AD\-\NTECH
Enabflngmlmwmmm
User Manual
UTC-320
Intel® Platform Processor-
based Ubiquitous Touch
Computer with 21.5” TFT LCD
UTC-320 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2016
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Award is a trademark of Award Software International, Inc. Intel® and Celeron® are
trademarks of Intel Corporation.
IBM, PC/AT, PS/2 and VGA are trademarks of International Business
Machines Corporation.
Intel® and Pentium® are trademarks of Intel Corporation.
Microsoft Windows® is a registered trademark of Microsoft Corp. RTL is a trademark
of Realtek Semiconductor Co., Ltd.
All other product names or trademarks are properties of their respective owners.
For more information on this and other Advantech products, please visit our websites
at:
http://www.advantech.com
For technical support and service, please visit our support website at:
http://support.advantech.com
This manual is for the UTC-320.
Part No. 200K032000 Edition 1
Printed in Taiwan May 2016
iii UTC-320 User Manual
Declaration of Conformity
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning! Any changes or modifications made to the equipment which are not
expressly approved by the relevant standards authority could void your
authority to operate the equipment.
UTC-320 User Manual iv
Packing List
Before you begin installing UTC-320, please make sure that the following materials
have been shipped:
UTC-320 series
Accessories for UTC-320
–Warranty card
–1 x adapter
–1 x SATA cable
–Packet of screws
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately.
Technical Support and Assistance
1. Visit the Advantech web site at http://support.advantech.com where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
v UTC-320 User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening in the device. This may cause fire or elec-
trical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
15. The power cord or plug is damaged.
16. Liquid has penetrated into the equipment.
17. The equipment has been exposed to moisture.
18. The equipment does not work well, or you cannot get it to work according to the
user's manual.
19. The equipment has been dropped and damaged.
20. The equipment has obvious signs of breakage.
21. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
22. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
23. The sound pressure level at the operator's position according to IEC 704-1:1982
is no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.
UTC-320 User Manual vi
vii UTC-320 User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ............................................................................................... 2
1.2 General Specifications .............................................................................. 2
1.2.1 General ......................................................................................... 2
1.2.2 Standard PC Functions................................................................. 2
1.2.3 Audio Function .............................................................................. 2
1.2.4 LAN Function ................................................................................ 2
1.2.5 Touch screen (Optional) ............................................................... 3
1.2.6 Environment.................................................................................. 3
1.3 LCD Specifications.................................................................................... 4
1.4 Optional modules ...................................................................................... 4
1.5 Dimensions ............................................................................................... 5
Figure 1.1 Dimensions of UTC-320 ............................................. 5
Chapter 2 System Setup.......................................7
2.1 A Quick Tour of the UTC-320.................................................................... 8
Figure 2.1 Front view of UTC-320 ............................................... 8
Figure 2.2 Rear view of UTC-320 ................................................ 8
2.2 Installation Procedures.............................................................................. 9
2.2.1 Connecting the power cord ........................................................... 9
2.2.2 Connecting the keyboard or mouse .............................................. 9
2.2.3 Switching on the power................................................................. 9
Figure 2.3 Connect the power cord to the DC inlet...................... 9
2.3 Running the BIOS Setup Program .......................................................... 10
2.4 Installing System Software...................................................................... 12
2.4.1 Method 1: Ethernet ..................................................................... 12
2.4.2 Method 2: External USB CD-ROM.............................................. 12
2.5 Installing the Drivers................................................................................ 12
Chapter 3 Hardware Installation and Upgrades ...
