F ree Lu mm” rm; Cm summons Wmmmw :3' fre escale‘ ssmlcanduclor
1 Kinetis Portfolio
Kinetis is the most scalable portfolio of low power, mixed-
signal ARM®Cortex™-M4 MCUs in the industry. Phase 1 of
the portfolio consists of five MCU families with over 200 pin-,
peripheral- and software-compatible devices. Each family
offers excellent performance, memory and feature scalability
with common peripherals, memory maps, and packages
providing easy migration both within and between families.
Kinetis MCUs are built from Freescale’s innovative 90nm
Thin Film Storage (TFS) flash technology with unique
FlexMemory. Kinetis MCU families combine the latest low-
power innovations and high performance, high precision
mixed-signal capability with a broad range of connectivity,
human-machine interface, and safety & security peripherals.
Kinetis MCUs are supported by a market-leading enablement
bundle from Freescale and numerous ARM 3rd party
ecosystem partners.
Freescale Semiconductor Document Number: K50PB
Product Brief Rev. 8, 5/2011
K50 Family Product Brief
Supports all K50, K51, K52, and K53 devices
© 2010–2011 Freescale Semiconductor, Inc.
Contents
1 Kinetis Portfolio................................................................1
2 K50 Family Introduction...................................................3
3 K50 Block Diagram..........................................................3
4 Features.............................................................................5
5 Power modes...................................................................36
6 Developer Environment..................................................38
7 Revision History.............................................................43
muck .5» mun in 9% mm ”$88 :fi 3 WWW? W
K30 Family 64-512KB 64-144pin
K20 Family 32KB-1MB 32-144pin
K10 Family 32KB-1MB 32-144pin
K40 Family 64-512KB 64-144pin
Family Program
Flash Packages Key Features
Low power Mixed signal USB Segment LCD Ethernet
K50 Family 128-512KB 64-144pin
K60 Family 256KB-1MB 100-256pin
K70 Family 512KB-1MB 196-256pin
Encryption and Tamper Detect DDR
Operational &
transimpedance
amplifiers
Graphic LCD
Figure 1. Kinetis MCU portfolio
All Kinetis families include a powerful array of analog, communication and timing and control peripherals with the level of
feature integration increasing with flash memory size and the number of inputs/outputs. Features common to all Kinetis
families include:
•Core:
• ARM Cortex-M4 Core delivering 1.25 DMIPS/MHz with DSP instructions (floating-point unit available on
certain Kinetis families)
• Up to 32-channel DMA for peripheral and memory servicing with minimal CPU intervention
• Broad range of performance levels rated at maximum CPU frequencies of 50 MHz, 72 MHz, 100 MHz, 120
MHz, and 150 MHz
• Ultra-low power:
• 10 low power operating modes for optimizing peripheral activity and wake-up times for extended battery life.
• Low–leakage wake-up unit, low power timer, and low power RTC for additional low power flexibility
• Industry-leading fast wake-up times
• Memory:
• Scalable memory footprints from 32 KB flash / 8 KB RAM to 1 MB flash / 128 KB RAM. Independent flash
banks enable concurrent code execution and firmware updates
• Optional 16 KB cache memory for optimizing bus bandwidth and flash execution performance. Offered on K10,
K20, and K60 family devices with CPU performance of up to 150 MHz.
• FlexMemory with up to 512 KB FlexNVM and up to 16 KB FlexRAM. FlexNVM can be partitioned to support
additional program flash memory (ex. bootloader), data flash (ex. storage for large tables), or EEPROM backup.
FlexRAM supports EEPROM byte-write/byte-erase operations and dictates the maximum EEPROM size.
• EEPROM endurance capable of exceeding 10 million cycles
Kinetis Portfolio
K50 Family Product Brief, Rev. 8, 5/2011
2 Freescale Semiconductor, Inc.
• EEPROM erase/write times an order of magnitude faster than traditional EEPROM
• Multi-function external bus interface capable of interfacing to external memories, gate-array logic, or an LCD
• Mixed-signal analog:
• Fast, high precision 16-bit ADCs, 12-bit DACs, programmable gain amplifiers, high speed comparators and an
internal voltage reference. Powerful signal conditioning, conversion and analysis capability with reduced system
cost
• Human Machine Interface (HMI):
• Capacitive Touch Sensing Interface with full low-power support and minimal current adder when enabled
• Connectivity and Communications:
• UARTs with ISO7816 and IrDA support, I2S, CAN, I2C and DSPI
• USB OTG controller
• Reliability, Safety and Security:
• Hardware cyclic redundancy check engine for validating memory contents/communication data and increased
system reliability
• Independent-clocked COP for protection against code runaway in fail-safe applications
• External watchdog monitor
• Timing and Control:
• Powerful FlexTimers which support general purpose, PWM, and motor control functions
• Carrier Modulator Transmitter for IR waveform generation
• Programmable Interrupt Timer for RTOS task scheduler time base or trigger source for ADC conversion and
programmable delay block
• System:
• 5 V tolerant GPIO with pin interrupt functionality
• Wide operating voltage range from 1.71 V to 3.6 V with flash programmable down to 1.71 V with fully
functional flash and analog peripherals
• Ambient operating temperature ranges from -40 °C to 105 °C
2 K50 Family Introduction
The K50 MCU family includes a flexible, low-power segment LCD controller with support for up to 320 segments, analog
front end capability, and full-speed USB 2.0 On-The-Go with device charger detect capability. Devices start from 128 KB of
flash in 64QFN packages extending up to 512 KB in a 144MAPBGA package with a rich suite of analog, communication,
timing and control peripherals. High-memory desnsity K50 family devices include IEEE1588 Ethernet.
3 K50 Block Diagram
The below figure shows a superset block diagram of the K50 device. Other devices within the family have a subset of the
features.
K50 Family Introduction
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 3
mm B
Memories and Memory Interfaces
Program
flash
RAM
12-bit DAC
x2
6-bit DAC
x3
CRC
interface
touch-sensing
Programmable
Analog Timers Communication InterfacesSecurity
and Integrity
SPI
x3
Carrier
modulator
transmitter
FlexMemory
Clocks
Frequency-
Core
Debug
interfaces DSP
Interrupt
controller
comparator
x3
Analog
Voltage
reference
Secure
Digital
Low power
timer
Human-Machine
Interface (HMI)
GPIO
System
protection
Memory
DMA
Internal
watchdogs
and external
Low-leakage
wakeup
locked loop
Serial
programming
interface
Phase-
locked loop
reference
Internal
clocks
delay block
timers
interrupt
Periodic
External
bus
real-time
Independent
clock
oscillators
Low/high
frequency
UART
x6
Xtrinsic
®
Cortex™-M4ARM
Kinetis K50 Family
Migration difference from K60 family
LEGEND
USB charger
detect
USB voltage
regulator
USB OTG
LS/FS
USB LS/FS
transceiver
I S
2
Segment
LCD
Op-amp
Trans-
amplifier
impedance
x2
x2
x2
I C
2
Timers
x3 (12ch)
IEEE 1588
Timers
Ethernet
IEEE 1588
Hardware
encryption
number
Random
generator
PGA
x2
16-bit ADC
x2
Figure 2. K50 Block Diagram
K50 Block Diagram
K50 Family Product Brief, Rev. 8, 5/2011
4 Freescale Semiconductor, Inc.
Features
4.1 Common features among the K50 family
All devices within the K50 family features the following at a minimum:
Table 1. Common features among all K50 devices
Operating characteristics • Voltage range 1.71V - 3.6V
•Flash memory programming down to 1.71V
• Temperature range (TA) -40 to 85°C
• Flexible modes of operation
Core features • Next generation 32-bit ARM Cortex-M4 core
•Supports DSP instructions
• Nested vectored interrupt controller (NVIC)
• Asynchronous wake-up interrupt controller (AWIC)
• Debug & trace capability
• 2-pin serial wire debug (SWD)
• IEEE 1149.1 Joint Test Action Group (JTAG)
• IEEE 1149.7 compact JTAG (cJTAG)
• Trace port interface unit (TPIU)
• Flash patch and breakpoint (FPB)
• Data watchpoint and trace (DWT)
• Instrumentation trace macrocell (ITM)
System and power management • Software and hardware watchdog with external monitor
pin
•DMA controller
• Low-leakage wake-up unit (LLWU)
• Power management controller with 10 different power
modes
• Non-maskable interrupt (NMI)
• 128-bit unique identification (ID) number per chip
Clocks • Multi-purpose clock generator
•PLL and FLL operation
• Internal reference clocks
• 3MHz to 32MHz crystal oscillator
• 32kHz to 40kHz crystal oscillator
• Internal 1kHz low power oscillator
• DC to 50MHz external square wave input clock
Memories and Memory Interfaces • FlexMemory consisting of FlexNVM (non-volatile flash
memory that can execute program code, store data, or
backup EEPROM data) or FlexRAM (RAM memory
that can be used as traditional RAM or as high-
endurance EEPROM storage, and also accelerates
flash programming)
•Flash security and protection features
• Serial flash programming interface (EzPort)
Security and integrity • Cyclic redundancy check (CRC)
Table continues on the next page...
4
Features
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 5
r=uul
Table 1. Common features among all K50 devices (continued)
Analog • 16-bit SAR ADC
•Programmable voltage reference (VREF)
• 12-bit DAC
• High-speed Analog comparator (CMP) with 6-bit DAC
• General purpose op-amps
• Transimpedance amplifiers
Timers • 1x8ch motor control/general purpose/PWM flexible
timer (FTM)
•1x2ch quadrature decoder/general purpose/PWM
flexible timer (FTM)
• Carrier modulator timer (CMT)
• Programmable delay block (PDB)
• 1x4ch programmable interrupt timer (PIT)
• Low-power timer (LPT)
Communications • USB Full Speed/Low Speed OTG/Host/Device
•SPI
•I2C with SMBUS support
• UART (w/ ISO7816, IrDA and hardware flow control)
Human-machine interface • GPIO with pin interrupt support, DMA request
capability, digital glitch filter, and other pin control
options
•5V tolerant inputs
• Capacitive touch sensing inputs
4.1.1 Memory and package options
The following table summarizes the memory and package options for the K50 family. All devices which share a common
package are pin-for-pin compatible.
Table 2. K50 family summary
Sub-Family
Performance (MHz)
Memory Features Package
Flash
(KB)
FlexNVM (KB)
SRAM
(KB)
EEPROM/ FlexRAM
(KB)
LC
D
Ethernet
64 LQFN (9x9)
64 LQFP (10x10)
80 LQFP (12x12)
81 BGA (8x8)
100 LQFP (14x14)
104BGA (8x8)
121 BGA (8x8)
144 LQFP (20x20)
144 BGA (13x13)
K50N 100 512 — 128 — — — — — — — + — + + +
K50X 72 128 32 32 2 — — + + + + — — — — —
72 256 32 64 2 — — — — + + + + — — —
100 256 256 64 4 — — — — + + + — + — —
K51N 100 256 — 64 — + — — — — — — — — + +
100 512 — 128 — + — — — — — + — + + +
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
6 Freescale Semiconductor, Inc.
Table 2. K50 family summary (continued)
Sub-Family
Performance (MHz)
Memory Features Package
Flash
(KB)
FlexNVM (KB)
SRAM
(KB)
EEPROM/ FlexRAM
(KB)
LC
D
Ethernet
64 LQFN (9x9)
64 LQFP (10x10)
80 LQFP (12x12)
81 BGA (8x8)
100 LQFP (14x14)
104BGA (8x8)
121 BGA (8x8)
144 LQFP (20x20)
144 BGA (13x13)
K51X 72 128 32 32 2 + — + + + + — — — — —
72 256 32 64 2 + — — — + + + + — — —
100 256 256 64 4 + — — — + + + — + — —
K52N 100 512 — 128 — — + — — — — — — — + +
K53N 100 512 — 128 — + + — — — — — — — + +
K53X 100 256 256 128 4 + + — — — — — — — + +
4.2 FlexMemory
Freescale’s new FlexMemory technology provides an extremely versatile and powerful solution for designers seeking on-
chip EEPROM and/or additional program or data flash memory. As easy and as fast as SRAM, it requires no user or system
intervention to complete programming and erase functions when used as high endurance byte-write/byte-erase EEPROM.
