.94/10.0 0.7 0.02 12.5
D8320N02T VF 200 180 40 80 Disc dia 100mm height 26mm / Ceramic Rectifier diodes 8320/56 95000 45000 0.94/10.0 0.7 0.02 12.5
D5810N06T VF 600 180 30 60 Disc dia 75mm height 26mm / Ceramic Rectifier diodes 5800/58 70000 24500 1.47/18.0 0.7 0.04 17
D5810N04T VF 400 180 30 60 Disc dia 75mm height 26mm / Ceramic Rectifier diodes 5800/58 70000 24500 1.47/18.0 0.7 0.04 17
D5810N02T VF 200 180 30 60 Disc dia 75mm height 26mm / Ceramic Rectifier diodes 5800/58 70000 24500 1.47/18.0 0.7 0.04 17
D970N08T 800 180 3.9 7.6 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 972/100 8800 387 1.45/2.3 0.7 0.31 57
D970N06T 600 180 3.9 7.6 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 972/100 8800 387 1.45/2.3 0.7 0.31 57
D970N04T 400 180 3.9 7.6 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 972/100 8800 387 1.45/2.3 0.7 0.31 57
D970N02T 200 180 3.9 7.6 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 972/100 8800 387 1.45/2.3 0.7 0.31 57
D2450N07T 700 180 12 24 Disc dia 58mm height 14mm / Ceramic Rectifier diodes 2452/100 4000 4061 1.5/7.7 0.7 0.1 25.3
D2450N06T 600 180 12 24 Disc dia 58mm height 14mm / Ceramic Rectifier diodes 2452/100 4000 4061 1.5/7.7 0.7 0.1 25.3
D2450N04T 400 180 12 24 Disc dia 58mm height 14mm / Ceramic Rectifier diodes 2452/100 4000 4061 1.5/7.7 0.7 0.1 25.3
D2450N02T 200 180 12 24 Disc dia 58mm height 14mm / Ceramic Rectifier diodes 2452/100 4000 4061 1.5/7.7 0.7 0.1 25.3
D650N08T 800 180 2.6 4.6 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 651/100 510 130 1.44/1.35 0.7 0.51 81
D650N06T 600 180 2.6 4.6 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 651/100 510 130 1.44/1.35 0.7 0.51 81
D650N04T 400 180 2.6 4.6 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 651/100 510 130 1.44/1.35 0.7 0.51 81
D650N02T 200 180 2.6 4.6 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 651/100 510 130 1.44/1.35 0.7 0.51 81
Ceramic discs up to 1800V
D1050N18T 1800 180 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 1050/130 18500 1710 1.76/5.0 0.81 0.17 38
D1050N16T 1600 180 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 1050/130 18500 1710 1.76/5.0 0.81 0.17 38
D1050N14T 1400 180 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 1050/130 18500 1710 1.76/5.0 0.81 0.17 38
D1050N12T 1200 180 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 1050/130 18500 1710 1.76/5.0 0.81 0.17 38
D1230N18T 1800 180 6 15 Disc dia 48mm height 14mm / Ceramic Rectifier diodes 1234/100 11800 696 1.77/3.2 0.81 0.28 39
D1230N16T 1600 180 6 15 Disc dia 48mm height 14mm / Ceramic Rectifier diodes 1234/100 11800 696 1.77/3.2 0.81 0.28 39
D1230N14T 1400 180 6 15 Disc dia 48mm height 14mm / Ceramic Rectifier diodes 1234/100 11800 696 1.77/3.2 0.81 0.28 39
D1230N12T 1200 180 6 15 Disc dia 48mm height 14mm / Ceramic Rectifier diodes 1234/100 11800 696 1.77/3.2 0.81 0.28 39
106
Thyristor /
diode discs
Product VRRM [V] Tvj [°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Housing Configuration IFAVM/TC [A/°C]
@180° el sin
IFSM [A]
@10ms, Tvj
max
∫I2dt [A2s ·
103] @10ms,
Tvj max
VF/IF [V/kA] @
Tvj max
VT0 [V] @Tvj
max max
rT [m] @Tvj
max max
RthJC [K/kW]
@180° el sin
max
Ceramic discs up to 3000V
D4201N22T 2200 160 36 52 Disc dia 120mm height 35mm / Ceramic Rectifier diodes 4830/100 73500 27000 0.94/4.0 0.67 0.08 9.2
D4201N20T 2000 160 36 52 Disc dia 120mm height 35mm / Ceramic Rectifier diodes 4830/100 73500 27000 0.94/4.0 0.67 0.08 9.2
D4810N28T VF 2800 160 42 95 Disc dia 111mm height 26mm / Ceramic Rectifier diodes 4810/100 60000 18000 1.45/10.0 0.83 0.06 8
D4810N24T VF 2400 160 42 95 Disc dia 111mm height 26mm / Ceramic Rectifier diodes 4810/100 60000 18000 1.45/10.0 0.83 0.06 8
D4810N22T VF 2200 160 42 95 Disc dia 111mm height 26mm / Ceramic Rectifier diodes 4810/100 60000 18000 1.45/10.0 0.83 0.06 8
D4810N20T VF 2000 160 42 95 Disc dia 111mm height 26mm / Ceramic Rectifier diodes 4810/100 60000 18000 1.45/10.0 0.83 0.06 8
D2650N24T VF 2400 180 24 60 Disc dia 75mm height 26mm / Ceramic Rectifier diodes 3520 / 100 41000 5611 2.25/9.0 0.82 0.15 16.9
D2200N24T VF 2400 160 24 60 Disc dia 75mm height 26mm / Ceramic Rectifier diodes 2200/100 35000 6125 1.17/2.5 0.83 0.15 17
D2520N22T VF 2200 175 15 24 Disc dia 76mm height 26mm / Ceramic Rectifier diodes 2520/100 35000 6125 1.57/10.2 0.73 0.1 22
D2200N22T VF 2200 160 24 60 Disc dia 74mm height 26mm / Ceramic Rectifier diodes 2200/100 35000 6125 1.17/2.5 0.83 0.15 17
D2200N20T VF 2000 160 24 60 Disc dia 74mm height 26mm / Ceramic Rectifier diodes 2200/100 35000 6125 1.17/2.5 0.83 0.15 17
D1030N26T 2600 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 1030/100 14500 1051 2.05/4.0 0.82 0.28 38
D1030N24T 2400 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 1030/100 14500 1051 2.05/4.0 0.82 0.28 38
D1030N22T 2200 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 1030/100 14500 1051 2.05/4.0 0.82 0.28 38
D950N22T 2200 180 6 12 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 950/100 10250 525 2.1/2.8 0.7 0.5 45
D950N18T 1800 180 6 12 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 950/100 10250 525 2.1/2.8 0.7 0.5 45
D820N28T 2800 160 6 15 Disc dia 48mm height 14mm / Ceramic Rectifier diodes 818/100 9000 405 2.15/2.4 0.83 0.52 39
D820N26T 2600 160 6 15 Disc dia 48mm height 14mm / Ceramic Rectifier diodes 818/100 9000 405 2.15/2.4 0.83 0.52 39
D820N24T 2400 160 6 15 Disc dia 48mm height 14mm / Ceramic Rectifier diodes 818/100 9000 405 2.15/2.4 0.83 0.52 39
D820N22T 2200 160 6 15 Disc dia 48mm height 14mm / Ceramic Rectifier diodes 818/100 9000 405 2.15/2.4 0.83 0.52 39
D820N20T 2000 160 6 15 Disc dia 48mm height 14mm / Ceramic Rectifier diodes 818/100 9000 405 2.15/2.4 0.83 0.52 39
D770N20T 2000 180 3.2 7.6 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 767/100 6000 180 1.76/1.6 0.81 0.54 57
D770N18T 1800 180 3.2 7.6 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 767/100 6000 180 1.76/1.6 0.81 0.54 57
D770N16T 1600 180 3.2 7.6 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 767/100 6000 180 1.76/1.6 0.81 0.54 57
D770N14T 1400 180 3.2 7.6 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 767/100 6000 180 1.76/1.6 0.81 0.54 57
D770N12T 1200 180 3.2 7.6 Disc dia 42mm height 14mm / Ceramic Rectifier diodes 767/100 6000 180 1.76/1.6 0.81 0.54 57
107
Thyristor /
diode discs
Rectifier diodes
Product VRRM [V] Tvj [°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Housing Configuration IFAVM/TC [A/°C]
@180° el sin
IFSM [A]
@10ms, Tvj
max
∫I2dt [A2s ·
103] @10ms,
Tvj max
VF/IF [V/kA] @
Tvj max
VT0 [V] @Tvj
max max
rT [m] @Tvj
max max
RthJC [K/kW]
@180° el sin
max
Ceramic discs up to 5000V
D6001N50T 5000 160 63 91 Disc dia 150mm height 26mm / Ceramic Rectifier diodes 6070/100 110000 60500 1.15/6.0 0.8 0.09 4.6
D3501N42T 4200 160 36 52 Disc dia 120mm height 35mm / Ceramic Rectifier diodes 3690/100 56000 15700 1.2/4.0 0.73 0.13 9.2
D3501N40T PR 4000 160 36 52 Disc dia 120mm height 35mm / Ceramic Rectifier diodes 3690/100 56000 15700 1.2/4.0 0.73 0.13 9.2
D3501N36T 3600 160 36 52 Disc dia 120mm height 35mm / Ceramic Rectifier diodes 3690/100 56000 15700 1.2/4.0 0.73 0.13 9.2
D2201N45T 4500 140 27 45 Disc dia 100mm height 26mm / Ceramic Rectifier diodes 2320/100 38000 7220 1.17/2.5 0.69 0.206 11.2
D1800N48T VF 4800 160 24 60 Disc dia 75mm height 26mm / Ceramic Rectifier diodes 1800/100 27500 3781 2.82/7.4 0.85 0.25 16.9
D1800N46T VF 4600 160 24 60 Disc dia 75mm height 26mm / Ceramic Rectifier diodes 1800/100 27500 3781 2.82/7.4 0.85 0.25 16.9
D1800N44T VF 4400 160 24 60 Disc dia 75mm height 26mm / Ceramic Rectifier diodes 1800/100 27500 3781 2.82/7.4 0.85 0.25 16.9
