ZXM62P02E6 Datasheet by Diodes Incorporated

muss. ® Gs C) TIT LKJ L||_|L| H F] [‘l zpozé 7 LJLJLI

ZXM62P02E6

Document Number DS33482 Rev. 2 - 2

1 of 7

www.diodes.com

March 2015

ZXM62P02E6

ADVANCE INFO R MA T I O N

20V P-CHANNEL ENHANCEMENT MODE MOSFET

Product Summary

BVDSS

RDS(ON)

ID

TA = +25°C

-20V

200mΩ @ VGS= -4.5V

-2.3A

Description

This new generation of high density MOSFETs from Zetex utilizes a

unique structure that combines the benefits of low on-resistance with

fast switching speed. This makes them ideal for high efficiency, low

voltage, power management applications.

Applications

• DC - DC Converters

• Power Management Functions

• Disconnect Switches

• Motor Control

Features and Benefits

 Low On-resistance

 Fast Switching Speed

 Low Threshold

 Low Gate Drive

 Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

 Halogen and Antimony Free.“Green” Device (Note 3)

Mechanical Data

 Case: SOT26

 Case Material: Molded Plastic, “Green” Molding Compound.

UL Flammability Classification Rating 94V-0

 Moisture Sensitivity: Level 1 per J-STD-020

 Terminals Connections: See Diagram Below

 Terminals: Finish - Matte Tin Annealed over Copper Leadframe.

Solderable per MIL-STD-202, Method 208

 Weight: 0.018 grams (Approximate)

Ordering Information (Note 4)

Part Number

Reel Size (inch)

Tape Width (mm)

Quantity Per Reel

ZXM62P02E6TA

7

8

3,000

ZXM62P02E6TC

13

8

10,000

Notes: 1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.

Marking Information

Date Code Key

Year

2015

2016

2017

2018

2019

2020

2021

2022

2023

2024

2025

2026

Code

C

D

E

F

G

H

I

J

K

L

M

N

Month

Jan

Feb

Mar

Apr

May

Jun

Jul

Aug

Sep

Oct

Nov

Dec

Code

1

2

3

4

5

6

7

8

9

O

N

D

e3

Equivalent Circuit

Top View

SOT26

D

SG

Pin Out

Top View

2P02 = Product Type Marking Code

YM = Date Code Marking

Y or Y = Year (ex: C = 2015)

M or M = Month (ex: 9 = September)

m5. ZXM62P02E6

ZXM62P02E6

Document Number DS33482 Rev. 2 - 2

2 of 7

www.diodes.com

March 2015

ZXM62P02E6

ADVANC E INF ORMA TIO N

Absolute Maximum Ratings

Characteristic

Symbol

Value

Unit

Drain-Source Voltage

VDSS

-20

V

Gate-Source Voltage

VGSS

12

V

Continuous Drain Current

VGS = -4.5V

TA = +25°C (Note 6)

ID

-2.3

A

TA = +70°C (Note 6)

-1.7

Pulsed Drain Current

(Note 7)

IDM

-13

A

Continuous Source Current (Body Diode)

(Note 6)

IS

-1.9

A

Pulsed Source Current (Body Diode)

(Note 7)

ISM

-13

A

Power Dissipation at TA = +25°C

Linear Derating Factor

(Note 5)

PD

1.1

8.8

W

mW/C

Power Dissipation at TA = +25°C

Linear Derating Factor

(Note 6)

PD

1.7

13.7

W

mW/C

Operating and Storage Temperature Range

TJ, TSTG

-55 to +150

C

Thermal Resistance

Characteristic

Symbol

Value

Unit

Junction to Ambient

(Note 5)

RθJA

113

C/W

(Note 6)

73

Electrical Characteristics (@TA = +25°C, unless otherwise stated.)

Characteristic

Symbol

Min

Typ

Max

Unit

Test Condition

STATIC

Drain-Source Breakdown Voltage

BVDSS

-20



V

ID = -250µA, VGS = 0V

Zero Gate Voltage Drain Current

IDSS



-1

µA

VDS = -20V, VGS = 0V

Gate-Source Leakage

IGSS



100

nA

VGS = 12V, VDS = 0V

Gate Threshold Voltage

VGS(TH)

-0.7



V

ID = -250µA, VDS = VGS

Static Drain-Source On-Resistance (Note 8)

RDS(ON)



0.2

Ω

VGS = -4.5V, ID = -1.6A

0.375

VGS = -2.7V, ID = -0.8A

Forward Transconductance (Note 10)

gfs

1.5



S

VDS = -10V, ID = -0.8A

DYNAMIC (Note 10)

Input Capacitance

Ciss



320



pF

VDS = -15V, VGS = 0V

f = 1MHz

Output Capacitance

Coss



150



pF

Reverse Transfer Capacitance

Crss



75



pF

SWITCHING (Notes 9 and10)

Total Gate Charge

Qg



5.8

nC

VDS = -16V, VGS = -4.5V

ID = -1.6A

(Refer to test circuit)

Gate-Source Charge

Qgs



1.25

nC

Gate-Drain Charge

Qgd



2.8

nC

Turn-On Delay Time

tD(ON)



4.1



ns

VDD = -10V, ID = -1.6A, RG = 6Ω,

RD = 6.1Ω

(Refer to test circuit)

Turn-On Rise Time

tR



15.4



ns

Turn-Off Delay Time

tD(OFF)



12.0



ns

Turn-Off Fall Time

tF



19.2



ns

SOURCE-DRAIN DIODE

Diode Forward Voltage (Note 8)

VSD





-0.95

V

TJ= +25°C, IS=-1.6A,

VGS=0V

Reverse recovery time (Note 10)

tRR



22.5



ns

TJ= +25°C, IF=-1.6A,

di/dt= 100A/µs

Reverse recovery charge (Note 10)

QRR



10.4



nC

Notes: 5. For a device surface mounted on 25mm x 25mm FR-4 PCB with high coverage of single sided 1oz copper, in still air conditions.

