HS35 ABSOLUTE ENCODER

Product Description

Built on the same rugged design as the incremental model, the HS35 Absolute Encoder is available with various output options including Gray Code and

Natural Binary. Designed with a cast aluminum housing, a sealed connector and shaft seals, it carries an IP65 environmental rating. With the optional

insulating inserts, it can be mounted on smaller diameter shafts. It is designed for either a through shaft mounting or blind shaft mounting with a closed

cover to maintain its environmental rating.

SPECIFICATIONS

Options

Parallel: NB or GC 12-14 Bits (See Table 1)

Serial (S3): 12-16 Bits (See Table 3)

Analog: (A1-A5) 12-15 Bits (See Table 2)

Count Transition

Accuracy

±1/2 Bit Maximum

(Consult factory over 13 Bits)

Counts per Shaft Turn 4096 - 65536, Depending on Options

Supply Voltage 5 to 28 VDC, 13 to 28 VDC for analog

Output Formats Parallel: Gray Code, Natural Binary, Serial and Analog

Voltage/Output

(see note 2)

28V/V: Line Driver, 5–28 VDC in, Vout = Vin

28V/5: Line Driver, 5–28 VDC in, Vout = 5 VDC

28V/OC: Open Collector, 5–28 VDC in, OCout

SSI: 5–28 VDC in/5Vout (consult factory for more information)

Analog: A1-A5

Protection Level Reverse, overvoltage and output short circuit protection

Frequency Response 500kHz or 6000 RPM (Parallel)

Output Termination

Pinouts

See Tables

For S3 options, reference Spec Addendum 02087-005

For A1-A5 options, reference Spec Addendum 02088-002

Electrical Specifications

BElsmsons

Page 2

Temperature Operating, 0° to 70°C; Extended temperature ratings are available in the following ranges: -40 to 70°C, -40

Environmental Specifications

Notes and Tables: All notes and tables referred to in the text can be found on the following pages.

Shaft Bore Many diameters from .375 to 1.000 inch are available, including metric.

(Consult factory for details)

Allowable Misalignments 0.005” T.I.R. on mating shaft 0.75” from shaft end

Bore Runout 0.001 T.I.R. maximum

Starting Torque at 25°CThrough shaft version (SS) = 7 in-oz (max);

Blind shaft version (BS) = 4 in-oz max

Bearings 52100 SAE High carbon steel

Shaft Material 416 stainless steel

Bearing Housing Die cast aluminum with iridite finish; stainless steel (special feature)

Cover Die cast aluminum with protective finish (For MS or CS terminations), otherwise drawl aluminum with protective finish;

stainless-steel (special feature)

Bearing Life 7.5 X 109 revs (50,000 hrs at 2500 RPM)

Maximum RPM 6,000 RPM (see frequency response above)

Moment of Inertia 0.019 oz-in-sec2

Weight 18 oz. typical

Mechanical Specifications

[0 "IF MS Connector Termmatian SM18 Comm F’I—(ﬁa) .' : '. : I : 5a CLAMP scwzw ! !H II IN. HEX — i ii: 15—20 LB-IN ! | ! l ‘ “.25 | i ' ' I190 i i R196 ——1 70—4 2 23 R1 Tetheramck and Pm f (o as) a In 39) no 203 THRU WITH no as x 25 C'BORE \ o 247 \\[ R1 15 ‘_ a 249 Termination Options SM14/19 Conn. M531 02!?! 8—1 P f [GUM 00 NM EDNNECYDR: usJI IZE‘A—I s? SCS CAB LE 3435 CABLE /'GLAND 250 2415 I I | . _ | _ _ _ _ _ _ aaR: +.uu1/—Ionu 3x {Io-52 x ,JIDP 0N am EL. m mum (RD’ ONLY) R2 Telheer m) 45 awe oz 9 (3/ I30 250 I 00 4 50 0.75 3 no a 52 7\ 30' ’ / L sz aozIE I ‘I Is-Iv \fggé/ BEISENSORS

Page 3

Dimensions in mm

DIMENSIONS

BEIsmsans

Page 4

Direction of Count: Standard is CW increasing when viewed from the shaft end. Pin R is normally HI (or N/C) and is pulled up internally to +V. To reverse the count

direction, Pin R must be pulled LO (COMMON).