EEPROM array size can also be configured for improved endurance to suit application requirements. FlexMemory can also
provide additional flash memory (FlexNVM) for data or program storage in parallel with the main program flash.
The key features of FlexMemory include:
• Configurability for designer:
• EEPROM array size and number of write/erase cycles
• Program or data flash size
• EEPROM endurance of 10M write/erase cycles possible over full voltage and temperature range
• Seamless EEPROM read/write operations: simply write or read a memory address
• High-speed byte, 16-bit, and 32-bit write/erase operations to EEPROM
• Eliminates the costs associated with external EEPROM ICs, and the software headaches and resource (CPU/flash/
RAM) impact of EEPROM emulation schemes
• Storage for large data tables or bootloader
• Read-while-write operation with main program flash memory
• Minimum write voltage 1.71V
4.2.1 Programmable Trade-Off
FlexMemory lets you fully configure the way FlexNVM and FlexRAM blocks are used to provide the best balance of
memory resources for their application.
The user can configure several parameters, including EEPROM size, endurance, write size, and the size of additional
program/data flash.
Features
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 7
rrrrr JJJJJLLLL
In addition to this flexibility, FlexMemory provides superior EEPROM performance, endurance, and low-voltage operation
when compared to traditional EEPROM solutions.
• Enhanced EEPROM — Combines FlexRAM and FlexNVM to create byte-write/erase, high-speed, and high-endurance
EEPROM
• FlexNVM — Can be used as:
• part of the EEPROM configuration,
• additional program or data flash, or
• a combination of the above. For example, a portion can be used as flash while the rest is used for enhanced
EEPROM backup.
• FlexRAM — Can be used as part of the EEPROM configuration or as additional system RAM
4.2.2 Use Case Example
The MCU has 128 KB program flash, 32 KB SRAM, and FlexMemory has 128 KB FlexNVM and 4 KB FlexRAM
(maximum EEPROM size). The application requires 8 KB additional program flash for a bootloader and 256 bytes of high-
endurance EEPROM. The user allocates 8 KB of FlexNVM for the additional program flash and the remaining 120 KB for
EEPROM backup.
The user defines 256 bytes of EEPROM size from the FlexRAM. In this example, the EEPROM endurance results in a
minimum of 2.32M write/erase cycles.
4.3 Part Numbers and Packaging
Q K## A M FFF T PP CC (N)
Qualification status
Family
Memory
Flash size
Temperature range (°C)
Speed (MHz)
Package identifier
Tape and Reel (T&R)
Key attribute
Figure 3. Part numbers diagrams
Field Description Values
Q Qualification status • M = Fully qualified, general market flow
•P = Prequalification
K## Kinetis family • K50
•K51
• K52
• K53
A Key attribute • D = Cortex-M4 w/ DSP
•F = Cortex-M4 w/ FPU
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
8 Freescale Semiconductor, Inc.
Field Description Values
M Flash memory type • N = Program flash only
•X = Program flash and FlexMemory
FFF Program flash memory size • 32 = 32 KB
•64 = 64 KB
• 128 = 128 KB
• 256 = 256 KB
• 512 = 512 KB
• 1M0 = 1 MB
T Temperature range (°C) • V = –40 to 105
•C = –40 to 85
PP Package identifier • FM = 32 QFN (5 mm x 5 mm)
•FT = 48 QFN (7 mm x 7 mm)
• LF = 48 LQFP (7 mm x 7 mm)
• EX = 64 QFN (9 mm x 9 mm)
• LH = 64 LQFP (10 mm x 10 mm)
• LK = 80 LQFP (12 mm x 12 mm)
• MB = 81 MAPBGA (8 mm x 8 mm)
• LL = 100 LQFP (14 mm x 14 mm)
• MC = 121 MAPBGA (8 mm x 8 mm)
• LQ = 144 LQFP (20 mm x 20 mm)
• MD = 144 MAPBGA (13 mm x 13 mm)
• MF = 196 MAPBGA (15 mm x 15 mm)
• MJ = 256 MAPBGA (17 mm x 17 mm)
CC Maximum CPU frequency (MHz) • 5 = 50 MHz
•7 = 72 MHz
• 10 = 100 MHz
• 12 = 120 MHz
• 15 = 150 MHz
N Packaging type • R = Tape and reel
•(Blank) = Trays
4.4 K50 family features
The following sections list the differences among the various devices available within the K50 family. The sections are split
by levels of performance.
The features listed below each part number specify the maximum configuration available on that device. The signal
multiplexing configuration determines which modules can be used simultaneously.
Features
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 9
r=uul
4.4.1 K50 family features (72MHz Performance) 1
Table 3. K50 72MHz Performance Table 1
MC Partnumber
MK50DX128CLH7(R)
MK50DX128CEX7(R)
MK50DX128CLK7(R)
MK50DX256CLK7(R)
MK50DX128CMB7(R)
MK50DX256CMB7(R)
MK50DX256CLL7(R)
MK50DX256CML7(R)
General
CPU Frequency 72 MHz 72 MHz 72 MHz 72 MHz 72 MHz 72 MHz 72 MHz 72 MHz
Pin Count 64 64 80 80 81 81 100 104
Package LQFP LQFN LQFP LQFP MAPBG
A
MAPBG
A
LQFP MAPBG
A
Memories and Memory Interfaces
Total Flash Memory 160KB 160KB 160KB 288KB 160KB 288KB 288KB 288KB
Flash 128KB 128KB 128KB 256KB 128KB 256KB 256KB 256KB
FlexNVM 32KB 32KB 32KB 32KB 32KB 32KB 32KB 32KB
EEPROM/FlexRAM 2KB 2KB 2KB 2KB 2KB 2KB 2KB 2KB
SRAM 32KB 32KB 32KB 64KB 32KB 64KB 64KB 64KB
Serial Programming Interface YES YES YES YES YES YES YES YES
External Bus Interface (FlexBus),
Addr/Data/CS
18/16/2 18/16/2 20/16/4 20/16/4 20/16/4 20/16/4 21/16/5 32/32/6
Non-Muxed External Bus Interface
(Flexbus), Addr/Data/CS
- - - - - - 21/8/5 30/16/6,
30/8/6
DDR Controller - - - - - - - -
NAND Flash Controller - - - - - - - -
Cache - - - - - - - -
Core Modules
DSP YES YES YES YES YES YES YES YES
SPFPU - - - - - - - -
Debug JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
Trace TPIU,
FPB,
DWT,
ITM
TPIU,
FPB,
DWT,
ITM
TPIU,
FPB,
DWT,
ITM
TPIU,
FPB,
DWT,
ITM
TPIU,
FPB,
DWT,
ITM
TPIU,
FPB,
DWT,
ITM
TPIU,
FPB,
DWT,
ITM
TPIU,
FPB,
DWT,
ITM
NMI YES YES YES YES YES YES YES YES
System Modules
Software Watchdog YES YES YES YES YES YES YES YES
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
10 Freescale Semiconductor, Inc.
Table 3. K50 72MHz Performance Table 1 (continued)
MC Partnumber
MK50DX128CLH7(R)
MK50DX128CEX7(R)
MK50DX128CLK7(R)
MK50DX256CLK7(R)
MK50DX128CMB7(R)
MK50DX256CMB7(R)
MK50DX256CLL7(R)
MK50DX256CML7(R)
Hardware Watchdog YES YES YES YES YES YES YES YES
PMC YES YES YES YES YES YES YES YES
MPU - - - - - - - -
DMA 16ch 16ch 16ch 16ch 16ch 16ch 16ch 16ch
Clock Modules
MCG YES YES YES YES YES YES YES YES
OSC (32-40kHz/3-32MHz) YES YES YES YES YES YES YES YES
RTC (32KHz Osc, Vbat) YES YES YES YES YES YES YES YES
Security and Integrity
Hardware Encryption - - - - - - - -
Tamper Detect - - - - - - - -
CRC YES YES YES YES YES YES YES YES
Analog
ADC0 (SE:single-ended,
DP:differential pair)
15ch SE
+ 1ch DP
15ch SE
+ 1ch DP
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
ADC1 12ch SE
+ 2ch DP
12ch SE
+ 2ch DP
16ch SE
+ 3ch DP
16ch SE
+ 3ch DP
16ch SE
+ 3ch DP
16ch SE
+ 3ch DP
18ch SE
+ 3ch DP
20ch SE
+ 3ch DP
ADC2 - - - - - - - -
ADC3 - - - - - - - -
ADC DP 2ch 2ch 4ch 4ch 4ch 4ch 4ch 4ch
ADC SE 20ch 20ch 23ch 23ch 23ch 23ch 23ch 25ch
PGA 1 1 2 2 2 2 2 2
12-bit DAC 1 1 1 1 1 1 1 1
Analog Comparator 2 2 3 3 3 3 3 3
Analog Comparator Inputs 6 / 4 / 1 /
0
6 / 4 / 1 /
0
6 / 5 / 3 /
0
6 / 5 / 3 /
0
6 / 5 / 3 /
0
6 / 5 / 3 /
0
6 / 5 / 5 /
0
6 / 5 / 5 /
0
OPAMP 1 1 2 2 2 2 2 2
TRIAMP 1 1 1 1 1 1 1 1
Vref YES YES YES YES YES YES YES YES
Timers
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 11
r=uul
Table 3. K50 72MHz Performance Table 1 (continued)
MC Partnumber
MK50DX128CLH7(R)
MK50DX128CEX7(R)
MK50DX128CLK7(R)
MK50DX256CLK7(R)
MK50DX128CMB7(R)
MK50DX256CMB7(R)
MK50DX256CLL7(R)
MK50DX256CML7(R)
Motor Control/General purpose/
PWM
1x8ch 1x8ch 1x8ch 1x8ch 1x8ch 1x8ch 1x8ch 1x8ch
Quad decoder/General purpose/
PWM
2x2ch 2x2ch 2x2ch 2x2ch 2x2ch 2x2ch 2x2ch 2x2ch
FTM External CLK 2 2 2 2 2 2 2 2
Low Power Timer 1 1 1 1 1 1 1 1
PIT 1x4ch 1x4ch 1x4ch 1x4ch 1x4ch 1x4ch 1x4ch 1x4ch
PDB 1 1 1 1 1 1 1 1
CMT(Carrier Module Transmitter) YES YES YES YES YES YES YES YES
Communication Interfaces
SDHC - - - - - - - -
High Baudrate UART w/ ISO7816 1 1 1 1 1 1 1 1
High Baudrate UART 1 1 1 1 1 1 1 1
UART 1 1 1 / 1 1 / 1 1 / 1 1 / 1 3 3
SPI chip selects per module 5 / 0 / 0 5 / 0 / 0 5 / 1 / 0 5 / 1 / 0 5 / 1 / 0 5 / 1 / 0 6 / 3 / 0 6 / 4 / 0
I2C 2 2 2 2 2 2 2 2
I2S 1 1 1 1 1 1 1 1
CAN - - - - - - - -
USB OTG LS/FS w/ on-chip xcvr 1 1 1 1 1 1 1 1
USB OTG HS - - - - - - - -
USB DCD YES YES YES YES YES YES YES YES
USB 120mAReg YES YES YES YES YES YES YES YES
Ethernet w /1588 - - - - - - - -
IEEE1588 Timer - - - - - - - -
Human-Machine Interface
Segment LCD - - - - - - - -
Graphic LCD - - - - - - - -
TSI(Capacitive Touch) 16 input 16 input 16 input 16 input 16 input 16 input 16 input 16 input
