            0603 Fast Acting Automotive Grade Fuses – CC06FA Series
                    Eaton’s CC06FA series fuses with an AEC-Q200 qualified ceramic and glass construction are designed for automotive applications


Image of Eaton's 0603 Fast Action Automotive Grade Fuses – CC06FA Series Eaton’s CC06FA series fast acting automotive-grade fuses with an SMD 0603 package size have a compact design that optimizes board space layout and are compatible with reflow and wave soldering processes. They have performance characteristics such as rapid interruption of excessive current with high breaking capacity up to 63 V from a rugged AEC-Q200 qualified ceramic and glass construction, designed specifically for automotive applications.

Additional Resources:

Features

AEC-Q200 qualified
0603 (1608 metric) compact design utilizes less board space
Rapid interruption of excessive current
Compatible with reflow and wave solder
Rugged ceramic and glass construction
Excellent environmental integrity
One time positive disconnect
High breaking capacity up to 63 V

Applications

Automotive
- Battery management systems (BMS)
- Central body control modules
- Doors, window lifts, and seat controls
- Digital instrument clusters
- In-vehicle infotainment (IVI) and navigation
- Electric pumps, motor controls, and auxiliaries
- Powertrain control module (PCU)/engine control unit (ECU)
- Transmission control unit (TCU)

0603 Fast Action Automotive Grade Fuses – CC06FA Series

Manufacturer Part Number	Description	Available Quantity	Price	View Details
CC06FA1A-TR	FUSE BOARD MOUNT 1A 63VDC 0603	0 - Immediate	$0.32	View Details
CC06FA500MA-TR	FUSE BOARD MNT 500MA 63VDC 0603	11369 - Immediate	$0.30	View Details
CC06FA750MA-TR	FUSE BOARD MNT 750MA 63VDC 0603	5000 - Immediate	$0.31	View Details