13
3.1 Introduction ............................................................................................. 14
3.2 Installing the 2.5" Hard Disk Drive (HDD) ............................................... 14
Figure 3.1 Installing primary 2.5" HDD ...................................... 14
3.3 Installing the mSATA Card...................................................................... 15
Figure 3.2 Installing the mSATA Card ....................................... 15
3.4 Installing the WLAN................................................................................. 16
Chapter 4 Jumper Settings and Connectors ....19
4.1 Jumpers and Connectors ........................................................................ 20
4.1.1 Setting jumpers ........................................................................... 20
4.1.2 Jumpers and connectors............................................................. 21
Table 4.1: Jumpers and Connector Functions........................... 21
4.1.3 Locating jumpers and connectors ............................................... 22
Figure 4.1 Jumpers and Connectors on UTC-320..................... 22
4.2 Jumpers .................................................................................................. 23
4.2.1 Jumper List ................................................................................. 23
Table 4.2: Jumper List ............................................................... 23
UTC-320 User Manual viii
4.2.2 Jumper Settings.......................................................................... 23
Table 4.3: JP1:LCD PWM POWER........................................... 23
Table 4.4: JP2:LCD ENABLE POWER ..................................... 23
Table 4.5: JP3:LCD POWER .................................................... 24
Table 4.6: JP4: TOUCH POWER.............................................. 24
Table 4.7: JP5: AT/ATX POWER SEL ...................................... 24
Table 4.8: JP6: CLEAR CMOS ................................................. 25
Table 4.9: CN9:COM1 /COM2 RING POWER.......................... 25
Table 4.10:CN10: CSAFE Power ............................................... 25
Appendix A I/O Pin Assignments ......................... 27
A.1 PIN Assignments .................................................................................... 28
Table A.1: CN1: Backlight.......................................................... 28
Table A.2: CN2: Internal USB.................................................... 28
Table A.3: CN3:SATA POWER ................................................. 29
Table A.4: CN4: LVDS............................................................... 29
Table A.5: CN5: SATA............................................................... 31
Table A.6: CN9:Touch ............................................................... 31
Table A.7: CN13:DDR3L SODIMM............................................ 32
Table A.8: MINIPCIE1:MINIPCIE .............................................. 33
Table A.9: MSATA1: MSATA..................................................... 34
Table A.10:CN11:CSAFE ........................................................... 36
Table A.11:CN13: COM2............................................................ 37
Table A.12:CN14: COM1............................................................ 38
Table A.13:CN15: SPEAKER ..................................................... 38
Table A.14:CN21: Line-out ......................................................... 39
Table A.15:CN22: MIC-IN........................................................... 39
Table A.16:CN17: LAN1/LAN2 ................................................... 39
Table A.17:CN24: HDMI ............................................................. 40
Table A.18:CN19:External USB.................................................. 41
Table A.19:CN20:External USB.................................................. 42
Table A.20:CN18: External USB................................................. 43
Table A.21:CN23: RJ11.............................................................. 43
Table A.22:SW2 BUTTON: Power button................................... 44
Table A.23:CN31: DC-IN ............................................................ 44
Table A.24:VGA.......................................................................... 45
Chapter 1
1General Information
This chapter gives background
information on the UTC-320.
Sections include:
Introduction
General Specifications
LCD Specifications
Dimensions
UTC-320 User Manual 2
1.1 Introduction
UTC-320 is a multi-purpose all-in-one computing system equipped with a wide for-
mat, touch based LCD panel. It is easy to integrate key peripherals and display sys-
tems for diversified self-service and interactive signage deployed in different
locations. With its removable frame, the system could also fulfill control system appli-
cations with its panel mounting design.
1.2 General Specifications
1.2.1 General
Dimensions: 520.2 mm (L) x 316.1 mm (H) x 45.9 mm (D)
Weight: 6.5 kg
Power adaptor: AC/DC (Standard Build in) 12 V, 84 W
Input voltage:100 ~ 240 VAC
Output voltage: 12 V @ 7 A
Disk drive housing: Space for one 2.5" SATA HDD
Front panel: IP65
1.2.2 Standard PC Functions
CPU: Intel® Haswell or Baytrail with 3 MB L2 cache
BIOS: AMI 16 MB Flash BIOS via SPI
System chipset: Intel® Haswell or Baytrail
System memory: 1 x SO-DIMM DDR3L 1333 MHz up to 8 GB
Serial ports: 1 x RS-232 COM , 1 x RS-232 / 422 / 485
Universal serial bus (USB) port: Supports up to 2 x USB 2.0 / 4 x USB 3.0
Mini PCI-E bus expansion slot: Accepts one mini PCI-E device (wireless LAN
card)
Watchdog timer: Single chip Watchdog 255-level interval timer, setup by soft-
ware
Power management: Full ACPI (Advanced Configuration and Power Interface)
2.0 Supports S0, S1, S3,S4, S5
1.2.3 Audio Function
Audio: High Definition Audio (HD), 1 W x 2 Speakers
Optional - Audio output function
1.2.4 LAN Function
Chipset:
–LAN1 Intel I218LM, LAN2 Intel WGI211AT for Core i
–LAN1 Intel WGI211AT, LAN2 Intel WGI211AT for Celeron
Speed: 1000 Mbps /Interface: 2 x RJ45
Wake-on-LAN: Supports Wake-on-LAN function with ATX power control
Supports LAN teaming (in fault tolerance)
3 UTC-320 User Manual
Chapter 1 General Information
1.2.5 Touch screen (Optional)
1.2.6 Environment
Operating temperature: 0 ~ 40° C (32 ~ 104° F)
Storage temperature: -20 ~ 60° C
Relative humidity: 10 ~ 90% @ 40° C (non-condensing)
Shock: 10 G peak acceleration (11 ms duration)
Certification: EMC: CE, FCC, BSMI, VCCI.
Safety: UL 60950, CB, CCC, BSMI
Vibration: 5 ~ 500 Hz 0.5 G RMS Random vibration
VESA Support: 100 x 100 mm (screw type- M4 x 8)
Supports landscape and portrait screen modes.
Type
Analog Resistive 5-wires (Res. Flat Glass)
/ Projected Capacitive Touch Panel (Pcap.