D1800N43T VF 4300 160 24 60 Disc dia 75mm height 26mm / Ceramic Rectifier diodes 1800/100 27500 3781 2.82/7.4 0.85 0.25 16.9
D1800N42T VF 4200 160 24 60 Disc dia 75mm height 26mm / Ceramic Rectifier diodes 1800/100 27500 3781 2.82/7.4 0.85 0.25 16.9
D1800N40T VF 4000 160 24 60 Disc dia 75mm height 26mm / Ceramic Rectifier diodes 1800/100 27500 3781 2.82/7.4 0.85 0.25 16.9
D1800N36T VF 3600 160 24 60 Disc dia 75mm height 26mm / Ceramic Rectifier diodes 1800/100 27500 3781 2.82/7.4 0.85 0.25 16.9
D850N40T 4000 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 850/100 12800 819 2.62/3.5 0.84 0.49 38
D850N36T 3600 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 850/100 12800 819 2.62/3.5 0.84 0.49 38
D850N34T 3400 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 850/100 12800 819 2.62/3.5 0.84 0.49 38
D850N32T 3200 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 850/100 12800 819 2.62/3.5 0.84 0.49 38
D850N30T 3000 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 850/100 12800 819 2.62/3.5 0.84 0.49 38
D850N28T 2800 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 850/100 12800 819 2.62/3.5 0.84 0.49 38
D740N48T 4800 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 750/100 11000 605 2.94/3.0 0.85 0.65 39
D740N46T 4600 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 750/100 11000 605 2.94/3.0 0.85 0.65 39
D740N44T 4400 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 750/100 11000 605 2.94/3.0 0.85 0.65 39
D740N42T 4200 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 750/100 11000 605 2.94/3.0 0.85 0.65 39
D740N40T 4000 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 750/100 11000 605 2.94/3.0 0.85 0.65 39
D740N36T 3600 160 10 24 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 750/100 11000 605 2.94/3.0 0.85 0.65 39
D270N36T 3600 150 3.2 7.6 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 270/100 4000 80 2.6/1.05 0.86 1.54 98
108
Thyristor /
diode discs
Product VRRM [V] Tvj [°C]
max
Clamping
force [kn]
min
Clamping
force [kn]
max
Housing Configuration IFAVM/TC [A/°C]
@180° el sin
IFSM [A]
@10ms, Tvj
max
∫I2dt [A2s ·
103] @10ms,
Tvj max
VF/IF [V/kA] @
Tvj max
VT0 [V] @Tvj
max max
rT [m] @Tvj
max max
RthJC [K/kW]
@180° el sin
max
Ceramic discs up to 10000V
D3041N68T 6800 160 36 52 Disc dia 120mm height 26mm / Ceramic Rectifier diodes 3040/100 53000 14040 1.7/4.0 0.84 0.22 8.55
D3001N68T 6800 160 36 52 Disc dia 120mm height 35mm / Ceramic Rectifier diodes 2900/100 53000 14040 1.8/4.0 0.84 0.22 9.2
D3041N65T 6500 160 36 52 Disc dia 120mm height 26mm / Ceramic Rectifier diodes 3040/100 53000 14040 1.7/4.0 0.84 0.22 8.55
D3041N58T 5800 160 36 52 Disc dia 120mm height 26mm / Ceramic Rectifier diodes 3040/100 53000 14040 1.7/4.0 0.84 0.22 8.55
D3001N58T 5800 160 36 52 Disc dia 120mm height 35mm / Ceramic Rectifier diodes 2900/100 53000 14040 1.8/4.0 0.84 0.22 9.2
D2601N90T 9000 160 36 52 Disc dia 120mm height 26mm / Ceramic Rectifier diodes 2240/100 50000 12500 2.6/4.0 0.94 0.41 8.55
D2601N85T 8500 160 36 52 Disc dia 120mm height 26mm / Ceramic Rectifier diodes 2240/100 50000 12500 2.6/4.0 0.94 0.41 8.55
D1721NH90T 9000 140 36 52 Disc dia 120mm height 26mm / Ceramic Pulse Power Diode 1670/85 35000 5780 3.5/4.0 1.36 0.65 7.5
D1481N68T VF 6800 160 15 36 Disc dia 75mm height 26mm / Ceramic Rectifier diodes 1650/100 24500 3000 1.8/2.5 0.75 0.42 15.8
D1481N62T 6200 160 15 36 Disc dia 75mm height 26mm / Ceramic Rectifier diodes 1650/100 24500 3000 1.8/2.5 0.75 0.42 15.8
D2601NH90T 9000 160 36 52 Disc dia 120mm height 26mm / Ceramic Pulse Power Diode 1440/85 22000 12500 2.6/4.0 0.94 0.41 8.55
D471N90T 9000 160 10 16 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 565/100 10000 500 3.0/1.2 1.04 1.78 31.5
D471N85T 8500 160 10 16 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 565/100 10000 500 3.0/1.2 1.04 1.78 31.5
D471N80T 8000 160 10 16 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 565/100 10000 500 3.0/1.2 1.04 1.78 31.5
D711N68T 6800 160 10 16 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 790/100 10500 550 1.77/1.2 0.84 0.87 31.5
D711N65T 6500 160 10 16 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 790/100 10500 550 1.77/1.2 0.84 0.87 31.5
D711N60T 6000 160 10 16 Disc dia 58mm height 26mm / Ceramic Rectifier diodes 790/100 10500 550 1.77/1.2 0.84 0.87 31.5
109
Thyristor /
diode discs
Accessories
Clamping Units for Discs
Product Clamping force [kn] max Disc diameter [mm] Disc height [mm] Creeping distance [mm] min
V100-35.200N 20 75 26 26
V89-26.400N 40 75 26 26
V89-26.300N 30 75 26 26
V89-26.170N 17 75 26 26
V72-26.150M 15 75 26 23
V72-26.120M 12 58 26 23
V72-26.80M 8 58 26 23
V72-14.150M 15 58 14 11
V61-14.80M 8 48 14 11
V61-14.80N 8 48 14 11
V50-14.60M 6 42 14 11
V50-14.60N 6 42 14 11
V50-14.45M 4.5 42 14 11
V50-14.45N 4.5 42 14 11
110
Thyristor /
diode discs
Gate Leads
Product Product Group For disc outline Connector
GATELEAD MEDIUM POWER Gateleads for Discs T42.14K0, T48.14K0, T58.14K0, T58.26K0, T75.26K0, T100.26K0, T111.26K0 4.8 x 0.5/2.8 x 0.5
GATELEAD HIGH POWER Gateleads for Discs T120.26K, T120.35K, T150.26K, T150.35K, T172.26K 6.3 x 0.8/4.8 x 0.8
Laser Diode & Light Fiber for LTT
Product Product Group For housing
LASER DIODE SPL-PL90 A Laserdiode for LTT T76.35L, T150.40L, T172.40L
LIGHT FIBER LWL R10-LR87 Light Fiber for LTT T150.40L, T172.40L
LIGHT FIBER LWL R10-LR50 Light Fiber for LTT T76.35L
111
Thyristor /
diode discs
112
We offer a broad range of Power Block modules which are designed and assembled in pressure contact technology
for highest reliability. The modules contain thyristor and diode pellets in a voltage range of 1600 V to 4400 V and
a current range of 60 A up to 1100 A.
Many Power Block modules are also available with pre-applied silicone-free Thermal Interface Material (TIM). The
optimized pattern of this reversible phase change material results in a stable thermal performance over life time
which increases reliability and lifetime of your system.
With the release of the 34 mm and 50 mm Eco Block modules in solder bond technology Infineon Technologies
Bipolar complemented the existing product portfolio of bipolar modules. Solder bond modules are ideal for
applications where the high robustness of pressure contact technology is not necessarily a must.
Thyristor / Diode modules
Infineon® Eco & Power Block
Main benefit of the new design concept in comparison to existing soft starter solutions is one slim foot-print (55 mm)
fitting all current classes which allows contactor compatible designs (LxWxH 134x55x100 mm).
Power Start provides integrated heatsink and can be mounted without thermal grease. By using double side cooling,
these modules can withstand overload currents up to 2200 A for a 21s duration of overload which gives best Power to
Price Ratio.
Infineon® Power Start
113
Thyristor /
diode modules
Thyristor Soft Starter Modules
Product VDRM / VRRM
[V]
Ioverload W1C (for 21s)2
[A]
ITSM @10ms,
@ Tj = 125°C
[A]
V(TO) @ Tj =125°C
[V]
rT @ Tj =125°C
[m]
RthJA 180°sin per chip
[K/W]
Tvj max (for 21s) [°C]
Housing
sTT800N16P55 1600 800 5400 0.9 0.83 0.203 155 length 134 mm, width 55 mm, height 100 mm
sTT1400N16P55 1600 1300 9000 0.9 0.49 0.123 155 length 134 mm, width 55 mm, height 100 mm
sTT1900N16P55 1600 1900 14000 0.9 0.28 0.087 155 length 134 mm, width 55 mm, height 100 mm
sTT2200N16P55 1600 2180 17500 0.9 0.24 0.084 155 length 134 mm, width 55 mm, height 100 mm
2 W1C; sin 180°; toverload = 21s; Tvjmax = 155°C; Tvjstart = 40°C
114
Thyristor /
diode modules
Thyristor / diode modules
Product VDRM / VRRM
[V]
Tvj [°C] max Housing Configuration IFAVM/TC / ITAVM/
TC [A/°C] @180°
el sin
IFSM / ITSM
[A] @10ms,
Tvj max
∫I2dt [A2s · 103]
@10ms,
Tvj max
VT0 [V]
@Tvj max max
rT [m]
@Tvj max max
