FW.24.SMA.M Specification Datasheet by Taoglas Limited

View All Related Products | Download PDF Datasheet
_|_J CI) Cl) _C U) (U _|_J (U Q Meteor Part No: FW.24.SMA.M Description: Features: www.taoglas.com
SPE-17-8-003/C/AW
Meteor
Part No:
FW.24.SMA.M
Description:
Meteor 2.4GHz Flexible Whip Monopole Antenna
Features:
External 2.4GHz Monopole Antenna
Rugged Design for Outdoor Use
Over 70% Efficiency*
Over 4dBi Peak Gain*
Robust Inner Steel Core
Antenna height 316mm
SMA(M) Straight Connector
IP65 dust and water-resistant
*Tested on 30*30cm Ground Plane
RoHS Compliant
A“ TAOGLAS. Taog‘as makes no warrarmes based on the accuracy or comp‘eteness ofme contents of ms document and reserves the nght to Iretand ISO Taiwan . 5‘ ISO 90111 2015 9001 ISO 9001: 2015 b % ? Denified FEES?“ Certified __ we IAYF1ML!
