VS1033 - MP3/AAC/WMA/MIDI AUDIO
CODEC
Features
•Decodes MPEG 1 & 2 audio layer III
(CBR +VBR +ABR); layers I & II op-
tional;
MPEG4 / 2 AAC-LC-2.0.0.0 (+PNS);
WMA 4.0/4.1/7/8/9 all profiles (5-384 kbps);
WAV (PCM + IMA ADPCM);
General MIDI / SP-MIDI format 0 files
•Encodes IMA ADPCM from microphone
or line input
•Streaming support for MP3 and WAV
•EarSpeaker Spatial Processing
•Bass and treble controls
•Operates with a single clock 12..13 MHz
•Can also be used with 24..26 MHz clocks
•Internal PLL clock multiplier
•Low-power operation
•High-quality on-chip stereo DAC with no
phase error between channels
•Stereo earphone driver capable of driv-
ing a 30 Ωload
•Quiet power-on and power-off
•I2S interface for external DAC
•Separate operating voltages for analog,
digital and I/O
•5.5 KiB On-chip RAM for user code /
data
•Serial control and data interfaces
•Can be used as a slave co-processor
•SPI flash boot for special applications
•UART for debugging purposes
•New functions may be added with soft-
ware and 8 GPIO pins
•Lead-free RoHS-compliant package (Green)
Instruction
RAM
Instruction
ROM
Stereo
DAC
Mono
ADC
L
R
UART
Serial
Data/
Control
Interface
Stereo Ear−
phone Driver
DREQ
SO
SI
SCLK
XCS
RX
TX
audio
output
X ROM
X RAM
Y ROM
Y RAM
GPIO GPIO
VSDSP
4
XDCS
MIC AMP
Clock
multiplier
MUX
line
audio
mic
audio
8
I2S
VS1033
Description
VS1033 is a single-chip MP3/AAC/WMA/MIDI
audio decoder and ADPCM encoder. It con-
tains a high-performance, proprietary low-power
DSP processor core VS_DSP4, working data
memory, 5 KiB instruction RAM and 0.5 KiB
data RAM for user applications, serial control
and input data interfaces, upto 8 general pur-
pose I/O pins, an UART, as well as a high-
quality variable-sample-rate mono ADC and
stereo DAC, followed by an earphone ampli-
fier and a common voltage buffer.
VS1033 receives its input bitstream through
a serial input bus, which it listens to as a
system slave. The input stream is decoded
and passed through a digital volume control
to an 18-bit oversampling, multi-bit, sigma-
delta DAC. The decoding is controlled via a
serial control bus. In addition to the basic de-
coding, it is possible to add application spe-
cific features, like DSP effects, to the user
RAM memory.
EarSpeaker spatial processing provides more
natural sound in headphone listening condi-
tions. It widens the stereo image and posi-
tions the sound sources outside the listener’s
head.
Version: 1.02, 2014-12-19 1
