2.4/5GHz SMT Chip Antenna

1.0 SCOPE

This Product Specification covers the mechanical, electrical and environmental

performances requirements and test methods for 2.4/5GHz SMT chip antenna.

2.0 PRODUCT DESCRIPTION

2.1 PRODUCT NAME AND SERIES NUMBER

Product name: 2.4/5GHz SMT Chip Antenna 146175-0001

2.2 Design and Construction

Antenna shall be of the design, construction and physical dimensions specified on the

applicable sales drawing.

2.3 Materials

a) Housing: Refer to respective Molex sales or engineering drawings

b) Plating: Refer to respective Molex sales or engineering drawings

3.0 APPLICABLE DOCUMENTS AND SPECIFICATIONS

See drawings and other sections of this specification for the relevant reference documents. In

cases where the specification differs from the drawings, the drawings take precedence.

4.0 RATINGS

4.1 RF POWER

2 Watts

4.2 TEMPERATURE

Operating: - 40°C to + 125°C

Storage : - 40°C to + 125°C

4.3 HUMIDITY

Storage : +15~70% RH

Test : +80~95% RH

D molex’ C REVTSION. ECR/ECN INFORMATION. TTTLE. SHEET No. B DATE. DOCUMENT NUMBER. CREATED / REVTSED BY. CHECKED BY. APPROVED BY.

PRODUCT SPECIFICATION

REVISION:

ECR/ECN INFORMATION:

TITLE:

2.4/5GHz SMT Chip Antenna

SHEET No.

B

ABU2016-0014

3 of 5

DATE:

2016-05-06

DOCUMENT NUMBER:

CREATED / REVISED BY:

CHECKED BY:

APPROVED BY:

PS-146175-001

Ryan Liu 2016-05-06

Chris Yu 2016-05-06

Welson Tan2016-05-06

TEMPLATE FILENAME: PRODUCT_SPEC[SIZE_A4](V.1).DOC

d

5.0 PERFORMANCE

5.2 MECHANICAL REQUIREMENTS

ITEM

DESCRIPTION

TEST CONDITION

REQUIREMENT

5.2.1

Plating thickness

measure

Use X-ray measure the thickness of

plating

The plating thickness spec:

Cu 12~16um; Ni 1~2.5um;

Au 0.1~0.2um.

5.2.2

Cross cut Test

Cross cut adhesion test

Testing is performed in accordance with

ASTM D-3359-93

Acceptance criteria > 2B as

acceptance, <35% peeling off.

5.3 RELIABILITY REQUIREMENTS

ITEM

DESCRIPTION

TEST CONDITION

REQUIREMENT

5.3.1

Peeling Force

Apply six axial peeling force on parts

soldered on the PCB at the speed rate of

253 mm/minute

8 N Min

5.3.2

Solderability testing

Dip solder tails into the molten solder (held

at 245+-5°C for 5s)

Solder coverage: 95% Min.

5.1 ELECTRICAL REQUIREMENTS

ITEM

DESCRIPTION

TEST CONDITION

REQUIREMENT

5.1.1

Frequency Range

Measure antenna on

recommended PCB through VNA

E5071C

2400MHz-2483.5MHz

5150MHz-5850MHz

5.1.2

Return Loss

Measure antenna on

recommended PCB through VNA

E5071C

< -6 dB

5.1.3

Peak Gain

Measure antenna on

recommended PCB through OTA

chamber

3dBi

4.2dBi

5.1.4

Avg. Total

Efficiency

Measure antenna on

recommended PCB through OTA

chamber

>70%

5.1.5

Polarization

Measure antenna on

recommended PCB through OTA

chamber

Linear

5.1.6

Input Impedance

Measure antenna on

recommended PCB through VNA

E5071C

50Ohms

D 55 REVTSION. ECR/ECN INFORMATION. TTTLE. SHEET No. B DATE. DOCUMENT NUMBER. CREATED / REVTSED BY. CHECKED BY. APPROVED BY.