GPIO (w interrupt) 35 35 39 39 39 39 59 78
Operating Characteristics
5V Tolerant YES YES YES YES YES YES YES YES
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
12 Freescale Semiconductor, Inc.
Table 3. K50 72MHz Performance Table 1 (continued)
MC Partnumber
MK50DX128CLH7(R)
MK50DX128CEX7(R)
MK50DX128CLK7(R)
MK50DX256CLK7(R)
MK50DX128CMB7(R)
MK50DX256CMB7(R)
MK50DX256CLL7(R)
MK50DX256CML7(R)
Voltage Range 1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
Flash Write V 1.71 1.71 1.71 1.71 1.71 1.71 1.71 1.71
Temp Range -40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
4.4.2 K50 family features (72MHz Performance) 2
Table 4. K50 72MHz Performance Table 2
MC Partnumber
MK51DX128CLH7(R)
MK51DX128CEX7(R)
MK51DX128CLK7(R)
MK51DX256CLK7(R)
MK51DX128CMB7(R)
MK51DX256CMB7(R)
MK51DX256CLL7(R)
MK51DX256CML7(R)
General
CPU Frequency 72 MHz 72 MHz 72 MHz 72 MHz 72 MHz 72 MHz 72 MHz 72 MHz
Pin Count 64 64 80 80 81 81 100 104
Package LQFP LQFN LQFP LQFP MAPBG
A
MAPBG
A
LQFP MAPBG
A
Memories and Memory Interfaces
Total Flash Memory 160KB 160KB 160KB 288KB 160KB 288KB 288KB 288KB
Flash 128KB 128KB 128KB 256KB 128KB 256KB 256KB 256KB
FlexNVM 32KB 32KB 32KB 32KB 32KB 32KB 32KB 32KB
EEPROM/FlexRAM 2KB 2KB 2KB 2KB 2KB 2KB 2KB 2KB
SRAM 32KB 32KB 32KB 64KB 32KB 64KB 64KB 64KB
Serial Programming Interface YES YES YES YES YES YES YES YES
External Bus Interface (FlexBus),
Addr/Data/CS
- - - - - - - -
Non-Muxed External Bus Interface
(Flexbus), Addr/Data/CS
- - - - - - - -
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 13
r=uul
Table 4. K50 72MHz Performance Table 2 (continued)
MC Partnumber
MK51DX128CLH7(R)
MK51DX128CEX7(R)
MK51DX128CLK7(R)
MK51DX256CLK7(R)
MK51DX128CMB7(R)
MK51DX256CMB7(R)
MK51DX256CLL7(R)
MK51DX256CML7(R)
DDR Controller - - - - - - - -
NAND Flash Controller - - - - - - - -
Cache - - - - - - - -
Core Modules
DSP YES YES YES YES YES YES YES YES
SPFPU - - - - - - - -
Debug JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
Trace TPIU,
FPB,
DWT,
ITM
TPIU,
FPB,
DWT,
ITM
TPIU,
FPB,
DWT,
ITM
TPIU,
FPB,
DWT,
ITM
TPIU,
FPB,
DWT,
ITM
TPIU,
FPB,
DWT,
ITM
TPIU,
FPB,
DWT,
ITM
TPIU,
FPB,
DWT,
ITM
NMI YES YES YES YES YES YES YES YES
System Modules
Software Watchdog YES YES YES YES YES YES YES YES
Hardware Watchdog YES YES YES YES YES YES YES YES
PMC YES YES YES YES YES YES YES YES
MPU - - - - - - - -
DMA 16ch 16ch 16ch 16ch 16ch 16ch 16ch 16ch
Clock Modules
MCG YES YES YES YES YES YES YES YES
OSC (32-40kHz/3-32MHz) YES YES YES YES YES YES YES YES
RTC (32KHz Osc, Vbat) YES YES YES YES YES YES YES YES
Security and Integrity
Hardware Encryption - - - - - - - -
Tamper Detect - - - - - - - -
CRC YES YES YES YES YES YES YES YES
Analog
ADC0 (SE:single-ended,
DP:differential pair)
15ch SE
+ 1ch DP
15ch SE
+ 1ch DP
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
14 Freescale Semiconductor, Inc.
Table 4. K50 72MHz Performance Table 2 (continued)
MC Partnumber
MK51DX128CLH7(R)
MK51DX128CEX7(R)
MK51DX128CLK7(R)
MK51DX256CLK7(R)
MK51DX128CMB7(R)
MK51DX256CMB7(R)
MK51DX256CLL7(R)
MK51DX256CML7(R)
ADC1 8ch SE +
2ch DP
8ch SE +
2ch DP
16ch SE
+ 3ch DP
16ch SE
+ 3ch DP
16ch SE
+ 3ch DP
16ch SE
+ 3ch DP
19ch SE
+ 3ch DP
20ch SE
+ 3ch DP
ADC2 - - - - - - - -
ADC3 - - - - - - - -
ADC DP 2ch 2ch 4ch 4ch 4ch 4ch 4ch 4ch
ADC SE 16ch 16ch 23ch 23ch 23ch 23ch 24ch 25ch
PGA 1 1 2 2 2 2 2 2
12-bit DAC 1 1 1 1 1 1 1 1
Analog Comparator 2 2 3 3 3 3 3 3
Analog Comparator Inputs 3 / 4 / 1 /
0
3 / 4 / 1 /
0
6 / 5 / 3 /
0
6 / 5 / 3 /
0
6 / 5 / 3 /
0
6 / 5 / 3 /
0
6 / 5 / 5 /
0
6 / 5 / 5 /
0
OPAMP 1 1 2 2 2 2 2 2
TRIAMP 1 1 1 1 1 1 1 1
Vref YES YES YES YES YES YES YES YES
Timers
Motor Control/General purpose/
PWM
1x8ch 1x8ch 1x8ch 1x8ch 1x8ch 1x8ch 1x8ch 1x8ch
Quad decoder/General purpose/
PWM
2x2ch 2x2ch 2x2ch 2x2ch 2x2ch 2x2ch 2x2ch 2x2ch
FTM External CLK 2 2 2 2 2 2 2 2
Low Power Timer 1 1 1 1 1 1 1 1
PIT 1x4ch 1x4ch 1x4ch 1x4ch 1x4ch 1x4ch 1x4ch 1x4ch
PDB 1 1 1 1 1 1 1 1
CMT(Carrier Module Transmitter) YES YES YES YES YES YES YES YES
Communication Interfaces
SDHC - - - - - - - -
High Baudrate UART w/ ISO7816 1 1 1 1 1 1 1 1
High Baudrate UART 1 1 1 1 1 1 1 1
UART 1 1 2 2 2 2 2 3
SPI chip selects per module 5 / 0 / 0 5 / 0 / 0 5 / 2 / 0 5 / 2 / 0 5 / 2 / 0 5 / 2 / 0 6 / 3 / 0 6 / 4 / 0
I2C 1 1 2 2 2 2 2 2
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 15
r=uul
Table 4. K50 72MHz Performance Table 2 (continued)
MC Partnumber
MK51DX128CLH7(R)
MK51DX128CEX7(R)
MK51DX128CLK7(R)
MK51DX256CLK7(R)
MK51DX128CMB7(R)
MK51DX256CMB7(R)
MK51DX256CLL7(R)
MK51DX256CML7(R)
I2S 1 1 1 1 1 1 1 1
CAN - - - - - - - -
USB OTG LS/FS w/ on-chip xcvr 1 1 1 1 1 1 1 1
USB OTG HS - - - - - - - -
USB DCD YES YES YES YES YES YES YES YES
USB 120mAReg YES YES YES YES YES YES YES YES
Ethernet w /1588 - - - - - - - -
IEEE1588 Timer - - - - - - - -
Human-Machine Interface
Segment LCD 16x8/20x
4
16x8/20x
4
24x8/28x
4
24x8/28x
4
24x8/28x
4
24x8/28x
4
32x8/36x
4
38x8/42x
4
Graphic LCD - - - - - - - -
TSI(Capacitive Touch) 16 input 16 input 16 input 16 input 16 input 16 input 16 input 16 input
GPIO (w interrupt) 31 31 39 39 39 39 57 78
Operating Characteristics
5V Tolerant YES YES YES YES YES YES YES YES
Voltage Range 1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
Flash Write V 1.71 1.71 1.71 1.71 1.71 1.71 1.71 1.71
Temp Range -40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
Features
K50 Family Product Brief, Rev. 8, 5/2011
16 Freescale Semiconductor, Inc.
4.4.3 K50 family features (100MHz Performance) 1
Table 5. K50 100MHz Performance Table 1
MC Partnumber
MK50DX256ZCLK10(R)
MK50DX256ZCMB10(R)
MK50DX256ZCLL10(R)
MK50DN512ZCLL10(R)
MK50DX256ZCMC10(R)
MK50DN512ZCMC10(R)
MK50DN512ZCLQ10(R)
MK50DN512ZCMD10(R)
General
CPU Frequency 100 MHz 100 MHz 100 MHz 100 MHz 100 MHz 100 MHz 100 MHz 100 MHz
Pin Count 80 81 100 100 121 121 144 144
Package LQFP MAPBG
A
LQFP LQFP MAPBG
A
MAPBG
A
LQFP MAPBG
A
Memories and Memory Interfaces
Total Flash Memory 512KB 512KB 512KB 512KB 512KB 512KB 512KB 512KB
Flash 256KB 256KB 256KB 512KB 256KB 512KB 512KB 512KB
FlexNVM 256KB 256KB 256KB - 256KB - - -
EEPROM/FlexRAM 4KB 4KB 4KB - 4KB - - -
SRAM 64KB 64KB 64KB 128KB 64KB 128KB 128KB 128KB
Serial Programming Interface YES YES YES YES YES YES YES YES
External Bus Interface (FlexBus),
Addr/Data/CS
20/16/4 20/16/5 21/16/5 21/16/5 32/32/6 32/32/6 32/32/6 32/32/6
Non-Muxed External Bus Interface
(Flexbus), Addr/Data/CS
- - 21/8/5 21/8/5 30/16/6,
30/8/6
30/16/6,
30/8/6
30/16/6,
30/8/6
30/16/6,
30/8/6
DDR Controller - - - - - - - -
NAND Flash Controller - - - - - - - -
Cache - - - - - - - -
Core Modules
DSP YES YES YES YES YES YES YES YES
SPFPU - - - - - - - -
Debug JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
JTAG,
cJTAG,
SWD
Trace TPIU,
FPB,
DWT,
ITM,
ETM,
ETB
TPIU,
FPB,
DWT,
ITM,
ETM,
ETB
TPIU,
FPB,
DWT,
ITM,
ETM,
ETB
TPIU,
FPB,
DWT,
ITM,
ETM,
ETB
TPIU,
FPB,
DWT,
ITM,
ETM,
ETB
TPIU,
FPB,
DWT,
ITM,
ETM,
ETB
TPIU,
FPB,
DWT,
ITM,
ETM,
ETB
TPIU,
FPB,
DWT,
ITM,
ETM,
ETB
NMI YES YES YES YES YES YES YES YES
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 17
r=uul
Table 5. K50 100MHz Performance Table 1 (continued)
MC Partnumber
MK50DX256ZCLK10(R)
MK50DX256ZCMB10(R)
MK50DX256ZCLL10(R)
MK50DN512ZCLL10(R)
MK50DX256ZCMC10(R)
MK50DN512ZCMC10(R)
MK50DN512ZCLQ10(R)
MK50DN512ZCMD10(R)
System Modules
Software Watchdog YES YES YES YES YES YES YES YES
Hardware Watchdog YES YES YES YES YES YES YES YES
PMC YES YES YES YES YES YES YES YES
MPU YES YES YES YES YES YES YES YES
DMA 16ch 16ch 16ch 16ch 16ch 16ch 16ch 16ch
Clock Modules
MCG YES YES YES YES YES YES YES YES
OSC (32-40kHz/3-32MHz) YES YES YES YES YES YES YES YES
RTC (32KHz Osc, Vbat) YES YES YES YES YES YES YES YES
Security and Integrity
Hardware Encryption - - - - - - - -
Tamper Detect - - - - - - - -
CRC YES YES YES YES YES YES YES YES
Analog
ADC0 (SE:single-ended,
DP:differential pair)