(diT/dt)cr [A/s]
@DIN IEC 747- 6
RthJC [K/W]
@180° el sin
max
Thyristor Modules - Baseplate = 20 mm - Pressure contact
TT61N16KOF 1600 125 Power Block 20 mm SCR / SCR Phase Control 104/85 1800 9.8 0.8 3.4 150 0.52
TT92N16KOF 1600 130 Power Block 20 mm SCR / SCR Phase Control 92/85 1800 16.2 0.85 2.15 150 0.37
TT61N14KOF 1400 125 Power Block 20 mm SCR / SCR Phase Control 104/85 1800 9.8 0.8 3.4 150 0.52
TT104N14KOF 1400 130 Power Block 20 mm SCR / SCR Phase Control 92/85 1800 16.2 0.85 2.15 150 0.37
TT104N12KOF 1200 130 Power Block 20 mm SCR / SCR Phase Control 92/85 1800 16.2 0.85 2.15 150 0.37
TT92N14KOF 1400 130 Power Block 20 mm SCR / SCR Phase Control 60/85 1400 16.2 0.85 2.15 150 0.37
TT61N12KOF 1200 125 Power Block 20 mm SCR / SCR Phase Control 60/85 1400 9.8 0.8 3.4 150 0.52
TT92N12KOF 1200 130 Power Block 20 mm SCR / SCR Phase Control 60/85 1400 16.2 0.85 2.15 150 0.37
Thyristor Modules - Baseplate = 34 mm - Pressure contact
TT162N16KOF 1600 125 Power Block 34 mm SCR / SCR Phase Control 162/85 4400 97 0.85 0.95 150 0.2
TT162N14KOF 1400 125 Power Block 34 mm SCR / SCR Phase Control 162/85 4400 97 0.85 0.95 150 0.2
TT162N12KOF 1200 125 Power Block 34 mm SCR / SCR Phase Control 162/85 4400 97 0.85 0.95 150 0.2
TT142N16KOF 1600 125 Power Block 34 mm SCR / SCR Phase Control 142/85 4100 84 0.9 1.1 150 0.22
TT180N16KOF 1600 130 Power Block 34 mm SCR / SCR Phase Control 180/85 4100 84 0.85 0.9 150 0.2
TT142N14KOF 1400 125 Power Block 34 mm SCR / SCR Phase Control 142/85 4100 84 0.9 1.1 150 0.22
TT142N12KOF 1200 125 Power Block 34 mm SCR / SCR Phase Control 142/85 4100 84 0.9 1.1 150 0.22
TT180N12KOF 1200 130 Power Block 34 mm SCR / SCR Phase Control 180/85 4100 84 0.85 0.9 150 0.2
TT140N22KOF 2200 125 Power Block 34 mm SCR / SCR Phase Control 140/85 3200 51.2 0.9 1.75 150 0.19
TT140N18KOF 1800 125 Power Block 34 mm SCR / SCR Phase Control 140/85 3200 51.2 0.9 1.75 150 0.19
TT122N22KOF 2200 125 Power Block 34 mm SCR / SCR Phase Control 122/85 2950 43.5 1 2.15 100 0.2
TT122N18KOF 1800 125 Power Block 34 mm SCR / SCR Phase Control 122/85 2950 43.5 1 2.15 100 0.2
Thyristor Modules - Baseplate = 20 mm - Solder solder
TT120N16SOF 1600 130 Eco Block 20 mm SCR / SCR Phase Control 119/85 1900 18.05 0.9 3.35 140 0.2
TT60N16SOFB01 1600 130 Eco Block 20 mm SCR / SCR Phase Control 1200 7.2 1 4.8 140 0.49
TT60N16SOF 1600 130 Eco Block 20 mm SCR / SCR Phase Control 55/85 1200 7.2 1 4.8 140 0.49
TT120N16SOFB01 1600 130 Eco Block 20 mm SCR / SCR Phase Control 18.05 0.9 3.35 140 0.2
115
Thyristor /
diode modules
Thyristor / diode modules
Product VDRM / VRRM
[V]
Tvj [°C] max Housing Configuration IFAVM/TC / ITAVM/
TC [A/°C] @180°
el sin
IFSM / ITSM
[A] @10ms,
Tvj max
∫I2dt [A2s · 103]
@10ms,
Tvj max
VT0 [V]
@Tvj max max
rT [m]
@Tvj max max
(diT/dt)cr [A/s]
@DIN IEC 747- 6
RthJC [K/W]
@180° el sin
max
Thyristor Modules - Baseplate = 50 mm - Pressure contact
TT270N16KOF 1600 125 Power Block 50 mm SCR / SCR Phase Control 270/92 9000 400 0.8 0.58 250 0.12
TT305N16KOF 1600 130 Power Block 50 mm SCR / SCR Phase Control 305/85 9000 551 0.8 0.58 250 0.12
TT260N22KOF 2200 125 Power Block 50 mm SCR / SCR Phase Control 260/85 8000 320 0.85 0.64 250 0.12
TT251N18KOF 1800 125 Power Block 50 mm SCR / SCR Phase Control 250/85 8000 320 0.8 0.7 250 0.13
TT330N16KOF TIM 1600 130 Power Block 50 mm SCR / SCR Phase Control 330/85 8000 500 0.8 0.5 250 0.112
TT285N16KOF 1600 130 Power Block 50 mm SCR / SCR Phase Control 285/92 8000 781 0.8 0.5 250 0.112
TT251N16KOF 1600 125 Power Block 50 mm SCR / SCR Phase Control 250/85 8000 320 0.8 0.7 250 0.13
TT330N16KOF 1600 130 Power Block 50 mm SCR / SCR Phase Control 330/85 8000 500 0.8 0.5 250 0.112
TT251N14KOF 1400 125 Power Block 50 mm SCR / SCR Phase Control 250/85 8000 320 0.8 0.7 250 0.13
TT330N14KOF 1400 130 Power Block 50 mm SCR / SCR Phase Control 330/85 8000 500 0.8 0.5 250 0.112
TT330N12KOF 1200 130 Power Block 50 mm SCR / SCR Phase Control 330/85 8000 500 0.8 0.5 250 0.112
TT251N12KOF 1200 125 Power Block 50 mm SCR / SCR Phase Control 250/85 8000 320 0.8 0.7 250 0.13
TT250N18KOF 1800 125 Power Block 50 mm SCR / SCR Phase Control 250/85 7000 245 0.8 0.7 150 0.13
TT250N16KOF TIM 1600 125 Power Block 50 mm SCR / SCR Phase Control 250/85 7000 245 0.8 0.7 150 0.13
TT250N16KOF 1600 125 Power Block 50 mm SCR / SCR Phase Control 250/85 7000 245 0.8 0.7 150 0.13
TT250N14KOF 1400 125 Power Block 50 mm SCR / SCR Phase Control 250/85 7000 245 0.8 0.7 150 0.13
TT250N12KOF 1200 125 Power Block 50 mm SCR / SCR Phase Control 250/85 7000 245 0.8 0.7 150 0.13
TT215N20KOF 2000 125 Power Block 50 mm SCR / SCR Phase Control 215/85 6300 198 0.95 0.92 100 0.13
TT215N22KOF 1800 125 Power Block 50 mm SCR / SCR Phase Control 215/85 6300 198 0.95 0.92 100 0.13
TT215N18KOF 1800 125 Power Block 50 mm SCR / SCR Phase Control 215/85 6300 198 0.95 0.92 100 0.13
TT210N18KOF 1800 125 Power Block 50 mm SCR / SCR Phase Control 210/85 5800 168 1 0.85 150 0.13
TT210N16KOF 1600 125 Power Block 50 mm SCR / SCR Phase Control 210/85 5800 168 1 0.85 150 0.13
Thyristor Modules - Baseplate = 34 mm - Solder bond
TT160N18SOF 1800 125 Eco Block 34 mm SCR / SCR Phase Control 160/85 5200 101.3 1.1 0.99 100 0.165
TT190N18SOF 1800 125 Eco Block 34 mm SCR / SCR Phase Control 190/85 5200 101.3 0.85 0.9 100 0.165
TT160N16SOF 1600 125 Eco Block 34 mm SCR / SCR Phase Control 160/85 5200 101.3 1.1 0.99 100 0.145
TT190N16SOF 1600 125 Eco Block 34 mm SCR / SCR Phase Control 190/85 5200 101.3 0.85 0.9 100 0.145
TT175N16SOF 1600 125 Eco Block 34 mm SCR / SCR Phase Control 175/85 5000 125 0.83 1.3 200 0.164
TT140N16SOF 1600 125 Eco Block 34 mm SCR / SCR Phase Control 140/85 4000 80 1 1.6 200 0.19
116
Thyristor /
diode modules
Product VDRM / VRRM
[V]
Tvj [°C] max Housing Configuration IFAVM/TC / ITAVM/
TC [A/°C] @180°
el sin
IFSM / ITSM
[A] @10ms,
Tvj max
∫I2dt [A2s · 103]
@10ms,
Tvj max
VT0 [V]
@Tvj max max
rT [m]
@Tvj max max
(diT/dt)cr [A/s]
@DIN IEC 747- 6
RthJC [K/W]
@180° el sin
max
Thyristor Modules - Baseplate = 50 mm - Solder bond
TT320N18SOF 1800 130 Eco Block 50 mm SCR / SCR Phase Control 160/85 9500 335 0.77 0.58 100 0.055
TT280N18SOF 1800 130 Eco Block 50 mm SCR / SCR Phase Control 160/85 9000 304.2 1.77 0.82 100 0.11
TT280N16SOF 1600 130 Eco Block 50 mm SCR / SCR Phase Control 280/85 9000 304 0.9 0.82 100 0.11
TT320N16SOF 1600 130 Eco Block 50 mm SCR / SCR Phase Control 320/85 8200 335 0.77 0.58 100 0.11
Thyristor Modules - Baseplate = 50 mm - Pressure contact
TT210N14KOF 1400 125 Power Block 50 mm SCR / SCR Phase Control 210/85 5800 168 1 0.85 150 0.13
TT210N12KOF 1200 125 Power Block 50 mm SCR / SCR Phase Control 210/85 5800 168 1 0.85 150 0.13
TT170N18KOF 1800 125 Power Block 50 mm SCR / SCR Phase Control 170/85 4600 106 0.95 1 150 0.17
TT150N26KOF 2600 125 Power Block 50 mm SCR / SCR Phase Control 150/85 4000 80 1.2 2.3 60 0.13
TT150N22KOF 2200 125 Power Block 50 mm SCR / SCR Phase Control 150/85 4000 80 1.2 2.3 60 0.13
Thyristor Modules - Baseplate = 60 mm - Pressure contact
TT600N16KOF 1600 125 Power Block 60 mm SCR / SCR Phase Control 600/85 21000 1531 0.8 0.23 200 0.058
TT520N22KOF 2200 125 Power Block 60 mm SCR / SCR Phase Control 520/85 18000 1051 0.85 0.35 200 0.058
TT500N18KOF 1800 125 Power Block 60 mm SCR / SCR Phase Control 500/85 14500 1051 0.85 0.35 200 0.058
TT500N16KOF TIM 1600 125 Power Block 60 mm SCR / SCR Phase Control 500/85 14500 1051 0.85 0.35 200 0.058
TT500N16KOF 1600 125 Power Block 60 mm SCR / SCR Phase Control 500/85 14500 1051 0.85 0.35 200 0.058
TT500N14KOF 1400 125 Power Block 60 mm SCR / SCR Phase Control 500/85 14500 1051 0.85 0.35 200 0.058
TT500N12KOF 1200 125 Power Block 60 mm SCR / SCR Phase Control 500/85 14500 1051 0.85 0.35 200 0.058