Flat Glass)
Light Transmission 80%
Controller USB interface
Durability (touches in a lifetime) 36 million
Caution! Use suitable mounting apparatus to avoid risk of injury.
Note! Please follow suggestion to install UTC-320 Models.
UTC-320 User Manual 4
1.3 LCD Specifications
Display type: 21.5" TFT LCD
Max. resolution: 1920 x 1080
Colors: 16.7 M
Pixel Pitch (um): 248.25 (H) x 248.25 (V)
View Angle: 89°/89°
Luminance: 200 cd/m2
1.4 Optional modules
Memory: 1 x SO-DIMM DDR3L 1333 MHz up to 8 GB
HDD: 2.5" SATA HDD
Operating System: Windows Embedded Standard 7, Windows Embedded
Standard 8.1, Embedded Linux 3.0, Windows Embedded Standard 10
Touchscreen: Analog resistive (Optional - PCT solution)
Power cord: 1702002600 (US) 1702002605 (Europe)
Wireless LAN Module:
Note! The color LCD display installed in the UTC-320 is high-quality and reli-
able. However, it may contain a few defective pixels which do not
always illuminate. With current technology, it is impossible to completely
eliminate defective pixels. Advantech is actively working to improve this
technology.
Part No. Description
968EMW0071 Wireless 802.11abgn AR9382 2T2R Full-size DNXA-1
1750006682-01 Main antenna wireless 200 mm
301.7
480.1
W
1 .. a . .. . a ..
520.2
266.6
316.1
210.1
91.0
CUT OUT
303.2
Figure 1.1 Dimensions of UTC-320
5 UTC-320 User Manual
Chapter 1 General Information
1.5 Dimensions
Figure 1.1 Dimensions of UTC-320
UTC-320 User Manual 6
Chapter 2
2System Setup
This chapter details system setup
on the UTC-320.
Sections include:
A Quick Tour of the UTC-320
Installation procedures
Running the BIOS Setup
Program
Installing System Software
UTC-320 User Manual 8
2.1 A Quick Tour of the UTC-320
Before you start to set up the UTC-320, take a moment to become familiar with the
locations and purposes of the controls, drives, connectors and ports, which are illus-
trated in the figures below.
When you place the UTC-320 upright on the desktop, its front panel appears as
shown in Figure 2.1.
Figure 2.1 Front view of UTC-320
When you turn the UTC-320 around and look at its rear cover, you will find the I/O
section as shown in Fig. 2.2. (The I/O section includes various I/O ports, including
serial ports, Ethernet ports, USB ports, HDMI, and LINE-OUT / MIC-IN, RJ11, DC-IN,
Power button.)
Figure 2.2 Rear view of UTC-320
:
9 UTC-320 User Manual
Chapter 2 System Setup
A. COM Port B. Line-out
C. MIC-IN D. Gigabit LAN x2
E. HDMI or VGA (optional) F. USB3.0 x4, USB2.0 x2 for Core i
USB2.0 x5, USB3.0 x1 for Celeron
G. RJ11 (optional) H. Power switch
I. DC-IN
2.2 Installation Procedures
2.2.1 Connecting the power cord
The UTC-320 can be powered by a DC electrical outlet. Be sure to always handle the
power cords by holding the plug ends only. Please follow the Figure 2.3 to connect
the male plug of the power cord to the DC inlet of the UTC-320.
2.2.2 Connecting the keyboard or mouse
Before you start the computer, please connect keyboard port on the I/O section of the
UTC-320.
2.2.3 Switching on the power
When you look at the rear side of the UTC-320, you will see the power switch as
shown in Figure 2.3.
Figure 2.3 Connect the power cord to the DC inlet
awn mum , E
r m [um
UTC-320 User Manual 10
2.3 Running the BIOS Setup Program
Your UTC-320 is likely to have been properly set up and configured by your dealer
prior to delivery. You may still find it necessary to use the UTC-320's BIOS (Basic
Input-Output System) setup program to change system configuration information,
such as the current date and time or your type of hard drive. The setup program is
stored in read-only memory (ROM). It can be accessed either when you turn on or
reset the UTC-320, by pressing the “Del” key on your keyboard immediately after
powering on the computer.
The settings you specify with the setup program are recorded in a special area of
memory called CMOS RAM. This memory is backed up by a battery so that it will not
be erased when you turn off or reset the system. Whenever you turn on the power,
the system reads the settings stored in CMOS RAM and compares them to the
equipment check conducted during the power on self-test (POST). If an error occurs,
an error message will be displayed on screen, and you will be prompted to run the
setup program.
COM2 RS232/RS422/RS485 Selection:
Enter Into BIOS setup Advanced Super IO Configuration.
Aptm Sewn mum 7 Bummgm (E 2(12 Ameucan Negetr‘ewds‘ Inc.
> same) Part 2 EDanur‘aUDn
Aptm Sewn mum 7 Bummgm (E 2(12 Ameucan Negetr‘ewds‘ Inc.
semal Part 2 Marie [R5232]
Em m m 2 ma:
MM;
RS422
RS4EE
11 UTC-320 User Manual
Chapter 2 System Setup
Select Serial Port 2 Configuration.