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
19ch SE
+ 3ch DP
21ch SE
+ 3ch DP
21ch SE
+ 3ch DP
ADC1 16ch SE
+ 3ch DP
16ch SE
+ 3ch DP
18ch SE
+ 3ch DP
18ch SE
+ 3ch DP
20ch SE
+ 3ch DP
20ch SE
+ 3ch DP
22ch SE
+ 3ch DP
22ch SE
+ 3ch DP
ADC2 - - - - - - - -
ADC3 - - - - - - - -
ADC DP 4ch 4ch 4ch 4ch 4ch 4ch 4ch 4ch
ADC SE 23ch 18ch 18ch 18ch 20ch 20ch 25ch 25ch
PGA 2 2 2 2 2 2 2 2
12-bit DAC 2 2 2 2 2 2 2 2
Analog Comparator 3 3 3 3 3 3 3 3
Analog Comparator Inputs 6 / 5 / 3 /
0
6 / 5 / 3 /
0
6 / 5 / 5 /
0
6 / 5 / 5 /
0
6 / 5 / 5 /
0
6 / 5 / 5 /
0
6 / 5 / 5 /
0
6 / 5 / 5 /
0
OPAMP 2 2 2 2 2 2 2 2
TRIAMP 2 2 2 2 2 2 2 2
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
18 Freescale Semiconductor, Inc.
Table 5. K50 100MHz Performance Table 1 (continued)
MC Partnumber
MK50DX256ZCLK10(R)
MK50DX256ZCMB10(R)
MK50DX256ZCLL10(R)
MK50DN512ZCLL10(R)
MK50DX256ZCMC10(R)
MK50DN512ZCMC10(R)
MK50DN512ZCLQ10(R)
MK50DN512ZCMD10(R)
Vref YES YES YES YES YES YES YES YES
Timers
Motor Control/General purpose/
PWM
1x8ch 1x8ch 1x8ch 1x8ch 1x8ch 1x8ch 1x8ch 1x8ch
Quad decoder/General purpose/
PWM
2x2ch 2x2ch 2x2ch 2x2ch 2x2ch 2x2ch 2x2ch 2x2ch
FTM External CLK 2 2 2 2 2 2 2 2
Low Power Timer 1 1 1 1 1 1 1 1
PIT 1x4ch 1x4ch 1x4ch 1x4ch 1x4ch 1x4ch 1x4ch 1x4ch
PDB 1 1 1 1 1 1 1 1
CMT(Carrier Module Transmitter) YES YES YES YES YES YES YES YES
Communication Interfaces
SDHC - - 4-bit 4-bit 8-bit,
CLKIN
8-bit,
CLKIN
8-bit,
CLKIN
8-bit,
CLKIN
High Baudrate UART w/ ISO7816 1 1 1 1 1 1 1 1
High Baudrate UART 1 1 1 1 1 1 1 1
UART 1 / 1 1 / 1 3 3 4 4 4 4
SPI chip selects per module 5 / 1 / 0 5 / 1 / 0 6 / 3 / 1 6 / 3 / 1 6 / 4 / 2 6 / 4 / 2 6 / 4 / 2 6 / 4 / 2
I2C 2 2 2 2 2 2 2 2
I2S 1 1 1 1 1 1 1 1
CAN - - - - - - - -
USB OTG LS/FS w/ on-chip xcvr 1 1 1 1 1 1 1 1
USB OTG HS - - - - - - - -
USB DCD YES YES YES YES YES YES YES YES
USB 120mAReg YES YES YES YES YES YES YES YES
Ethernet w /1588 - - - - - - - -
IEEE1588 Timer - - - - - - - -
Human-Machine Interface
Segment LCD - - - - - - - -
Graphic LCD - - - - - - - -
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 19
r=uul
Table 5. K50 100MHz Performance Table 1 (continued)
MC Partnumber
MK50DX256ZCLK10(R)
MK50DX256ZCMB10(R)
MK50DX256ZCLL10(R)
MK50DN512ZCLL10(R)
MK50DX256ZCMC10(R)
MK50DN512ZCMC10(R)
MK50DN512ZCLQ10(R)
MK50DN512ZCMD10(R)
TSI(Capacitive Touch) 16 input 16 input 16 input 16 input 16 input 16 input 16 input 16 input
GPIO (w interrupt) 39 39 59 59 78 78 96 96
Operating Characteristics
5V Tolerant YES YES YES YES YES YES YES YES
Voltage Range 1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
1.71-3.6
V
Flash Write V 1.71 1.71 1.71 1.71 1.71 1.71 1.71 1.71
Temp Range -40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
-40 to
85C
4.4.4 K50 family features (100MHz Performance) 2
Table 6. K50 100MHz Performance Table 2
MC Partnumber
MK51DX256ZCLK10(R)
MK51DX256ZCMB10(R)
MK51DX256ZCLL10(R)
MK51DN512ZCLL10(R)
MK51DX256ZCMC10(R)
MK51DN512ZCMC10(R)
MK51DN256ZCLQ10(R)
MK51DN256ZCMD10(R)
MK51DN512ZCLQ10(R)
MK51DN512ZCMD10(R)
MK52DN512ZCLQ10(R)
MK52DN512ZCMD10(R)
MK53DN512ZCLQ10(R)
MK53DN512ZCMD10(R)
MK53DX256ZCLQ10(R)
MK53DX256ZCMD10(R)
General
CPU Frequency 100
MHz
100
MHz
100
MHz
100
MHz
100
MHz
100
MHz
100
MHz
100
MHz
100
MHz
100
MHz
100
MHz
100
MHz
100
MHz
100
MHz
100
MHz
100
MHz
Pin Count 80 81 100 100 121 121 144 144 144 144 144 144 144 144 144 144
Package LQF
P
MAP
BGA
LQF
P
LQF
P
MAP
BGA
MAP
BGA
LQF
P
MAP
BGA
LQF
P
MAP
BGA
LQF
P
MAP
BGA
LQF
P
MAP
BGA
LQF
P
MAP
BGA
Memories and Memory Interfaces
Total Flash Memory 512
KB
512
KB
512
KB
512
KB
512
KB
512
KB
256
KB
256
KB
512
KB
512
KB
512
KB
512
KB
512
KB
512
KB
512
KB
512
KB
Flash 256
KB
256
KB
256
KB
512
KB
256
KB
512
KB
256
KB
256
KB
512
KB
512
KB
512
KB
512
KB
512
KB
512
KB
256
KB
256
KB
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
20 Freescale Semiconductor, Inc.
Table 6. K50 100MHz Performance Table 2 (continued)
MC Partnumber
MK51DX256ZCLK10(R)
MK51DX256ZCMB10(R)
MK51DX256ZCLL10(R)
MK51DN512ZCLL10(R)
MK51DX256ZCMC10(R)
MK51DN512ZCMC10(R)
MK51DN256ZCLQ10(R)
MK51DN256ZCMD10(R)
MK51DN512ZCLQ10(R)
MK51DN512ZCMD10(R)
MK52DN512ZCLQ10(R)
MK52DN512ZCMD10(R)
MK53DN512ZCLQ10(R)
MK53DN512ZCMD10(R)
MK53DX256ZCLQ10(R)
MK53DX256ZCMD10(R)
FlexNVM 256
KB
256
KB
256
KB
- 256
KB
---------256
KB
256
KB
EEPROM/FlexRAM 4KB 4KB 4KB - 4KB - - - - - - - - - 4KB 4KB
SRAM 64K
B
64K
B
64K
B
128
KB
64K
B
128
KB
64K
B
64K
B
128
KB
128
KB
128
KB
128
KB
128
KB
128
KB
64K
B
64K
B
Serial Programming
Interface
YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
External Bus
Interface (FlexBus),
Addr/Data/CS
- - - - - - 21/1
6/6
21/1
6/6
21/1
6/6
21/1
6/6
32/3
2/6
32/3
2/6
21/1
6/6
21/1
6/6
21/1
6/6
21/1
6/6
Non-Muxed
External Bus
Interface (Flexbus),
Addr/Data/CS
- - - - - - 21/8
/6
21/8
/6
21/8
/6
21/8
/6
30/1
6/6,
30/8
/6
30/1
6/6,
30/8
/6
21/8
/6
21/8
/6
21/8
/6
21/8
/6
DDR Controller - - - - - - - - - - - - - - - -
NAND Flash
Controller
----------------
Cache ----------------
Core Modules
DSP YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
SPFPU ----------------
Debug JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
JTA
G,
cJT
AG,
SW
D
Trace TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
TPI
U,
FPB
,
DW
T,
ITM,
ETM
,
ETB
NMI YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 21
r=uul
Table 6. K50 100MHz Performance Table 2 (continued)
MC Partnumber
MK51DX256ZCLK10(R)
MK51DX256ZCMB10(R)
MK51DX256ZCLL10(R)
MK51DN512ZCLL10(R)
MK51DX256ZCMC10(R)
MK51DN512ZCMC10(R)
MK51DN256ZCLQ10(R)
MK51DN256ZCMD10(R)
MK51DN512ZCLQ10(R)
MK51DN512ZCMD10(R)
MK52DN512ZCLQ10(R)
MK52DN512ZCMD10(R)
MK53DN512ZCLQ10(R)
MK53DN512ZCMD10(R)
MK53DX256ZCLQ10(R)
MK53DX256ZCMD10(R)
System Modules
Software Watchdog YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
Hardware
Watchdog
YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
PMC YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
MPU YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
DMA 16ch 16ch 16ch 16ch 16ch 16ch 16ch 16ch 16ch 16ch 16ch 16ch 16ch 16ch 16ch 16ch
Clock Modules
MCG YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
OSC (32-40kHz/
3-32MHz)
YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
RTC (32KHz Osc,
Vbat)
YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
Security and Integrity
Hardware
Encryption
- - - - - - - - - - YES YES YES YES YES YES
Tamper Detect - - - - - - - - - - - - - - - -
CRC YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
Analog
ADC0 (SE:single-
ended,
DP:differential pair)
19ch
SE
+
3ch
DP
19ch
SE
+
3ch
DP
19ch
SE
+
3ch
DP
19ch
SE
+
3ch
DP
19ch
SE
+
3ch
DP
19ch
SE
+
3ch
DP
21ch
SE
+
3ch
DP
21ch
SE
+
3ch
DP
21ch
SE
+
3ch
DP
21ch
SE
+
3ch
DP
21ch
SE
+
3ch
DP
21ch
SE
+
3ch
DP
21ch
SE
+
3ch
DP
21ch
SE
+
3ch
DP
21ch
SE
+
3ch
DP
21ch
SE
+
3ch
DP
ADC1 16ch
SE
+
3ch
DP
16ch
SE
+
3ch
DP
19ch
SE
+
3ch
DP
19ch
SE
+
3ch
DP
20ch
SE
+
3ch
DP
20ch
SE
+
3ch
DP
22ch
SE
+
3ch
DP
22ch
SE
+
3ch
DP
22ch
SE
+
3ch
DP
22ch
SE
+
3ch
DP
22ch
SE
+
3ch
DP
22ch
SE
+
3ch
DP
22ch
SE
+
3ch
DP
22ch
SE
+
3ch
DP
22ch
SE
+
3ch
DP
22ch
SE
+
3ch
DP
ADC2 ----------------
ADC3 ----------------
ADC DP 4ch 4ch 4ch 4ch 4ch 4ch 4ch 4ch 4ch 4ch 4ch 4ch 4ch 4ch 4ch 4ch
ADC SE 23ch 18ch 18ch 18ch 20ch 20ch 25ch 25ch 25ch 25ch 25ch 25ch 25ch 25ch 25ch 25ch