TT570N16KOF 1600 125 Power Block 60 mm SCR / SCR Phase Control 570/87 14000 1531 0.8 0.23 200 0.058
TT425N18KOF 1800 125 Power Block 60 mm SCR / SCR Phase Control 425/85 12500 1051 0.9 0.35 120 0.065
TT425N16KOF 1600 125 Power Block 60 mm SCR / SCR Phase Control 425/85 12500 1051 0.9 0.35 120 0.065
TT425N14KOF 1400 125 Power Block 60 mm SCR / SCR Phase Control 425/85 12500 1051 0.9 0.35 120 0.065
TT425N12KOF 1200 125 Power Block 60 mm SCR / SCR Phase Control 425/85 12500 1051 0.9 0.35 120 0.065
TT430N22KOF 2200 125 Power Block 60 mm SCR / SCR Phase Control 430/85 12000 1051 0.95 0.45 150 0.065
TT400N26KOF 2600 125 Power Block 60 mm SCR / SCR Phase Control 400/85 11000 605 1 0.5 150 0.065
TT400N24KOF 2400 125 Power Block 60 mm SCR / SCR Phase Control 400/85 11000 605 1 0.5 150 0.065
TT310N26KOF 2600 125 Power Block 60 mm SCR / SCR Phase Control 310/85 9000 405 1 0.86 120 0.078
117
Thyristor /
diode modules
Thyristor / diode modules
Product VDRM / VRRM
[V]
Tvj [°C] max Housing Configuration IFAVM/TC / ITAVM/
TC [A/°C] @180°
el sin
IFSM / ITSM
[A] @10ms,
Tvj max
∫I2dt [A2s · 103]
@10ms,
Tvj max
VT0 [V]
@Tvj max max
rT [m]
@Tvj max max
(diT/dt)cr [A/s]
@DIN IEC 747- 6
RthJC [K/W]
@180° el sin
max
Thyristor/Diode Modules - Baseplate = 34 mm - Pressure contact
TD162N16KOF 1600 125 Power Block 34 mm SCR / Diode Phase Control 162/85 4400 97 0.85 0.95 150 0.2
TD162N14KOF 1400 125 Power Block 34 mm SCR / Diode Phase Control 162/85 4400 97 0.85 0.95 150 0.2
TD162N12KOF 1200 125 Power Block 34 mm SCR / Diode Phase Control 162/85 4400 97 0.85 0.95 150 0.2
TD142N16KOF 1600 125 Power Block 34 mm SCR / Diode Phase Control 142/85 4100 84 0.9 1.1 150 0.22
TD180N16KOF 1600 130 Power Block 34 mm SCR / Diode Phase Control 180/85 4100 84 0.85 0.9 150 0.2
TD142N14KOF 1400 125 Power Block 34 mm SCR / Diode Phase Control 142/85 4100 84 0.9 1.1 150 0.22
Thyristor/Diode Modules - Baseplate = 20 mm - Solder bond
TD120N16SOF 1600 130 Eco Block 20 mm SCR / Diode Phase Control 119/85 1900 18.05 0.9 3.35 140 0.2
TD60N16SOF 1600 130 Eco Block 20 mm SCR / Diode Phase Control 55/85 1200 7.2 1 4.8 140 0.49
Thyristor/Diode Modules - Baseplate = 20 mm - Pressure contact
TD92N16KOF 1600 130 Power Block 20 mm SCR / Diode Phase Control 92/85 1800 16.2 0.85 2.15 150 0.37
TD104N14KOF 1400 140 Power Block 20 mm SCR / Diode Phase Control 104/85 1800 16.2 0.85 2.15 150 0.37
TD92N14KOF 1400 130 Power Block 20 mm SCR / Diode Phase Control 92/85 1800 16.2 0.85 2.15 150 0.37
TD104N12KOF 1200 140 Power Block 20 mm SCR / Diode Phase Control 104/85 1800 16.2 0.85 2.15 150 0.37
TD92N12KOF 1200 130 Power Block 20 mm SCR / Diode Phase Control 92/85 1800 16.2 0.85 2.15 150 0.37
TD61N16KOF 1600 125 Power Block 20 mm SCR / Diode Phase Control 60/85 1400 9.8 0.8 3.4 150 0.52
TD61N14KOF 1400 125 Power Block 20 mm SCR / Diode Phase Control 60/85 1400 9.8 0.8 3.4 150 0.52
TD61N12KOF 1200 125 Power Block 20 mm SCR / Diode Phase Control 60/85 1400 9.8 0.8 3.4 150 0.52
Thyristor Modules - Baseplate = 60 mm - Pressure contact
TT310N24KOF 2400 125 Power Block 60 mm SCR / SCR Phase Control 310/85 9000 405 1 0.86 120 0.078
TT310N22KOF 2200 125 Power Block 60 mm SCR / SCR Phase Control 310/85 9000 405 1 0.86 120 0.078
TT310N20KOF 2000 125 Power Block 60 mm SCR / SCR Phase Control 310/85 9000 405 1 0.86 120 0.078
TT240N38KOF 3800 125 Power Block 60 mm SCR / SCR Phase Control 240/85 5500 151 1.17 1.7 100 0.078
TT240N36KOF 3600 125 Power Block 60 mm SCR / SCR Phase Control 240/85 5500 151 1.17 1.7 100 0.078
TT240N34KOF 3400 125 Power Block 60 mm SCR / SCR Phase Control 240/85 5500 151 1.17 1.7 100 0.078
TT240N32KOF 3200 125 Power Block 60 mm SCR / SCR Phase Control 240/85 5500 151 1.17 1.7 100 0.078
TT240N28KOF 2800 125 Power Block 60 mm SCR / SCR Phase Control 240/85 5500 151 1.17 1.7 100 0.078
118
Thyristor /
diode modules
Product VDRM / VRRM
[V]
Tvj [°C] max Housing Configuration IFAVM/TC / ITAVM/
TC [A/°C] @180°
el sin
IFSM / ITSM
[A] @10ms,
Tvj max
∫I2dt [A2s · 103]
@10ms,
Tvj max
VT0 [V]
@Tvj max max
rT [m]
@Tvj max max
(diT/dt)cr [A/s]
@DIN IEC 747- 6
RthJC [K/W]
@180° el sin
max
Thyristor/Diode Modules - Baseplate = 34 mm - Solder bond
TD190N18SOF 1800 125 Eco Block 34 mm SCR / Diode Phase Control 160/85 5200 101.3 0.85 0.9 100 0.165
TD160N18SOF 1800 125 Eco Block 34 mm SCR / Diode Phase Control 160/85 5200 101.3 1.1 0.99 100 0.165
TD190N16SOF 1600 125 Eco Block 34 mm SCR / Diode Phase Control 190/85 5200 101.3 0.85 0.9 100 0.145
TD160N16SOF 1600 125 Eco Block 34 mm SCR / Diode Phase Control 160/85 5200 101.3 1.1 0.99 100 0.145
TD175N16SOF 1600 125 Eco Block 34 mm SCR / Diode Phase Control 175/85 5000 125 0.83 1.3 200 0.164
TD140N16SOF 1600 125 Eco Block 34 mm SCR / Diode Phase Control 140/85 4000 80 1 1.6 200 0.19
Thyristor/Diode Modules - Baseplate = 34 mm - Pressure contact
TD142N12KOF 1200 125 Power Block 34 mm SCR / Diode Phase Control 142/85 4100 84 0.9 1.1 150 0.22
TD140N22KOF 2200 125 Power Block 34 mm SCR / Diode Phase Control 140/85 3200 51.2 0.9 1.75 150 0.19
TD140N18KOF 1800 125 Power Block 34 mm SCR / Diode Phase Control 140/85 3200 51.2 0.9 1.75 150 0.19
TD122N24KOF 2400 125 Power Block 34 mm SCR / Diode Phase Control 122/85 2950 43.5 1 2.15 100 0.2
TD122N22KOF 2200 125 Power Block 34 mm SCR / Diode Phase Control 122/85 2950 43.5 1 2.15 100 0.2
Thyristor/Diode Modules - Baseplate = 50 mm - Pressure contact
TD270N16KOF 1600 125 Power Block 50 mm SCR / Diode Phase Control 270/85 9000 400 0.8 0.58 250 0.12
TD260N22KOF 2200 125 Power Block 50 mm SCR / Diode Phase Control 260/85 8000 320 0.85 0.64 250 0.12
TD251N18KOF 1800 125 Power Block 50 mm SCR / Diode Phase Control 250/85 8000 320 0.8 0.7 250 0.13
TD330N16KOF 1600 130 Power Block 50 mm SCR / Diode Phase Control 330/85 8000 500 0.8 0.5 250 0.112
TD330N16KOF TIM 1600 130 Power Block 50 mm SCR / Diode Phase Control 330/85 8000 500 0.8 0.5 250 0.112
TD285N16KOF 1600 130 Power Block 50 mm SCR / Diode Phase Control 285/92 8000 500 0.8 0.5 250 0.056
TD251N16KOF 1600 125 Power Block 50 mm SCR / Diode Phase Control 250/85 8000 320 0.8 0.7 250 0.13
TD251N14KOF 1400 125 Power Block 50 mm SCR / Diode Phase Control 250/85 8000 320 0.8 0.7 250 0.13
TD250N18/25KOF 1800 125 Power Block 50 mm SCR / Diode Phase Control 250/85 7000 320 0.8 0.7 150 0.13
TD250N18KOF 1800 125 Power Block 50 mm SCR / Diode Phase Control 250/85 7000 245 0.8 0.7 150 0.13
TD250N16KOF 1600 125 Power Block 50 mm SCR / Diode Phase Control 250/85 7000 245 0.8 0.7 150 0.13
TD250N16/25KOF 1600 125 Power Block 50 mm SCR / Diode Phase Control 250/85 7000 320 0.8 0.7 150 0.13
TD250N16KOF TIM 1600 125 Power Block 50 mm SCR / Diode Phase Control 250/85 7000 245 0.8 0.7 150 0.13
TD250N14KOF 1400 125 Power Block 50 mm SCR / Diode Phase Control 250/85 7000 245 0.8 0.7 150 0.13
119
Thyristor /
diode modules
Thyristor / diode modules
Product VDRM / VRRM
[V]
Tvj [°C] max Housing Configuration IFAVM/TC / ITAVM/
TC [A/°C] @180°
el sin
IFSM / ITSM
[A] @10ms,
Tvj max
∫I2dt [A2s · 103]
@10ms,
Tvj max
VT0 [V]
@Tvj max max
rT [m]
@Tvj max max
(diT/dt)cr [A/s]
@DIN IEC 747- 6
RthJC [K/W]
@180° el sin
max
Thyristor/Diode Modules - Baseplate = 50 mm - Solder solder
TD320N18SOF 1800 130 Eco Block 50 mm SCR / Diode Phase Control 320/85 9500 335 0.77 0.58 100 0.11
TD320N16SOF 1600 130 Eco Block 50 mm SCR / Diode Phase Control 320/85 9500 335 0.77 0.58 100 0.11
TD280N18SOF 1800 130 Eco Block 50 mm SCR / Diode Phase Control 160/85 9000 304.2 1.77 0.82 100 0.11
TD280N16SOF 1600 130 Eco Block 50 mm SCR / Diode Phase Control 280/85 9000 304 0.9 0.82 100 0.11
Thyristor/Diode Modules - Baseplate = 50 mm - Pressure contact
TD250N14/20KOF 1400 125 Power Block 50 mm SCR / Diode Phase Control 250/85 7000 320 0.8 0.7 150 0.13