Change Serial Port 2 Mode [RS232/RS422/RS485].
UTC-320 User Manual 12
2.4 Installing System Software
Recent releases of operating systems from major vendors include setup programs
which load automatically and guide you through hard disk preparation and operating
system installation. The guidelines below will help you determine the steps necessary
to install your operating system on the UTC-320 hard drive.
Installing software requires an installed HDD. Software can be loaded in the UTC-320
using any of four methods:
2.4.1 Method 1: Ethernet
You can use the Ethernet port to download software to the HDD.
2.4.2 Method 2: External USB CD-ROM
If required, insert your operating system's installation or setup diskette into the dis-
kette drive until the release button pops out.
The BIOS of UTC-320 supports system boot-up directly from the CD-ROM drive. You
may also insert your system installation CD-ROM into the CD-ROM drive.
Power on your UTC-320 or reset the system by pressing the “Ctrl+Alt+Del” keys
simultaneously. The UTC-320 will automatically load the operating system from the
diskette or CD-ROM.
If you are presented with the opening screen of a setup or installation program, follow
the instructions on screen. The setup program will guide you through preparation of
your hard drive, and installation of the operating system. If you are presented with an
operating system command prompt, such as A:\>, then you must partition and format
your hard drive, and manually copy the operating system files to it. Refer to your
operating system user manual for instructions on partitioning and formatting a hard
drive.
2.5 Installing the Drivers
After installing your system software, you will be able to set up Ethernet, chipset,
graphics, audio, USB 3.0 and touchscreen functions; download the drivers from the
Advantech website.
www.advantech.com
Note! Some distributors and system integrators may have already pre-
installed system software prior to shipment of your UTC-320.
Note! The drivers and utilities used for the UTC-320 are subject to change
without notice.
If in doubt, check Advantech's website or contact our application engi-
neers for the latest information regarding drivers and utilities.
Chapter 3
3Hardware Installation
and Upgrades
This chapter details installing the
UTC-320 hardware.
Sections include:
Overview of Hardware Installa-
tion and Upgrading
Installing the 2.5" Hard Disk
Drive (HDD)
Installing the mSATA
Installing the WLAN
UTC-320 User Manual 14
3.1 Introduction
The UTC-320 consists of a PC-based computer that is housed in an plastic enclo-
sure. You can install a HDD, DRAM, and MiniSATA card by removing the rear cover.
Any maintenance or hardware upgrades can be easily completed after removing the
rear cover.
3.2 Installing the 2.5" Hard Disk Drive (HDD)
You can attach one Serial Advanced Technology Attachment (SATA) hard disk drive
to the UTC-320's internal controller. The SATA controller supports faster data transfer
and allows the SATA hard drive to exceed 150 MB. The following are instructions for
installation:
1. Detach and remove the rear cover.
2. Place the HDD in the metal bracket, and tighten the screws (see Figure 3.1).
3. The HDD cable (SATA 7P+1*5P-2.5/SATA(15+7)P) is next to the metal brace.
Connect the HDD cable to the motherboard (SATA1/SATA POWER). Plug the
other end of the cable into the SATA hard drive.
4. Put the rear cover on and tighten the screws.
Figure 3.1 Installing primary 2.5" HDD
Warning! Do not remove the rear cover until you have verified that no power is
flowing within the UTC-320. Power must be switched off and the power
cord must be unplugged. Every time you service the UTC-320, you
should be aware of this.
15 UTC-320 User Manual
Chapter 3 Hardware Installation and Upgrades
3.3 Installing the mSATA Card
1. Remove 12 screws on the back cover.
2. Remove 6 screws on the reinforced board.
Figure 3.2 Installing the mSATA Card
UTC-320 User Manual 16
3.4 Installing the WLAN
Reserve two locations for the external Antenna. One is at the IO port, the other is at
the rear cover. Customers can choose based on their requirement.
1. Remove 12 x screws from the back cover.
2. Remove 6 screws on the reinforced board.
3. Coaxial cable (Advantech P/N: 1750006682-01)
17 UTC-320 User Manual
Chapter 3 Hardware Installation and Upgrades
4. Connect the coaxial cable to "ANT1" on the WLAN card.
5. Install the WLAN card on M/B bottom side.
6. Cable routing of the wireless antenna is shown below.
UTC-320 User Manual 18
Chapter 4
4Jumper Settings and
Connectors
This chapter tells how to set up
the UTC-320 hardware, including
instructions on setting jumpers
and connecting peripherals,
switches and indicators. Be sure
to read all the safety precautions
before you begin the installation
procedures.