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
22 Freescale Semiconductor, Inc.
Table 6. K50 100MHz Performance Table 2 (continued)
MC Partnumber
MK51DX256ZCLK10(R)
MK51DX256ZCMB10(R)
MK51DX256ZCLL10(R)
MK51DN512ZCLL10(R)
MK51DX256ZCMC10(R)
MK51DN512ZCMC10(R)
MK51DN256ZCLQ10(R)
MK51DN256ZCMD10(R)
MK51DN512ZCLQ10(R)
MK51DN512ZCMD10(R)
MK52DN512ZCLQ10(R)
MK52DN512ZCMD10(R)
MK53DN512ZCLQ10(R)
MK53DN512ZCMD10(R)
MK53DX256ZCLQ10(R)
MK53DX256ZCMD10(R)
PGA 2222222222222222
12-bit DAC 2222222222222222
Analog Comparator 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3
Analog Comparator
Inputs
6 /
5 /
3 / 0
6 /
5 /
3 / 0
6 /
5 /
5 / 0
6 /
5 /
5 / 0
6 /
5 /
5 / 0
6 /
5 /
5 / 0
6 /
5 /
5 / 0
6 /
5 /
5 / 0
6 /
5 /
5 / 0
6 /
5 /
5 / 0
6 /
5 /
5 / 0
6 /
5 /
5 / 0
6 /
5 /
5 / 0
6 /
5 /
5 / 0
6 /
5 /
5 / 0
6 /
5 /
5 / 0
OPAMP 2222222222222222
TRIAMP 2222222222222222
Vref YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
Timers
Motor Control/
General purpose/
PWM
1x8c
h
1x8c
h
1x8c
h
1x8c
h
1x8c
h
1x8c
h
1x8c
h
1x8c
h
1x8c
h
1x8c
h
1x8c
h
1x8c
h
1x8c
h
1x8c
h
1x8c
h
1x8c
h
Quad decoder/
General purpose/
PWM
2x2c
h
2x2c
h
2x2c
h
2x2c
h
2x2c
h
2x2c
h
2x2c
h
2x2c
h
2x2c
h
2x2c
h
2x2c
h
2x2c
h
2x2c
h
2x2c
h
2x2c
h
2x2c
h
FTM External CLK 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
Low Power Timer 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
PIT 1x4c
h
1x4c
h
1x4c
h
1x4c
h
1x4c
h
1x4c
h
1x4c
h
1x4c
h
1x4c
h
1x4c
h
1x4c
h
1x4c
h
1x4c
h
1x4c
h
1x4c
h
1x4c
h
PDB 1111111111111111
CMT(Carrier
Module
Transmitter)
YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
Communication Interfaces
SDHC - - 4-bit 4-bit 8-
bit,
CLK
IN
8-
bit,
CLK
IN
8-
bit,
CLK
IN
8-
bit,
CLK
IN
8-
bit,
CLK
IN
8-
bit,
CLK
IN
8-
bit,
CLK
IN
8-
bit,
CLK
IN
8-
bit,
CLK
IN
8-
bit,
CLK
IN
8-
bit,
CLK
IN
8-
bit,
CLK
IN
High Baudrate
UART w/ ISO7816
1111111111111111
High Baudrate
UART
1111111111111111
UART 2222444444444444
Table continues on the next page...
Features
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 23
r=uul
Table 6. K50 100MHz Performance Table 2 (continued)
MC Partnumber
MK51DX256ZCLK10(R)
MK51DX256ZCMB10(R)
MK51DX256ZCLL10(R)
MK51DN512ZCLL10(R)
MK51DX256ZCMC10(R)
MK51DN512ZCMC10(R)
MK51DN256ZCLQ10(R)
MK51DN256ZCMD10(R)
MK51DN512ZCLQ10(R)
MK51DN512ZCMD10(R)
MK52DN512ZCLQ10(R)
MK52DN512ZCMD10(R)
MK53DN512ZCLQ10(R)
MK53DN512ZCMD10(R)
MK53DX256ZCLQ10(R)
MK53DX256ZCMD10(R)
SPI chip selects per
module
5 /
2 / 0
5 /
2 / 0
6 /
3 / 1
6 /
3 / 1
6 /
4 / 2
6 /
4 / 2
6 /
4 / 2
6 /
4 / 2
6 /
4 / 2
6 /
4 / 2
6 /
4 / 2
6 /
4 / 2
6 /
4 / 2
6 /
4 / 2
6 /
4 / 2
6 /
4 / 2
I2C 2222222222222222
I2S 1111111111111111
CAN ----------------
USB OTG LS/FS w/
on-chip xcvr
1111111111111111
USB OTG HS ----------------
USB DCD YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
USB 120mAReg YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
Ethernet w /1588 - - - - - - - - - - MII /
RMII
MII /
RMII
MII /
RMII
MII /
RMII
MII /
RMII
MII /
RMII
IEEE1588 Timer - - - - - - - - - - 1x4c
h,
CLK
IN
1x4c
h,
CLK
IN
1x4c
h,
CLK
IN
1x4c
h,
CLK
IN
1x4c
h,
CLK
IN
1x4c
h,
CLK
IN
Human-Machine Interface
Segment LCD 24x8
/
28x4
24x8
/
28x4
32x8
/
36x4
32x8
/
36x4
38x8
/
42x4
38x8
/
42x4
40x8
/
44x4
40x8
/
44x4
40x8
/
44x4
40x8
/
44x4
- - 40x8
/
44x4
40x8
/
44x4
40x8
/
44x4
40x8
/
44x4
Graphic LCD ----------------
TSI(Capacitive
Touch)
16
input
16
input
16
input
16
input
16
input
16
input
16
input
16
input
16
input
16
input
16
input
16
input
16
input
16
input
16
input
16
input
GPIO (w interrupt) 39 39 57 57 78 78 94 94 94 94 96 96 94 94 94 94
Operating Characteristics
5V Tolerant YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
Voltage Range 1.71
-3.6
V
1.71
-3.6
V
1.71
-3.6
V
1.71
-3.6
V
1.71
-3.6
V
1.71
-3.6
V
1.71
-3.6
V
1.71
-3.6
V
1.71
-3.6
V
1.71
-3.6
V
1.71
-3.6
V
1.71
-3.6
V
1.71
-3.6
V
1.71
-3.6
V
1.71
-3.6
V
1.71
-3.6
V
Flash Write V 1.71 1.71 1.71 1.71 1.71 1.71 1.71 1.71 1.71 1.71 1.71 1.71 1.71 1.71 1.71 1.71
Temp Range -40
to
85C
-40
to
85C
-40
to
85C
-40
to
85C
-40
to
85C
-40
to
85C
-40
to
85C
-40
to
85C
-40
to
85C
-40
to
85C
-40
to
85C
-40
to
85C
-40
to
85C
-40
to
85C
-40
to
85C
-40
to
85C
Features
K50 Family Product Brief, Rev. 8, 5/2011
24 Freescale Semiconductor, Inc.
4.5 Module-by-module feature list
The following sections describe the high-level module features for the family's superset device. See the previous section for
differences among the subset devices.
Core modules
4.5.1.1 ARM Cortex-M4 Core
• Supports up to 100 MHz frequency with 1.25DMIPS/MHz
•ARM Core based on the ARMv7 Architecture & Thumb®-2 ISA
•Microcontroller cores focused on very cost sensitive, deterministic, interrupt driven environments
• Harvard bus architecture
• 3-stage pipeline with branch speculation
• Integrated bus matrix
• Integrated Digital Signal Processor (DSP)
• Configurable nested vectored interrupt controller (NVIC)
• Advanced configurable debug and trace components
• Embedded Trace Macrocell (ETM)
4.5.1.2 Nested Vectored Interrupt Controller (NVIC)
• Close coupling with Cortex-M4 core's Harvard architecture enables low latency interrupt handling
•Up to 120 interrupt sources
• Includes a single non-maskable interrupt
• 16 levels of priority, with each interrupt source dynamically configurable
• Supports nesting of interrupts when higher priority interrupts are activated
• Relocatable vector table
4.5.1.3 Wake-up Interrupt Controller (WIC)
• Supports interrupt handling when system clocking is disabled in low power modes
• Takes over and emulates the NVIC behavior when correctly primed by the NVIC on entry to very-deep-sleep
• A rudimentary interrupt masking system with no prioritization logic signals for wake-up as soon as a non-masked
interrupt is detected
• Contains no programmer’s model visible state and is therefore invisible to end users of the device other than through
the benefits of reduced power consumption while sleeping
4.5.1.4 Debug Controller
• Serial Wire JTAG Debug Port (SWJ-DP) combines
• external interface that provides a standard JTAG or cJTAG interface for debug access
• external interface that provides a serial-wire bidirectional debug interface
• Debug Watchpoint and Trace (DWT) with the following functionality:
• four comparators configurable as a hardware watchpoint, an ETM trigger, a PC sampler event trigger, or a data
address sampler event trigger
4.5.1
Core modules
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 25
.e 0’:
• several counters or a data match event trigger for performance profiling
• configurable to emit PC samples at defined intervals or to emit interrupt event information
• Instrumentation Trace Macrocell (ITM) with the following functionality:
• Software trace - writes directly to ITM stimulus registers can cause packets to be emitted
• Hardware trace - packets generated by DWT are emitted by ITM
• Time stamping - emitted relative to packets
• Embedded Trace Macrocell (ETM) supports instruction trace
•CoreSight™ Embedded Trace Buffer (ETB) is a memory-mapped buffer to store trace data. Allows reconstruction of
program flow with standard JTAG tools.
• Test Port Interface Unit (TPIU) acts as a bridge between ITM or ETM and an off-chip Trace Port Analyzer
• Flash Patch and Breakpoints (FPB) implements hardware breakpoints and patches code and data from code space to
system space
System modules
4.5.2.1 Power Management Control Unit (PMC)
• Separate digital (regulated) and analog (referenced to digital) supply outputs
•Programmable power saving modes
• No output supply decoupling capacitors required
• Available wake-up from power saving modes via RTC and external inputs
• Integrated Power-on Reset (POR)
• Integrated Low Voltage Detect (LVD) with reset (brownout) capability
• Selectable LVD trip points
• Programmable Low Voltage Warning (LVW) interrupt capability
• Buffered bandgap reference voltage output
• Factory programmed trim for bandgap and LVD
• 1 kHz Low Power Oscillator (LPO)
4.5.2.2 DMA Channel Multiplexer (DMA MUX)
• 16 independently selectable DMA channel routers
• 4 periodic trigger sources available
• Each channel router can be assigned to 1 of 64 possible peripheral DMA sources
4.5.2.3 DMA Controller
• Up to 32 fully programmable channels with 32-byte transfer control descriptors
• Data movement via dual-address transfers for 8-, 16-, 32- and 128-bit data values
• Programmable source, destination addresses, transfer size, support for enhanced address modes
• Support for major and minor nested counters with one request and one interrupt per channel
• Support for channel-to-channel linking and scatter/gather for continuous transfers with fixed priority and round-robin
