BC846S Dual NPN Transistor in SOT-363 Case Outline
Diotec's BC846S transistor is a space-saving solution in a SOT-363 case outline
The BC846S by Diotec Semiconductor offers the widely used industry standard BC846 parameters but comes as a dual transistor in the SOT-363 case outline. Both BJTs are NPN types and allow for a continuous collector current of 100 mA, a peak of 200 mA, and a maximum collector-emitter voltage of 45 V. DC current gain is typically 290, suitable for amplification of low input signals but also for various switching applications. Typical applications include control boards for consumer devices like vacuum cleaners, hair dryers, shavers, power tools, and LED lighting.
Features
- Dual transistor
- Board space savings
- Industry standard parameters
- For amplification and switching
Specifications
- Nominal 100 mA collector current (IC)
- Peak collector current 200 mA (ICM)
- Nominal 45 V collector-emitter voltage (VCEO)
- DC current gain typ 290 at 2 mA/5 V (hFE)
- Total power dissipation 150 mW at 25°C (Ptot)
- SOT-363 case outline
Applications
- LED lighting
- Consumer devices
- Vacuum cleaners
- Hair dryers and shavers
- Power tools
BC846S Dual NPN Transistor in SOT-363 Case Outline
| Image | Manufacturer Part Number | Description | Transistor Type | Current - Collector (Ic) (Max) | Voltage - Collector Emitter Breakdown (Max) | Available Quantity | Price | View Details | |
|---|---|---|---|---|---|---|---|---|---|
 |  | BC846S | TRANS 2NPN 65V 100MA SOT-363 | 2 NPN (Dual) | 100mA | 65V | 8903 - Immediate | $0.20 | View Details |
Published: 2023-12-20