6. For a device surface mounted on FR-4 PCB measured at t  5 secs.

7. Repetitive rating - pulse width limited by maximum junction temperature. Refer to Transient Thermal Impedance graph.

8. Measured under pulsed conditions. Width= 300µs; duty cycle  2%.

9. Switching characteristics are independent of operating junction temperatures.

10. For design aid only, not subject to production testing.

Thermal Resistance (“C/W) ‘ID‘ Drain Current (A) -|D - Drain Current (A) ' 0.1 20 0 0 0001 0.001 100 1D 0.1 1 l0 »Vps - Drain-Source Voltage 1V) Sale Operating Area 100 mm Nur- 4m 0.01 Pulse Width (5) Transient Thermal Impedance 0.1 I In 100 ill I 10 -VDS - Drain-Source Voltage (V) Output Characteristics 100 Thermal Resistance (cc/w) Max Power Dissipation (Watts) -In - Drain Current (A) 1.5 0.5 o 20 ‘0 so 80100120 T - Temperature 1° ) Derating Curve no 160 I20 Helm Nm: 1.) I00 40 0:0 20 mar 30001 0 001 001 0,1 I ll) Pulse Width (5) Transient Thermal Impedance I00 1000 100 ll) 0.1 0.1 1 l0

ZXM62P02E6

Document Number DS33482 Rev. 2 - 2

3 of 7

www.diodes.com

March 2015

ZXM62P02E6

ADVANC E INF ORMA TIO N

m5. 2 1.6 vns:.mv g | R u nDsw-n g > "‘ vas.15v .. 2: mm“ c c .2 / B 3 ' ~ g g 10 \\/ m . /\ a sz-vns E n: as / \ any». _ g ' vssmn n .,, . ' = 0.5 D a —. E 0 0.4 2 -1on -5a a so Ian 15:2 200 I LE 2 2.5 3 3.5 A 1.5 5 j-JunctionTemperaturs(“Cl -YG$ ' GEIB‘SWYW V°"399 EV) . Normalised RDSlon) and VGSllh) Typical Transfer Charaaerlstlcs v Temperature ‘0 100 ID war: ”we 0.1 0.1 I 10 100 -ID — Drain Current (A) On-Rasistance v Drain Current 0.1 0.2 0.4 0.6 0,5 1.0 I.2 Ll -VSD - Source»Drain Voltage (V) Source-Drain Diode Forward Voltage HDS(on) - Drain-Source On-Resislance (ﬂ) -Isn - Reverse Drain Current (A) 4 00 vww ; A 600 "' M” a) 4.5 “- \ 3 3 500 \ = ‘ a: c... 0 2.5 2 :00 ~ \ 5““ Z 3 3 Cu: E g 300 3 2'5 % \ w 2 u 200 ‘ § . _5 Q 100 \ \ L? 1 .. w 0 ~ 0 0.5 0.1 1 10 we >. 0 Nos-Drain SourceVoltagelV) o 0'5 ‘ La-zhgfgelncij ‘ "5 5 Capacitance v Drain-Source Voltage Gate-Source Voltage v Gate Charge

ZXM62P02E6

Document Number DS33482 Rev. 2 - 2

4 of 7

www.diodes.com

March 2015

ZXM62P02E6

ADVANC E INF ORMA TIO N

-A‘5V as I07- 90% us Charge Currenl Regulator 50x Same as --|zv ==o.zur 9'” T 7 Basic Gale Charge Waveform _L 5 > : 4,5v H¢—. H {H 'Im r, 9M» ‘1 T Switching ﬁme Waveforms mm Wm». , ms Duw Fnzov a o w. Switching Time Test Circuit

ZXM62P02E6

Document Number DS33482 Rev. 2 - 2

5 of 7

www.diodes.com

March 2015

ZXM62P02E6

ADVANC E INF ORMA TIO N

Test Circuits

ms; ZXM62P02E6 <+——>| I<——>I

ZXM62P02E6

Document Number DS33482 Rev. 2 - 2

6 of 7

www.diodes.com

March 2015

ZXM62P02E6

ADVANC E INF ORMA TIO N

Package Outline Dimensions

Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for the latest version.

Suggested Pad Layout

Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.

SOT26

Dim

Min

Max

Typ

A

0.35

0.50

0.38

B

1.50

1.70

1.60

C

2.70

3.00

2.80

D



0.95

H

2.90

3.10

3.00

J

0.013

0.10

0.05

K

1.00

1.30

1.10

L

0.35

0.55

0.40

M

0.10

0.20

0.15



0°

8°



All Dimensions in mm

Dimensions

Value (in mm)

Z

3.20

G

1.60

X

0.55

Y

0.80

C1

2.40

C2

0.95

A

M

JL

D

B C

H

K

X

Z

Y

C1

C2

G

ms. ZXM62P02E6

ZXM62P02E6

Document Number DS33482 Rev. 2 - 2

7 of 7

www.diodes.com

March 2015