channel arbitration
4.5.2.4 Watchdog Timer (WDOG)
• Independent, configurable clock source input
4.5.2
System modules
K50 Family Product Brief, Rev. 8, 5/2011
26 Freescale Semiconductor, Inc.
• Write-once control bits with unlock sequence
• Programmable timeout period
• Ability to test watchdog timer and reset
• Windowed refresh option
• Robust refresh mechanism
• Cumulative count of watchdog resets between power-on resets
• Configurable interrupt on timeout
4.5.2.5 External Watchdog Monitor (EWM)
• Independent 1 kHz LPO clock source
• Output signal to gate an external circuit which is controlled by CPU service or external input
4.5.2.6 System Clocks
• Frequency-locked loop (FLL)
• Digitally-controlled oscillator (DCO)
• DCO frequency range is programmable
• Option to program DCO frequency for a 32,768 Hz external reference clock source
• Internal or external reference clock can be used to control the FLL
• 0.2% resolution using 32 kHz internal reference clock
• 2% deviation over voltage and temperature using internal 32 kHz internal reference clock, 1% deviation with
limited temperature range (0°C to 70°C)
• Phase-locked loop (PLL)
• Voltage-controlled oscillator (VCO)
• External reference clock is used to control the PLL
• Modulo VCO frequency divider Phase/Frequency detector
• Integrated loop filter
• Internal reference clock generator
• Slow clock with nine trim bits for accuracy
• Fast clock with four trim bits
• Can be used to control the FLL
• Either the slow or the fast clock can be selected as the clock source for the MCU
• Can be used as a clock source for other on-chip peripherals
• External clock from the Crystal Oscillator (XOSC)
• Can be used to control the FLL and/or the PLL
• Can be selected as the clock source for the MCU
• External clock monitor with reset request capability
• Lock detector with interrupt request capability for use with the PLL
• Auto Trim Machine (ATM) for trimming both the slow and fast internal reference clocks
• Multiple clock source options available for most peripherals
Memories and Memory Interfaces
4.5.3.1 On-Chip Memory
• 72MHz performance devices
4.5.3
Memories and Memory Interfaces
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 27
• Up to 256KB program flash memory
• Flexmemory block contains up to 32KB FlexNVM and 2KB FlexRAM with up to 2KB EEPROM capability
• Up to 64KB SRAM
• 100MHz performance devices
• Up to 512KB program flash memory
• Flexmemory block contains up to 256KB FlexNVM and 4KB FlexRAM with up to 4KB EEPROM capability
• Up to 128KB SRAM
• Security circuitry to prevent unauthorized access to RAM and flash contents
4.5.3.2 External Bus Interface (FlexBus)
• Six independent, user-programmable chip-select signals that can interface with external SRAM, PROM, EPROM,
EEPROM, flash, and other peripherals
• Supports up to 2 GB addressable space
• 8-, 16- and 32-bit port sizes with configuration for multiplexed or non-multiplexed address and data buses
• Byte-, word-, longword-, and 16-byte line-sized transfers
• Programmable address-setup time with respect to the assertion of chip select
• Programmable address-hold time with respect to the negation of chip select and transfer direction
4.5.3.3 Serial Programming Interface (EzPort)
• Same serial interface as, and subset of, the command set used by industry-standard SPI flash memories
• Ability to read, erase, and program flash memory
• Reset command to boot the system after flash programming
Security and Integrity
4.5.4.1 Cyclic Redundancy Check (CRC)
• Hardware CRC generator circuit using 16/32-bit shift register
•User Configurable 16/32 bit CRC
• Programmable Generator Polynomial
• Error detection for all single, double, odd, and most multi-bit errors
• Programmable initial seed value
• High-speed CRC calculation
• Optional feature to transpose input data and CRC result via transpose register, required on applications where bytes are
in lsb format
4.5.4.2 Hardware Cryptographic Acceleration Unit (CAU)
• Supports DES, 3DES, AES, MD5, SHA-1, and SHA-256 algorithms
• Simple C calls to optimized security functions provided by Freescale
4.5.4.3 Random Number Generator (RNG)
• Supports the key generation algorithm defined in the Digital Signature Standard
4.5.4
Security and Integrity
K50 Family Product Brief, Rev. 8, 5/2011
28 Freescale Semiconductor, Inc.
•http://www.itl.nist.gov/fipspubs/fip186.htm
• Integrated entropy sources capable of providing the PRNG with entropy for its seed
Analog
4.5.5.1 16-bit Analog-to-Digital Converter (ADC)
• Linear successive approximation algorithm with up to 16-bit resolution
•Output modes:
• Differential 16-bit, 13-bit, 11-bit, and 9-bit modes, in two’s complement 16-bit sign-extended format
• Single-ended 16-bit, 12-bit, 10-bit, and 8-bit modes, in right-justified unsigned format
• Single or continuous conversion
• Configurable sample time and conversion speed/power
• Conversion complete and hardware average complete flag and interrupt
• Input clock selectable from up to four sources
• Operation in low power modes for lower noise operation
• Asynchronous clock source for lower noise operation with option to output the clock
• Selectable asynchronous hardware conversion trigger with hardware channel select
• Automatic compare with interrupt for various programmable values
• Temperature sensor
• Hardware average function
• Selectable voltage reference
• Self-calibration mode
4.5.5.2 High-Speed Analog Comparator (CMP)
• 6-bit DAC programmable reference generator output
• Up to eight selectable comparator inputs; each input can be compared with any input by any polarity sequence
• Selectable interrupt on rising edge, falling edge, or either rising or falling edges of comparator output
• Comparator output supports:
• Sampled
• Windowed (ideal for certain PWM zero-crossing-detection applications
• Digitally filtered using external sample signal or scaled peripheral clock
• Two performance modes:
• Shorter propagation delay at the expense of higher power
• Low power, with longer propagation delay
• Operational in all MCU power modes
4.5.5.3 12-Bit Digital-to-Analog Converter (DAC)
• 12-bit resolution
• Guaranteed 6-sigma monotocity over input word
• High- and low-speed conversions
•1 μs conversion rate for high speed, 2 μs for low speed
• Power-down mode
• Choice of asynchronous or synchronous updates
4.5.5
Analog
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 29
• Automatic mode allows the DAC to generate its own output waveforms including square, triangle, and sawtooth
• Automatic mode allows programmable period, update rate, and range
• DMA support with configurable watermark level
4.5.5.4 Voltage Reference (VREF)
• Programmable trim register with 0.5mV steps, automatically loaded with room temp value upon reset
• Programmable mode selection:
• Off
• Bandgap out (or stabilization delay)
• Low-power buffer mode
• Tight-regulation buffer mode
• 1.2V output at room temperature
• Dedicated output pin
4.5.5.5 General Purpose Operational Amplifier (OPAMP)
• 1.71 - 3.6V VDD operation
• Programmable voltage gain
• On-chip generation of bias voltages
• Low-power, low-voltage CMOS technology
• Low-input offset voltage and current
• Low-input bias current
• Low-current consumption
4.5.5.6 Trans-Impedance Amplifier (TRIAMP)
• 1.71 - 3.6V VDD operation
• On-chip generation of bias voltages
• Low-power, low voltage CMOS technology
• Low-input offset voltage and current
• Low-input bias current
• Low-current consumption
Timers
4.5.6.1 Programmable Delay Block (PDB)
• Up to 15 trigger input sources and software trigger source
•Up to eight configurable PDB channels for ADC hardware trigger
• One PDB channel is associated with one ADC.
• One trigger output for ADC hardware trigger and up to eight pre-trigger outputs for ADC trigger select per PDB
channel
• Trigger outputs can be enabled or disabled independently.
• One 16-bit delay register per pre-trigger output
• Optional bypass of the delay registers of the pre-trigger outputs
• Operation in One-Shot or Continuous modes
4.5.6
Timers
K50 Family Product Brief, Rev. 8, 5/2011
30 Freescale Semiconductor, Inc.
• Optional back-to-back mode operation, which enables the ADC conversions complete to trigger the next PDB
channel
• One programmable delay interrupt
• One sequence error interrupt
• One channel flag and one sequence error flag per pre-trigger
• DMA support
• Up to eight DAC interval triggers
• One interval trigger output per DAC
• One 16-bit delay interval register per DAC trigger output
• Optional bypass the delay interval trigger registers
• Optional external triggers
• Up to eight pulse outputs (pulse-out's)
• Pulse-out's can be enabled or disabled independently.
• Programmable pulse width
4.5.6.2 FlexTimers (FTM)
• Selectale FTM source clock
• Programmable prescaler
• 16-bit counter supporting free-running or initial/final value, and countin is up or up-down
• Input capture, output compare, and edge-aligned and center-aligned PWM modes
• Input capture and output compare modes
• Operation of FTM channels as pairs with equal outputs, pairs with complimentary outputs, or independent channels
with independent outputs
• Deadtime insertion is available for each complementary pair
• Generation of hardware triggers
• Software control of PWM outputs
• Up to 4 fault inputs for global fault control
• Configurable channel polarity
• Programmable interrupt on input capture, reference compare, overflowed counter, or detected fault condition
• Quadrature decoder with input filters, relative position counting, and interrupt on position count or capture of position
count on external event
• DMA support for FTM events
• Global time base mode shares single time base across multiple FTM instances
4.5.6.3 Programmable Interrupt Timers (PITs)
• Up to 4 general purpose interrupt timers
• Up to 4 interrupt timers for triggering ADC conversions
• 32-bit counter resolution
• Clocked by system clock frequency
• DMA support
4.5.6.4 Low Power Timer
• Operation as timer or pulse counter
• Selectable clock for prescaler/glitch filter
• 1 kHz internal LPO
• External low power crystal oscillator
Timers
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 31
uu .m
• Internal reference clock (not available in low leakage power modes)
• Secondary external reference clock (for example, 32 kHz crystal)
• Configurable glitch filter or prescaler
• Interrupt generated on timer compare
• Hardware trigger generated on timer compare
4.5.6.5 Carrier Modulator Timer (CMT)
• Four modes of operation
• Time with independent control of high and low times
• Baseband
• Frequency shift key (FSK)
• Direct software control of CMT_IRO signal
• Extended space operation in time, baseband, and FSK modes
• Selectable input clock divider
• Interrupt on end of cycle
• Ability to disable CMT_IRO signal and use as timer interrupt
4.5.6.6 Real-Time Clock (RTC)
• Independent power supply, POR and 32 kHz crystal oscillator
• 32-bit seconds counter with 32-bit alarm
• 16-bit prescaler with compensation
• Register write protection
• Hard Lock requires VBAT POR to enable write access
• Soft lock requires system reset to enable write/read access
Communication interfaces
4.5.7.1 10/100Mbps Ethernet MAC
• Ethernet controller with 10/100 BaseT/TX capability; half duplex or full duplex
•Hardware support for IEEE Standard for a Precision Clock Synchronization Protocol for Networked
Measurement and Control Systems, IEEE 1588
• Media independent interface (MII) and reduced media independent interface (RMII) support
• Built-in unified DMA
• On-chip transmit and receive FIFOs
• Supports legacy buffer descriptor programming models and functionality
• Enchanced buffer descriptor programming model for new Ethernet functionality
• Supports wake-up from low power mode through magic packets
• Multiple clock source options for time-stamping clock
4.5.7.2 USB On-The-Go Module (FS/LS)
• Complies with USB specification rev 2.0
• USB host mode
4.5.7
Communication interfaces
K50 Family Product Brief, Rev. 8, 5/2011
32 Freescale Semiconductor, Inc.
• Supports enhanced-host-controller interface (EHCI)
• Allows direct connection of FS/LS devices without an OHCI/UHCI companion controller
• Supported by Linux and other commercially available operating systems
• USB device mode
• Full-speed operation via the on-chip transceiver
• Supports one upstream facing port
• Supports four programmable, bidirectional USB endpoints, including endpoint 0
• Suspend mode/low power
• As host, firmware can suspend individual devices or the entire USB and disable chip clocks for low-power
operation
• Device supports low-power suspend
• Remote wake-up supported for host and device
• Integrated with the processor’s low power modes
• Includes an on-chip full-speed (12 Mbps) and low-speed (1.5 Mbps) transceiver
4.5.7.3 USB Device Charger Detect (USBDCD)
• Compatible with systems powered from:
• Rechargable battery
• Non-rechargable battery
• External 3.3v LDO regulator powered from USB or
• Directly from USB using internal regulator
• Programmable event timers for flexibility and better compatibility with future udpates to the standards
• Compliant with the latest industry standard specification, USB Battery Charging Specification, Revision 1.1
4.5.7.4 USB Voltage Regulator
• 5V regulator input typically provided by USB VBUS power
• 3.3V regulated output powers on-chip USB transceiver
• Output pin from regulator can be used to power external board components and source up to 120mA
• Eliminates cost of external LDO
• 3.3V regulated output can power MCU main power supply
4.5.7.5 Serial Peripheral Interface (SPI)
• Master and slave mode
• Full-duplex, three-wire synchronous transfers
• Programmable transmit bit rate
• Double-buffered transmit and receive data registers
• Serial clock phase and polarity options
• Slave select output
• Mode fault error flag with CPU interrupt capability
• Control of SPI operation during wait mode
• Selectable MSB-first or LSB-first shifting
• Programmable 8-bit or 16-bit data transmission length
• Receive data buffer hardware match feature
• 64-bit FIFO mode for high speed transfers of large amounts of data
• Support for both transmit and receive by DMA
Communication interfaces
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 33
uu .m
4.5.7.6 Inter-Integrated Circuit (I2C)
•Compatible with I2C bus standard and SMBus Specification Version 2 features
•Up to 100 kbps with maximum bus loading
• Multi-master operation
• Software programmable for one of 64 different serial clock frequencies
• Programmable slave address and glitch input filter
• Interrupt or DMA driven byte-by-byte data transfer
• Arbitration lost interrupt with automatic mode switching from master to slave
• Calling address identification interrupt
• Bus busy detection broadcast and 10-bit address extension
• Address matching causes wake-up when processor is in low power mode
4.5.7.7 UART
• Support for ISO 7816 protocol for interfacing with smartcards
•Full-duplex operation
• Standard mark/space non-return-to-zero (NRZ) format
• 13-bit baud rate selection with fractional divide of 32
• Programmable 8-bit or 9-bit data format
• Separately enabled transmitter and receiver
• Programmable transmitter output polarity
• Programmable receive input polarity
• 13-bit break character option
• 11-bit break character detection option
• Parameterizable buffer support for one dataword for each transmit and receive
• Independent FIFO structure for transmit and receive
• Two receiver wakeup methods:
• Idle line wakeup
• Address mark wakeup
• Address match feature in receiver to reduce address mark wakeup ISR overhead
• Interrupt or DMA driven operation
• Receiver framing error detection
• Hardware parity generation and checking
• 1/16 bit-time noise detection
4.5.7.8 Secure Digital Host Controller (SDHC)
• Compatible with the following specifications:
•SD Host Controller Standard Specification, Version 2.0 (http://www.sdcard.org ) with test event register and
advanced DMA support
•MultiMediaCard System Specification, Version 4.2 (http://www.mmca.org )
•SD Memory Card Specification, Version 2.0 (http://www.sdcard.org ), supporting high capacity SD memory
cards
•SDIO Card Specification, Version 2.0 (http://www.sdcard.org )
•CE-ATA Card Specification, Version 1.0 (http://www.sdcard.org )
• Designed to work with CE-ATA, SD Memory, miniSD Memory, SDIO, miniSDIO, SD Combo, MMC, MMCplus, and
RS-MMC cards
• SD bus clock frequency up to 50 MHz
• Supports 1-/4-bit SD and SDIO modes, 1-/4-/8-bit MMC modes, 1-/4-/8-bit CE-ATA devices