Sections include:
Jumpers and Connectors
CMOS Clear for External RTC
(JP3)
COM Port Interface
Watchdog Timer Configuration
UTC-320 User Manual 20
4.1 Jumpers and Connectors
4.1.1 Setting jumpers
You can configure your UTC-320 to match the needs of your application by setting
jumpers. A jumper is the simplest kind of electrical switch. It consists of two metal
pins and a small metal clip (often protected by a plastic cover) that slides over the
pins to connect them. To 'close’ a jumper, you connect the pins with the clip. To ‘open’
a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1, 2,
and 3. In this case, you would connect either pins 1 and 2 or pins 2 and 3.
open closed closed 2-3
The jumper settings are schematically depicted in this manual as follows:.
open closed closed 2-3
A pair of needle-nose pliers may be helpful when working with jumpers. If you have
any doubts about the best hardware configuration for your application, contact your
local distributor or sales representative before you make any changes.
21 UTC-320 User Manual
Chapter 4 Jumper Settings and Connectors
4.1.2 Jumpers and connectors
The motherboard of the UTC-320 has a number of jumpers and connectors that allow
you to configure your system to suit your applications. The table below lists the func-
tion of each of the board’s jumpers.
Table 4.1: Jumpers and Connector Functions
Label Function
CN1 Back_Light
CN2 Internal USB
CN3 SATA POWER
CN4 LVDS
CN5 SATA
CN6 Touch
CN9 Touch
DIMM1 DDR3L SODIMM
MINIPCIE1 MINIPCIE
MSATA1 MSATA
CN11 CSAFE
CN13 COM2
CN14 COM1
CN15 Speaker
CN21 Line-out
CN22 MIC-IN
CN17 LAN1/LAN2
CN24 HDMI
CN19 External USB
CN20 External USB
CN18 External USB
CN23 RJ11
SW2 Power button
CN25 DC-IN
CNZ [NJ [N] (Na
CNS
CN6
M‘N‘POEl
DIMMl
MSATAl
CNI]
CN13
CN14
CN15
CNZICNZZ CN17 CN24 [N19 CNZD CN18 (NB swz £st
CNZCNSCN3 (Ni CN4 VGA
ch
CNS
MIN‘PC‘EI mmw
MSATAI
CN13
CN 14
CNIS
anchz (~17 CNZA (mg chn (ma swz CN31
UTC-320 User Manual 22
4.1.3 Locating jumpers and connectors
Figure 4.1 Jumpers and Connectors on UTC-320
23 UTC-320 User Manual
Chapter 4 Jumper Settings and Connectors
4.2 Jumpers
4.2.1 Jumper List
4.2.2 Jumper Settings
Table 4.2: Jumper List
JP1 LCD PWM POWER
JP2 LCD ENABLE POWER
JP3 LCD POWER
JP4 TOUCH POWER
JP5 AT/ATX POWER SEL
JP6 Clear CMOS
CN9 COM1/COM2 RING POWER
CN10 CSAFE POWER
Table 4.3: JP1:LCD PWM POWER
Part Number 1653003101
Footprint HD_3x1P_79_D
Description PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS
Setting Function
(1-2) 5V
(2-3)* 3.3V
Table 4.4: JP2:LCD ENABLE POWER
Part Number 1653003101
Footprint HD_3x1P_79_D
Description PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS
Setting Function
(1-2) 5V
(2-3)* 3.3V
'l“ W
UTC-320 User Manual 24
Table 4.5: JP3:LCD POWER
Part Number 1653003100
Footprint HD_3x1P_100_D
Description PIN HEADER 3x1P 2.54mm 180D(M) DIP 1130-000-03S
Setting Function
(1-2) 5V
(2-3)* 3.3V
Table 4.6: JP4: TOUCH POWER
Part Number 1653003101
Footprint HD_3x1P_79_D
Description PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS
Setting Function
(1-2)* +3.3V
(2-3) +3.3VSB
Table 4.7: JP5: AT/ATX POWER SEL
Part Number 1653005101
Footprint HD_5x1P_79_D
Description PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS
Setting Function
(1-2) AT
(2-3)* ATX
' I” W
ESE
23—6781
Js_5"7,9_
25 UTC-320 User Manual
Chapter 4 Jumper Settings and Connectors
Table 4.8: JP6: CLEAR CMOS
Part Number 1653005101
Footprint HD_5x1P_79_D
Description PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS
Setting Function
(1-2) Clear CMOS
(2-3)* Normal
Table 4.9: CN9:COM1 /COM2 RING POWER
Part Number 1653005261
Footprint HD_5x2P_79
Description PIN HEADER 5x2P 2.0mm 180D(M) SMD 21N22050
Setting Function
(1-3) * COM1 RING
(3-5) COM1 RI output +5V
(7-9) COM1 RI output +12V
(2-4) * COM2 RING
(4-6) COM2 RI output +5V
(8-10) COM2 RI output +12V
Table 4.10: CN10: CSAFE Power
Part Number 1653003201
Footprint HD_3x2P_79_D
Description PIN HEADER 3x2P 2.0mm 180D(M) DIP 21N22050
Setting Function
(1-3) * CSAFE output +5V
(3-4) CSAFE output +9V
(3-5) CSAFE output +12V
UTC-320 User Manual 26
Appendix A
AI/O Pin Assignments
CN1
.0... II...