PRODUCT SPECIFICATION

REVISION:

ECR/ECN INFORMATION:

TITLE:

2.4/5GHz SMT Chip Antenna

SHEET No.

B

ABU2016-0014

4 of 5

DATE:

2016-05-06

DOCUMENT NUMBER:

CREATED / REVISED BY:

CHECKED BY:

APPROVED BY:

PS-146175-001

Ryan Liu 2016-05-06

Chris Yu 2016-05-06

Welson Tan2016-05-06

TEMPLATE FILENAME: PRODUCT_SPEC[SIZE_A4](V.1).DOC

d

The meaning of text “No mechanical damage” in the table above is:

a. no soldering problem

b. no adhesion problem of glue

c. no peel off of plating

6.0 TEST GROUPINGS

Note: All test specimens (except group 5) shall pass the reflow process for 3 times.

5.4 ENVIRONMENTAL REQUIREMENTS

ITEM

DESCRIPTION

TEST CONDITION

REQUIREMENT

5.4.1

Humidity Test

1.Test condition:

The device under test is kept for 12 hours

in an environment with a temperature of 55

degrees and a relating humidity of 95%.

Thereafter for 12 Hours in an environment

with a temperature of 25 degrees and a

relative humidity of 95%. The cycle is

repeated until a total of 6 cycles have

been completed. Hereafter the conditions

are stabilized at room temperature.

1) Parts should meet RF spec

before and after test.

2） No cosmetic problem

5.4.2

Temperature

cycling test

1.Test condition:

The device under test at -40 ℃⇔125 ℃

by 72 cycles, Dwell of 30 mins, tranistion

time between Dwell 15 secs (~ 61 mins /

cycle ) and each item should be measured

after exposing them in normal temperature

and humidity for 24 h.

1) Parts should meet RF spec

before and after test.

2） No cosmetic problem

5.4.3

Salt mist test

1.Test condition:

The device under test is exposed to a

spray of a 5% (by volume) resolution of

Nacl in water for 2 hours. Thereafter the

device under test is left for 1 week in room

temperature at a relative humidity of 95%.

The cycle is repeated until a total of 2

cycles have been completed. Here after

the conditions are stabilized at room

temperature.

1) Parts should meet RF spec

before and after test.

2) No visible corrosion.

Discoloration accept.

5.4.4

HNO3 Test

General test condition

1) No corrosion.

D molex“ C temp-mun! C) 2w 180 ‘60 HO I20 I00 Scam; Ion.» “we. 1W, ‘—I7mm mm ' wlowsoc IIIIIII .— mu mum-mum 7:0 lo 235 c ,0 sec mm“ 9 IIsI \q/hno mo mm mm I I , I . I Isa: ‘ I I I I I I I I I I I I I I no no 90 I20 I50 I90 2m 240 270 YIm(Socood-) III In IIIII lone: pvmahng snow noI nxeood 2 S‘C’m EO prawn? vaba” locmabm 0! one! delta: REVISION: ECR/ECN INFORMATION: TITLE: SHEET N0. 5 DATE: DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY:

PRODUCT SPECIFICATION

REVISION:

ECR/ECN INFORMATION:

TITLE:

2.4/5GHz SMT Chip Antenna

SHEET No.

B

ABU2016-0014

5 of 5

DATE:

2016-05-06

DOCUMENT NUMBER:

CREATED / REVISED BY:

CHECKED BY:

APPROVED BY:

PS-146175-001

Ryan Liu 2016-05-06

Chris Yu 2016-05-06

Welson Tan2016-05-06

TEMPLATE FILENAME: PRODUCT_SPEC[SIZE_A4](V.1).DOC

d

Test

Item

Description

Group1

Group2

Group3

Group4

Group5

Group6

5.3.1

Peeling Force

X

5.3.2

Solderability

testing

X

5.4.1

Humidity Test

X

5.4.2

Temperature

cycling test

X

5.4.3

Salt mist test

X

5.4.4

HNO3 Test

X

Sample Quantity

5

7.0 RECOMMENDED REFLOW CONDITION

8.0 PACKAGING

Refer to the Molex related packaging drawings.