TD250N12KOF 1200 125 Power Block 50 mm SCR / Diode Phase Control 250/85 7000 245 0.8 0.7 150 0.13
TD215N22KOF 2200 125 Power Block 50 mm SCR / Diode Phase Control 215/85 6300 198 0.95 0.92 100 0.13
TD210N18KOF 1800 125 Power Block 50 mm SCR / Diode Phase Control 210/85 5800 168 1 1 150 0.13
TD210N16KOF 1600 125 Power Block 50 mm SCR / Diode Phase Control 210/85 5800 168 1 1 150 0.13
TD210N14KOF 1400 125 Power Block 50 mm SCR / Diode Phase Control 210/85 5800 168 1 1 150 0.13
TD210N12KOF 1200 125 Power Block 50 mm SCR / Diode Phase Control 210/85 5800 168 1 1 150 0.13
TD170N16KOF 1600 125 Power Block 50 mm SCR / Diode Phase Control 170/85 4600 106 0.95 1 150 0.17
TD170N12KOF 1200 125 Power Block 50 mm SCR / Diode Phase Control 170/85 4600 106 0.95 1 150 0.17
TD150N26KOF 2600 125 Power Block 50 mm SCR / Diode Phase Control 150/85 4000 80 1.2 2.3 60 0.13
TD150N24KOF 2400 125 Power Block 50 mm SCR / Diode Phase Control 150/85 4000 80 1.2 2.3 60 0.13
Thyristor/Diode Modules - Baseplate = 60 mm - Pressure contact
TD600N16KOF 1600 125 Power Block 60 mm SCR / Diode Phase Control 600/85 21000 1531 0.8 0.23 200 0.058
TD600N16KOF TIM 1600 125 Power Block 60 mm SCR / Diode Phase Control 600/85 21000 1531 0.8 0.23 200 0.058
TD520N22KOF 2200 125 Power Block 60 mm SCR / Diode Phase Control 520/85 18000 1051 0.85 0.35 200 0.058
TD500N18KOF 1800 125 Power Block 60 mm SCR / Diode Phase Control 500/85 14500 1051 0.85 0.35 200 0.058
TD500N16KOF TIM 1600 125 Power Block 60 mm SCR / Diode Phase Control 500/85 14500 1051 0.85 0.35 200 0.058
TD500N16KOF 1600 125 Power Block 60 mm SCR / Diode Phase Control 500/85 14500 1051 0.85 0.35 200 0.058
TD500N12KOF 1200 125 Power Block 60 mm SCR / Diode Phase Control 500/85 14500 1051 0.85 0.35 200 0.058
TD570N16KOF 1600 125 Power Block 60 mm SCR / Diode Phase Control 570/87 14000 980 0.8 0.23 200 0.058
TD425N18KOF 1800 125 Power Block 60 mm SCR / Diode Phase Control 425/85 12500 781 0.9 0.35 120 0.065
TD425N16KOF 1600 125 Power Block 60 mm SCR / Diode Phase Control 425/85 12500 781 0.9 0.35 120 0.065
120
Thyristor /
diode modules
Product VDRM / VRRM
[V]
Tvj [°C] max Housing Configuration IFAVM/TC / ITAVM/
TC [A/°C] @180°
el sin
IFSM / ITSM
[A] @10ms,
Tvj max
∫I2dt [A2s · 103]
@10ms,
Tvj max
VT0 [V]
@Tvj max max
rT [m]
@Tvj max max
(diT/dt)cr [A/s]
@DIN IEC 747- 6
RthJC [K/W]
@180° el sin
max
Thyristor/Diode Modules - Baseplate = 60 mm - Pressure contact
TD430N22KOF TIM 2200 125 Power Block 60 mm SCR / Diode Phase Control 430/85 12000 720 0.95 0.45 150 0.65
TD430N22KOF 2200 125 Power Block 60 mm SCR / Diode Phase Control 430/85 12000 720 0.95 0.45 150 0.065
TD400N26KOF 2600 125 Power Block 60 mm SCR / Diode Phase Control 400/85 11000 605 1 0.5 150 0.065
TD310N26KOF 2600 125 Power Block 60 mm SCR / Diode Phase Control 310/85 9000 405 1 0.86 120 0.078
TD310N22KOF 2200 125 Power Block 60 mm SCR / Diode Phase Control 310/85 9000 405 1 0.86 120 0.078
TD310N20KOF 2000 125 Power Block 60 mm SCR / Diode Phase Control 310/85 9000 405 1 0.86 120 0.078
TD240N36KOF 3600 125 Power Block 60 mm SCR / Diode Phase Control 240/85 5500 151 1.17 1.7 100 0.078
TD240N32KOF 3200 125 Power Block 60 mm SCR / Diode Phase Control 240/85 5500 151 1.17 1.7 100 0.078
Single Thyristor Modules - Baseplate = 50 mm - Pressure contact
TZ500N18KOF 1800 125 Power Block 50 mm Single SCR Phase Control 500/85 14500 1051 0.9 0.27 200 0.065
TZ500N16KOF 1600 125 Power Block 50 mm Single SCR Phase Control 500/85 14500 1051 0.9 0.27 200 0.065
TZ500N14KOF 1400 125 Power Block 50 mm Single SCR Phase Control 500/85 14500 1051 0.9 0.27 200 0.065
TZ500N12KOF 1200 125 Power Block 50 mm Single SCR Phase Control 500/85 14500 1051 0.9 0.27 200 0.065
TZ600N14KOF 1600 125 Power Block 50 mm Single SCR Phase Control 600/85 14000 980 0.9 0.27 200 0.065
TZ600N16KOF 1600 125 Power Block 50 mm Single SCR Phase Control 600/85 14000 980 0.9 0.27 200 0.065
TZ600N12KOF 1200 125 Power Block 50 mm Single SCR Phase Control 600/85 14000 980 0.9 0.27 200 0.065
TZ425N18KOF 1800 125 Power Block 50 mm Single SCR Phase Control 425/85 12500 781 0.9 0.3 120 0.078
TZ425N16KOF 1600 125 Power Block 50 mm Single SCR Phase Control 425/85 12500 781 0.9 0.3 120 0.078
TZ425N14KOF 1400 125 Power Block 50 mm Single SCR Phase Control 425/85 12500 781 0.9 0.3 120 0.078
TZ425N12KOF 1200 125 Power Block 50 mm Single SCR Phase Control 425/85 12500 781 0.9 0.3 120 0.078
TZ430N22KOF 2200 125 Power Block 50 mm Single SCR Phase Control 430/85 12000 720 0.95 0.45 150 0.065
TZ430N20KOF 2000 125 Power Block 50 mm Single SCR Phase Control 430/85 12000 720 0.95 0.45 150 0.065
TZ400N26KOF 2600 125 Power Block 50 mm Single SCR Phase Control 400/85 11000 605 1 0.5 150 0.065
TZ400N24KOF 2400 125 Power Block 50 mm Single SCR Phase Control 400/85 11000 605 1 0.5 150 0.065
TZ400N20KOF 2000 125 Power Block 50 mm Single SCR Phase Control 400/85 11000 605 1 0.5 150 0.065
TZ310N26KOF 2600 125 Power Block 50 mm Single SCR Phase Control 310/85 8000 320 1 0.86 120 0.078
TZ310N24KOF 2400 125 Power Block 50 mm Single SCR Phase Control 310/85 8000 320 1 0.86 120 0.078
TZ310N22KOF 2200 125 Power Block 50 mm Single SCR Phase Control 310/85 8000 320 1 0.86 120 0.078
TZ310N20KOF 2000 125 Power Block 50 mm Single SCR Phase Control 310/85 8000 320 1 0.86 120 0.078
121
Thyristor /
diode modules
Thyristor / diode modules
Product VDRM / VRRM
[V]
Tvj [°C] max Housing Configuration IFAVM/TC / ITAVM/
TC [A/°C] @180°
el sin
IFSM / ITSM
[A] @10ms,
Tvj max
∫I2dt [A2s · 103]
@10ms,
Tvj max
VT0 [V]
@Tvj max max
rT [m]
@Tvj max max
(diT/dt)cr [A/s]
@DIN IEC 747- 6
RthJC [K/W]
@180° el sin
max
Diode/Thyristor Modules - Baseplate = 20 mm - Pressure contact
DT92N16KOF 1600 130 Power Block 20 mm Diode / SCR Phase Control 92/85 1800 16.2 0.85 2.15 150 0.37
DT61N16KOF 1600 125 Power Block 20 mm Diode / SCR Phase Control 60/85 1400 9.8 0.8 3.4 150 0.52
Single Thyristor Modules - Baseplate = 70 mm - Pressure contact
TZ860N16KOF TIM 1600 125 Power Block 70 mm Single SCR Phase Control 860/85 46000 8000 0.8 1.45 200 0.042
TZ860N16KOF 1600 125 Power Block 70 mm Single SCR Phase Control 860/85 46000 8000 0.8 0.145 200 0.042
TZ810N22KOF TIM 2200 125 Power Block 70 mm Single SCR Phase Control 819/85 35000 6125 0.82 0.17 200 0.42
TZ810N22KOF 2200 125 Power Block 70 mm Single SCR Phase Control 819/85 35000 6125 0.82 0.17 200 0.042
TZ800N18KOF TIM 1800 125 Power Block 70 mm Single SCR Phase Control 800/85 30000 4500 0.82 0.17 200 0.042
TZ800N18KOF 1800 125 Power Block 70 mm Single SCR Phase Control 800/85 30000 4500 0.82 0.17 200 0.042
TZ800N16KOF TIM 1600 125 Power Block 70 mm Single SCR Phase Control 800/85 30000 4500 0.82 0.17 200 0.042
TZ800N16KOF 1600 125 Power Block 70 mm Single SCR Phase Control 800/85 30000 4500 0.82 0.17 200 0.042
TZ800N14KOF 1400 125 Power Block 70 mm Single SCR Phase Control 800/85 30000 4500 0.82 0.17 200 0.042
TZ800N12KOF 1200 125 Power Block 70 mm Single SCR Phase Control 800/85 30000 4500 0.82 0.17 200 0.042
TZ740N22KOF 2200 125 Power Block 70 mm Single SCR Phase Control 740/85 26500 3500 0.82 0.17 200 0.042
TZ740N22KOF TIM 2200 125 Power Block 70 mm Single SCR Phase Control 819/85 30000 3500 0.82 0.17 200 0.042
TZ740N20KOF 2000 125 Power Block 70 mm Single SCR Phase Control 740/85 26500 3500 0.82 0.17 200 0.042
TZ630N28KOF 2800 125 Power Block 70 mm Single SCR Phase Control 630/85 23000 2650 0.95 0.37 150 0.042
TZ630N24KOF 2400 125 Power Block 70 mm Single SCR Phase Control 630/85 23000 2650 0.95 0.37 150 0.042
TZ630N22KOF 2200 125 Power Block 70 mm Single SCR Phase Control 630/85 23000 2650 0.95 0.37 150 0.042
TZ530N36KOF 3600 125 Power Block 70 mm Single SCR Phase Control 530/85 20000 2000 1.05 0.49 80 0.045
TZ530N32KOF 3200 125 Power Block 70 mm Single SCR Phase Control 530/85 20000 2000 1.05 0.49 80 0.045