Liarrzv: 1_2:4rT
UTC-320 User Manual 28
A.1 PIN Assignments
Table A.1: CN1: Backlight
Part Number 1655004512-01
Footprint WF_8P_49_BOX_D
Description WAFER BOX 8P 1.25mm 180D(M) DIP A1251WV0-8P
Pin Pin name
1 +12V_INVERTER
2 +12V_INVERTER
3GND
4GND
5 BKLT_EN
6BRIGHT1
7 +12V_INVERTER
8GND
Table A.2: CN2: Internal USB
Part Number 1655000453
Footprint WHL5V-2M-24W1140
Description WAFER BOX 2.0mm 5P 180D(M) DIP WO/Pb JIH VEI
Pin Pin name
1+5V
2D-
3D+
4GND
5GND
IUCCI
29 UTC-320 User Manual
Appendix A I/O Pin Assignments
Table A.3: CN3:SATA POWER
Part Number 1659254005
Footprint SATA_7P_WATM-07DBN4A3B8UW_D
Description Serial ATA 7P 1.27mm 180D(M) DIP WATM-07DBN4A3B8
Pin Pin name
1 +3.3V
2GND
3+5V
4GND
5+12V
Table A.4: CN4: LVDS
Part Number 1653920200
Footprint SPH20X2
Description B/B Conn. 40P 1.25mm 90D SMD DF13-40DP-1.25V(91)
Pin Pin name
1 +3.3V or +5V
2 +3.3V or +5V -
3GND
4GND
5 +3.3V or +5V
6 +3.3V or +5V
7 LVDS0_D0-
8 LVDS1_D0-
9 LVDS0_D0+
10 LVDS1_D0+
11 GND
12 GND-
13 LVDS0_D1-
14 LVDS1_D1-
15 LVDS0_D1+
16 LVDS1_D1+
17 GND
18 GND
19 LVDS0_D2-
20 LVDS1_D2-
21 LVDS0_D2+
22 LVDS1_D2+-
23 GND
24 GND
2_._s_.Tvzwww¥_g¥¥_x¥_
E DEEMED—EB EB DEEMED—BEE
EMBEBEDEE @E EBEEEBEEBLI
1.: 1+1- TWTTTTWE TIL.»
UTC-320 User Manual 30
25 LVDS0_CLK-
26 LVDS1_CLK-
27 LVDS0_CLK+
28 LVDS1_CLK+
29 GND
30 GND
31 LVDS0_DDC_SC
32 LVDS0_DDC_SD
33 GND
34 GND
35 LVDS0_D3-
36 LVDS1_D3-
37 LVDS0_D3+
38 LVDS1_D3+
39 +3.3V or +5V
40 +3.3V or +5V
Table A.4: CN4: LVDS
UUUUL
31 UTC-320 User Manual
Appendix A I/O Pin Assignments
Table A.5: CN5: SATA
Part Number 1654004659
Footprint WF_5P_98_BOX_D
Description WAFER BOX 5P 2.5mm 180D(M) DIP 2503-WS-5
Pin Pin name
1GND
2TX+
3TX-
4GND
5RX+
6RX-
7GND
Table A.6: CN9:Touch
Part Number 1655005110
Footprint WF_5P_100_RA_D
Description WAFER 5P 2.54mm 90D(M) DIP 2542-WR-5
Pin Pin name
1Y+
2Y-
3 SENSE
4X+
5X-
UTC-320 User Manual 32
Table A.7: CN13:DDR3L SODIMM
Part Number 1651002087-11
Footprint DDR3_204P_AS0A626-N2S6-7H
Description DDR3 SODIMM H=5.2mm STD 204P SMD AS0A626-H2S6-7H
Pin Pin name
1 VREF_DQ
2GND
3GND
4DQ4
5DQ0
6DQ5
7DQ1
8GND
9GND
10 DQS0
11 GND
12 GND
13 DQ4
14 DQ0
15 DQ5
16 DQ1
17 GND
18 GND
19 GND
20 GND
21 DQ4
22 DQ0
23 DQ5
24 DQ1
25 GND
26 GND
27 DQS1
28 GND
29 GND
30 DQ4
31 DQ0
32 DQ5
33 DQ1
34 GND
35 GND
33 UTC-320 User Manual
Appendix A I/O Pin Assignments
Table A.8: MINIPCIE1:MINIPCIE
Part Number 1654002538
Footprint FOX_AS0B226-S68K7F
Description MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68Q-7H
Pin Pin name
1 MPCIE1_WAKE#
2 +3.3VSB
3NC
4GND
5NC
6NC
7 MPCIE_CLKREQ#
8NC
9GND
10 NC
11 CLK_MINI_PCIE-
12 NC
13 CLK_MINI_PCI+
14 NC
15 GND
16 NC
17 NC
18 GND
19 NC
20 MPCIE1_DISABLE#
21 GND
22 PLTRST#
23 PCIE_RX-
24 +3.3VSB
25 PCIE_RX+
26 GND
27 GND
28 +1.5V
29 GND
30 SMB_CLK_MPCIE1
31 PCIE_TX-
32 SMB_DAT_MPCIE1
33 PCIE_TX+
34 GND
35 GND
36 USB_D-
37 GND
38 USB_D+
39 +3.3VSB