Latch Control: Encoder outputs are active and provide continuous parallel position information when Pin U is HI (or N/C). Pin U is pulled up internally to +V. When

Pin U is LO (COMMON) the encoder outputs are latched at the logic state that is present when the latch is applied and will stay latched until Pin U is no longer LO

(COMMON).

M18 Connector is a MS3102R18-1P, 10-pin connector on the encoder body and mates to an MS3106F18-1S connector or can be used with a standard cable/connec-

tor assembly, BEI P/N 924-31186-18XX (Where XX = 10, 20 30 or 50 for a 10, 20, 30, or 50 foot length). This is the preferred connector for SSI output.

M14/19 Connector is a MS3112E14-19P, 19-pin connector on the encoder body and mates to an MS3116J14-19S or equivalent.

Ordering SSI:

HOW TO SPECIFY SSI OUTPUT IN THE ENCODER MODEL NUMBER: Example:

HS35-100-R2-SS-12-NB-S3-CW-SM18

TABLES

Table 1 —

Parallel Output Code and Terminations

Table 2 —

Analog Termination and Options

Table 3 —

SSI Termination

Analog

A1, 2, 3, 4, & A5 M18 M14/19 Cable

Color

A+ OUT A A YEL

A Return H B W/YEL

Dir Control C U ORN

Reset *B C BLU

OV Return F T BLK

+V Supply D V RED

CASE GND G S GRN

* Optional

Termination

SSI M18 M14/19 Cable

Color

DATA + A A YEL

DATA - H B W/YEL

CLK + B C BLU

CLK - I D W/BLU

Dir Control C R ORN

ENABLE *J P W/ORN

OV RETURN F T BLK

+V SUPPLY D V RED

CASE GND G S GRN

SHIELD DRAIN — — BARE

* Optional

Termination

Parallel

Gray or Natural Code M14/19

CONN Cable Color

14 Bit 13 Bit 12 Bit Std.

B13 (MSB) B12 (MSB) B11 (MSB) A W/BLK

B12 B11 B10 B W/BRN

B11 B10 B9 C W/RED

B10 B9 B8 D W/ORN

B9 B8 B7 E W/YEL

B8 B7 B6 F W/GRN

B7 B6 B5 G W/BLU

B6 B5 B4 H W/VIO

B5 B4 B3 J W/GRY

B4 B3 B2 K WHT

B3 B2 B1 L GRY/BLK

B2 B1 B0 (LSB) M GRY/BRN std

B1 B0 (LSB) or NC N GRY/RED *

0V std. (BO_LSB 14 BIT or Enable, Dir C, latch) P GRY/ORN *

Dir Control std. (Optional: Latch or Enable) R ORN *

Case GND S GRN

OV Return T BLK

LATCH std. (Optional: DC or Enable) U YEL *

+V SUPPLY V RED

SHIELD DRAIN — BARE

* Optional

Items highlighted in blue are standard Express Encoders and ship in one to three days.

an -mWU—Ll—U‘U‘U—LJ—L m #J—I—J—I—l—Ll—Ll—I—J—I—J—I—J—LJ— a. V—\ l—I l—V l—I es ,mi N _—I—|— Msamn) —l— 2‘ 'WL 21 ‘WL f 'WL 1’ 7 m- N _—IT¥ MSBKI“) _—I——_ BEISENSORS

Page 5

FIGURES

NOTES

Figure 1 —

Gray Code

Figure 2 —

Natural Binary

1. The rubber shaft seal is recommended in virtually all installations. The most common exceptions are applications requiring a very low starting torque

or those requiring operation at both high temperature and high speed. For these exceptions, a felt shaft seal is recommended. Felt seals require very

low starting torque and can virtually eliminate frictional heat. Encoders ordered with felt shaft seals will have an enclosure rating of IP50 and will

have less than 1/10th the Starting Torque specified under Mechanical Configurations.