Single Thyristor Modules - Baseplate = 50 mm - Pressure contact
TZ240N36KOF 3600 125 Power Block 50 mm Single SCR Phase Control 240/85 5500 151 1.17 1.7 100 0.078
TZ240N34KOF 3400 125 Power Block 50 mm Single SCR Phase Control 240/85 5500 151 1.17 1.7 100 0.078
TZ240N32KOF 3200 125 Power Block 50 mm Single SCR Phase Control 240/85 5500 151 1.17 1.7 100 0.078
TZ240N30KOF 3000 125 Power Block 50 mm Single SCR Phase Control 240/85 5500 151 1.17 1.7 100 0.078
TZ150N26KOF 2600 125 Power Block 50 mm Single SCR Phase Control 150/85 4000 101 1.2 2.3 60 0.13
122
Thyristor /
diode modules
Product VDRM / VRRM
[V]
Tvj [°C] max Housing Configuration IFAVM/TC / ITAVM/
TC [A/°C] @180°
el sin
IFSM / ITSM
[A] @10ms,
Tvj max
∫I2dt [A2s · 103]
@10ms,
Tvj max
VT0 [V]
@Tvj max max
rT [m]
@Tvj max max
(diT/dt)cr [A/s]
@DIN IEC 747- 6
RthJC [K/W]
@180° el sin
max
Diode/Thyristor Modules - Baseplate = 50 mm - Pressure contact
DT250N16KOF 1600 125 Power Block 50 mm Diode / SCR Phase Control 250/85 7000 245 0.8 0.7 150 0.13
DT170N20/14KOF 1400 125 Power Block 50 mm Diode / SCR Phase Control 170/85 4600 245 0.8 0.7 150 0.13
Diode/Thyristor Modules - Baseplate = 34 mm - Pressure contact
DT142N12KOF 1200 125 Power Block 34 mm Diode / SCR Phase Control 142/85 4100 84 0.9 1.1 150 0.22
Rectifier Diode Modules - Baseplate = 20 mm - Pressure contact
ND104N18K 1800 150 Power Block 20 mm Single Rectifier Diode 104/100 2500 31.25 0.7 2.1 - 0.39
DD104N18K 1800 150 Power Block 20 mm Rectifier Diode 104/100 2500 31.25 0.7 2.1 - 0.39
ND104N16K 1600 150 Power Block 20 mm Single Rectifier Diode 104/100 2500 31.25 0.7 2.1 - 0.39
DD104N16K 1600 150 Power Block 20 mm Rectifier Diode 104/100 2500 31.25 0.7 2.1 - 0.39
DD104N14K 1400 150 Power Block 20 mm Rectifier Diode 104/100 2500 31.25 0.7 2.1 - 0.39
ND104N12K 1200 150 Power Block 20 mm Single Rectifier Diode 104/100 2500 31.25 0.7 2.1 - 0.39
DD104N12K 1200 150 Power Block 20 mm Rectifier Diode 104/100 2500 31.25 0.7 2.1 - 0.39
DD89N18K 1800 150 Power Block 20 mm Rectifier Diode 89/100 2400 28.8 0.75 2.3 - 0.45
ND89N16K 1600 150 Power Block 20 mm Single Rectifier Diode 89/100 2400 28.8 0.75 2.3 - 0.45
DD89N16K 1600 150 Power Block 20 mm Rectifier Diode 89/100 2400 28.8 0.75 2.3 - 0.45
DD89N14K 1400 150 Power Block 20 mm Rectifier Diode 89/100 2400 28.8 0.75 2.3 - 0.45
ND89N12K 1200 150 Power Block 20 mm Single Rectifier Diode 89/100 2400 28.8 0.75 2.3 - 0.45
DD89N12K 1200 150 Power Block 20 mm Rectifier Diode 89/100 2400 28.8 0.75 2.3 - 0.45
DD98N25K 2500 150 Power Block 20 mm Rectifier Diode 98/100 2000 20 0.82 2 - 0.39
DD98N24K 2400 150 Power Block 20 mm Rectifier Diode 98/100 2000 20 0.82 2 - 0.39
DD98N22K 2200 150 Power Block 20 mm Rectifier Diode 98/100 2000 20 0.82 2 - 0.39
DD98N20K 2000 150 Power Block 20 mm Rectifier Diode 98/100 2000 20 0.82 2 - 0.39
DD81S14K 1400 150 Power Block 20 mm Fast Diodes 81/100 1900 18.1 1 1.7 - 0.47
DD82S10K 1000 150 Power Block 20 mm Fast Diodes 81/100 1900 18.1 1 1.7 - 0.47
DD61S14K 1400 150 Power Block 20 mm Fast Diodes 61/100 1600 12.8 1 2.2 - 0.61
DD46S12K 1200 125 Power Block 20 mm Fast Diodes 45/85 850 3.6 0.9 3.9 - 0.64
123
Thyristor /
diode modules
Thyristor / diode modules
Product VDRM / VRRM
[V]
Tvj [°C] max Housing Configuration IFAVM/TC / ITAVM/
TC [A/°C] @180°
el sin
IFSM / ITSM
[A] @10ms,
Tvj max
∫I2dt [A2s · 103]
@10ms,
Tvj max
VT0 [V]
@Tvj max max
rT [m]
@Tvj max max
(diT/dt)cr [A/s]
@DIN IEC 747- 6
RthJC [K/W]
@180° el sin
max
Rectifier Diode Modules - Baseplate = 34 mm - Solder bond
DD180N22S 2200 125 Eco Block 34 mm Rectifier Diode 192/85 5750 131.6 0.85 0.95 - 0.14
DD180N20S 2000 125 Eco Block 34 mm Rectifier Diode 192/85 5750 131.6 0.85 0.95 - 0.14
DD180N18S 1800 125 Eco Block 34 mm Rectifier Diode 192/85 5750 131.6 0.85 0.95 - 0.14
DD180N16S 1600 125 Eco Block 34 mm Rectifier Diode 192/85 5750 131.6 0.85 0.95 - 0.14
DD170N16S 1600 135 Eco Block 34 mm Rectifier Diode 165/85 5500 151.25 0.75 1.05 - 0.18
Rectifier Diode Modules - Baseplate = 34 mm - Pressure contact
DD171N18K 1800 150 Power Block 34 mm Rectifier Diode 170/100 5600 157 0.75 0.8 - 0.26
ND171N18K 1800 150 Power Block 34 mm Single Rectifier Diode 170/100 5600 157 0.75 0.8 - 0.26
DD171N16K 1600 150 Power Block 34 mm Rectifier Diode 170/100 5600 157 0.75 0.8 - 0.26
ND171N16K 1600 150 Power Block 34 mm Single Rectifier Diode 170/100 5600 157 0.75 0.8 - 0.26
DD171N14K 1400 150 Power Block 34 mm Rectifier Diode 170/100 5600 157 0.75 0.8 - 0.26
ND171N14K 1400 150 Power Block 34 mm Single Rectifier Diode 170/100 5600 157 0.75 0.8 - 0.26
DD171N12K 1200 150 Power Block 34 mm Rectifier Diode 170/100 5600 157 0.75 0.8 - 0.26
ND171N12K 1200 150 Power Block 34 mm Single Rectifier Diode 170/100 5600 157 0.75 0.8 - 0.26
DD160N22K 2200 150 Power Block 34 mm Rectifier Diode 160/100 4600 105.8 0.8 1 - 0.26
Rectifier Diode Modules - Baseplate = 20 mm - Solder solder
DD100N16S 1600 130 Eco Block 20 mm Rectifier Diode 134/85 2000 20 0.87 2.45 - 0.2
124
Thyristor /
diode modules
Product VDRM / VRRM
[V]
Tvj [°C] max Housing Configuration IFAVM/TC / ITAVM/
TC [A/°C] @180°
el sin
IFSM / ITSM
[A] @10ms,
Tvj max
∫I2dt [A2s · 103]
@10ms,
Tvj max
VT0 [V]
@Tvj max max
rT [m]
@Tvj max max
(diT/dt)cr [A/s]
@DIN IEC 747- 6
RthJC [K/W]
@180° el sin
max
Rectifier Diode Modules - Baseplate = 50 mm - Pressure contact
DZ600N18K 1800 150 Power Block 50 mm Single Rectifier Diode 600/100 19000 1805 0.75 0.22 - 0.078
DZ600N16K 1600 150 Power Block 50 mm Single Rectifier Diode 600/100 19000 1805 0.75 0.22 - 0.078
DZ600N14K 1400 150 Power Block 50 mm Single Rectifier Diode 600/100 19000 1805 0.75 0.22 - 0.078
DZ600N12K 1200 150 Power Block 50 mm Single Rectifier Diode 600/100 19000 1805 0.75 0.22 - 0.078
DZ540N26K 2600 150 Power Block 50 mm Single Rectifier Diode 540/100 14000 980 0.78 0.31 - 0.078
DZ540N22K 2200 150 Power Block 50 mm Single Rectifier Diode 540/100 14000 980 0.78 0.31 - 0.078
DZ540N20K 2000 150 Power Block 50 mm Single Rectifier Diode 540/100 14000 980 0.78 0.31 - 0.078
DD360N22K 2200 150 Power Block 50 mm Rectifier Diode 360/100 13000 550 0.75 0.4 - 0.125
DZ435N40K 4000 150 Power Block 50 mm Single Rectifier Diode 435/100 12000 720 0.84 0.6 - 0.078
DZ435N36K 3600 150 Power Block 50 mm Single Rectifier Diode 435/100 12000 720 0.84 0.6 - 0.078
DD380N16K 1600 150 Power Block 50 mm Rectifier Diode 380/100 11500 660 0.75 0.32 - 0.125
DD350N18K 1800 150 Power Block 50 mm Rectifier Diode 350/100 11000 605 0.75 0.4 - 0.13
ND350N16K 1600 150 Power Block 50 mm Single Rectifier Diode 350/100 11000 605 0.75 0.4 - 0.13
DD350N16K 1600 150 Power Block 50 mm Rectifier Diode 350/100 11000 605 0.75 0.4 - 0.13
DD350N14K 1400 150 Power Block 50 mm Rectifier Diode 350/100 11000 605 0.75 0.4 - 0.13
DD350N12K 1200 150 Power Block 50 mm Rectifier Diode 350/100 11000 605 0.75 0.4 - 0.13
ND350N12K 1200 150 Power Block 50 mm Single Rectifier Diode 350/100 11000 605 0.75 0.4 - 0.13
ND261N26K 2600 150 Power Block 50 mm Single Rectifier Diode 260/100 8300 344 0.7 0.68 - 0.17
ND261N22K 2200 150 Power Block 50 mm Single Rectifier Diode 260/100 8300 344 0.7 0.68 - 0.17
DD261N22K 2200 150 Power Block 50 mm Rectifier Diode 260/100 8300 344 0.7 0.68 - 0.17
ND261N20K 2000 150 Power Block 50 mm Single Rectifier Diode 260/100 8300 344 0.7 0.68 - 0.17
DD261N20K 2000 150 Power Block 50 mm Rectifier Diode 260/100 8300 344 0.7 0.68 - 0.17
DD260N18K 1800 150 Power Block 50 mm Rectifier Diode 260/100 8300 344 0.7 0.68 - 0.17
ND260N16K 1600 150 Power Block 50 mm Single Rectifier Diode 260/100 8300 344 0.7 0.68 - 0.17
DD260N16K 1600 150 Power Block 50 mm Rectifier Diode 260/100 8300 344 0.7 0.68 - 0.17
ND260N14K 1400 150 Power Block 50 mm Single Rectifier Diode 260/100 8300 344 0.7 0.68 - 0.17