40 GND
41 +3.3VSB
42 NC
UTC-320 User Manual 34
43 NC
44 NC
45 NC
45 NC
47 NC
48 NC
49 NC
50 GND
51 NC
52 +3.3VSB
Table A.9: MSATA1: MSATA
Part Number 1654002538
Footprint FOX_AS0B226-S68K7F
Description MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68Q-7H
Pin Pin name
1NC
2 +3.3V
3NC
4NC
5NC
6NC
7NC
8NC
9GND
10 NC
11 NC
12 NC
13 NC
14 NC
15 GND
16 NC
17 NC
18 GND
19 NC
20 NC
21 GND
22 NC
23 SATA1_RX+
24 +3.3V
25 SATA1_RX-
26 GND
27 GND
28 NC
29 GND
30 NC
Table A.8: MINIPCIE1:MINIPCIE
35 UTC-320 User Manual
Appendix A I/O Pin Assignments
31 SATA1_TX-
32 NC
33 SATA1_TX+
34 GND
35 GND
36 NC
37 GND
38 NC
39 +3.3V
40 GND
41 +3.3V
42 NC
43 NC
44 NC
45 NC
45 NC
47 NC
48 NC
49 NC
50 GND
51 +3.3V
52 +3.3V
Table A.9: MSATA1: MSATA
UTC-320 User Manual 36
Table A.10: CN11:CSAFE
Part Number 1655000197
Footprint WF_5x2P_79_BOX_D_P1R
Description 1655_WF_5x2P_79_BOX_D_P1R_0.Normal
Pin Pin name
1 LINE_IN1_L
2 LINIE_IN1_R
3COM3_ RX+
4COM3_TX
5 V_CSAFE
6COM3_CTS#
7GND
8GND
9
@EEEE
@flEEE
#, fi_
17:57:;
37 UTC-320 User Manual
Appendix A I/O Pin Assignments
UART RS485 Auto Flow Control
COM2 supports RS485 auto flow control function for all UART.
When enabling the RS485 auto control function, it will automatically drive RTS# pin
to logic high or low for flow control.
To make this RS485 auto flow control function work, please be noted that the parity
and stop-bit setting has to be one of the following three settings:
(1) 8 data bits + 1 parity bit + 1stop bit
(2) 8 data bits + 1 parity bit + 2 stop bits
(3) 8 data bits + 2 stop bits
Table A.11: CN13: COM2
Part Number 1655000197
Footprint WF_5x2P_79_BOX_D_P1R
Description 1655_WF_5x2P_79_BOX_D_P1R_0.Normal
Pin Pin name
1422/485 TX-
2422/485 TX+
3422 RX+
4422 RX-
5GND
6DSR#
7RTS#
8CTS#
9RI#
EEEEH‘
EEEEE
_# fi_
L 3. s_ 7_ L
UTC-320 User Manual 38
Table A.12: CN14: COM1
Part Number 1655000197
Footprint WF_5x2P_79_BOX_D_P1R
Description 1655_WF_5x2P_79_BOX_D_P1R_0.Normal
Pin Pin name
1DCD
2RXD
3TXD
4DTR#
5GND
6DSR#
7RTS#
8CTS#
9RI#
Table A.13: CN15: SPEAKER
Part Number 1655304020
Footprint WF_4P_79_BOX_R1_D
Description WAFER BOX 2.0mm 4P 180D(M) W/LOCK A2001WV2-4P
Pin Pin name
1 AUD_OUTA-
2 AUD_OUTA+
3 AUD_OUTB+
4 AUD_OUTB-
JACK_5H
JACKjH
39 UTC-320 User Manual
Appendix A I/O Pin Assignments
Table A.14: CN21: Line-out
Part Number 1652001586
Footprint KUONYI_PJ-2508PC-5-L
Description PHONE JACK 5P 3.5φ 90D(F) AZALIA GREEN DIP WO/P
Pin Pin name
1GND
2OUT_L
3JD
4OUT_R
5GND
Table A.15: CN22: MIC-IN
Part Number 1652001584
Footprint KUONYI_PJ-2508PA-5-L
Description PHONE JACK 5P 3.5φ 90D(F) AZALIA PINK DIP WO/Pb
Pin Pin name
1GND
2MIC_L
3JD
4MIC_R
5GND
Table A.16: CN17: LAN1/LAN2
Part Number 1652003274
Footprint RJ45_28P_RTB-19GB9J1A
Description PHONE JACK RJ45 28P DIP RTB-19GB9J1A
Pin Pin name
‘qaqqfiqqfiwflww-
@40ij
"2|.le 9n
<><>
UTC-320 User Manual 40
Table A.17: CN24: HDMI