2. Output IC’s: Output IC’s are available as either Line Driver (LD) or NPN Open Collector (OC) types. Open Collectors require pull-up resistors, resulting

in higher output source impedance (sink impedance is similar to that of line drivers). In general, use of a Line Driver style output is recommended.

Line Drivers source or sink current and their lower impedance mean better noise immunity and faster switching times. Warning: Do not connect any

line driver outputs directly to circuit common/OV, which may damage the driver. Unused outputs should be isolated and left floating. Our applications

specialists would be pleased to discuss your system requirements and the compatibility of your receiving electronics with Line Driver type outputs.

28V/V: Multi-voltage Line Driver (7272*): 100 mA source/sink. Input voltage 5 to 28 VDC ±5% standard (Note: Vout = Vin). This driver is TTL compatible

when used with 5 volt supply. Supply lines are protected against overvoltage to 60 volts and reverse voltage. Outputs are short circuit protected for

one minute. Supply current is 120 mA typical (plus load current). This is the recommended replacement for 3904R and 7406R open collector outputs

with internal pullup resistors. It is also a direct replacement for any 4469, 88C30, 8830 or 26LS31 line driver

13-28VDC: For Analog

28V/5: Multi-voltage Line Driver (7272*): 100 mA source/sink. Input voltage 5 to 28 VDC +/- 5% standard, internally regulated with 5V (TTL compatible)

logic out. Supply lines are protected against overvoltage to 60 volts and reverse voltage. Outputs are short circuit protected for one minute. Supply

current is 90 mA typical (plus load current). Note: Limit encoder load to 2.5W max at ambient. Example at 12 VDC: 2.5W/(+12VDC minus +5VDC) =

357 mA total allowed current. Consult factory for your specific requirements.

28V/OC: NPN Open Collector (3904*, 7273*). Current sink of 80 mA max. Current sourced by external pull- up resistor. Output can be pulled up to

voltage other than supply voltage (30 V max). Input voltage 5 to 28 VDC ± 5% standard. Supply current is 120 mA typical. This replaces prior IC’s with

designations of 3904, 7406, 3302, 681 and 689.

3. Special –S at the end of the model number is used to define a variety of non-standard features such as special shaft lengths, voltage options, or

special testing. Please consult the factory to discuss your special requirements.

* Products manufactured prior to April 2007 used the line driver IC number instead of voltage output in model number.

ONE REVOLUTI ON

CW Increasing Count Viewing Shaf t

ETC. THRU LSB (GO)

CW Increasing Count Viewing Shaf t

ONE REVOLUTION

ETC. THRU LSB (20)

X HS35 F 100 B1 SS 12 GO ZﬂV/V W S —--------——— BElsmsons

Page 6

ORDERING OPTIONS

100: 1.00”

87: 0.875”

75: 0.75”

62: 0.625”

50: 0.50” etc.

HS: Hollow Shaft

35: 3.5” Encoder Diameter

X: Express Encoder

R1: Tether Block and Pin

R2: Tether Arm

SS: Through Shaft, Rubber Seals

BS: Blind Shaft, Rubber Seal

FS: Through Shaft, Felt Seals

BFS: Blind Shaft Felt

(See Note 1)

12: 12 Bits, 4096 Counts

13: 13 Bits, 8192 Counts

14: 14 Bits, 16384 Counts

15: 15 Bits, 32768 Counts

16: 16 Bits, 65536 Counts

GC: Gray Code

NB: Natural Binary

(* Leave Blank for A1-A5)

28V/V: 5-28Vin/out

28V/5: 5-28Vin/5Vout

28V/OC: 5-28Vin/OCout

S3: SSI

A1: 4-20mA

A2: 0-10V

A3: 0-20mA

A4: 0-5V

A5: 0-24mA

(See Note 2)

CW: Clockwise Increasing Count

CCW: Counter Clockwise Increasing Count

SM14/19: 19 Pin Connector

SCS: Shielded/Jacketed Cable with Cable Seal.