DD260N14K 1400 150 Power Block 50 mm Rectifier Diode 260/100 8300 344 0.7 0.68 - 0.17
ND260N12K 1200 150 Power Block 50 mm Single Rectifier Diode 260/100 8300 344 0.7 0.68 - 0.17
125
Thyristor /
diode modules
Thyristor / diode modules
Product VDRM / VRRM
[V]
Tvj [°C] max Housing Configuration IFAVM/TC / ITAVM/
TC [A/°C] @180°
el sin
IFSM / ITSM
[A] @10ms,
Tvj max
∫I2dt [A2s · 103]
@10ms,
Tvj max
VT0 [V]
@Tvj max max
rT [m]
@Tvj max max
(diT/dt)cr [A/s]
@DIN IEC 747- 6
RthJC [K/W]
@180° el sin
max
Rectifier Diode Modules - Baseplate = 50 mm - Solder bond
DD340N22S 2200 130 Eco Block 50 mm Rectifier Diode 330/100 10000 385 0.81 0.3 - 0.086
DD340N20S 2000 130 Eco Block 50 mm Rectifier Diode 330/100 10000 385 0.81 0.3 - 0.086
DD340N18S 1800 130 Eco Block 50 mm Rectifier Diode 330/100 10000 385 0.81 0.3 - 0.086
DD340N16S 1600 130 Eco Block 50 mm Rectifier Diode 330/100 10000 385 0.81 0.3 - 0.086
Rectifier Diode Modules - Baseplate = 50 mm - Pressure contact
DD260N12K 1200 150 Power Block 50 mm Rectifier Diode 260/100 8300 344 0.7 0.68 - 0.17
DD285N04K 400 150 Power Block 50 mm Rectifier Diode 285/100 8300 344 0.75 0.4 - 0.17
DD285N02K 400 150 Power Block 50 mm Rectifier Diode 285/100 8300 344 0.75 0.4 - 0.17
DD230S26K 2600 150 Power Block 50 mm Fast Diodes 230/100 7500 281 1 0.8 - 0.15
DD241S14K 1400 150 Power Block 50 mm Fast Diodes 240/100 7500 281 1.1 0.5 - 0.15
DD242S10K 1400 150 Power Block 50 mm Fast Diodes 240/100 7500 281 1.1 0.5 - 0.15
ND242S10K 1000 150 Power Block 50 mm Fast Single Diode 240/100 7500 281 1.1 0.5 - 0.15
ND241S14K 1000 150 Power Block 50 mm Fast Single Diode 240/100 7500 281 1.1 0.5 - 0.15
DD231N26K 2600 150 Power Block 50 mm Rectifier Diode 231/100 6400 205 0.8 0.84 - 0.17
DD231N24K 2400 150 Power Block 50 mm Rectifier Diode 231/100 6400 205 0.8 0.84 - 0.17
DD231N22K 2200 150 Power Block 50 mm Rectifier Diode 231/100 6400 205 0.8 0.84 - 0.17
DD231N20K 2000 150 Power Block 50 mm Rectifier Diode 231/100 6400 205 0.8 0.84 - 0.17
DD175N34K 3400 150 Power Block 50 mm Rectifier Diode 175/100 4000 80 0.9 1.8 - 0.17
DD175N32K 3200 150 Power Block 50 mm Rectifier Diode 175/100 4000 80 0.9 1.8 - 0.17
DD175N30K 3000 150 Power Block 50 mm Rectifier Diode 175/100 4000 80 0.9 1.8 - 0.17
126
Thyristor /
diode modules
Product VDRM / VRRM
[V]
Tvj [°C] max Housing Configuration IFAVM/TC / ITAVM/
TC [A/°C] @180°
el sin
IFSM / ITSM
[A] @10ms,
Tvj max
∫I2dt [A2s · 103]
@10ms,
Tvj max
VT0 [V]
@Tvj max max
rT [m]
@Tvj max max
(diT/dt)cr [A/s]
@DIN IEC 747- 6
RthJC [K/W]
@180° el sin
max
Rectifier Diode Modules - Baseplate = 70 mm - Pressure contact
DZ1100N22K 2200 150 Power Block 70 mm Single Rectifier Diode 1100/100 48000 8000 0.75 0.073 - 0.048
DZ1070N22K 2200 150 Power Block 70 mm Single Rectifier Diode 1100/100 41000 6125 0.75 0.073 - 0.045
DZ1070N18K 1800 150 Power Block 70 mm Single Rectifier Diode 1100/100 41000 6125 0.75 0.073 - 0.045
DZ1070N28K 2800 160 Power Block 70 mm Single Rectifier Diode 1070/100 35000 6125 0.8 0.17 - 0.045
DZ1070N26K 2600 160 Power Block 70 mm Single Rectifier Diode 1070/100 35000 6125 0.8 0.17 - 0.045
DZ950N44K 4400 150 Power Block 70 mm Single Rectifier Diode 950/100 29000 4205 0.85 0.28 - 0.042
DZ950N36K 3600 150 Power Block 70 mm Single Rectifier Diode 950/100 29000 4205 0.85 0.28 - 0.042
Rectifier Diode Modules - Baseplate = 60 mm - Pressure contact
DD710N16K 1600 150 Power Block 60 mm Rectifier Diode 710/100 26000 2420 0.75 0.15 - 0.065
DD700N22K 2200 150 Power Block 60 mm Rectifier Diode 700/100 21000 1805 0.78 0.19 - 0.065
DD600N18K 1800 150 Power Block 60 mm Rectifier Diode 600/100 19000 1800 0.75 0.215 - 0.078
DD600N16K 1600 150 Power Block 60 mm Rectifier Diode 600/100 19000 1800 0.75 0.215 - 0.078
DD600N14K 1400 150 Power Block 60 mm Rectifier Diode 600/100 19000 1800 0.75 0.215 - 0.078
DD600N12K 1200 150 Power Block 60 mm Rectifier Diode 600/100 19000 1800 0.75 0.215 - 0.078
DD540N26K 2600 150 Power Block 60 mm Rectifier Diode 540/100 14000 980 0.78 0.31 - 0.078
DD540N22K 2200 150 Power Block 60 mm Rectifier Diode 540/100 14000 980 0.78 0.31 - 0.078
DD435N40K 4000 150 Power Block 60 mm Rectifier Diode 435/100 12000 720 0.84 0.6 - 0.078
DD435N36K 3600 150 Power Block 60 mm Rectifier Diode 435/100 12000 720 0.84 0.6 - 0.078
DD435N34K 3400 150 Power Block 60 mm Rectifier Diode 435/100 12000 720 0.84 0.6 - 0.078
DD435N28K 2800 150 Power Block 60 mm Rectifier Diode 435/100 12000 720 0.84 0.6 - 0.078
127
Thyristor /
diode modules
Bridge rectifier and AC-switches
Product VDRM/ VRRM (V)
[V]
IRMSM
[A]
I(FSM) max
[A]
Housing Configuration Dimensions length
[mm]
Dimensions width
[mm]
Diode Bridges
DDB6U205N16L 1600 205 1375 IsoPACK™ Diode Bridges 94 42
DDB6U215N16L 1600 215 1850 IsoPACK™ Diode Bridges 94 54
DDB6U144N16R 1600 144 1000 EconoBRIDGE™ Diode Bridges 107.5 45
DDB6U145N16L 1600 145 1000 IsoPACK™ Diode Bridges 94 42
DDB6U85N16L 1600 85 550 IsoPACK™ Diode Bridges 94 42
Half Controlled Bridges
TDB6HK95N16LOF 1600 95 620 IsoPACK™ Half Controlled Bridges 94 54
Fully Controlled Bridges
TTB6C165N16LOF 1600 165 1050 IsoPACK™ Fully Controlled Bridges 94 54
TTB6C135N16LOF 1600 135 870 IsoPACK™ Fully Controlled Bridges 94 54
Fully Controlled AC-Switches
TTW3C85N16LOF 1600 85 620 IsoPACK™ Fully Controlled AC-Switches 94 54
Diode Bridges with Brake Chopper, NTC and pre-applied Thermal Interface Material
DDB6U104N16RRP_B37 1600 104 550 EconoBRIDGE™ Diode Bridges with Brake Chopper and NTC 107.5 45
Diode Bridges with Brake Chopper and pre-applied Thermal Interface Material
DDB6U180N16RRP_B37 1600 180 1600 EconoBRIDGE™ Diode Bridges with Brake Chopper 107.5 45
Diode Bridges with Brake Chopper and NTC
DDB6U134N16RR_B11 1600 134 550 EconoBRIDGE™ Diode Bridges with Brake Chooper and NTC 107.5 45
DDB6U104N16RR 1600 104 550 EconoBRIDGE™ Diode Bridges with Brake Chopper and NTC 107.5 45
DDB6U75N16W1R 1600 75 605 EasyBRIDGE 1 Diode Bridges with Brake Chopper and NTC 62.8 33.8
DDB6U75N16W1R_B11 1600 75 605 EasyBRIDGE 1 Diode Bridges with Brake Chopper and NTC 62.8 33.8
DDB6U134N16RR 1600 134 550 EconoBRIDGE™ Diode Bridges with Brake Chopper and NTC 107.5 45
Diode Bridges with Brake Chopper
DDB6U180N16RR_B37 1600 180 1600 EconoBRIDGE™ Diode Bridges with Brake Chopper 107.5 45
DDB6U180N16RR_B11 1600 180 1600 EconoBRIDGE™ Diode Bridges with Brake Chopper 107.5 45
128
Thyristor /
diode modules
mm W — — —————
Product VDRM/ VRRM (V)
[V]
IRMSM
[A]
I(FSM) max
[A]
Housing Configuration Dimensions length
[mm]
Dimensions width
[mm]
Half Controlled Bridges with NTC
TDB6HK240N16P 1600 240 1800 EconoBRIDGE™ Half Controlled Bridges with NTC 130 70.6
TDB6HK360N16P 1600 360 2300 EconoBRIDGE™ Half Controlled Bridges with NTC 130 70.6
Half Controlled Bridges with Brake Chopper
TDB6HK180N16RR_B11 1600 180 1400 EconoBRIDGE™ Half Controlled Bridges with Brake Chopper 107.5 45
TDB6HK180N16RR 1600 180 1400 EconoBRIDGE™ Half Controlled Bridges with Brake Chopper 107.5 45
Half Controlled Bridges with Brake Chopper and NTC
TDB6HK124N16RR 1600 124 550 EconoBRIDGE™ Half Controlled Bridges with Brake Chopper and NTC 107.5 45
Accessories
Gate leads
Product Product Group Type Terminal# Terminal descr.
GATELEAD PB20 G1K1 Gateleads for Modules PB20 5/4 G1/K1
GATELEAD PB20 G2K2 Gateleads for Modules PB20 6/7 G2/K2
GATELEAD PB34-60 G1K1 Gateleads for Modules PB34, PB50, PB50 (Single), PB60 5/4 G1/K1, G2/K2, G1/K1
GATELEAD PB34-70 G2K2 Gateleads for Modules PB34, PB50, PB70 (Single), PB60 6/7, 5/4, 6/7 G2/K2
129
Thyristor /
diode modules
130
Our solid-state relay range consists of HEXFET® power MOSFET and IGBT output
photovoltaic relays plus photovoltaic isolators that give designers the flexibility to
create their own relays.