• Up to 200 Mbps data transfer for SD/SDIO cards using four parallel data lines
Communication interfaces
K50 Family Product Brief, Rev. 8, 5/2011
34 Freescale Semiconductor, Inc.
• Up to 416 Mbps data transfer for MMC using 8 parallel data lines
• Single- and multi-block read and write
• 1-4096 byte block size
• Write-protection switch for write operations
• Synchronous and asynchronous abort
• Pause during the data transfer at a block gap
• SDIO read wait and suspend/resume operations
• Auto CMD12 for multi-block transfer
• Host can initiate non-data transfer commands while the data transfer is in progress
• Allows cards to interrupt the host in 1- and 4-bit SDIO modes
• Supports interrupt period, defined in the SDIO standard
• Fully configurable 128 x 32-bit FIFO for read/write data
• Internal DMA capabilities
• Supports voltage selection by configuring vendor specific register bit
• Supports advanced DMA to perform linked memory access
4.5.7.9 Synchronous Serial Interface (I2S)
• Independent (asynchronous) or shared (synchronous) transmit and receive sections with separate or shared internal/
external clocks and frame syncs, operating in master or slave mode intended for audio support
• Master or slave mode operation
• Normal mode operation using frame sync
• Network mode operation allowing multiple devices to share the port with up to 32 time slots
•Programmable data interface modes, such as I2S, LSB aligned, and MSB aligned
• Programmable word length (8, 10, 12, 16, 18, 20, 22 or 24 bits)
• AC97 support
Human-machine interface
4.5.8.1 General Purpose Input/Output (GPIO)
• Progammable glitch filter and interrupt with selectable polarity on all input pins
•Hysteresis and configurable pull up/down device on all input pins
• Configurable slew rate and drive strength on all output pins
• Independent pin value register to read logic level on digital pin
• Optional devices with 5V tolerance
4.5.8.2 Touch Sensor Input (TSI)
• 16 channel inputs, supporting up to 16 individual touch buttons
• 4 touch buttons can be combined for a slider
• Configurable button- and slider-sensitive interrupts
• Operation in low-power modes allows wakeup from lowest power mode via a single touch
• Option to use internal reference clock
4.5.8.3 Segment LCD
• LCD waveforms functional in low-power modes
• Up to 48 LCD pins with selectable frontplane/backplane configuration
4.5.8
Human-machine interface
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 35
nme
• Generate up to 44 frontplane signals
• Generate up to 8 backplanes signals
• Programmable LCD frame frequency
• Programmable blink modes and frequency
• All segments blank during blink period
• Alternate display for each LCD segment in x4 or less mode
• Blink operation in low-power modes
• Programmable LCD power supply switch, making it an ideal solution for battery-powered and board-level applications
• Charge pump requires only four external capacitors
• Internal LCD power using VDD
• Internal VIREG regulated power supply option for 3 V or 5 V LCD glass
• External VLL3 power supply option (3 V)
• Internal-regulated voltage source with a 4-bit trim register to apply contrast control
• Integrated charge pump for generating LCD bias voltages
• Hardware-configurable to drive 3 V or 5 V LCD panels
• On-chip generation of bias voltages
• Waveform storage registers
• Backplane reassignment to assist in vertical scrolling on dot-matrix displays
• Software-configurable LCD frame frequency interrupt
5 Power modes
The power management controller (PMC) provides the user with multiple power options. All together 10 different modes of
operation are supported to allow the user to optimize power consumption for the level of functionality needed.
Depending on the stop requirements of the user application, a variety of stop modes are available that provide state retention,
partial power down or full power down of certain logic and/or memory. I/O states are held in all modes of operation. The
following table compares the various power modes available.
For each run mode there is a corresponding wait and stop mode. Wait modes are similar to ARM sleep modes. Stop modes
(VLPS, STOP) are similar to ARM sleep deep mode. The very low power run (VLPR) operating mode can drastically reduce
runtime power when the maximum bus frequency is not required to handle the application needs.
The three primary modes of operation are run, wait and stop. The WFI instruction invokes both wait and stop modes for the
chip. The primary modes are augmented in a number of ways to provide lower power based on application needs.
Table 7. Chip power modes
Chip mode Description Core mode Normal
recovery
method
Normal run Allows maximum performance of chip. Default mode out of reset; on-
chip voltage regulator is on.
Run -
Normal Wait -
via WFI
Allows peripherals to function while the core is in sleep mode,
reducing power. NVIC remains sensitive to interrupts; peripherals
continue to be clocked.
Sleep Interrupt
Normal Stop -
via WFI
Places chip in static state. Lowest power mode that retains all
registers while maintaining LVD protection. NVIC is disabled; AWIC is
used to wake up from interrupt; peripheral clocks are stopped.
Sleep Deep Interrupt
Table continues on the next page...
Power modes
K50 Family Product Brief, Rev. 8, 5/2011
36 Freescale Semiconductor, Inc.
Table 7. Chip power modes (continued)
Chip mode Description Core mode Normal
recovery
method
VLPR (Very
Low Power
Run)
On-chip voltage regulator is in a low power mode that supplies only
enough power to run the chip at a reduced frequency. Reduced
frequency Flash access mode (1 MHz); LVD off; internal oscillator
provides a low power 2 MHz source for the core, the bus and the
peripheral clocks.
Run Interrupt
VLPW (Very
Low Power
Wait) -via WFI
Same as VLPR but with the core in sleep mode to further reduce
power; NVIC remains sensitive to interrupts (FCLK = ON). On-chip
voltage regulator is in a low power mode that supplies only enough
power to run the chip at a reduced frequency.
Sleep Interrupt
VLPS (Very
Low Power
Stop)-via WFI
Places chip in static state with LVD operation off. Lowest power mode
with ADC and pin interrupts functional. Peripheral clocks are stopped,
but LPTimer, RTC, CMP, TSI, DAC can be used. NVIC is disabled
(FCLK = OFF); AWIC is used to wake up from interrupt. On-chip
voltage regulator is in a low power mode that supplies only enough
power to run the chip at a reduced frequency. All SRAM is operating
(content retained and I/O states held).
Sleep Deep Interrupt
LLS (Low
Leakage Stop)
State retention power mode. Most peripherals are in state retention
mode (with clocks stopped), but LLWU, LPTimer, RTC, CMP, TSI,
DAC can be used. NVIC is disabled; LLWU is used to wake up.
NOTE: The LLWU interrupt must not be masked by the interrupt
controller to avoid a scenario where the system does not fully
exit stop mode on an LLS recovery.
All SRAM is operating (content retained and I/O states held).
Sleep Deep Wakeup
Interrupt1
VLLS3 (Very
Low Leakage
Stop3)
Most peripherals are disabled (with clocks stopped), but LLWU,
LPTimer, RTC, CMP, TSI, DAC can be used. NVIC is disabled; LLWU
is used to wake up.
SRAM_U and SRAM_L remain powered on (content retained and I/O
states held).
Sleep Deep Wakeup Reset2
VLLS2 (Very
Low Leakage
Stop2)
Most peripherals are disabled (with clocks stopped), but LLWU,
LPTimer, RTC, CMP, TSI, DAC can be used. NVIC is disabled; LLWU
is used to wake up.
SRAM_L is powered off. A portion of SRAM_U remains powered on
(content retained and I/O states held).
Sleep Deep Wakeup Reset2
VLLS1 (Very
Low Leakage
Stop1)
Most peripherals are disabled (with clocks stopped), but LLWU,
LPTimer, RTC, CMP, TSI, DAC can be used. NVIC is disabled; LLWU
is used to wake up.
All of SRAM_U and SRAM_L are powered off. The 32-byte system
register file and the 32-byte VBAT register file remain powered for
customer-critical data.
Sleep Deep Wakeup Reset2
BAT (backup
battery only)
The chip is powered down except for the VBAT supply. The RTC and
the 32-byte VBAT register file for customer-critical data remain
powered.
Off Power-up
Sequence
1. Resumes normal run mode operation by executing the LLWU interrupt service routine.
2. Follows the reset flow with the LLWU interrupt flag set for the NVIC.
Power modes
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 37
Tower is approx. 3.5" when fully assembled
6 Developer Environment
Freescale's products are supported by a widespread, established network of tools and third party developers and software
vendors. The Kinetis families take advantage of these and similar development resources.
6.1 Freescale's Tower System Support
Freescale's Tower System is a modular development platform for 8-bit, 16-bit, and 32-bit microcontrollers that enables
advanced development through rapid prototyping. Featuring multiple development boards or modules, the Tower System
provides designers with building blocks for entry-level to advanced microcontroller development.
The Freescale Tower System
MCU/MPU Module
• Tower controller board
• Works stand-alone or
in Tower System
• Features new on-board
debug interface for
easy programming
and debugging via
mini-B USB cable
Secondary Elevator
• Additional serial and
expansion buses and
peripheral interfaces
Peripheral Module
• (i.e. serial, prototype, etc.)
Size
• Tower is approx. 3.5” H x 3.5” W x 3.5” D
when fully assembled
Primary Elevator
• Common serial
and expansion
bus signals
• Two 2x80 connectors
on backside for easy
signal access and
side-mounting board
(i.e. LCD module)
• Power regulation
circuitry
• Standardized signal
assignments
Board Connectors
• Four card-edge
connectors
• Uses PCI Express®
connectors
(x16, 90 mm/3.5”
long, 164 pins)
Figure 4. Freescale's Tower System
The following Tower modules are available for the Kinetis families. For more information on the Tower System see http://
www.freescale.com/tower.
Developer Environment
K50 Family Product Brief, Rev. 8, 5/2011
38 Freescale Semiconductor, Inc.
Table 8. Tower Modules for Kinetis MCU Families
Microcontroller Modules Features
Kinetis K40 Family MCU Module K40 family 512 KB flash MCU in 144 MAPBGA package
On-board JTAG debug interface
Access to all features including Segment LCD and USB
Kinetis K60 Family MCU Module K60 family 512 KB flash MCU in 144 MAPBGA package
On-board JTAG debug interface
Access to all features including Ethernet and USB
Kinetis K53 Family MCU Module K53 family 512 KB flash MCU in 144 MAPBGA package
On-board JTAG debug interface
Access to all features including Ethernet, USB, Segment LCD (TWRPI),
and medical expansion connector
6.2 CodeWarrior Development Studio
Freescale's CodeWarrior Development Studio for Microcontrollers v10.x integrates the development tools for the RS08,
HCS08, ARM, and ColdFire architectures into a single product based on the Eclipse open development platform. Eclipse
offers an excellent framework for building software development environments and is becoming a standard framework used
by many embedded software vendors.