Part Number 1654011175-01
Footprint HDMI_19P_QJ51191-LFB4-7F
Description HDMI Conn. 19P 0.5mm 90D(F) SMD QJ51191-LFB4-7F
Pin Pin name
1HDMI_TX0+
2GND
3HDMI_TX0-
4HDMI_TX1+
5GND
6HDMI_TX1-
7HDMI_TX2+
8GND
9HDMI_TX2-
10 HDMI_TX3+
11 GND
12 HDMI_TX3-
13 NC
14 NC
15 HDMI_CLK
16 HDMI_DAT
17 GND
18 +5V
19 HDMI_DET
use [4 NPE
USBRD
pm < mu="" m;="" m="" 4="" (cmmrehm:="" amuse="">41 UTC-320 User Manual
Appendix A I/O Pin Assignments
Table A.18: CN19:External USB
Part Number 1654010969-01
Footprint USB_9x2P_UEA1112C-8HS6-4F
Description USB CONN. 18P 2.0mm 90D(F) DIP UEA1112C
Pin Pin name
1+5VSB
2D-
3D+
4GND
5 SSRX-
6 SSRX+
7GND
8 SSTX-
9 SSTX+
10 +5VSB
11 D-
12 D+
13 GND
14 SSRX-
15 SSRX+
16 GND
17 SSTX-
18 SSTX+
.55 A was
L58 3 0
m
H:
n:
m
5ND_USB
UTC-320 User Manual 42
Table A.19: CN20:External USB
Part Number 1654010969-01
Footprint USB_9x2P_UEA1112C-8HS6-4F
Description USB CONN. 18P 2.0mm 90D(F) DIP UEA1112C
Pin Pin name
1 +5VSB
2D-
3D+
4GND
5 SSRX-
6 SSRX+
7GND
8 SSTX-
9 SSTX+
10 +5VSB
11 D-
12 D+
13 GND
14 SSRX-
15 SSRX+
16 GND
17 SSTX-
18 SSTX+
vcc_usao
usaoj
usaooj
GND_1
VCC_USE1
USB-I_B
usa~1_s
GND_2
pm_1
43 UTC-320 User Manual
Appendix A I/O Pin Assignments
Table A.20: CN18: External USB
Part Number 1654009513
Footprint USB_8P_UB1112C-8FDE-4F
Description USB CONN. 8P 2.0mm 90D DIP UB1112C-8FDE-4F
Pin Pin name
1+5VSB
2D-
3D+
4GND
5+5VSB
6D-
7D+
8GND
Table A.21: CN23: RJ11
Part Number 1652005977-02
Footprint RJ11_6P_RJ1201-66N024R0
Description PHONE JACK RJ11 6P6C 90D(F) DIP 6u RJ1201-66N024
Pin Pin name
1GND
2GPIOA
3Status
4POWER
5GPIOB
6GND
(Charactenstlp
UTC-320 User Manual 44
Table A.22: SW2 BUTTON: Power button
Part Number 1600000055
Footprint SW_6P_TC003-N11AABRGXX-RK_D
Description PUSH SW DIP 6P W/LED WO/Pb TC003-N11AABRGXX-RK
Pin Pin name
1GND
2GND
3ATX_PWRBTN#
4ATX_PWRBTN#
5+5V
6GND
Table A.23: CN31: DC-IN
Part Number 1652005624
Footprint PJ_2P_2DC-G213B200
Description DC POWER JACK 2.5mm 90D(M) DIP 2DC-G213B200
Pin Pin name
1DC_IN
2GND
m
m
E
EECfifififiifi
[31313151315151
45 UTC-320 User Manual
Appendix A I/O Pin Assignments
Table A.24: VGA
Part Number 1653208260
Footprint HD_8x2P_79_BOX
Description BOX HEADER 8x2P 2.00mm 180D(M) SMD 23N6850
Pin Pin name
1 VGA_R
2 +5V
3 VGA_G
4 GND
5 VGA_B
6NC
7 NC
8 VGA_DDAT
9 GND
10 VGA_HS
11 GND
12 VGA_VS
13 GND
14 VGA_DCLK
15 GND
16 GND
AD\-\NTECH
Enabling-ulmlligml’lana
www.advantech.com
Please verify specifications before quoting. This guide is intended for reference
purposes only.
All product specifications are subject to change without notice.
No part of this publication may be reproduced in any form or by any means,
electronic, photocopying, recording or otherwise, without prior written permis-
sion of the publisher.
All brand and product names are trademarks or registered trademarks of their
respective companies.
© Advantech Co., Ltd. 2016