Photovoltaic isolators offer single- and dual-channel, optically isolated outputs that can
be used for directly driving the gates of discrete power MOSFETs and/or IGBTs. This range
of devices gives designers the flexibility to create custom solid-state relays capable of
controlling loads in excess of 1000 V and 100 A.
www.infineon.com/photovoltaic-isolators
The operating parameters of photovoltaic relays are ideal for switching low-level signal
loads in instrumentation and data acquisition to medium power loads in industrial
controls and process automation, i.e. from microvolts and microamps to 400 V (AC peak
or DC) and up to 6.0 A of load current at a contact resistance as low as 15 milliohms.
www.infineon.com/photovoltaic-relays
Solid state relays
Photovoltaic isolators & relays
131
Solid State
Relay
Photovoltaic Isolators
Product Type Package name Isolation Voltage
[Vrms]
Control Current nominal
min [mA]
Short Circuit Current
min [A]
Output Voltage
[V]
Outputs
Technology
PVI5033RS 2 Form A SMT8 3750 10 5 5 2 MER
PVI5013RS 2 Form A SMT8 3750 5 5 5 2 MER
PVI1050NS 2 Form A SMT8 2500 10 1 5 2 MER
PVI5033R 2 Form A DIP8 3750 5 5 5 2 MER
PVI5013R 2 Form A DIP8 3750 5 1 5 2 MER
PVI1050N 2 Form A DIP8 2500 10 5 5 - MER
PVI5080NS 1 Form A SMT8 4000 10 8 5 1 MER
PVI5080N 1 Form A DIP8 4000 10 8 5 1 MER
PVI5050N 1 Form A DIP8 4000 10 5 5 2 MER
PVI5050NS 1 Form A SMT8 4000 10 8 5 1 MER
132
Solid State
Relay
Photovoltaic Relays
Product Type Package name Isolation
Voltage
[Vrms]
Control Current
nominal min
[mA]
Load Current AC
[mA]
Load Current
DC
[mA]
Load Voltage AC
V(peak) max
[V]
Load Voltage DC
max
[V]
Response Time
On max
[s]
Response Time
Off max
[s]
Thermal Offset
[V]
Technology
20 V
PVN012 1 Form A DIP6 4000 5 2500 4500 20 20 5000 500 - MER
PVN012A 1 Form A DIP6 4000 10 4000 6000 20 20 3000 500 - MER
PVN012AS 1 Form A SMT6 4000 10 4000 6000 20 20 3000 500 - MER
PVN012S 1 Form A SMT6 4000 5 2500 4500 20 20 5000 500 - MER
PVN013 1 Form A DIP6 4000 5 2500 4500 20 20 5000 500 - MER
PVN013S 1 Form A SMT6 4000 5 2500 4500 20 20 5000 500 - MER
60 V
PVAZ172N 1 Form A DIP8 4000 10 1000 1000 60 60 2000 500 - MER
PVAZ172NS 1 Form A SMT8 4000 10 1000 1000 60 60 2000 500 - MER
PVDZ172N 1 Form A DIP8 4000 10 - 1500 - 60 2000 500 - MER
PVDZ172NS 1 Form A SMT8 4000 10 - 1500 - 60 2000 500 - MER
PVG612 1 Form A DIP6 4000 10 1000 2000 60 60 2000 500 - MER
PVG612S 1 Form A SMT6 4000 10 1000 2000 60 60 2000 500 - MER
PVG612A 1 Form A DIP6 4000 10 2000 4000 60 60 3500 500 - MER
PVG612AS 1 Form A SMT6 4000 10 2000 4000 60 60 3500 500 - MER
PVG613 1 Form A DIP6 4000 10 1000 2000 60 60 2000 500 0.2 MER
PVG613S 1 Form A SMT6 4000 10 1000 2000 60 60 2000 500 - MER
133
Solid State
Relay
Photovoltaic Relays
Product Type Package name Isolation
Voltage
[Vrms]
Control Current
nominal min
[mA]
Load Current AC
[mA]
Load Current
DC
[mA]
Load Voltage AC
V(peak) max
[V]
Load Voltage DC
max
[V]
Response Time
On max
[s]
Response Time
Off max
[s]
Thermal Offset
[V]
Technology
100 V - 150 V
PVA1352N 1 Form A DIP8 4000 5 375 375 100 100 150 125 0.2 MER
PVA1352NS 1 Form A SMT8 4000 5 375 375 100 100 150 125 0.2 MER
PVA1354N 1 Form A DIP8 4000 5 375 375 100 100 150 125 0.2 MER
PVA1354NS 1 Form A SMT8 4000 5 375 375 100 100 150 125 0.2 MER
PVD1352N 1 Form A DIP8 4000 5 - 550 - 100 150 125 0.2 MER
PVD1352NS 1 Form A SMT8 4000 5 - 550 - 100 150 125 0.2 MER
PVD1354N 1 Form A DIP8 4000 5 - 550 - 100 150 125 0.2 MER
PVD1354NS 1 Form A SMT8 4000 5 - 550 - 100 150 125 0.2 MER
PVR1300N 2 Form A DIP16 1500 5 360 660 100 100 150 125 0.2 MER
PVR1301N 2 Form A DIP16 1500 5 360 660 100 100 150 125 0.2 MER
PVT212 1 Form A DIP6 4000 5 550 825 150 150 3000 500 - MER
PVT212S 1 Form A SMT6 4000 5 550 825 150 150 3000 500 - MER
200 V - 250 V
PVA2352N 1 Form A DIP8 4000 5 150 150 200 200 100 110 0.2 MER
PVA2352NS 1 Form A SMT8 4000 5 150 150 200 200 100 110 0.2 MER
PVT312 1 Form A DIP6 4000 5 190 320 250 250 3000 500 - MER
PVT312S 1 Form A SMT6 4000 5 190 320 250 250 3000 500 - MER
PVT312L 1 Form A DIP6 4000 5 170 300 250 250 3000 500 - MER
PVT312LS 1 Form A SMT6 4000 5 170 300 250 250 3000 500 - MER
PVT322 2 Form A DIP8 4000 5 170 170 250 250 3000 500 - MER
PVT322S 2 Form A SMT8 4000 5 170 170 250 250 3000 500 - MER
PVT322A 2 Form A DIP8 4000 5 170 170 250 250 3000 500 - MER
PVT322AS 2 Form A SMT8 4000 5 170 170 250 250 3000 500 - MER
134
Solid State
Relay
Product Type Package name Isolation
Voltage
[Vrms]
Control Current
nominal min
[mA]
Load Current AC
[mA]
Load Current
DC
[mA]
Load Voltage AC
V(peak) max
[V]
Load Voltage DC
max
[V]
Response Time
On max
[s]
Response Time
Off max
[s]
Thermal Offset
[V]
Technology
400 V
PVT412 1 Form A DIP6 4000 5 140 210 400 400 2000 500 0.5 MER
PVT412S 1 Form A SMT6 4000 5 140 210 400 400 2000 500 MER
PVT412A 1 Form A DIP6 4000 5 240 360 400 400 3000 500 0.5 MER
PVT412AS 1 Form A SMT6 4000 5 240 360 400 400 3000 500 0.5 MER
PVT412L 1 Form A DIP6 4000 5 120 200 400 400 2000 500 0.5 MER
PVT412LS 1 Form A SMT6 4000 5 120 200 400 400 2000 500 0.5 MER
PVT422 2 Form A DIP8 4000 5 120 120 400 400 2000 2000 - MER
PVT422S 2 Form A SMT8 4000 5 120 120 400 400 2000 2000 - MER
PVU414 1 Form A DIP6 4000 5 140 210 400 400 500 200 0.2 MER
PVU414S 1 Form A SMT6 4000 5 140 210 400 400 500 200 0.2 MER
PVX6012 1 Form A DIP14 3750 5 1000 1000 400 400 7000 1000 - MER
300 V
PVA3054N 1 Form A DIP8 4000 5 50 50 300 300 60 100 0.2 MER
PVA3054NS 1 Form A SMT8 4000 5 50 50 300 300 60 100 0.2 MER
PVA3055N 1 Form A DIP8 4000 5 50 50 300 300 60 100 0.2 MER
PVA3055NS 1 Form A SMT8 4000 5 50 50 300 300 60 100 0.2 MER
PVA3324N 1 Form A DIP8 4000 2 150 150 300 300 100 110 0.2 MER
PVA3324NS 1 Form A SMT8 4000 2 150 150 300 300 100 110 0.2 MER
PVA3354N 1 Form A DIP8 4000 5 150 150 300 300 100 110 0.2 MER
PVA3354NS 1 Form A SMT8 4000 5 150 150 300 300 100 110 0.2 MER
135
Solid State
Relay
Notes
136
137
138
Published by
Infineon Technologies AG
81726 Munich, Germany
© 2018 Infineon Technologies AG.
All rights reserved.
Order number: B133-H9881-V4-7600-EU-EC-P
Date: 05 / 2018
Please note!
THIS DOCUMENT IS FOR INFORMATION PURPOSES ONLY AND ANY INFORMATION GIVEN HEREIN
SHALL IN NO EVENT BE REGARDED AS A WARRANTY, GUARANTEE OR DESCRIPTION
OF ANY FUNCTIONALITY, CONDITIONS AND/OR QUALITY OF OUR PRODUCTS OR ANY
SUITABILITY FOR A PARTICULAR PURPOSE. WITH REGARD TO THE TECHNICAL SPECIFICATIONS
OF OUR PRODUCTS, WE KINDLY ASK YOU TO REFER TO THE RELEVANT PRODUCT DATA SHEETS
PROVIDED BY US. OUR CUSTOMERS AND THEIR TECHNICAL DEPARTMENTS ARE REQUIRED TO
EVALUATE THE SUITABILITY OF OUR PRODUCTS FOR THE INTENDED APPLICATION.
WE RESERVE THE RIGHT TO CHANGE THIS DOCUMENT AND/OR THE INFORMATION GIVEN HEREIN
AT ANY TIME.
Additional information
For further information on technologies, our products, the application of our products, delivery
terms and conditions and/or prices, please contact your nearest Infineon Technologies office
(www.infineon.com).
Warnings
Due to technical requirements, our products may contain dangerous substances. For information
on the types in question, please contact your nearest Infineon Technologies office.
Except as otherwise explicitly approved by us in a written document signed by authorized
representatives of Infineon Technologies, our products may not be used in any life- endangering
applications, including but not limited to medical, nuclear, military, life-critical or any other
applications where a failure of the product or any consequences of the use thereof can result
in personal injury.
Service hotline
Infineon offers its toll-free 0800/4001 service hotline as one central number,
available 24/7 in English, Mandarin and German.
› Germany .................... 0800 951 951 951 (German/English)
› China, mainland ....... 4001 200 951 (Mandarin/English)
› India .......................... 000 800 4402 951 (English)
› USA ............................ 1-866 951 9519 (English/German)
› Other countries ......... 00* 800 951 951 951 (English/German)
› Direct access ............. +49 89 234-0 (interconnection fee, German/English)
* Please note: Some countries may require you to dial a code other than “00” to access this international number.
Please visit www.infineon.com/service for your country!
Where to buy
Infineon distribution partners and sales offices:
www.infineon.com/WhereToBuy
www.infineon.com