• Eclipse IDE 3.4
• Build system with optimizing C/C++ compilers for RS08, HCS08, ARM, and ColdFire processors
• Extensions to Eclipse C/C++ Development Tools (CDT) to provide sophisticated features to troubleshoot and repair
embedded applications
Table 9. CodeWarrior 10.x Differentiating Features
Differentiating
features
Customer
benefits
Details
MCU Change
Wizard
Ability to
easily
retarget
project to a
new
processor
Simply select a new device (from the same or a different architecture) and select the
default connection, and the CodeWarrior tool suite automatically reconfigures the project
for the new device with the correct build tools and support files.
•Compiler
• Assembler
• Linker
• Header files
• Vector tables
• Libraries
• Linker configuration files
Table continues on the next page...
Developer Environment
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 39
Table 9. CodeWarrior 10.x Differentiating Features (continued)
Differentiating
features
Customer
benefits
Details
Freescale
Processor Expert
Problems in
hardware
layer can be
resolved
during initial
design phase
Combines easy-to-use component-based application creation with an expert knowledge
system.
•CPU, on-chip peripherals, external peripherals, and software functionality are
encapsulated into embedded components
• Each component’s functionality can be tailored to fit application requirements by
modifying the component’s properties, methods and events
• When the project is built, Processor Expert automatically generates highly optimized
embedded C code and places the source files into the project
• Graphical user interface: Allows an application to be specified by the functionality
needed
• Automatic code generator: Creates tested, optimized C code tuned to application
needs and the selected Freescale device
• Built-in knowledgebase: Immediately flags resource conflicts and incorrect settings,
so errors are caught early in design cycle
• Component wizard: Allows user-specific, hardware-independent embedded
components to be created
Trace and profile
support for on-
chip trace buffers
Sophisticate
d emulator-
like debug
capability
without
additional
hardware
The CodeWarrior profiling and analysis tools provide visibility into an application as it runs
on the processor to identify operational problems.
•Supports architectures with on-chip trace buffers (HCS08, V1 ColdFire, ARM)
• Allows tracepoints to be set to enable and disable trace output
• Can step through trace data and the corresponding source code simultaneously
• Allows trace data to be exported into a Microsoft® Excel® file
For more information see the CodeWarrior web site at http://www.freescale.com/codewarrior.
6.3 Freescale's MQX™ Software Solutions
The increasing complexity of industrial applications and expanding functionality of semiconductors are driving embedded
developers toward solutions that combine proven hardware and software platforms. These solutions help accelerate time to
market and improve application development success.
Freescale Semiconductor offers the MQX real-time operating system (RTOS), with TCP/IP and USB software stacks and
peripheral drivers, to customers of ARM, ColdFire and ColdFire+ MCUs at no additional charge. The combination of
Freescale's MQX software solutions and Freescale's silicon portfolio creates a comprehensive source for hardware, software,
tools, and services.
Developer Environment
K50 Family Product Brief, Rev. 8, 5/2011
40 Freescale Semiconductor, Inc.
Application
HAL
Hardware
On Device
PC Hosted
CodeWarrior™
Development
Environment
(MQX OS
Aware)
CodeWarrior
Processor
Expert™
MQX Design
and
Development
Tools
Third Party:
IAR
(MQX OS
Aware)
Open Source
BDM and
Third Party:
Emulator/Probe
Demo Code Applications Customized
Applications
Application Tasks and
Industry-Specific Libraries
BSP/PSP
Freescale Comprehensive Solution
Enablement
Layer
Ethernet
(RTCS)
File System
USB
CAN
MQX RTOS
Optional
Services
Core Services MQX RTOS
Discrete
Driver,
Third
Party
and
Freescale
BDM/JTAG
Figure 5. MQX Comprehensive Solution
Key benefits of Freescale's MQX RTOS include:
•Small memory footprint: The RTOS was designed for speed and size efficiency in embedded systems. It delivers true
real-time performance, with context switching and low-level interrupt routines hand-optimized in assembly.
• Component-based architecture: Provides a fully-functional RTOS core with additional, optional services. Freescale's
MQX RTOS includes 25 components (8 core components and 17 optional). Components are linked in only if needed,
preventing unused functions from bloating the memory footprint.
• Full and lightweight components: Key components are included in both full and lightweight versions for further control
of size, RAM/ROM utilization, and performance options.
• Real-time, priority-based, preemptive multithreading: Allows high-priority threads to meet their deadlines consistently,
no matter how many other threads are competing for CPU time.
• Scheduling: Enables faster development time by offloading from developers the task of creating or maintaining an
efficient scheduling system and interrupt handling.
• Code reuse: Provides a framework with a simple, intuitive API to build and organize the features across Freescale’s
broad portfolio of embedded processors.
Developer Environment
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 41
• Fast boot sequence: Ensures the application is running quickly after the hardware has been reset.
• Simple Message Passing: Messages can be passed either from a system pool or a private pool, sent with either urgent
status or a user-defined priority, and broadcast or task specific. For maximum flexibility, a receiving task can operate
on either the same CPU as the sending task or on a different CPU within the same system.
For more information see the MQX web site at http://www.freescale.com/mqx.
MQX RTOS—Customizable Component Set
Task Errors
Utilities
Initialization
Core Memory
Services
Automatic Task
Creation
Lightweight
Semaphores
Task Queue
Scheduling
RR and FIFO
Scheduling
Queues
Name
Services Interrupts
Messages
Events
Mutexes
IPCs
Exception
Handling
Kernel
Log
Logs
I/O
Subsystems
Formatted
I/O
Timers
Watchdogs
Task
Management
Partitions
As-Needed
Core
Semaphores
Figure 6. MQX Customizable Component Set
6.4 Additional Software Stacks Provided
• Math, DSP and Encryption Libraries
• Motor Control Libraries
• Touch Sensing Software Suite
• Complimentary Bootloaders (USB, Ethernet, RF, serial)
• Complimentary Freescale Embedded GUI
•Complimentary Freescale MQX™ RTOS , USB, TCP/IP stack and MFS filesystem
•Low Cost Nano™ SSL/Nano™ SSH for Freescale MQX™ RTOS
•Plus full ARM® ecosystem
Developer Environment
K50 Family Product Brief, Rev. 8, 5/2011
42 Freescale Semiconductor, Inc.
7 Revision History
The following table provides a revision history for this document.
Table 10. Revision History
Rev. No. Date Substantial Changes
7 2/2011 Initial public revision
8 5/2011 Updated memory and package option table
Updated family feature tables
Updated module feature lists
Revision History
K50 Family Product Brief, Rev. 8, 5/2011
Freescale Semiconductor, Inc. 43
0" :3' fre escale‘ semiconductor
How to Reach Us:
Home Page:
www.freescale.com
Web Support:
http://www.freescale.com/support
USA/Europe or Locations Not Listed:
Freescale Semiconductor
Technical Information Center, EL516
2100 East Elliot Road
Tempe, Arizona 85284
+1-800-521-6274 or +1-480-768-2130
www.freescale.com/support
Europe, Middle East, and Africa:
Freescale Halbleiter Deutschland GmbH
Technical Information Center
Schatzbogen 7
81829 Muenchen, Germany
+44 1296 380 456 (English)
+46 8 52200080 (English)
+49 89 92103 559 (German)
+33 1 69 35 48 48 (French)
www.freescale.com/support
Japan:
Freescale Semiconductor Japan Ltd.
Headquarters
ARCO Tower 15F
1-8-1, Shimo-Meguro, Meguro-ku,
Tokyo 153-0064
Japan
0120 191014 or +81 3 5437 9125
support.japan@freescale.com
Asia/Pacific:
Freescale Semiconductor China Ltd.
Exchange Building 23F
No. 118 Jianguo Road
Chaoyang District
Beijing 100022
China
+86 10 5879 8000
support.asia@freescale.com
For Literature Requests Only:
Freescale Semiconductor Literature Distribution Center
1-800-441-2447 or +1-303-675-2140
Fax: +1-303-675-2150
LDCForFreescaleSemiconductor@hibbertgroup.com
Document Number: K50PB
Rev. 8, 5/2011
Information in this document is provided solely to enable system and sofware
implementers to use Freescale Semiconductors products. There are no express or implied
copyright licenses granted hereunder to design or fabricate any integrated circuits or
integrated circuits based on the information in this document.
Freescale Semiconductor reserves the right to make changes without further notice to any
products herein. Freescale Semiconductor makes no warranty, representation, or
guarantee regarding the suitability of its products for any particular purpose, nor does
Freescale Semiconductor assume any liability arising out of the application or use of any
product or circuit, and specifically disclaims any liability, including without limitation
consequential or incidental damages. "Typical" parameters that may be provided in
Freescale Semiconductor data sheets and/or specifications can and do vary in different
applications and actual performance may vary over time. All operating parameters,
including "Typicals", must be validated for each customer application by customer's
technical experts. Freescale Semiconductor does not convey any license under its patent
rights nor the rights of others. Freescale Semiconductor products are not designed,
intended, or authorized for use as components in systems intended for surgical implant
into the body, or other applications intended to support or sustain life, or for any other
application in which failure of the Freescale Semiconductor product could create a
situation where personal injury or death may occur. Should Buyer purchase or use
Freescale Semiconductor products for any such unintended or unauthorized application,
Buyer shall indemnify Freescale Semiconductor and its officers, employees, subsidiaries,
affiliates, and distributors harmless against all claims, costs, damages, and expenses, and
reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury
or death associated with such unintended or unauthorized use, even if such claims alleges
that Freescale Semiconductor was negligent regarding the design or manufacture of
the part.
RoHS-compliant and/or Pb-free versions of Freescale products have the functionality and
electrical characteristics as their non-RoHS-complaint and/or non-Pb-free counterparts.
For further information, see http://www.freescale.com or contact your Freescale
sales representative.
For information on Freescale's Environmental Products program, go to
http://www.freescale.com/epp.
Freescale™ and the Freescale logo are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners.
© 2010–2011 Freescale Semiconductor, Inc.

Products related to this Datasheet

IC MCU 32BIT 128KB FLASH 64LQFP
IC MCU 32BIT 512KB FLASH 144LQFP
IC MCU 32B 256KB FLASH 121MAPBGA
IC MCU 32BIT 128KB FLASH 64LQFP
IC MCU 32BIT 512KB FLASH 100LQFP
IC MCU 32BIT 128KB FLASH 121BGA
IC MCU 32BIT 128KB FLASH 121BGA
IC MCU 32B 256KB FLASH 121MAPBGA
IC MCU 32BIT 256KB FLASH 121BGA
IC MCU 32BIT 512KB FLASH 144LQFP
IC MCU 32B 512KB FLASH 121MAPBGA
IC MCU 32BIT 128KB FLASH 64LQFP
IC MCU 32B 256KB FLASH 144MAPBGA
IC MCU 32BIT 256KB FLASH 144BGA
IC MCU 32B 256KB FLASH 144MAPBGA
IC MCU 32BIT 128KB FLASH 64LQFP
IC MCU 32BIT 512KB FLASH 144LQFP
IC MCU 32B 512KB FLASH 144MAPBGA
IC MCU 32BIT 256KB FLASH 80FQFP
IC MCU 32BIT 128KB FLASH 80FQFP
IC MCU 32BIT 128KB FLASH 100LQFP
IC MCU 32BIT 256KB FLASH 100LQFP
IC MCU 32BIT 256KB FLASH 100LQFP
IC MCU 32BIT 256KB FLASH 80FQFP
IC MCU 32BIT 512KB FLASH 144LQFP
IC MCU 32BIT 256KB FLASH 144LQFP
IC MCU 32B 512KB FLASH 144MAPBGA
IC MCU 32BIT 256KB FLASH 100LQFP
IC MCU 32BIT 512KB FLASH 144LQFP
TOWER SYSTEM K53 EVAL BRD