Length of Cable is specified in inches.

(i.e. SCS18 = 18 inches) SM18 = MS3102R18-1P (A1–A5 and S3 outputs only)

(Consult Factory for More Information)

S: Special Features specified on Purchase Order.

(See Note 3)

(Consult Factory for More Information)

F: Standard

Housing Configuration

Shaft Bore

Type

Encoder

Tether

Shaft Seal Configuration

Number of Bits

Code Type

Voltage / Output

Direction of Count

Output Termination

Special Features

HS35 F 100 12R1 28V/VGCSS CW SX

Items highlighted in blue are standard Express Encoders and ship in one to three days.

SM14/19

Page 7

www.sensata.com

Americas

+1 (800) 350 2727 – Option 1

sales.beisensors@sensata.com

Europe, Middle East & Africa

+33 (3) 88 20 8080

position-info.eu@sensata.com

Asia Pacific

sales.isasia@list.sensata.com

China +86 (21) 2306 1500

Japan +81 (45) 277 7117

Korea +82 (31) 601 2004

India +91 (80) 67920890

Rest of Asia +886 (2) 27602006

ext 2808

Sensata Technologies, Inc. (“Sensata”) data sheets are solely intended to assist designers (“Buyers”) who are developing systems that

incorporate Sensata products (also referred to herein as “components”). Buyer understands and agrees that Buyer remains responsible

for using its independent analysis, evaluation and judgment in designing Buyer’s systems and products. Sensata data sheets have

been created using standard laboratory conditions and engineering practices. Sensata has not conducted any testing other than that

specifically described in the published documentation for a particular data sheet. Sensata may make corrections, enhancements,

improvements and other changes to its data sheets or components without notice.

Buyers are authorized to use Sensata data sheets with the Sensata component(s) identified in each particular data sheet. HOWEVER, NO

OTHER LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE TO ANY OTHER SENSATA INTELLECTUAL PROPERTY RIGHT, AND

NO LICENSE TO ANY THIRD PARTY TECHNOLOGY OR INTELLECTUAL PROPERTY RIGHT, IS GRANTED HEREIN. SENSATA DATA SHEETS

ARE PROVIDED “AS IS”. SENSATA MAKES NO WARRANTIES OR REPRESENTATIONS WITH REGARD TO THE DATA SHEETS OR USE

OF THE DATA SHEETS, EXPRESS, IMPLIED OR STATUTORY, INCLUDING ACCURACY OR COMPLETENESS. SENSATA DISCLAIMS

ANY WARRANTY OF TITLE AND ANY IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, QUIET

ENJOYMENT, QUIET POSSESSION, AND NON-INFRINGEMENT OF ANY THIRD PARTY INTELLECTUAL PROPERTY RIGHTS WITH REGARD

TO SENSATA DATA SHEETS OR USE THEREOF.

All products are sold subject to Sensata’s terms and conditions of sale supplied at www.sensata.com SENSATA ASSUMES NO

LIABILITY FOR APPLICATIONS ASSISTANCE OR THE DESIGN OF BUYERS’ PRODUCTS. BUYER ACKNOWLEDGES AND AGREES THAT IT

IS SOLELY RESPONSIBLE FOR COMPLIANCE WITH ALL LEGAL, REGULATORY AND SAFETY-RELATED REQUIREMENTS CONCERNING

ITS PRODUCTS, AND ANY USE OF SENSATA COMPONENTS IN ITS APPLICATIONS, NOTWITHSTANDING ANY APPLICATIONS-RELATED

INFORMATION OR SUPPORT THAT MAY BE PROVIDED BY SENSATA.

Mailing Address: Sensata Technologies, Inc., 529 Pleasant Street, Attleboro, MA 02703, USA.

Specification No: 02070-001 Revised 05/30/18

AGENCY APPROVALS & CERTIFICATIONS

Agency File Number

CE EN 55011 and EN 61000-6-2

Consult factory for more details.
